1. Optidrive P2 Parameter Set Overview

1.1. About this section

This document provides a list of the available parameters, and a description of their respective functions, for the Optidrive P2.

1.2. Parameter Structure Overview

The parameter set is arranged in Groups according to the following structure
Parameter Group Range
Group 0 P0-01 to P0-50
P0-51 to P0-80
Group 1 P1-01 to P1-14
Group 2 P2-01 to P2-40
Group 3 P3-01 to P3-12
Group 4 P4-01 to P4-12
Group 5 P5-01 to P5-10
Group 6 P6-01 to P6-30
Group 7 P7-01 to P7-10
Group 8 P8-01 to P8-10
Group 9 P9-01 to P9-30
Access to all parameter groups is controlled by setting P1-14 as follows
P1-14 = P2-40 (Factory setting: 101) Allows Extended Parameter Access
P1-14 = P6-30 (Factory Setting: 201) Allows Advanced Parameter Access
4
Optidrive P2 Advanced User Guide Rev 2.00
Name Access Level
Basic Monitoring Extended
Advanced Monitoring Advanced
Quick Start Menu Basic
Extended Parameters Extended
PID Controller Extended
Motor Control Extended
Communications Extended
Advanced Functions Advanced
Advanced Motor Data Advanced
Application Specific Group Advanced
Programmable Logic Advanced
www.invertekdrives.com
Access Type
Read Only
Read Only
Read / Write
Read / Write
Read / Write
Read / Write
Read / Write
Read / Write
Read / Write
Read / Write
Read / Write
