Summary of Contents for DigiTech drop

  • Page 1 Owner’s Manual...
  • Page 2 The foregoing is in lieu of all other warranties, expressed or implied, and DigiTech neither assumes nor authorizes any person to assume any obligation or liability in connection with the sale of this product. In no event shall DigiTech or its dealers be liable for special or consequential damages or from any delay in the performance of this warranty due to causes beyond their control.
  • Page 3 1/2 step (1 semitone) intervals. To use the Drop pedal, enable the effect with the Footswitch (the LED will light when the effect is enabled), turn the Effect Selector knob to select the desired drop tune interval, then set the Momentary switch for the desired operation (see, “Momentary On/Off Switch”...
  • Page 4 Connect the provided power adapter to this jack. Do not use any power adapter other than the one supplied. 2. Effect Selector Knob Selects which of the Drop effect settings is used when the Drop effect is active. 3. Drop Effect Amount LEDs Shows which Drop effect has been selected using the Effect Selector knob, settings include: - Transposes guitar signal down 1 semitone.
  • Page 5 Connect your instrument to this jack. 7. Effect LED Shows the on/off status of the Drop effect. This LED lights to indicate the Drop effect is on. When the Drop effect is bypassed, this LED will be off. 8. Effect Footswitch...
  • Page 6 Strum your guitar and gradually increase your amplifier’s master volume control until the desired level is achieved. CONNECTION DIAGRAM HARMAN PS0913DC POWER SUPPLY OTHER EFFECTS NOTE: The Drop should be the first pedal in your effects chain. Placing any effect in front of it can impact the pitch shifting performance.
  • Page 7 > -105 dB (A weighted); ref = max level, 22 kHz bandwidth THD: 0.004% @ 1 kHz; ref = 1 dBu w/ unity gain A/D/A Conversion: 24-bit Effect Range Drop Tune Range: 1-7 Semitones Down, Octave Down, Octave Down + Dry Input Input Type: 1/4” Unbalanced TS Max Input Level:...
  • Page 8 PHONE: (801) 566-8800 WEB: digitech.com SUPPORT: digitech.com/en-US/support Drop Owner's Manual 5049647-B © 2015 Harman. All rights reserved. DigiTech is a registered trademark of Harman.
