- Page 1 USER MANUAL FOR MODELS: Gen2000 Gen3600 Gen3600v Portable Generator Portable Generator Portable Generator 2000 Running Watts 3600 Running Watts 3600 Running Watts 2500 Peak Watts 4650 Peak Watts 4650 Peak Watts...
-
Page 2: Wgen Technical Specifications
The effect of altitude on horsepower will be greater if no carburetor modification is made. A decrease in engine horsepower will de- crease the power output of the generator. HAVE QUESTIONS? Email us at service@wpowereq.com or call 1-855-944-3571 2 | Westinghouse Portable Power... -
Page 3: Product Registration
IMPORTANT: KEEP YOUR PURCHASE RECEIPT TO ENSURE TROUBLE-FREE WARRANTY COVERAGE. PRODUCT REGISTRATION To ensure trouble-free warranty coverage, it is important you register your Westinghouse generator. You can register your generator by either: 1. Filling in the product registration form below and mailing to:... -
Page 4: Table Of Contents
WGen3600 Engine View ..... 28 ASSEMBLY -WGen3600 ..... . . 10 WGen3600 Exploded View . -
Page 5: Safety
NOTE: Indicates a procedure, practice or condition that should be followed in order for the generator to function in the manner intended. Westinghouse Portable Power | 5... -
Page 6: General Safety Rules
Never use the generator to power medical support engine misfires often. equipment. Always disconnect tools or Always remove any tools or other service equipment used appliances from the during maintenance from the generator before operating. generator before starting. 6 | Westinghouse Portable Power... -
Page 7: Safety Labels And Decals
Number : Numéro de contrat MWE Investments LLC Designed in Columbus , Ohio USA principa l de CSA Columbus Ohio 43228 Etats-Unis Co n u à columbus , Ohio,tats-Unis Made in China/ Fabriqu é en Chine Westinghouse Portable Power | 7... - Page 8 SAFETY SAFETY LABELS AND DECALS Sample from WGen5500 WGen3600 WGen3600 268850 268850 Sample from WGen5500 8 | Westinghouse Portable Power...
-
Page 9: Unpacking
Tools required – box cutter or similar device. 1. Carefully cut the packing tape on top of the carton. 2. Fold back top flaps to reveal the manual. 3. Remove the Wheel Kit Accessories (WGen3600 only) cardboard box. 4. Carefully cut two sides of the carton to Figure 1 - (WGen3600 only) Wheel remove the generator. -
Page 10: Assembly -Wgen3600
4. Repeat previous steps on other wheel. 3. Install the mounting foot to the frame using M8 flange bolts. 1 - Mounting Feet 2 - Flange Bolts M8 Figure 1 - Assemble Mounting Feet to Frame 10 | Westinghouse Portable Power... -
Page 11: Features
FEATURES Gen3600 Engine Control Switch: Allows fuel to flow to Never Flat Wheels (WGen3600 Only): For easy engine and energizes the ignition system. portability Fuel Cap: Close until clicking sound is heard. Fuel Shut off Valve: Controls the flow of fuel to the engine. - Page 12 CARB Canister: Required for models sold into and used in California. Muffler and Spark Arrester: Avoid contact until engine is cooled down. Spark arrestor prevents sparks from exiting the muffler. It must be removed for servicing. Gen2000 | Gen3600v 12 | Westinghouse Portable Power...
-
Page 13: Control Panel Features
30 amps and 120 volts. Ground Terminal: The ground terminal is used to 120-Volt, 30 Amp Twistlock Outlet (L5-30R ): ground the generator. Outlet can supply 120V output. Gen2000 2000 Running Watts | 2500 Peak Watts Westinghouse Portable Power | 13... -
Page 14: Operation
Placing the generator on non level surfaces can cause the Floating Neutral (WGen2000, WGen3600 & WGen3600v): generator to tip over, causing fuel The generator (stator winding) is isolated from the frame and oil to spill. Spilled fuel can ignite and from the AC receptacle ground pin. -
Page 15: Engine Fluids And Fuel
The owner of the generator is responsible to ensure the proper oil level is maintained during the operation of the generator. Failure to maintain the proper oil level can result in engine damage. Figure 5 Westinghouse Portable Power | 15... -
Page 16: Adding Gasoline To The Fuel Tank
Failure to maintain the proper oil CAUTION level can result in engine damage. Avoid prolonged skin contact with gasoline. Avoid prolonged breathing of gasoline vapors. 16 | Westinghouse Portable Power... -
Page 17: Starting The Generator
OFF position (see Figure 12 below). 4. Move the choke lever to the “ON” position (see Figure 9 below). Figure 12 - Choke Lever - OFF Figure 9 - Choke Lever - ON Westinghouse Portable Power | 17... -
Page 18: Stopping The Generator
Always perform maintenance in a well- Allow hot components to cool to ventilated area. Gasoline fuel and fuel the touch prior to performing any vapors are extremely flammable and maintenance procedure. can ignite under certain conditions. 18 | Westinghouse Portable Power... -
Page 19: Maintenance
Spark Plug Check/Clean Replace Spark Arrestor Check/Clean *Service more frequently if operating in dry and dusty conditions TABLE 2: MAINTENANCE SCHEDULE - AUTHORIZED WESTINGHOUSE SERVICE DEALER PERFORMED After First 20 After 50 Hours After 100 Hour After 300 Hours Before Every... -
Page 20: Engine Oil Maintenance
Stop frequently to check the level to avoid overfilling. 8. Continue to add oil until the oil is at the correct level (see Figure 16). Figure 15 - Oil Fill Plug/Dipstick 20 | Westinghouse Portable Power... -
Page 21: Changing Engine Oil
NEVER twist or tear the foam air filter element during cleaning or drying. Only apply slow but firm squeezing action. 6. Rinse in clean water by submerging the air filter elements in fresh water and applying a slow squeezing action Westinghouse Portable Power | 21... -
Page 22: Spark Plug Maintenance
Never apply any side load or move the spark plug Torch: F7TC laterally when removing the spark plug. Applying a side load or moving the spark plug laterally may crack and damage the spark plug boot. 22 | Westinghouse Portable Power... -
Page 23: Cleaning The Generator
4. With the fuel shut off valve open, start the engine and allow the generator to run until all the remaining gasoline in the fuel lines and carburetor is consumed and the engine shuts off. Westinghouse Portable Power | 23... -
Page 24: Troubleshooting
(GFCI outlets only). 6. If trying 1-5 above does not solve 6. Take the generator to your nearest the problem, the cause might be the authorized service dealer. generator has a fault. 24 | Westinghouse Portable Power... -
Page 25: Troubleshooting
RPM. 4. If trying 1-3 above does not solve 4. Take the generator to your nearest the problem, the cause might be a authorized service dealer. fault in the generator Westinghouse Portable Power | 25... -
Page 26: Exploded And Engine Views
M6X12 180559 Vent 180555 Valve Cover 180566 Dust Plate Gasket 140506 Fitting 180567 M6X20 180554 Valve Cover 180550 Govenor Spring 180540 Flywheel Assy 140515 M6 Stud 180509 Amplifier 180539 Engine Cooling 140516 Gasket 180557 Dipstick 26 | Westinghouse Portable Power... -
Page 27: Wgen2000 Exploded View
M8X16 150522 Hose 110502 Spring Washer 120538 Alternator Assy 100548 M6 Nut 110521 Muffler Assy 14.1 120526 Terminal Block 100530 Bracket 150521 Fuel Tank 14.2 120525 Brush Assy 100549 Rubber Foot 27.1 150517 Fuel Strainer Westinghouse Portable Power | 27... -
Page 28: Wgen3600 Engine View
M6X12 180559 Vent 180555 Valve Cover 180566 Dust Plate Gasket 140506 Fitting 180567 M6X20 180554 Valve Cover 180550 Govenor Spring 180540 Flywheel Assy 140515 M6 Stud 180509 Amplifier 180539 Engine Cooling 140516 Gasket 180557 Dipstick 28 | Westinghouse Portable Power... -
Page 29: Wgen3600 Exploded View
150520 Carbon Canister 100545 Handle Fastener 120524 Alternator Assy 120528 Ground Strap 100543 Handle 14.1 120525 Brush Assy 120508 M6 Tooth Washer 100544 Handle Cover 14.2 120526 Terminal Block 120527 Rear Bearing Carrier 120532 Washer Westinghouse Portable Power | 29... -
Page 30: Wgen3600V Engine View
M6X12 180559 Vent 180555 Valve Cover 180566 Dust Plate Gasket 140506 Fitting 180567 M6X20 180554 Valve Cover 180550 Govenor Spring 180540 Flywheel Assy 140515 M6 Stud 180509 Amplifier 180539 Engine Cooling 140516 Gasket 180557 Dipstick 30 | Westinghouse Portable Power... -
Page 31: Wgen3600V Exploded View
11.6 130512 R5-20 Receptacle 150521 Fuel Tank 180568 Dust Plate 27.1 150517 Fuel Strainer 100516 M8X16 120536 M6X25 120524 Alternator Assy 150501 M6 Washer 14.1 120525 Brush Assy 150520 Carbon Canister 14.2 120526 Terminal Block Westinghouse Portable Power | 31... -
Page 32: Schematics
WGen3600/WGen3600v SCHEMATIC 32 | Westinghouse Portable Power... -
Page 33: Wgen2000 Schematic
WGen2000 SCHEMATIC Westinghouse Portable Power | 33... - Page 34 Maintenance Notes 34 | Westinghouse Portable Power...
- Page 35 Maintenance Notes Westinghouse Portable Power | 35...
- Page 36 Version 7.11.17KD 36 | Westinghouse Portable Power...
