Monitoring A Port from Other Ports
Any port may be selectively monitored by any other port. In the RC210, with multiple monitor commands you can create any
combination of monitoring from port to port. This provides considerable flexibility in audio routing. Each of these monitoring commands
is a one-way connection. In other words, if you select to monitor Port 2 from Port 1, activity on Port 1 will not be retransmitted on Port 2.
To create a two-way path between ports, you have two choices. You can either establish 2, one-way connections between ports or you
could use the Linking Commands (this is explained below).
Assume you're on Port 1 and want to monitor activity on Port 2. Enter the command 1301 and a one-way connection is established,
allowing the monitoring of Port 2 by Port 1. Now, activity on Port 2 is retransmitted out Port 1, but Port 1 is not retransmitted out Port 2.
It doesn't matter what port is used to issue these commands.
1301 Monitor Port 2 From Port 1 ON
1300 Monitor Port 2 From Port 1 OFF*
1311 Monitor Port 3 From Port 1 ON
1310 Monitor Port 3 From Port 1 OFF*
After monitoring for a while, you decide you want to join in the conversation. By issuing the command 2301, activity on Port 1 is now
retransmitted out Port 2. In other words, there is now a two-way connection between Ports 1 & 2.
A two-way connection made in the above manner can be taken down by first turning off monitoring from the port you are on from being
monitored by the other port. Then stop monitoring that other port with a second command. For example, if you have a two-way monitor
between Ports 1 and 2, and you are actively using Port 1, send the command 2300 first so Port 1 activity does not appear on Port 2,
then send 1300 to stop monitoring Port 2. It can be taken down the other way, but if there is an interruption you will be transmitting Port
1 audio on Port 2 and not realize when Port 2 is busy.
Linking Ports Quickly
You may also establish two-way connections (linking) between ports quickly and easily by using only one command. Likewise, you can
also disconnect (unlink) ports using these commands.
you may use the Linking Commands to turn them off or modify them. In other words, the Linking Commands take precedence over
Monitoring commands.
A11 Link Port 1 to Port 2
A21 Link Port 1 to Port 3
A31 Link Port 2 to Port 3
A41 Link all ports to all other ports

User DTMF Pad Test

By using this feature, users can test their DTMF pads to make sure their digits are being properly decoded by the RC210. By sending
the User DTMF Pad Test Command Prefix, followed by up to 16 digits, the RC210 will read back each digit it correctly decodes.
< User DTMF Pad Test Command Prefix> <up to 16 DTMF digits>
See the Programming Section of this manual for programming the Command Prefix for this feature.

Port Linking

2301 Monitor Port 1 From Port 2 ON
2300 Monitor Port 1 From Port 2 OFF*
2311 Monitor Port 3 From Port 2 ON
2310 Monitor Port 3 From Port 2 OFF*
Note: Even if you established port monitoring using the Monitor Commands above,
A10 Unlink Port 1 from Port 2*
A20 Unlink Port 1 from Port 3*
A30 Unlink Port 2 from Port 3*
A40 Unlink all ports from all other ports*
11
3301 Monitor Port 1 From Port 3 ON
3300 Monitor Port 1 From Port 3 OFF*
3311 Monitor Port 2 From Port 3 ON
3310 Monitor Port 2 From Port 3 OFF*
