Chapter 4: Battery Test

Battery Test Results

After the test the tester will display the battery decisions
with the complete results in a series of screens. Use the
DOWN ARROW
keys to scroll through each result. To print
PRINT
the results press the
END softkey.
Menu, press the
VOLTAGE:
MEASURED:
RATED:
TEMPERATURE:
SOC:
Battery Decisions and Recommendations
Battery Decisions
Decision Recommended Action
GOOD BATTERY Return the battery to service.
CHARGE & RETEST Fully charge the battery and retest.
Failure to fully charge the battery
before retesting may cause false
readings. If CHARGE REQUIRED
appears again after you fully charge
the battery, replace the battery.
REPLACE BATTERY A REPLACE BATTERY result
may also mean a poor connection
between the battery and the vehicle.
If you tested the battery using the
IN-VEHICLE Test, disconnect the
battery cables and retest using
the OUT-OF-VEHICLE Test before
replacing it.
BAD CELL–REPLACE Replace the battery and retest.
FROZEN BATTERY Thaw the battery and retest.
Midtronics B.V. Hoofdveste 6 - 8
softkey. To return to the Main
12.79V
721 A(SAE)
760 A(SAE)
21 °C
94%
Houten NL
Battery
decision
Measured
UP/
voltage
Battery
temperature
12
EXP-1080 JLR
Measured
CCA
Selected
rating
