Auxiliary Audio Inputs; General Logic Outputs; Extended Logic Outputs - Arcom RC210 Operation Manual

These inputs can be used for connecting external audio devices, such as a weather receiver. When turned on, the selected transmitter
is locked on for a period selected by a programmable timer. After this timer times out, the audio is disconnected and the transmitter is
unkeyed. Which port a particular input is routed to is determined by programming commands.
1961 Turn Auxiliary Audio Input 1 ON
1960 Turn Auxiliary Audio Input 1 OFF
2961 Turn Auxiliary Audio Input 2 ON
2960 Turn Auxiliary Audio Input 2 OFF
There are 7 switched outputs that can be commanded on or off. They can also be pulsed ( 0.1 s open, 0.1 s low, 0.1 s open). When an
output is high, it is actually an open collector. If you need a logic high present, you can provide a pull up resistor (up to 100 vdc).
1810 Logic Output 1 Open Collector
1811 Logic Output 1 Low
1812 Logic Output 1 Pulsed (open, low, open)
1820 Logic Output 2 Open Collector
1821 Logic Output 2 Low
1822 Logic Output 2 Pulsed (open, low, open)
1830 Logic Output 3 Open Collector
1831 Logic Output 3 Low
1832 Logic Output 3 Pulsed (open, low, open)
1840 Logic Output 4 Open Collector
1841 Logic Output 4 Low
1842 Logic Output 4 Pulsed (open, low, open)
Note: These outputs are independent of the "Output Sinker" functions provided by the Doug Hall RBI-1 Remote Base Interface. See the
Remote Base section of this manual for details.
If you have connected external shift registers as described in the RC210 Hardware Reference Manual, you have a total of 32 Extended
Logic Outputs available.These are available in addition to the 7 on-board Logic Outputs
180xxy Logic Output xx (1-32) to state y
y = 0 Logic low
y = 1 Logic High
y =2 Pulsed output (low, open, low)

Auxiliary Audio Inputs

3961 Turn Auxiliary Audio Input 3 ON
3960 Turn Auxiliary Audio Input 3 OFF

General Logic Outputs

1850 Logic Output 5 Open Collector
1851 Logic Output 5 Low
1852 Logic Output 5 Pulsed (open, low, open)
1860 Logic Output 6 Open Collector
1861 Logic Output 6 Low
1862 Logic Output 6 Pulsed (open, low, open)
1870 Logic Output 7 Open Collector
1871 Logic Output 7 Low
1872 Logic Output 7 Pulsed (open, low, open)

Extended Logic Outputs
