- Page 1 ICE-101 Low Fog Machine User Manual BODENNEBLER B English Français Deutsch • • • 中文 © 2014 Antari Lighting and Effects Ltd.
- Page 3 ANTARI FOG MACHINE. Introduction Thank you for choosing an ANTARI Fog Machine. You now own a rugged and powerful state-of-the-art machine. Prior to use, we suggest that you carefully read all of the instructions. By following the suggestions found in this user manual, you can look forward to the reliable and satisfactory performance of your ANTARI Fog Machine for years to come.
- Page 4 Before beginning initial setup of your ANTARI Fog Machine, make sure that there is no evident damage caused by transportation. In the event that the unit’s housing or cable is damaged, do not plug it in and do not attempt to use it until after contacting your ANTARI dealer for assistance.
- Page 5 ♦ Place fog machine on a flat surface and remove fog liquid tank cap. ♦ Fill with ANTARI Fog Liquid or other high-quality water-based fog fluid. Any other types of fluid can damage the unit. When filled, place cap back on liquid tank.
- Page 6 Return the machine to your ANTARI dealer. Remote Control Operation: Z-8: 25 feet wired multi-function remote control with 4-PIN XLR connector for ANTARI ICE-101. Interval knob: Rotate it to set the interval time between fog outputs in the Timer ․...
- Page 7 To keep pressing the green Manual button can make the machine generate fog at ․ maximum volume. Once Manual button is released, the fog output stops immediately. Cleaning your fog machine regularly will help reduce costly parts replacement and repair charges. Maintenance Do not allow the fog liquid to become contaminated.
- Page 8 down for a short period in order to heat back up. During this time no fog can be produced. The green “READY” L.E.D. on the remote will be off during this time and will light up again when the machine is ready. Save these instructions DMX Connector Pin Assignment The machine provide 3 pin XLR connector for DMX connection.
- Page 9 Note: In the example above, if the machine were assigned the DMX address of 124, Channel A would correspond to DMX address 124. In general, Antari fog machines with onboard DMX conform to the following performance specifications: 1. Average Operating temperature = 250oC 2.
- Page 10 Be careful when open and close the cover!
