Page 1: Table Of Contents
SAFETY PRECAUTIONS INTRODUCTION INSTALLATION CONNECTIONS DETAILED INSTALLATION DESIGN PHILOSOPHY TECHNICAL DATA CARE and HANDLING WARRANTY WARRANTY REGISTRATION ADDRESS OPERATION MANUAL AMPLIFIER v10... -
Page 2: Safety Precautions
SAFETY PRECAUTIONS CAUTION: TO PREVENT ELECTRIC SHOCK, DO NOT REMOVE COVER. NO USER SERVICEABLE PARTS INSIDE, REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE. TO AVOID ELECTRICAL SHOCK, DO NOT OPEN THE UNIT. -
Page 3: Introduction
This amplifier is a precision device, designed in an effort to provide the listener with unmatched sound quality, design, and construction. In order to operate your amplifier properly and to realize all of the capabilites of the AMPLIFIER v10, we recommend that you read this entire manual carefully. -
Page 4: Installation Connections
These brief steps will allow you to begin operating your system. Make sure during installation that the main AC power switch on the back of the AMPLIFIER v10 is turned off. While the diagram may be self explanatory, we strongly recommend that you read the detailed instructions following this introductory section. -
Page 5: Detailed Installation
4. The MAIN POWER switch, once all appropriate connectsions are made, may be left on as the AMPLIFIER v10 draws a negligible amount of current when the BIAS is turned off. 5. The FUSE AND VOLTAGE SELECTOR houses a 5 X 20 slow blow fuse and voltage selector cartridge. - Page 6 4. This two color LED indicates that the main power is on. When it is red the balanced inputs are in use. When it is yellow the unbalanced inputs are in use. MULTI CHANNEL A/V AMPLIFIER v10 Note: If a power interruption occurs to the system the AMPLIFIER v10 defaults to bias off. BIAS INPUT...
- Page 7 1. The BIAS button turns on the bias and opens shunting relays that mute the input. 2. The BAL«»UNBAL button switches between the balanced and unbalanced inputs. Note: If a power interruption occurs to the system the AMPLIFIER v10 defaults to bias off. BIAS VOL–...
- Page 8 BRIDGED operation consists of one, or both sets of AMPLIFIER v10 channels. The amount of power from a four channel AMPLIFIER v10 is 100 Watts with 8 Watts class A per channel. A bridged AMPLIFIER v10 has 400 Watts with 8 Watts class A per set of channels. To bridge, set the MODE switch on the back of the amplifier to the BRIDGED position.
- Page 9 DETAILED INSTALLATION BRIDGED set up diagram Before setting up the BRIDGED AMPLIFIER v10, read the entire DETAILED INSTALLATION section of this manual. As stated on the previous page, either the left set or right set, or both sets of channels may be bridged.
-
Page 10: Design Philosophy
This allows direct coupling without servo circuitry. The unit also uses output followers operating without feedback. The front end of the Amplifier v10 is designed to operate without ever entering Class B operation as is common in many other designs. This combined with excellent high frequency design insures linear operation at high speed, and translates into a sonic reproduction which is extremely transparent in character. - Page 11 Advanced tracking techniques results in absolute control of bias curents under all conditions in the Amplifier v10. The main power supply of the amplifier consists of a 1000VA toroidal power transformer with dual rectifiers to isolate one set of channels from the other.
- Page 12 The XLR input and output connectors are manufactured by Neutrik of Switzerland. Speaker connecters are also gold plated. 7. Wire - All signal wire has been eliminated whenever possible. Where wire is used, Coda employs solid silver and silver plated copper, 141 strand, 18 guage wire with a silicone insulation.
-
Page 13: Technical Data
TECHNICAL DATA AMPLIFIER v10 Rated Power: 100 Watts with 25 Watts class A @ 8 Ohms both channels driven from 20Hz to 20kHz Frequency Response: DC to -3dB @ 100kHz Distortion: < .1 percent from 10Hz to 20kHz @ 100 Watts both channels driven into... -
Page 14: Care And Handling
If a cleaner is necessary, any dilute commercial ammonia based product will be appropriate. NEVER use any abrasive rags, cleaners or chemical solvents on the AMPLIFIER v10. When handling the unit, take care not to mar the aluminum. Aluminum is a medium hardness metal and can be scratched by the harder tool steels. -
Page 15: Warranty
Technologies, Inc. dealer for a period of one year from date of purchase. II. Procedure- If the Amplifier v10 should require service under warranty, take it with proof of purchase date, with its carton and packing material, to a Coda Technologies, Inc. -
Page 16: Warranty Registration
WARRANTY REGISTRATION Fill in and retain this copy of the warranty registration sheet for your records . MODEL DESIGNATION:__________________________________ SERIAL NUMBER:______________________________________ DATE OF PURCHASE: PLACE OF PURCHASE Dealer:___________________________________________ Address:__________________________________________ City:_____________________ State:____ Zip:__________ Phone:____________________________________________ PURCHASER Name:_____________________________________________ Address:__________________________________________ City:_____________________ State:____ Zip:__________ Phone:____________________________________________ NOTES:... -
Page 17: Address
WARRANTY REGISTRATION Please fill in and send this copy of the warranty registration sheet to Coda Technologies, Inc. Include copy of proof of purchase. MODEL DESIGNATION:__________________________________ SERIAL NUMBER:______________________________________ DATE OF PURCHASE: PLACE OF PURCHASE Dealer:___________________________________________ Address:__________________________________________ City:_____________________ State:____ Zip:__________ Phone:____________________________________________... - Page 18 ADDRESS Coda Technologies, Inc. 9941 Horn Road Suite A Sacramento, CA 95827 Phone: (916) 363-4653 Fax: (916) 363-4627...
