Content Diagram
Output
Terminal Blocks
4
F E NIE X .
2016
IN STR U CT I ON MA NUA L
WE B. w w w.feniex .co m
Input
Terminal Block
Labeled
USB Port
RJ45 Port
(not used)
30A Fuse
Positive
Important!
Do not use the unmarked RJ45 slot. This
is an unactivated slot. Use of this slot can
cause damage to unit.
V3.1
Ground
Unmarked RJ45 Port
