Hart Tag - Fisher FIELDVUE DVC2000 Instruction Manual

Instruction Manual
D103176X012
Hot Key
1 Instrument Mode
1 Tuning Set
2 Protection
2 Damping Factor
3 Tuning
3 Expert Tuning Gains
1
Setup
1 Basic Setup
2 Detailed Setup
3 Calibrate
Online
1 Setup
2
2 Display
Display
1 Device Information
2 DD Revision
Field Communicator
1 Offline
1
2 Online
3 Utility
Note:
1 Available only if the instrument has a transmitter
and limit switches installed.
1 2
Field Communicator Menu Tree for
Instrument Level AC
1 Prop Gain
2 Vel Gain
3 MLFB Gain
1‐1‐1
Auto Setup
1 Setup Wizard
2 Auto Calib Travel
1‐1
3 Auto Tuner
Basic Setup
4 Tuning
1 Auto Setup
2 Manual Setup
Manual Setup
1‐1‐2
1 Instrument Mode
2 Press and Actuator
3 Tuning and Calib
1‐2
Detailed Setup
1 General
2 Measured Var
3 Response Control
4 Transmitter/Switches
1‐3
Calibrate
1 Analog In Calib
2 Auto Calib Travel
3 Manual Calib Travel
4 Transmitter Calib
2‐1
Device Information
1 HART Univ Rev
2 Device Rev
3 Firmware Rev
4 Firmware Date
5 Main Elec Rev
6 Sec Elec Rev
7 Sensor Serial Num
8 Inst Level
9 Device Id
3
Local Interface Flow Chart/Menu Trees
1‐1‐1‐4
Tuning
1 Tuning Set
2 Damping Factor
3 Expert Tuning Gains
1‐1‐2‐2
Press and Actuator
1 Pressure Units
2 LUI Pressure Units
3 Max Supply Press
4 Zero Control Signal
1‐1‐2‐3
Tuning and Calib
1 Tuning Set
2 Damping Factor
3 Expert Tuning Gains
4 Tvl Cutoff Lo
5 Auto Calib Travel
1‐2‐1
General
1 HART Tag
2 Message
3 Descriptor
4 Date
5 Valve Serial Num
1
6 Inst Serial Num
7 Polling Address
8 LUI Language
1‐2‐2
Measured Var
1 Analog Input Units
2 Input Range Hi
1
3 Input Range Lo
4 Pressure Units
5 LUI Pressure Units
1‐2‐3
Response Control
1 Tuning Set
2 Damping Factor
3 Expert Tuning Gains
4 Input Char
5 Travel Cutoffs
6 Integral Settings
1‐2‐4
Transmitters / Switches
1 Switch 1 Trip Point
2 Switch 1 Closed
3 Switch 2 Trip Point
4 Switch 2 Closed
5 Transmitter Action
4
June 2017
1‐1‐1‐4‐3
Expert Tuning Gains
1 Prop Gain
2 Vel Gain
3 MLFB Gain
1‐1‐2‐3‐3
Expert Tuning Gains
1 Prop Gain
2 Vel Gain
3 MLFB Gain
1‐2‐3‐3
Expert Tuning Gains
1 Prop Gain
2 Vel Gain
3 MLFB Gain
1‐2‐3‐5
Travel Cutoffs
1 Travel Cutoff Hi
2 Travel Cutoff Lo
1‐2‐3‐6
Integral Settings
1 Enab Int Control
1
2 Integral Gain
3 Integral Dead Zone
5
A
B
C
D
E
F
G
H
I
6
63
