LG Multi V 5 Data Manual page 152

HEATING CAPACITY DATA
ARUM480BTE5 / ARUM480DTE5
480,000 Btu/h 208-230V / 460V Outdoor Units
Outdoor air
Combination temp.
(%)
TC
°F DB °F WB
MBh
-12.6 -13.0 367.1
-7.0 -7.6 399.8
-4.0 -4.4 419.5
0.0 -0.4 443.2
5.0 4.5 472.6
10.0 9.0 505.2
15.0 14.0 533.3
20.0 19.0 576.4
100%
25.0 23.0 613.2
30.0 28.0 642.4
35.0 32.0 653.1
40.0 36.0 653.1
45.0 41.0 653.1
47.0 43.0 653.1
50.0 46.0 653.1
55.0 51.0 653.1
60.0 56.0 653.1
-12.6 -13.0 365.6
-7.0 -7.6 398.2
-4.0 -4.4 417.7
0.0 -0.4 443.2
5.0 4.5 472.6
10.0 9.0 505.2
15.0 14.0 533.3
20.0 19.0 590.4
90%
25.0 23.0 598.9
30.0 28.0 598.9
35.0 32.0 598.9
40.0 36.0 598.9
45.0 41.0 598.9
47.0 43.0 598.9
50.0 46.0 598.9
55.0 51.0 598.9
60.0 56.0 598.9
-12.6 -13.0 364
-7.0 -7.6 396.5
-4.0 -4.4 416.0
0.0 -0.4 440.9
5.0 4.5 472.1
10.0 9.0 518.3
15.0 14.0 535.7
20.0 19.0 535.7
80%
25.0 23.0 535.7
30.0 28.0 535.7
35.0 32.0 535.7
40.0 36.0 535.7
45.0 41.0 535.7
47.0 43.0 535.7
50.0 46.0 535.7
55.0 51.0 535.7
60.0 56.0 535.7
TC = Total Capacity (MBh). PI = Power Input (kW) (includes compressor and outdoor fan).
The System Combination Ratio must be between 50–130%.
Nominal capacity as rated: 0 ft. above sea level with 25 ft. of refrigerant piping.
0 ft. level difference between outdoor and indoor units.
152 | PERFORMANCE DATA
59 61 64
PI TC PI TC
kW MBh kW MBh
33.98 367.1 35.52 367.1
37.43 399.8 38.97 399.8
39.52 419.5 41.04 419.5
42.07 442.3 43.60 440.9
45.27 472.6 46.81 472.6
48.47 503.8 50.00 501.7
51.60 533.3 53.14 533.3
55.55 574.3 56.40 571.1
59.29 604.5 56.86 591.5
55.23 622.9 53.21 593.6
51.18 629.3 49.55 593.6
47.14 629.3 45.88 593.6
43.18 629.3 42.30 593.6
42.04 629.3 41.17 593.6
40.48 629.3 39.65 593.6
37.99 629.3 37.21 593.6
35.33 629.3 34.61 593.6
33.64 365.6 34.79 365.6
37.09 398.2 38.25 398.2
39.16 417.7 40.32 417.7
41.73 442.3 42.88 440.9
44.93 472.6 46.08 472.6
48.13 503.8 49.27 501.7
51.26 533.3 52.42 533.3
56.03 571.1 54.90 542.2
52.70 576.3 51.64 542.2
49.38 576.3 48.38 542.2
46.05 576.3 45.11 542.2
42.72 576.3 41.86 542.2
39.45 576.3 38.66 542.2
38.40 576.3 37.63 542.2
36.99 576.3 36.24 542.2
34.71 576.3 34.01 542.2
32.28 576.3 31.63 542.2
29.26 364 30.25 364
32.72 396.5 33.71 396.5
34.79 416.0 35.78 416.0
37.34 440.9 38.34 440.9
40.55 472.1 41.54 472.1
43.74 505.6 44.74 486.3
47.31 516.0 47.88 486.3
47.99 516.0 47.14 486.3
45.10 516.0 44.29 486.3
42.20 516.0 41.44 486.3
39.30 516.0 38.59 486.3
36.40 516.0 35.72 486.3
33.57 516.0 32.93 486.3
32.67 516.0 32.04 486.3
31.47 516.0 30.86 486.3
29.53 516.0 28.98 486.3
27.46 516.0 26.94 486.3
©
Indoor Air Temp. °F DB/°F WB
67 70
PI TC PI TC
kW MBh kW MBh kW
37.82 366 39.44 364.7 41.04
41.27 398.6 42.89 397.3 44.5
43.35 418.1 44.96 416.9 46.57
45.92 440.3 47.52 439.7 49.13
49.11 471.3 50.72 470.0 52.33
52.32 501.5 53.92 501.2 55.53
55.45 532.0 55.68 530.7 55.92
57.68 555.6 55.32 540.0 52.97
53.22 565.7 51.64 540.0 50.08
50.16 566.7 48.66 540.0 47.18
47.08 566.7 45.68 540.0 44.28
44.01 566.7 42.69 540.0 41.37
40.97 566.7 39.73 540.0 38.51
39.88 566.7 38.69
540.0 37.49
38.42 566.7 37.25 540.0 36.11
36.06 566.7 34.97 540.0 33.90
33.53 566.7 32.52 540.0 31.51
36.52 364.4 38.42 363.3 40.32
39.98 396.9 41.88 395.7 43.78
42.05 416.4 43.95 415.1 45.85
44.61 440.0 46.51 439.1 48.41
47.80 470.9 49.70 469.1 51.60
51.01 496.9 52.90 492.0 54.81
54.14 514.0 53.50 494.5 52.86
53.21 518.4 51.54 494.5 49.87
50.05 518.4 48.49 494.5 46.92
46.89 518.4 45.43 494.5 43.98
43.72 518.4 42.39 494.5 41.04
40.58 518.4 39.33 494.5 38.10
37.46 518.4 36.34 494.5 35.21
36.47 518.4 35.38
494.5 34.28
35.12 518.4 34.07 494.5 33.01
32.97 518.4 31.98 494.5 30.98
30.66 518.4 29.74 494.5 28.81
31.75 362.9 34 361.7 36.24
35.21 395.3 37.45 394 39.7
37.28 414.7 39.52 413.4 41.77
39.84 437.7 42.09 434.4 44.33
43.04 457.6 45.28 442.9 47.53
46.24 464.6 46.95 442.9 47.67
48.73 464.6 46.94 442.9 45.15
45.88 464.6 44.21 442.9 42.53
43.08 464.6 41.52 442.9 39.96
40.30 464.6 38.84 442.9 37.39
37.49 464.6 36.16 442.9 34.83
34.71 464.6 33.48 442.9 32.25
31.96 464.6 30.85 442.9 29.74
31.12 464.6 30.03
442.9 28.94
29.97 464.6 28.92 442.9 27.88
28.13 464.6 27.14 442.9 26.17
26.16 464.6 25.25 442.9 24.33
Nominal heating capacity rating obtained with air entering the indoor unit at 70ºF dry bulb (DB) and
outdoor ambient conditions of 47ºF dry bulb (DB) and 43ºF wet bulb (WB).
73 76
PI TC PI TC PI
MBh kW MBh kW
364.7 44.21 364.7 46.02
397.3 47.65 397.3 49.48
416.9 49.72 416.9 51.55
439.7 52.29 439.7 54.11
470.0 55.49 470.0 57.30
495.3 57.39 482.8 56.45
508.3 54.94 478.5 53.27
508.3 51.78 478.5 50.19
508.3 48.66 478.5 47.16
508.3 45.56 478.5 44.14
508.3 42.46 478.5 41.12
508.3 39.35 478.5 38.10
508.3 36.31 478.5 35.13
508.3 35.33 478.5 34.19
508.3 34.03 478.5 32.93
508.3 31.94 478.5 30.91
508.3 29.70 478.5 28.74
363.3 43.85 363.3 46.74
395.7 47.31 395.7 50.19
415.1 49.38 415.1 52.25
438.0 51.94 435.5 54.82
458.0 53.74 439.7 53.62
465.4 52.70 437.1 50.33
465.4 49.99 437.1 47.73
465.4 47.18 437.1 45.03
465.4 44.42 437.1 42.37
465.4 41.65 437.1 39.71
465.4 38.88 437.1 37.05
465.4 36.13 437.1 34.40
465.4 33.41 437.1 31.79
465.4 32.52 437.1 30.94
465.4 31.33 437.1 29.80
465.4 29.40 437.1 27.96
465.4 27.34 437.1 26.01
361.7 41.04 361.7 43.93
394 44.29 394 46.74
407.1 46.25 393.3 48.44
415.2 47.94 390.7 48.27
415.3 46.92 390.7 45.49
415.3 44.58 390.7 43.19
415.3 42.29 390.7 40.95
415.3 39.90 390.7 38.60
415.3 37.57 390.7 36.31
415.3 35.22 390.7 34.01
415.3 32.89 390.7 31.72
415.3 30.55 390.7 29.42
415.3 28.24 390.7 27.17
415.3 27.50 390.7 26.45
415.3 26.49 390.7 25.47
415.3 24.86 390.7 23.91
415.3 23.12 390.7 22.24
80
TC Pl
MBh kW
364.7 48.45
397.3 51.91
416.9 53.99
439.7 56.55
470.0 59.75
466.0 55.19
438.9 51.05
438.9 48.08
438.9 45.16
438.9 42.25
438.9 39.33
438.9 36.42
438.9 33.57
438.9 32.67
438.9 31.47
438.9 29.53
438.9 27.46
363.3 50.57
395.7 54.03
415.1 56.10
432.1 58.66
415.3 53.46
399.3 47.19
399.3 44.73
399.3 42.16
399.3 39.64
399.3 37.13
399.3 34.61
399.3 32.09
399.3 29.62
399.3 28.84
399.3 27.78
399.3 26.07
399.3 24.24
361.7 47.76
394 50.01
374.9 51.36
358.0 48.70
357.7 43.60
357.7 41.36
357.7 39.16
357.7 36.88
357.7 34.64
357.7 32.40
357.7 30.16
357.7 27.92
357.7 25.72
357.7 25.04
357.7 24.12
357.7 22.63
357.7 21.06
