- Page 1 Instruction Manual HI 931100 HI 931101 HI 931102 Accurate Sodium/Sodium Chloride and Temperature Meters w w w. h a n n a i n s t . c o m...
-
Page 2: Table Of Contents
WARRANTY HI 931100, HI 931101 and HI 931102 are guaranteed for two years against defects in workmanship and materials when used for their intended purpose and maintained according to instructions. Electrodes and probes are guaranteed for six months. -
Page 3: Preliminary Examination
All defective items must be returned in the original packing with the supplied accessories. GENERAL DESCRIPTION Hanna Instruments Sodium (HI 931101) / Sodium Chloride (HI 931100/ HI 931102) analyzers are state-of-the-art, hand held meters, designed to provide laboratory results and accuracy under harsh industrial conditions. -
Page 4: Functional Description
FUNCTIONAL DESCRIPTION 1) BNC electrode connector 2) Temperature probe socket 3) Battery holder cap 4) Liquid Crystal Display (LCD) 5) On/Off key, to turn the instrument ON and OFF. 6) MODE key, to select the range (HI 931101, HI 931102 only) 7) CAL key, to enter/exit calibration mode. -
Page 5: Specifications Hi 931100
SPECIFICATIONS HI 931100 1 . 0 5 . 1 L / g 0 5 . 0 0 . L / g 0 . 5 0 . 0 L / g L / g 0 . 0 0 . 0 C °... -
Page 6: Specifications Hi 931101
SPECIFICATIONS HI 931101 0 . 0 0 0 . 0 . 5 0 . 0 L / g p p ( 1 . 0 5 . 1 L / g 0 5 . 0 0 . L / g . 5 1 0 . -
Page 7: Specifications Hi 931102
SPECIFICATIONS HI 931102 1 . 0 5 . 1 L / g 0 5 . 0 0 . L / g 0 . 5 0 . 0 L / g L / g 0 0 . 0 0 . 0 . 0 0 . -
Page 8: Operational Guide
In order to take accurate measurements, make sure the instru- ment is calibrated before use (see page 11 for HI 931101 and page 13 for HI 931100 & HI 931102). For greatest accuracy, calibration should be performed (or at least verified) every day for measurements taken in the same type of samples (e.g. - Page 9 TAKING SODIUM MEASUREMENTS Remove the protective cap of the FC 300B sodium-sensitive electrode and, if possible, rinse it with some of the sample you are going to measure. Lower the rubber sleeve to get the junction to work properly. Immerse the tip of the FC300B electrode (2.5 cm/1"...
- Page 10 Press the MODE key during measure- ment to convert the displayed value of HI 931102 to %. Press the same key to return to g/L measurements. AFTER USE Turn the meter off by pressing the ON/OFF key again. For a faster and accurate measure, the elec- trode should be stored in a solution with a Na/NaCl concentration similar to the sample to be measured.
-
Page 11: Calibration
CALIBRATION In order to obtain accurate measurements, frequent calibration is recommended. For better results, calibrate at a temperature close to that of the solution to be tested (no more than ±3°C apart). The instrument can be calibrated in 1 or 2 points. Two-point calibration is always recommended for better accuracy. - Page 12 • Remove the protective cap of the electrode and rinse it with some of the buffer calibration solution you are going to use first. • Lower the rubber sleeve to get the junction to work properly. TWO-POINT CALIBRATION • Press CAL. The instrument will dis- play the measured concentration on the primary LCD, if a previous calibration exists, or “----”...
- Page 13 NaCl CALIBRATION (HI 931100 / HI 931102) The calibration is performed by immersing the FC 300B sodium- sensitive electrode in 2 different standard NaCl solutions to achieve accurate 2 point calibration.
- Page 14 TWO-POINT CALIBRATION • Press CAL. The instrument will dis- play the measured concentration on the primary LCD, if a previous calibration exists, or “----”, and the “3.00 g/L” standard on the secondary LCD, together with “CAL” and “Cal Point 1” tags. •...
-
Page 15: Setup
Notes: • For best results, wait for a couple of minutes before pressing the CFM key. • Press and hold Setup then Select before “CFM” tag appears, to toggle between standard and temperature display on secondary LCD line reading during calibration. •... -
Page 16: Special Applications & Additional Information
Note: ACCU criteria is recommended. SPECIAL APPLICATIONS & ADDITIONAL INFORMATION HOW TO MEASURE SODIUM CHLORIDE IN CHEESE AND MEAT (HI 931100 & HI 931102) 1. Take a sample of cheese or meat to be analyzed. 2. Grind the sample. 3. Pour a quantity of X g in a glass beaker. - Page 17 4. Cover the beaker to prevent any spilling during stirring, place the beaker on the top of a hot plate stirrer and agitate the sample at 40-50°C (104-122°F) for 15-20 minutes. 5. Let the sample cool to the ambient temperature, then filter it. 6.
-
Page 18: Temperature Calibration (For Technical Personnel Only)
(± 1°C/±2°F). Na CONCENTRATION WITH HI 931100 AND HI 931102 It is always possible to determine the Na concentration by using the formula: •... - Page 19 • Submerse the temperature probe into the vessel with ice and water as close as possible to the reference thermometer. Allow a few seconds for the probe to stabilize. • Use the Select key to set the reading on the secondary LCD to that of ice and water, measured by the reference thermometer.
-
Page 20: Battery Replacement
BATTERIES REPLACEMENT If the batteries become weak, the display will flash the battery symbol to advise the user that approx. 1 hour of working time is left. It is recommended to replace the batteries soon. To replace the batteries, follow the next steps: •... -
Page 21: Lcd Message Guide
The instrument is provided with the BEPS (Battery Error Prevention System) feature, which automatically turns the instrument off when the batteries level is too low to ensure reliable readings. At start up the display will show “0 bAtt” message for a few seconds, then the instrument automatically turns off. -
Page 22: Fc300B Conditioning & Maintenance
If the bulb and/or junction are dry, soak the electrode overnight in HI 7081 NaCl 30.0 g/L solution before using with the HI 931100 or HI 931102 sodium meter. Soak it overnight in HI 7086 or HI 8086 Na 23 g/L solution before using with the HI 931101 sodium meter. - Page 23 For frequent use in different samples (1 or 2 times per week), store the electrode in HI 7081 or HI 8081 (30.0 g/L NaCl) if used for NaCl measurements (in conjunction with HI 931100 or HI 931102). Store the electrode in HI 7080 or HI 8080 (2.3 g/L Na) if used for Na measurements (in conjunction with HI 931101).
-
Page 24: Troubleshooting Guide
TROUBLESHOOTING GUIDE g n i c u l f a u t s e t t r i e l C e h t e l e o r t c . e d i o n . ) e s r t c e e d o i t c n... -
Page 25: Accessories
ISA solution, 230 mL HI 7090L ISA solution, 460 mL NaCl CALIBRATION (& STORAGE) SOLUTIONS IN FDA APPROVED BOTTLES FOR HI 931100 & HI 931102: HI 8081M 30 g/L NaCl solution, 230 mL HI 8081L 30 g/L NaCl solution, 460 mL HI 8083M 3.0 g/L NaCl solution, 230 mL... - Page 26 ELECTRODE CLEANING SOLUTIONS: HI 7061M General Cleaning Sol., 230 mL HI7061L General Cleaning Sol., 460 mL HI 7073M Protein Cleaning Sol., 230 mL HI7073L Protein Cleaning Sol., 460 mL HI 7074M Inorganic Cleaning Sol., 230 mL HI7074L Inorganic Cleaning Sol., 460 mL HI 7077M Oil &...
- Page 27 RECOMMENDATIONS FOR USERS Before using these products, make sure that they are entirely suitable for the environment in which they are used. Operation of these instruments in residential area could cause unacceptable interferences to radio and TV equipments, requiring the operator to take all necessary steps to correct interferences.
- Page 28 Hanna Instruments Inc. Highland Industrial Park 584 Park East Drive Woonsocket, RI 02895 USA Technical Support for Customers Tel. (800) 426 6287 Fax (401) 765 7575 E-mail tech@hannainst.com www.hannainst.com Local Sales and Customer Service Office Printed in ROMANIA MAN931100Y 11/12...
