SI-95.BOOK Page 44 Friday, March 31, 2000 10:59 AM
Test Operation
1 Service monitor <HAP>
(Green)
2 Function setting switch or LED
LED display
8
: On
9
: Flicker
7
: Off
3 Jumper pin
M
I I
D X26A
BLUE
S
(VL015)
44
Normal ................ licker
Malfunction ......... On or off
Mode button ......... Mode change
Setting mode 1
Push 1 time.
(H1P off)
Push and hold for 5 sec.
• Set return button .......... Changes or enters address or data.
• Wiring check button .... Push and hold for 5 sec. to start wiring check.
• Reset button ................. Push and hold for 5 sec. if the indoor unit's PC board has been replaced, or
there has been a change in the combination of indoor and outdoor units, such as indoor unit extension,
etc.
Forced defrost operation by short circuit.
Monitor mode
Push 1 time.
(H1P flickers)
Setting mode 2
Push 1 time.
(H1P on)
(VF014)
Test Operation Inverter K Series
Si-95
