KYROS
4. Insert the rawl plugs in the holes made.
5. Screw the plastic fastener to the wall with the 5.5 x 50 mm screw.
6. Screw the two brackets for supporting the heated towel rail and
the plastic fastener to the horizontal tube of the heated towel rail
like in Figure 1 with the 8 x 26 mm screw.
7. Insert what you have assembled in Section 6 into the plastic piece
and fix well with the 5 x 12 mm screw.
8. Place the cover on the piece supporting the heated towel rail.
1
2
3
1
2
3
4
5
6
7
8
9
26
4
5
7
6
10 x 40 mm Rawl Plug
Bracket
5.5 x 50 mm screw
5 x 12 mm screw
Bracket insert
Bracket head
8 x 26 mm screw
Cap
Towel Rail
9
8
