FAQ

Fig 7.1
1.) How do I know if there is power to my
4200 Relay?
A flashing green LED light on the PCBA will
indicate if there is power to the board if the
firmware is fully operational.
2.) Why can't I program to outputs 1 - 2?
Outputs 1 - 2 are only for the WigWag
Function Box.
3. What are T1 - T8 outputs used for?
T1 - T8 are used for traffic advisor control.
A lightbar or stick utilizing 12V(-) outputs
can connect into outputs T1 - T8.
4. My traffic advisor on my Cobra
lightstick doesn't work in T1-T8?
Do not connect the blue and gray wire
(product directional wires) to T1-T8. Use
one of available outputs from 3-28 for your
16
F E NIE X . 2016
WE B. w w w.feniex .co m
Halogen Bulb
IN STR U CT I ON MA NUA L
LED /
High beam Factory
directional needs. If you would like the light
stick to work with T1-T8; you will need a
lightstick manufactured without an internal
driver.
5. My controller does not turn on after I
programmed it?
Make sure to provide 12V+ into the
"Ignition Input" (Input H).
6. What are outputs 29 - 32 used for?
Outputs 29 - 32 are a 12V junction
connection that use continuous current.
These outputs are used to provide power
to low voltage products, like Apollo
Innerbar, Cobra Light Bars and not high
voltage ones like siren systems.
7. What is the password for Feniex
Bluetooth Module?
Android: The password is: 1111
Apple: The password is: 11111111
