Macro Function Number List - Arcom RC210 Operation Manual

FN Description
001 Port 1 CTCSS Access
002 Port 2 CTCSS Access
003 Port 3 CTCSS Access
004 Port 1 Carrier Access
005 Port 2 Carrier Access
006 Port 3 Carrier Access
007 Port 1 DTMF Covertone ON
008 Port 2 DTMF Covertone ON
009 Port 3 DTMF Covertone ON
010 Port 1 DTMF Covertone OFF
011 Port 2 DTMF Covertone OFF
012 Port 3 DTMF Covertone OFF
013 Port 1 TX Enable
014 Port 2 TX Enable
015 Port 3 TX Enable
016 Port 1 TX Disable
017 Port 2 TX Disable
018 Port 3 TX Disable
019 Monitor Port 1 from Port 2
020 Monitor Port 1 from Port 3
021 Disconnect Port 1 from Port 2
022 Disconnect Port 1 from Port 3
023 Monitor Port 2 from Port 1
024 Monitor Port 2 from Port 3
025 Disconnect Port 2 from Port 1
026 Disconnect Port 2 from Port 3
027 Monitor Port 3 from Port 1
028 Monitor Port 3 from Port 2
029 Disconnect Port 3 from Port 1
030 Disconnect Port 3 from Port 2
031 Port 1 Monitor Mute
032 Port 2 Monitor Mute
033 Port 3 Monitor Mute
034 Port 1 Monitor Mix
035 Port 2 Monitor Mix
036 Port 3 Monitor Mix
037 Port 1 Repeat ON
038 Port 2 Repeat ON
039 Port 3 Repeat ON
040 Port 1 Repeat OFF
041 Port 2 Repeat OFF
042 Port 3 Repeat OFF
043 Port 1 Speech Override ON
044 Port 2 Speech Override ON
045 Port 3 Speech Override ON
046 Port 1 Speech Override OFF
047 Port 2 Speech Override OFF
048 Port 3 Speech Override OFF
049 Port 1 Courtesy Tone 1
050 Port 1 Courtesy Tone 2
051 Port 1 Courtesy Tone 3
052 Port 1 Courtesy Tone 4
053 Port 1 Courtesy Tone 5
054 Port 1 Courtesy Tone 6
055 Port 1 Courtesy Tone 7
056 Port 1 Courtesy Tone 8
057 Port 1 Courtesy Tone 9
058 Port 1 Courtesy Tone 10
059 Port 2 Courtesy Tone 1
060 Port 2 Courtesy Tone 2

Macro Function Number List

FN
061 Port 2 Courtesy Tone 3
062 Port 2 Courtesy Tone 4
063 Port 2 Courtesy Tone 5
064 Port 2 Courtesy Tone 6
065 Port 2 Courtesy Tone 7
066 Port 2 Courtesy Tone 8
067 Port 2 Courtesy Tone 9
068 Port 2 Courtesy Tone 10
069 Port 3 Courtesy Tone 1
070 Port 3 Courtesy Tone 2
071 Port 3 Courtesy Tone 3
072 Port 3 Courtesy Tone 4
073 Port 3 Courtesy Tone 5
074 Port 3 Courtesy Tone 6
075 Port 3 Courtesy Tone 7
076 Port 3 Courtesy Tone 8
077 Port 3 Courtesy Tone 9
078 Port 3 Courtesy Tone 10
079 Port 1 DTMF Muting ON
080 Port 2 DTMF Muting ON
081 Port 3 DTMF Muting ON
082 Port 1 DTMF Muting OFF
083 Port 2 DTMF Muting OFF
084 Port 3 DTMF Muting OFF
085 CTCSS Encode ON (for the duration of this Macro)
086 CTCSS Encode OFF (for the duration of this Macro)
087 Read ADC Channel 1
088 Read ADC Channel 2
089 Read ADC Channel 3
090 Read ADC Channel 4
091 Read ADC Channel 5
092 Read ADC Channel 6
093 Read ADC Channel 7
094 Read ADC Channel 8
095 UF1 ON
096 UF2 ON
097 UF3 ON
098 UF4 ON
099 UF5 ON
100 UF6 ON
101 UF7 ON
102 UF1 OFF
103 UF2 OFF
104 UF3 OFF
105 UF4 OFF
106 UF5 OFF
107 UF6 OFF
108 UF7 OFF
109 UF1 Pulse
110 UF2 Pulse
111 UF3 Pulse
112 UF4 Pulse
113 UF5 Pulse
114 UF6 Pulse
115 UF7 Pulse
116 Say Time
117 Say Date
118 Link Port 1 to Port 2
35
Description
