HEATING CAPACITY DATA
ARUM264BTE5 / ARUM264DTE5
264,000 Btu/h 208-230V / 460V Outdoor Units
Outdoor air
temp.
Combination
(%)
TC
°F DB °F WB
MBh
-12.6 -13.0 200.2
-7.0 -7.6 215.1
-4.0 -4.4 224.1
0.0 -0.4 240.3
5.0 4.5 249.4
10.0 9.0 249.6
15.0 14.0 249.6
20.0 19.0 249.6
70%
25.0 23.0 249.6
30.0 28.0 249.6
35.0 32.0 249.6
40.0 36.0 249.6
45.0 41.0 249.6
47.0 43.0 249.6
50.0 46.0 249.6
55.0 51.0 249.6
60.0 56.0 249.6
-12.6 -13.0 184.4
-7.0 -7.6 199.1
-4.0 -4.4 212.3
0.0 -0.4 213.7
5.0 4.5 213.7
10.0 9.0 213.7
15.0 14.0 213.7
20.0 19.0 213.7
60%
25.0 23.0 213.7
30.0 28.0 213.7
35.0 32.0 213.7
40.0 36.0 213.7
45.0 41.0 213.7
47.0 43.0 213.7
50.0 46.0 213.7
55.0 51.0 213.7
60.0 56.0 213.7
-12.6 -13.0 178.8
-7.0 -7.6 178.8
-4.0 -4.4 178.8
0.0 -0.4 178.8
5.0 4.5 178.8
10.0 9.0 178.8
15.0 14.0 178.8
20.0 19.0 178.8
50%
25.0 23.0 178.8
30.0 28.0 178.8
35.0 32.0 178.8
40.0 36.0 178.8
45.0 41.0 178.8
47.0 43.0 178.8
50.0 46.0 178.8
55.0 51.0 178.8
60.0 56.0 178.8
TC = Total Capacity (MBh). PI = Power Input (kW) (includes compressor and outdoor fan).
The System Combination Ratio must be between 50–130%.
Nominal capacity as rated: 0 ft. above sea level with 25 ft. of refrigerant piping.
0 ft. level difference between outdoor and indoor units.
126 | PERFORMANCE DATA
59 61 64
PI TC PI TC
kW MBh kW MBh
15.43 200.2 16.29 200.2
17.34 215.1 18.2 215.1
18.49 224.1 19.34 224.1
19.91 235.1 20.75 227.2
21.67 240.6 22.53 227.2
23.45 240.6 24.29 227.2
26.40 240.6 25.66 227.2
24.68 240.6 23.98 227.2
22.99 240.6 22.35 227.2
21.30 240.6 20.71 227.2
19.60 240.6 19.07 227.2
17.91 240.6 17.43 227.2
16.27 240.6 15.84 227.2
15.83 240.6 15.43 227.2
15.25 240.6 14.85 227.2
14.32 240.6 13.95 227.2
13.31 240.6 12.97 227.2
15.68 184.4 16.48 184.4
17.59 197.7 18.39 195.5
18.73 205.6 19.54 195.5
20.14 206.5 20.96 195.5
21.92 206.5 22.72 195.5
24.86 206.5 24.50 195.5
24.16 206.5 23.46 195.5
22.53 206.5 21.86 195.5
20.94 206.5 20.29 195.5
19.36 206.5 18.72 195.5
17.77 206.5 17.15 195.5
16.19 206.5 15.58 195.5
14.64 206.5 14.05 195.5
14.26 206.5 13.68 195.5
13.74 206.5 13.18 195.5
12.89 206.5 12.36 195.5
11.99 206.5 11.50 195.5
14.15 172.2 15.43 162.5
16.07 172.2 17.34 162.5
17.21 172.2 18.48 162.5
18.63 172.2 19.90 162.5
21.68 172.2 21.67 162.5
22.66 172.2 21.70 162.5
21.14 172.2 20.25 162.5
19.55 172.2 18.72 162.5
17.99 172.2 17.24 162.5
16.43 172.2 15.74 162.5
14.87 172.2 14.26 162.5
13.31 172.2 12.76 162.5
11.81 172.2 11.34 162.5
11.50 172.2 11.04 162.5
11.08 172.2 10.63 162.5
10.40 172.2 9.98 162.5
9.68 172.2 9.28 162.5
©
Indoor Air Temp. °F DB/°F WB
67 70
PI TC PI TC
kW MBh kW MBh kW
17.56 199.6 18.91 199 20.28
19.46 210.7 20.96 206.5 22.44
20.62 215.3 22.17 206.5 23.74
22.03 216.8 23.68 206.5 25.34
23.80 216.8 24.53 206.5 25.26
25.57 216.8 24.71 206.5 23.85
24.54 216.8 23.51 206.5 22.47
22.96 216.8 21.99 206.5 21.03
21.40 216.8 20.51 206.5 19.62
19.83 216.8 19.03 206.5 18.22
18.28 216.8 17.55 206.5 16.81
16.72 216.8 16.06 206.5 15.40
15.21 216.8 14.62 206.5 14.03
14.81 216.8 14.23
206.5 13.66
14.26 216.8 13.71 206.5 13.16
13.38 216.8 12.87 206.5 12.35
12.45 216.8 11.96 206.5 11.49
17.7 180.7 19.28 177.1 20.87
19.61 186.3 21.23 177.1 22.85
20.75 186.3 22.38 177.1 24.00
22.16 186.3 23.21 177.1 24.26
23.94 186.3 23.42 177.1 22.90
23.94 186.3 22.74 177.1 21.54
22.42 186.3 21.31 177.1 20.20
20.84 186.3 19.83 177.1 18.82
19.30 186.3 18.38 177.1 17.46
17.75 186.3 16.93 177.1 16.10
16.20 186.3 15.47 177.1 14.73
14.66 186.3 14.02 177.1 13.38
13.16 186.3 12.61 177.1 12.06
12.82 186.3 12.27
177.1 11.74
12.34 186.3 11.83 177.1 11.31
11.59 186.3 11.10 177.1 10.61
10.77 186.3 10.32 177.1 9.87
17.34 155.1 18.96 147.9 20.59
19.25 155.1 20.23 147.9 21.22
20.39 155.1 21.39 147.9 22.37
21.81 155.1 21.67 147.9 21.54
21.65 155.1 20.93 147.9 20.22
20.26 155.1 19.58 147.9 18.90
18.90 155.1 18.26 147.9 17.61
17.49 155.1 16.87 147.9 16.26
16.11 155.1 15.52 147.9 14.94
14.72 155.1 14.17 147.9 13.62
13.34 155.1 12.82 147.9 12.30
11.95 155.1 11.46 147.9 10.98
10.61 155.1 10.17 147.9 9.71
10.33 155.1 9.90
147.9 9.46
9.96 155.1 9.53 147.9 9.10
9.34 155.1 8.94 147.9 8.55
8.69 155.1 8.32 147.9 7.95
Nominal heating capacity rating obtained with air entering the indoor unit at 70ºF dry bulb (DB) and
outdoor ambient conditions of 47ºF dry bulb (DB) and 43ºF wet bulb (WB).
73 76
PI TC PI TC PI
MBh kW MBh kW
194.2 22.96 184.2 24.57
195.2 24.62 183.9 25.59
195.2 25.61 183.9 26.20
195.2 25.43 183.9 25.00
195.2 24.08 183.9 23.63
195.2 22.72 183.9 22.25
195.2 21.40 183.9 20.89
195.2 20.02 183.9 19.48
195.2 18.66 183.9 18.10
195.2 17.31 183.9 16.72
195.2 15.96 183.9 15.34
195.2 14.61 183.9 13.95
195.2 13.29 183.9 12.61
195.2 12.94 183.9 12.27
195.2 12.46 183.9 11.83
195.2 11.70 183.9 11.10
195.2 10.88 183.9 10.32
166.7 23.63 157.6 25.28
166.7 23.98 157.6 25.05
166.7 24.35 157.6 23.73
166.7 23.40 157.6 22.60
166.7 22.04 157.6 21.26
166.7 20.69 157.6 19.92
166.7 19.36 157.6 18.60
166.7 17.98 157.6 17.24
166.7 16.63 157.6 15.89
166.7 15.27 157.6 14.55
166.7 13.92 157.6 13.21
166.7 12.57 157.6 11.87
166.7 11.25 157.6 10.58
166.7 10.95 157.6 10.30
166.7 10.55 157.6 9.92
166.7 9.90 157.6 9.31
166.7 9.21 157.6 8.66
139.1 21.71 131 22.78
139.1 21.99 131 20.91
139.1 21.19 131.0 20.16
139.1 20.21 131.0 19.21
139.1 18.97 131.0 18.04
139.1 17.74 131.0 16.85
139.1 16.54 131.0 15.70
139.1 15.28 131.0 14.49
139.1 14.05 131.0 13.31
139.1 12.82 131.0 12.14
139.1 11.58 131.0 10.95
139.1 10.35 131.0 9.77
139.1 9.17 131.0 8.64
139.1 8.92 131.0 8.42
139.1 8.60 131.0 8.11
139.1 8.06 131.0 7.60
139.1 7.50 131.0 7.07
80
TC Pl
MBh kW
170.8 26.72
169 26.88
169.0 26.98
169.0 24.44
169.0 23.02
169.0 21.61
169.0 20.21
169.0 18.76
169.0 17.34
169.0 15.92
169.0 14.50
169.0 13.07
169.0 11.71
169.0 11.40
169.0 10.98
169.0 10.30
169.0 9.59
145.4 27.49
145.4 26.46
145.4 22.90
145.4 21.54
145.4 20.22
145.4 18.89
145.4 17.59
145.4 16.24
145.4 14.92
145.4 13.59
145.4 12.27
145.4 10.95
145.4 9.68
145.4 9.42
145.4 9.07
145.4 8.52
145.4 7.92
120.1 24.19
120.1 19.49
120.1 18.76
120.1 17.88
120.1 16.78
120.1 15.66
120.1 14.57
120.1 13.44
120.1 12.33
120.1 11.22
120.1 10.11
120.1 9.00
120.1 7.94
120.1 7.72
120.1 7.44
120.1 6.98
120.1 6.49
