REFERENCE
KTN030 *** 500 mm
KTN050 *** 500 mm
KTN075 *** 500 mm
KTN100 *** 500 mm
CODE MODEL
KTN030SEB2 T.WHITE 030
KTN050SEB2 T.WHITE 050
KTN075SEB2 T.WHITE 075
KTN100SEB2 T.WHITE 100
CODE MODEL
KTN030SEM2 T.METALLIC 030
KTN050SEM2 T.METALLIC 050
KTIN075SEM2 T.METALLIC 075
KTN100SEM2 T.METALLIC 100
CODE MODEL
KTN030SEC2 T.CHROME 030
KTN050SEC2 T.CHROME 050
KTN075SEC2 T.CHROME 075
KTN100SEC2 T.CHROME 100

3.2. Specific Regulations for Bathrooms

This device is in compliance with CLASS II safety regulations (double
insulation). It can be installed in areas 2 and 3, position A and B
whenever it observes the following regulations:
• In bathrooms, the towel rail must never be installed in such a way
that the switches and other control devices may be touched by
someone in the bathtub or having a shower.
• In a kitchen or bathroom, the body of the heated towel rail shall
be placed at least 25 cm from the floor.
• It must not be earthed.
H1 H2
300 mm
300 mm
300 mm
300 mm
POWER VOLTAGE
300 W 230V~
500 W 230V~
750 W 230V~
1,000 W 230V~
POWER VOLTAGE
300 W 230V~
500 W 230V~
750 W 230V~
1,000 W 230V~
POWER VOLTAGE
300 W 230V~
300 W 230V~
500 W 230V~
750 W 230V~
V1
800 mm
1,200 mm
1,600 mm
1,800 mm
HEIGHT WIDTH DEPTH
800 mm 500 mm 50 mm
1,200 mm 500 mm 50 mm
1,600 mm 500 mm 50 mm
1,800 mm 500 mm 50 mm
HEIGHT WIDTH DEPTH
800 mm 500 mm 50 mm
1,200 mm 500 mm 50 mm
1,600 mm 500 mm 50 mm
1,800 mm 500 mm 50 mm
HEIGHT WIDTH DEPTH
800 mm 500 mm 50 mm
1,200 mm 500 mm 50 mm
1,600 mm 500 mm 50 mm
1,800 mm 500 mm 50 mm
V2 V3
640 mm 49 mm
1,040 mm 49 mm
1,360 mm 128 mm
1,360 mm 325 mm
INST. DEPTH WEIGHT
100 mm 11 kg
100 mm 15 kg
100 mm 22 kg
100 mm 28 kg
INST. DEPTH WEIGHT
100 mm 11 kg
100 mm 15 kg
100 mm 22 kg
100 mm 28 kg
INST. DEPTH WEIGHT
100 mm 11 kg
100 mm 15 kg
100 mm 22 kg
100 mm 28 kg
29
