Invertek optidrive cp2 User Manual page 32

P1-13 = 13
Open Closed
Stop Run Forward
Stop Run Reverse
Selected Speed Preset Speed 1
Reference
Analog Input 1
Analog Input 2 (E.g. Torque Reference)
Safe Torque OFF inputs
Contacts must be closed to operate drive
P1-13 = 15
Open Closed
Stop Run Forward
Stop Run Reverse
Selected Speed Analog Input 2
Reference Speed Reference
Analog Input 1
Analog Input 2
Safe Torque OFF inputs
Contacts must be closed to operate drive
P1-13 = 17
Open Closed
Stop Run Forward
Stop Run Reverse
Preset Speed Reference Selected as
follows:-
DIN3 AIN1 Preset
OFF OFF P2-01
ON OFF P2-02
OFF ON P2-03
ON ON P2-04
External Trip
Safe Torque OFF inputs
Contacts must be closed to operate drive
P1-13 = 19
Open Closed
Stop Run Forward
Stop Run Reverse
Preset Speed Reference Selected as
follows:-
DIN3 AIN1 Preset
OFF OFF P2-01
ON OFF P2-02
OFF ON P2-03
ON ON P2-04
Selected Speed Preset Speeds
Reference Reference 1 - 4
Safe Torque OFF inputs
Contacts must be closed to operate drive
32
Optidrive P2 Advanced User Guide Rev 2.00
P1-13 = 14
Open
Stop
Stop
Selected Speed
Reference
Decel ramp 1
(P1-04)
Contacts must be closed to operate drive
P1-13 = 16
Open
Stop
Stop
Selected Speed
Reference
Contacts must be closed to operate drive
P1-13 = 18
Open
Stop
Stop
Preset Speed Reference Selected as
DIN3
OFF
ON
OFF
ON
Decel ramp 1
(P1-04)
Contacts must be closed to operate drive
P1-13 = 20
Open
Stop
Stop
Selected Speed
Reference
Contacts must be closed to operate drive
1)
www.invertekdrives.com
Closed
Run Forward
Run Reverse
Preset Speed 1
Analog Input 1
Decel Ramp 2
(P8-11)
Safe Torque OFF inputs
Closed
Run Forward
Run Reverse
Preset Speed 1
Analog Input 1
External Trip
Safe Torque OFF inputs
Closed
Run Forward
Run Reverse
follows:-
AIN1 Preset
OFF P2-01
OFF P2-02
ON P2-03
ON P2-04
Decel Ramp 2
(P2-25)
Safe Torque OFF inputs
Closed
Run Forward
Run Reverse
1)
Increase Speed
1)
Decrease Speed
Preset Speed 1
Safe Torque OFF inputs
Increase / Decrease speed function only works if the Selected Speed
reference is the Motorised Pot (P1-12 = 1 or 2)
