Electrical system

Basic electric items are:
HEADLIGHT:
low beam type: H7 (12 V-55 W).
high beam type: H1 (12 V-55 W).
Parking light: LED 13.5V 3.2W/0.1W.
Electrical controls on handlebars
turn indicators:
lamp type: 12 V-10 W.
Horn.
Stop light switches.
Battery, 12 V-10 Ah.
Generator 12V-360W.
ELECTRONIC REGULATOR, protected with a 30 A
fuse located to the side of the control unit
(11, Fig. 110).
Starter motor, 12 V-0.7 kW.
Tail and stop light: LEDs.
Number plate light
lamp type: C5W (12 V-5 W).
Note
For the bulb replacement refer to paragraph
"Replacing the bulbs".
Fuses
The electrical system components are protected by
eight fuses located in the fusebox. Only six fuses are
connected to the system, two are spares.
Refer to the table below to identify the circuits
protected by the various fuses and their ratings.
Key to the fusebox
Pos
El. item
1
Key ON
2
Parking lights, high/low
beams
3
El. item
4
Instrument panel
5
Injection
6
Ecu
7
Spare
8
Spare
Rat.
10 A
15 A
15 A
5 A
20 A
5 A
20 A
15 A
147
