Keysight E8257D/67D
PSG Signal Generators and
E8663B Analog Signal Generator
Add Option UNW (Narrow Pulse Modulation 10 MHz-3.2 GHz)
Kit Part Numbers: E8257DK-UNW, E8267DK-UNW, and
E8663BK-UNW
NOTE: For the latest revision of this installation note, go to the
website for your instrument:
http://www.keysight.com/find/psg
or
http://keysight.com/find/e8663b
Installation Note

Advertisement

Table of Contents
loading

Related Manuals for Keysight E8267D

Summary of Contents for Keysight E8267D

  • Page 1 Keysight E8257D/67D PSG Signal Generators and E8663B Analog Signal Generator Add Option UNW (Narrow Pulse Modulation 10 MHz-3.2 GHz) Kit Part Numbers: E8257DK-UNW, E8267DK-UNW, and E8663BK-UNW NOTE: For the latest revision of this installation note, go to the website for your instrument: http://www.keysight.com/find/psg...
  • Page 2 The information contained in this document is subject to change without notice. Keysight Technologies makes no warranty of any kind with regard to this material, including but not limited to, the implied warranties of merchantability and fitness for a particular purpose.
  • Page 3 Estimated Verification Time: ....2.0 hours Introduction This upgrade kit adds Option UNW (Narrow Pulse Modulation) to the E8257D (Analog), E8267D (Vector) PSG Signal Generators and the E8663B Analog Signal Generator. Installation includes the following major steps, starting on page 1.

  • Page 4: Installation Kit Parts List

    Add Option UNW (Narrow Pulse Modulation 10 MHz-3.2 GHz) Kit Part Numbers: E8257DK-UNW, E8267DK-UNW, and E8663BK-UNW Installation Kit Parts List Item Quantity Description Part Number Installation Note E8251-90381 Screw M3x0.5 8mm-LG 0515-0372 W120 Semi-Rigid Cable E8251-20342 W76 Semi-Rigid Cable E8251-20590 A12 Pulse Modulator E8251-60112 Cable Retainer Base...

  • Page 5: Safety Considerations

    Add Option UNW (Narrow Pulse Modulation 10 MHz-3.2 GHz) Kit Part Numbers: E8257DK-UNW, E8267DK-UNW, and E8663BK-UNW Safety Considerations Before you disassemble the signal generator, turn the power switch off and unplug the power cord. Failure to unplug the signal generator can result in personal injury.

  • Page 6: Remove The Outer And Inner Signal Generator Covers

    Add Option UNW (Narrow Pulse Modulation 10 MHz-3.2 GHz) Kit Part Numbers: E8257DK-UNW, E8267DK-UNW, and E8663BK-UNW Remove the Outer and Inner Signal Generator Covers Remove the Outer Cover Refer to Figure 1. Disconnect the power cord. 2. Using a T-20 driver, loosen the two screws (1) and remove the strap handle (2). 3.
  • Page 7 Add Option UNW (Narrow Pulse Modulation 10 MHz-3.2 GHz) Kit Part Numbers: E8257DK-UNW, E8267DK-UNW, and E8663BK-UNW Figure 1 Outer Cover Removal Installation Note E8251-90381...
  • Page 8 Refer to Figure 1. Using a T-10 driver, remove the screws (1) from the inner-top cover (2). There are twelve screws for the E8257D & E8663B and eleven screws for the E8267D. 2. Remove the inner-top cover. Figure 2 Inner Top Cover Removal...

  • Page 9: Install The A12 Pulse Modulator Assembly (For Instruments With Option 1Eh)

    Add Option UNW (Narrow Pulse Modulation 10 MHz-3.2 GHz) Kit Part Numbers: E8257DK-UNW, E8267DK-UNW, and E8663BK-UNW Install the A12 Pulse Modulator Assembly (For instruments with Option 1EH) Refer to Figure 1. Remove the A38 Lowband Switch Filter assembly. 2. Using needle-nose pliers, remove the cable retainer base for W119 (E8251-20333, not shown). 3.
  • Page 10 Add Option UNW (Narrow Pulse Modulation 10 MHz-3.2 GHz) Kit Part Numbers: E8257DK-UNW, E8267DK-UNW, and E8663BK-UNW Figure 3 A12 Pulse Modulator Board W120 Installation Note E8251-90381...
  • Page 11 Add Option UNW (Narrow Pulse Modulation 10 MHz-3.2 GHz) Kit Part Numbers: E8257DK-UNW, E8267DK-UNW, and E8663BK-UNW Install the A12 Pulse Modulator Assembly (For instruments without Option 1EH) Refer to Figure 1. Remove A6 thru A8. 2. Using needle-nose pliers remove the cable retainer base for W37 (E8251-20225, not shown). 3.
  • Page 12 Add Option UNW (Narrow Pulse Modulation 10 MHz-3.2 GHz) Kit Part Numbers: E8257DK-UNW, E8267DK-UNW, and E8663BK-UNW Figure 4 A12 Pulse Modulator Board W120 Installation Note E8251-90381...

  • Page 13: Activate Option Unw

    Activate Option UNW 1. Turn the signal generator on and allow it to warm up for 5 minutes. 2. Connect the instrument to the LAN, using the instructions in the Keysight Signal Generator Programming Guide. 3. Load the IP address into the instrument, by pressing Utility > GPIB/RS-232/LAN > LAN Setup >...

  • Page 14: Verify Proper Installation Of Option Unw

    Add Option UNW (Narrow Pulse Modulation 10 MHz-3.2 GHz) Kit Part Numbers: E8257DK-UNW, E8267DK-UNW, and E8663BK-UNW cd "ALC RED PULSE DELAY", 13, 180 cd "ALC RED PULSE DELAY", 14, 180 cd "ALC RED PULSE DELAY", 15, 180 cc "ALC RED PULSE DELAY" ky 42718 f.
  • Page 15 This information is subject to change without notice. © Keysight Technologies 2004-2015 Edition 1, August 2015 E8251-90381 www.keysight.com...
