Invertek optidrive cp2 User Manual page 51

Parameter R/W Modbus CAN CAN
Number RTU Open Open
Register Index Sub
Number Index
P9-09 R/W 909 238Dh 0h
P9-10 R/W 910 238Eh 0h
P9-11 R/W 911 238Fh 0h
P9-12 R/W 912 2390h 0h
P9-13 R/W 913 2391h 0h
P9-14 R/W 914 2392h 0h
P9-15 R/W 915 2393h 0h
P9-16 R/W 916 2394h 0h
P9-17 R/W 917 2395h 0h
P9-18 R/W 918 2396h 0h
P9-19 R/W 919 2397h 0h
P9-20 R/W 920 2398h 0h
P9-21 R/W 921 2399h 0h
P9-22 R/W 922 239Ah 0h
P9-23 R/W 923 239Bh 0h
P9-24 R/W 924 239Ch 0h
P9-25 R/W 925 239Dh 0h
Profibus DeviceNet EtherNet EtherCAT
DP IP
3, 143 A2h, 909, X A2h, 909, X 238Dh
3, 144 A2h, 910, X A2h, 910, X 238Eh
3, 145 A2h, 911, X A2h, 911, X 238Fh
3, 146 A2h, 912, X A2h, 912, X 2390h
3, 147 A2h, 913, X A2h, 913, X 2391h
3, 148 A2h, 914, X A2h, 914, X 2392h
3, 149 A2h, 915, X A2h, 915, X 2393h
3, 150 A2h, 916, X A2h, 916, X 2394h
3, 151 A2h, 917, X A2h, 917, X 2395h
3, 152 A2h, 918, X A2h, 918, X 2396h
3, 153 A2h, 919, X A2h, 919, X 2397h
3, 154 A2h, 920, X A2h, 920, X 2398h
3, 155 A2h, 921, X A2h, 921, X 2399h
3, 156 A2h, 922, X A2h, 922, X 239Ah
3, 157 A2h, 923, X A2h, 923, X 239Bh
3, 158 A2h, 924, X A2h, 924, X 239Ch
3, 159 A2h, 925, X A2h, 925, X 239Dh
Modbus Profinet
TCP IO
1436 0, 0, 1, 038Dh Terminal Control
Override Source
1437 0, 0, 1, 038Eh Speed Source 1
1438 0, 0, 1, 038Fh Speed Source 2
1439 0, 0, 1, 0390h Speed Source 3
1440 0, 0, 1, 0391h Speed Source 4
1441 0, 0, 1, 0392h Speed Source 5
1442 0, 0, 1, 0393h Speed Source 6
1443 0, 0, 1, 0394h Speed Source 7
1444 0, 0, 1, 0395h Speed Source 8
1445 0, 0, 1, 0396h Speed Source Select
Input Bit 0
1446 0, 0, 1, 0397h Speed Source Select
Input Bit 1
1447 0, 0, 1, 0398h Speed Source Select
Input Bit 2
1448 0, 0, 1, 0399h Preset Speed Select
Bit 0
1449 0, 0, 1, 039Ah Preset Speed Select
Bit 1
1450 0, 0, 1, 039Bh Preset Speed Select
Bit 2
1451 0, 0, 1, 039Ch Acceleration Ramp
Select Bit 0
1452 0, 0, 1, 039Dh Acceleration Ramp
Select Bit 1
Scaling Type
3 : Digital Input 3 U16
4 : Digital Input 4
5 : Digital Input 5
6 : Digital Input 6
7 : Digital Input 7
8 : Digital Input 8
9 : Analog Output 1
10 : Analog Output 2
11 : Digital Output 1
12 : Digital Output 2
13 : Digital Output 3
14 Digital Output 4
15 : Digital Output 5
16 : ON
17 : User Register 1
18 : User Register 2
19 : User Register 3
20 : User Register 4
21 : User Register 5
22 : User Register 6
23 : User Register 7
24 : User Register 8
25 : User Register 9
0 : Analog Input 1 U16
1 : Analog Input 2 U16
2 : Preset Speed
U16
3 : Keypad Speed
U16
4 : User PID Speed
U16
5 : Master Speed
U16
6 : Fieldbus Speed
U16
7 : User Speed
U16
8 : Frequency Input
9 : Preset Speed 1
10 : Preset Speed 2
11 : Preset Speed 3
12 : Preset Speed 4
13 : Preset Speed 5
14 : Preset Speed 6
15 : Preset Speed 7
16 : Preset Speed 8
0 : Safety Input U16
1 : Digital Input 1
2 : Digital Input 2
U16
3 : Digital Input 3
4 : Digital Input 4
U16
5 : Digital Input 5
6 : Digital Input 6
U16
7 : Digital Input 7
8 : Digital Input 8
U16
9 : Analog Output 1
10 : Analog Output 2
U16
11 : Digital Output 1
12 : Digital Output 2
U16
13 : Digital Output 3
14 Digital Output 4
U16
15 : Digital Output 5
Parameter Access Tables
