Summary of Contents for DigiTech WEAPON

  • Page 2 European Contact: Your local DigiTech Sales and apparatus has been exposed to rain or moisture, does Service Office or not operate normally, or has been dropped.
  • Page 3 1.The warranty registration card must be mailed within ten days after purchase date to validate this warranty. 2. DigiTech warrants this product, when used solely within the U.S., to be free from defects in materials and workmanship under normal use and service.
  • Page 4 "DigiTech helped me recreate some of the effects I used in the studio and then put them all into one pedal. It’s now easier to pull off live!”...

  • Page 5: Included Items

    Before you get started, please make sure that the following items have been included: • DigiTech ® ’s Artist Series Dan Donegan Pedal - The Weapon™ • Artist Series Pedal Gig Bag • PS200R Power Supply • Artist Series Dan Donegan Guitar Pick...
  • Page 6 2 3 4...

  • Page 7: Ac Adapter Jack

    2. Cntrl 1 Controls different functions depending on which Weapon™ Type is selected. See the Knob Function Descriptions section on following pages for a more detailed explanation of the Cntrl 1 knob’s functions.
  • Page 8 5.Type Knob Selects one of the seven different signature Dan Donegan tones. 1. “Stupify” Rhythm Guitar - Distortion 2. “Mistress” Rhythm Guitar - Medium Distortion 3. “Voices” Intro Phaser/Ramp to Full Distortion 4. “Bound” Intro - Wah w/Distortion 5. “Rise” and “Intoxication” Octave Pitch Shift Effect 6.

  • Page 9: Indicator Led

    7. Pedal Release Pins These two pins are spring-loaded hinges that hold the pedal in place. Push these pins in to release the pedal from the pedal chassis exposing the battery compartment. (See the Battery Replacement Diagram at the end of this Owner’s Manual.) 8.
  • Page 10 Knob Function Descriptions LEVEL CNTRL 1 TYPE CNTRL 2 1- "Stupify" Rhythm Guitar - Distortion Output Level Low Freq. EQ Boost/Cut High Freq. EQ Boost/Cut Output Level Low Freq. EQ Boost/Cut High Freq. EQ Boost/Cut 2- "Mistress" Rhythm Guitar - Moderate Distortion Output Level Phase Amount Ramp Time...
  • Page 11 Weapon. When the pedal is first engaged, a clean phaser effect is present. You can adjust the amount of the phaser intensity using the Cntrl 1 knob.
  • Page 12 Set the Cntrl 1 and Cntrl 2 knobs to the twelve o’clock position to produce this sound. Type 5.“Rise” and “Intoxication” Octave Pitch Shift Effect - This is the DigiTech ® Whammy™ octave effect Dan used in the songs “Rise” and “Intoxication”. The Cntrl 1 knob adjusts the Wet/Dry ratio of the pitch shift effect.
  • Page 13 Set the Cntrl 1 and Cntrl 2 knobs to the twelve o’clock position to produce this effect. Type 7.“Mistress” Radio-Style Guitar Break - Distortion - This is the DigiTech ® Metal Master™ distortion sound that Dan uses live during the radio-style guitar break section of the song “Mistress”.
  • Page 14 4. Connect the power supply to the pedal. (Please refer to the Connections Diagrams on the following pages.) 5. Set the Weapon’s Level control to the minimum position. 6.Turn up your amplifier/mixer level to your desired listening level. 7.Turn on the pedal by pressing the pedal switch and gradually turn up...
  • Page 15 Connections The Weapon™ has a single Input and a pair of outputs, Out 1 (Amp) and Out 2 (Mixer). These two outputs give you the option of running into a guitar amplifier, running directly to a mixing console or recording device, or both simultaneously.
  • Page 16 Connections Diagram (Amp and Mixer)

  • Page 17: Specifications

    Specifications: • Controls - Level, Cntrl 1, Cntrl 2,Type, On/Off Pedal • Jacks - Input, Output 1 (Amp), Output 2 (Mixer) • Input Impedance - 1 MOhms • Output Impedance - 100 Ohms • Power Supply - 9V Alkaline Dry Battery •...

  • Page 18: Battery Replacement

    Battery Replacement 1. Using the tip of a 1/4” guitar cable, push one of the release pins in on either side of the pedal, and remove the pedal from the pedal chassis. 2. Remove the battery from the battery compartment and disconnect the battery cable.

  • Page 19: Battery Replacement Diagram

    Battery Replacement Diagram...
  • Page 20 DigiTech 8760 South Sandy Parkway Sandy, Utah 84070 PH (801) 566-8800 FAX (801) 566-7005 DigiTech and The Weapon are trademarks of the Harman Music Group Inc. Copyright - Harman Music Group Printed 3/2004 Manufactured in the USA The Weapon™ Owners Manual 18-1820-B...
