RECARO Performance BOOSTER Instruction Manual page 33

5
6
7
8
9
5. Hook the button holes
located in top/back of the
backrest cover onto the
hooks in the backrest frame.
6. Hook the (2) elastic loops
located in the lowest corners
of the backrest cover to same
hooks used to attach the
bottom of the headrest cover.
7. Place seat cushion foam on
seat frame with the thin layer
side up.
8. Position the seat cushion
cover over the armrests of
the cushion frame and then
slide the openings (2) onto
the armrests.
9. Pull the front edge of the
cushion cover down and
around the front of the
cushion frame. Snap the
button located in the back of
the back rest. Replace the
cup holder inserts.
29 29
