5. Diagnostic and Fault Messages

Fault No. Description
Code
no-Flt 00 No Fault
OI-b 01 Brake channel over current
OL-br 02 Brake resistor overload
O-I 03 Instantaneous over current
I.t-trp 04 Motor Thermal Overload (I2t)
SAFE-1 05 Safety input circuit error (Processor output)
O-Volt 06 Over voltage on DC bus
U-Volt 07 Under voltage on DC bus
O-t 08 Heatsink over temperature
U-t 09 Under temperature
P-dEF 10 Factory Default parameters have been loaded
E-trip 11 External trip
SC-ObS 12 Optibus comms loss
FLt-dc 13 DC bus ripple too high
P-LOSS 14 Input phase loss trip
h O-I 15 Instantaneous over current on drive output.
th-Flt 16 Faulty thermistor on heatsink.
dAtA-F 17 Internal memory fault. (IO)
4-20 F 18 4-20mA Signal Lost
dAtA-E 19 Internal memory fault. (DSP)
U-dEF 20 User Default Parameters Loaded
F-Ptc 21 Motor PTC thermistor trip
FAN-F 22 Cooling Fan Fault
O-hEAt 23 Environmental temperature too high
O-torq 24 Reserved
U-torq 25 Output torque too low (hoist mode)
Out-F 26 Drive output fault
Err-01 27 Reserved
Err-02 28 Reserved
SAFE-2 29 Safety input circuit error (Buffer output)
Enc-01 30 Encoder comms/data loss
SP-Err 31 Speed error
Enc-03 32 Incorrect Encoder PPR count set in parameters
Enc-04 33 Encoder Channel A Fault
Enc-05 34 Encoder Channel B Fault
Enc-06 35 Encoder Channels A & B Fault
Enc-07 36 Reserved
Enc-08 37 Reserved
Enc-09 38 Reserved
Enc-10 39 Reserved
58
Optidrive P2 Advanced User Guide Revision 2.00
Fault
Code
AtF-01
AtF-02
AtF-03
AtF-04
Out-Ph
Ph-Seq
AtF-07
AtF-08
AtF-09
Out-Ph
SC-F01
SC-F02
SC-F03
SC-F04
SC-F05
SC-F06
SC-F07
SC-F08
SC-F09
SC-F10
OF-01
OF-02
OF-03
OF-04
OF-05
OF-06
OF-07
OF-08
OF-09
OF-10
PLC-01
PLC-02
PLC-03
PLC-04
PLC-05
PLC-06
PLC-07
PLC-08
PLC-09
PLC-10
www.invertekdrives.com
No. Description
40 Measured motor stator resistance varies between phases.
41 Measured motor stator resistance is too large.
42 Measured motor inductance is too low.
43 Measured motor inductance is too large.
44 Output (motor) phase missing
45 Supply Phase SequenceIncorrect (FS8 Only)
46 Reserved
47 Reserved
48 Reserved
49 Output (Motor) phase loss
50 Modbus comms loss fault
51 CANopen comms loss trip
52 Anybus module comms loss trip
53 IO card comms loss trip
54 Reserved
55 Reserved
56 Reserved
57 Reserved
58 Reserved
59 Reserved
60 Internal link to option module loss
61 Option module in exceptional condition
62 Reserved
63 Reserved
64 Reserved
65 Reserved
66 Reserved
67 Reserved
68 Reserved
69 Reserved
70 Unsupported Function Block Program block
71 Function Block Program over size
72 Divide by 0
73 Lower limit larger than higher limit
74 Table function block index overflow
75 Reserved
76 Reserved
77 Reserved
78 Reserved
79 Reserved
