Chapter 3: Specifications
Filter Response Graphs
d
B
A
d
B
r
A
10
+5
+0
-5
-10
-15
-20
-25
r
-30
-35
-40
-45
-50
-55
-60
20 50 100 200
Figure 6. AUX-0025 overall response showing attenuation beyond the audio band.
+0.1
+0.075
+0.05
+0.025
-0
-0.025
-0.05
-0.075
-0.1
10 20 50
Figure 7. AUX-0025 passband response showing flatness out to 20 kHz.
500 1k 2k 5k
Hz
100 200 500 1k
Hz
10k 20k 50k 100k
2k 5k 10k 20k
