INSTRUCTIONS FOR
INSTALLATION AND OPERATION
MODELS V1332AF
SWITCHERS
This manual provides information on installation and opera-
tion for the V1332AF and V2332AF Series Relay/Audio-
Follow-video Switchers. These units should only be
installed by qualified technicians using approved materials
and wiring practices in accordance with federal, state, and
local electrical codes. Read these instructions thoroughly
before installation.
The V1332AF and V2332AF Series Relay/Audio-Follow-
Video Switchers are microprocessor-controlled units that
allow audio devices associated with video systems to be
switched at the same time as the video. Both models
provide passive relay-based audio switching.
This series of relay switchers is compatible with Matrix 44TM
and Matrix 66TM switchers and with NovaTM VPSTM1300,
VPS 1344, and VPS328 digital control systems. In a typical
application, the audio signal from an intercom microphone
associated with a video camem can be switched to a speaker
at the guard station at the same time the video is switched to
the guards monitor.
Two basic models of the relay switcher are available:
model V1332AFprovides
while model V2332AF provides 32 balanced stereo inputs.
Refer to Figure 1 and Figure 2. Each input/ output of the
ports stereophonic audio systems or other systems re-
quiring four contacts to be active at each switch.
Input/output proportions are configured by setting inter-
nal jumpers and include the following combinations:
WARNING: TO PREVENT RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE.
Product specifications subject to change without notice.
VICON INDUSTRIES INC. 525 BROAD HOLLOW ROAD, MELVILLE, N.Y. 11747 TEL: 516-293-2200 FAX: 516-293-2627
TOLL FREE: I-800-645-9116 UK: 44/(O) 1489/577775
AND V2332AF RELAY/AUDIO-FOLLOW-VIDEO
1. INTRODUCTION
32 balanced monaural inputs,
NOTES
32 inputs, 1 output, mono-balanced;
16 inputs, 2 outputs, mono-balanced;
8 inputs, 4 outputs, mono-balanced;
32 inputs, 1 output, stereo-balanced;
16 inputs, 2 outputs, stereo-balanced;
8 inputs, 4 outputs, stereo-balanced.
Multiple relay switchers may be cascaded, enabling them
to be used with switching systems of more than 256
cameras. Relay connections are made via convenient
detachable screw terminal blocks.
Both inputs and outputs are balanced to provide maxi-
mum hum and noise rejection. Unit specifications have
been designed for a high-fidelity range and include:
crosstalk: better than -70 dB at 20 kHz;
frequency response: flat within 0.3 dB from
hum and noise: typically better than -60 dBm.
This precise conformity to the highest standards makes
the V 1332AF and the V2332AF relay switcher suitable
for virtually any audio application.
Any Vicon Nova digital control can supply the V1332AF
or the V2332AF with the information necessary to relay
the signal from a source to an output. In the standard
configuration, an operator selects a desired source/output
combination and enters the assigned numbers into the
keypad.
Vicon part number 8006-8537-00-00
c
INFOFAX: l-800-287-1207
E
E
.
10 Hz to 20 kHz;
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the V1332AF and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Vicon V1332AF

  • Page 1 WARNING: TO PREVENT RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE. Vicon part number 8006-8537-00-00 Product specifications subject to change without notice. VICON INDUSTRIES INC. 525 BROAD HOLLOW ROAD, MELVILLE, N.Y. 11747 TEL: 516-293-2200 FAX: 516-293-2627 TOLL FREE: I-800-645-9116 UK: 44/(O) 1489/577775 INFOFAX: l-800-287-1207...
  • Page 2: Important Safeguards

    16. Overloading - Do not overload wall outlets and extension cords 6. Attachments - Do not use attachments not recommended by Vicon as this can result in a risk of fire or electric shock. as they may cause hazards.
  • Page 3: Coaxial Cable Recommendations

    Careful Installation Tips essential to obtain the best performance from this equipment. Vicon assumes no responsibility for Do not stretch cable or subject it to sharp bends. poor performance when cables other than those Keep the cable out of contact with hot pipes or any other he;...
  • Page 4: Fcc Notice

    European Normaliza- 2. INSTALLATION Five 16-position screw terminated connectors Prior to installation, check that the accessory kit supplied with each V1332AF or V2332AF unit contains the following: One pair of rack mounting brackets, four bracket mounting screws Two DB25 female to female terminated cables One AC power cord.
  • Page 5 TECHNICAL BULLETIN Start-Up Procedures for V1332AF and V2332AF Carefully follow these steps when starting a system with either model of the audio-follow-video switchers: Perform all cable installation with power to both the VPS CPU and to the audio-follow-video switcher OFF.
  • Page 6: Output Connector

    AC POWER CONNECTOR FUSE DRAWER NOT USED COMBINER ‘INPUT CONNECTORS (TBI -TB4) OUTPUT CONNECTOR CONTROL CABLE CONNECTORS Figure 1 AC POWER CONNECTOR NOT USED COMBINER OUTPUT CONNECTOR INPUT CONNECTORS (TBi-TB4) ‘CONTROL CABLE CONNECTORS Figure 2 X537-396...
  • Page 7: Rack Installation

    These terms are defined: ON = CLOSED, OFF = OPEN 2.3 V1332AF and V2332AF DIP Switch Settings MONITOR GROUP 3 The V1332AF and V2332AF DIP switches on the main MONITOR GROUP 4 board are designated as follows: DIP switches SW1 through SW8 are eight pole switches.
  • Page 8 TABLE 1 AUDIO INPUT DIP SWITCH SETTINGS (1 - 256) Audio Pole 7 Pole 8 Pole 6 Pole 5 Pole 4 Pole 3 Pole 2 P o l e 1 Inputs Unit/SW # Unit 1 SW1 9 - 1 6 Unit 1 SW2 1 7 - 2 4 Unit 1 SW3...
  • Page 9 TABLE 2 AUDIO OUTPUT DIP SWITCH SETTINGS (1 - 128) Unit 3 SW5 Unit 3 SW6 Unit 3 SW7 Unit 3 SW8 X537-396...
  • Page 10 TABLE 2 AUDIO OUTPUT DIP SWITCH SETTINGS (1 - 128) (continued) Audio Pole 8 Pole 7 Pole 5 Pole 4 Pole 3 Pole 2 Pole Pole 8 Unit/SW # O f f O f f O f f O f f Unit 3 SW5 Unit 3 SW6 O f f...
  • Page 11 TABLE 2 AUDIO OUTPUT DIP SWITCH SETTINGS (1 Audio Pole 7 Pole 8 Pole 6 Pole 5 Pole 4 Pole 3 Pole 2 Pole 1 Unit/SW # Unit 4 SW5 Unit 4 SW6 Unit 4 SW7 Unit 4 SW8 Unit 4 SW5 Unit 7 SW6 Unit 7 SW7 1 0 0...
  • Page 12 TABLE 2 AUDIO OUTPUT DIP SWITCH SETTINGS (1 - 128) (continued) 1 2 5 Unit 8 SW5 1 2 6 Unit 8 SW6 1 2 7 Unit 8 SW7 1 2 8 Unit 8 SW4 S W 8 S W 6 MAIN BOARD FRONT Figure 3 Location of Address DIP Switches...
  • Page 13 Installing the V1332AF or V2332AF in the Rack ets into the threaded holes provided unit’s hous- The V1332AF and V2332AF are supplied with two rack on the ing. Align the holes in the brackets with appropriate mounting brackets included in the accessory kit. Using...
  • Page 14: Control Cable Connection

    Table 5 contains the pair correlation data used with ment to the V1332AF or V2332AF inputs and outputs. a V1332AF and V2332AF. Table 6 shows the audio input Input and output circuit wiring methods are identical on address versus the labeled connection numbers on each both the units.
  • Page 15 TABLE 6 AUDIO INPUT VERSUS LABELED CONNECTOR NUMBERS (l-256) Connector Input Input Input input Input Input Input Number 129-160 33-64 65-96 97-128 161-192 193-224 225-256 1 6 1 1 3 1 1 0 1 2 0 1 1 7 1 1 4 1 1 1 1 2 4 1...
  • Page 16 TABLE 7 AUDIO OUTPUT VERSUS LABELED CONNECTION NUMBERS (1-128) X537-396...
  • Page 17: Power Cable Connection

    2.8 Power Cable Connection The V1332AF and V2332AF are provided with an The front panel of both the V1332AF and the V2332AF IEC4301 recessed AC power connector and a detachable is furnished with a red AC power indicator and a green AC power cord.
  • Page 18: Shipping Instructions

    14891577775 Fax: 44/(O) 1489/578923 Attach a sheet of paper to the unit with the fol- lowing information: Vicon and its logo arc registered trademarks of Vicon Intlustries Inc. Copyright 0 1996 Vicon Industries Inc. All Rights Reserved. X537-396...
