FE N I E X / /
V 3. 1
/ /
INSTR U CTIO N M ANUAL
WE B // w w w.feni ex .co m
C-4200-DL
INSTRUCTION MANUAL
Feniex Product Copyrights This price List and the mentioned Feniex products include or describe copyrighted Feniex material. Laws in the United States and other countries
preserve for Feniex Industries and its licensors certain exclusive rights for copyrighted material, including the exclusive right to copy, reproduce in any form, distribute and make
derivative works of the copyrighted material. Accordingly, any copyrighted material of Feniex and its licensors contained herein or in the Feniex products described in this Price
List may not be copied, reproduced, distributed, merged or modified, transmitted, transcribed, stored in retrieval system or translated into any language or computer language,
in any form or by any means, without prior written permission of Feniex Industries, Inc.. Feniex and the stylized Feniex logo are registered in the U.S. Patent & Trademark Office.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C-4200-DL and is the answer not in the manual?

Questions and answers

BRAD MARQUIS
June 10, 2025

controler will not come on after loosing power

0

Related Manuals for Feniex C-4200-DL

Summary of Contents for Feniex C-4200-DL

  • Page 1 List may not be copied, reproduced, distributed, merged or modified, transmitted, transcribed, stored in retrieval system or translated into any language or computer language, in any form or by any means, without prior written permission of Feniex Industries, Inc.. Feniex and the stylized Feniex logo are registered in the U.S. Patent & Trademark Office.
  • Page 2 TABLE OF CONTENTS Safety Regulations & Warranty Service after Expiration Copyright Feniex Product Copyright Box Contents, Specifications, & Wiring Diagram Box Contents Wig-Wag Flash Patterns System Specifications Dimensions Power & Configuration Power Auto Power On Wiring Diagram Latching or Momentary Buttons...

  • Page 3: Safety Regulations & Warranty

    SAFETY REGULATIONS CONDITIONS The following provides all the information necessary to Feniex Industries, Inc. will not be held responsible for any safely operate the previously listed products of Feniex costs associated with equipment removal and/or Industries, Inc. Please read this manual thoroughly before re-installation resulting from a warranty claim.
  • Page 4 SPECIFICATIONS & BOX CONTENTS COMPONENT QUANTITY SYSTEM SPECIFICATIONS 1. 4200 Data Link Relay Input Power 11 - 16 VDC 2. 4200 Data Link Keypad Max Input Current 60 Amps 3. Keypad Bail Bracket Maximum Output 60 Amps 4. Ethernet Cable Standby Current 100mA +/- 5.

  • Page 5: Connection Diagram

    CONNECTION DIAGRAM DataLink Products Fusion Series Lightbars Geo Series Lightbars Storm Pro 100w Storm Pro 200w RJ45 RJ45 Postive Battery Terminal Inputs A-H Negative Battery Terminal Wig-Wag Outputs FUNCTION POLARITY FUNCTION POLARITY Headlight Flasher, Channel 1 12v (+) Programmable Output #11 12v (+) Headlight Flasher, Channel 2 12v (+)

  • Page 6: Mounting Instructions

    MOUNTING INSTRUCTIONS SWIVEL MOUNT INSTALLATION L-BRACKET INSTALLATION 1) Secure the Swivel Ball to the base of the controller Note: The provided L-brackets can be mounted either using the #10 screw. way, L-inward or L-outward. The instructions reflect the default mounting method: L-outward. 2) Attach the swivel ball to the swivel bracket base using the #10 screw.

  • Page 7: Configuration Record

    CONFIGURATION RECORD Use this page to record the products connected to each outlet to assist when programming the control head with the provided software package. Outputs: Buttons: (1 - 18, P1 - P3) Input/Polarity: A (-) F- Night (+) B (-) G- Day (+) C (+) H- Ignition (+)

  • Page 8: Button Legends

    Outputs 13 - 16 Input Examples • Highbeam Override • Park-Kill • Reverse Override Fuse 5 Outputs 17 - 20 FE NIE X / / IN STR UCT ION MAN UAL WE B / / w w w.feniex .co m...
  • Page 9 Body Control Module Highbeam Override Using the programming software, configure Input E (in this example) to "Highbeam Override" (see page 17). FE NIE X / / IN STR UCT ION MAN UAL WE B / / w w w.feniex .co m...

  • Page 10: Programming Software

    Please note a button cannot activate another button. Multiple buttons can be activated through the slide switch or input set up. F E NIE X / / IN STR UCTI ON MA NUAL W E B / / w w w.feniex .co m...
  • Page 11 (input, slide switch, button) then select the lightbar function. Multiple functions can be selected on 1 switch. F E NIE X / / IN STR UCTI ON MA NUAL W E B / / w w w.feniex .co m...
  • Page 12 For example: Tone 1 programmed on speaker 1 will play through both speakers #1 and #2 on a 200W siren. F E NIE X / / IN STR UCTI ON MA NUAL W E B / / w w w.feniex .co m...
  • Page 13 (input, slide switch, button) then select the lightbar function. Multiple functions can be selected on 1 switch. F E NIE X / / IN STR UCTI ON MA NUAL W E B / / w w w.feniex .co m...

  • Page 14: Bluetooth Connectivity

    • iPad 3rd Gen or newer installation. Devices must have Bluetooth 4.0 and iOS 6.0 software or newer. F E NIE X / / IN STR UCTI ON MA NUAL W E B / / w w w.feniex .co m...

  • Page 15: Frequently Asked Questions

    Enter new name for button when text box appears. On Apple app, select “settings” to edit labels on buttons. F E NIE X / / IN STR UCTI ON MA NUAL W E B / / w w w.feniex .co m...
