Refrigerated Air Dryer
IDFB22E-11
IDFB22E-23
IDFB37E-23
IDFB55E-46
IDFB75E-46
Please read this manual prior of using the air dryer. Keep the manual readily available for
reference.
PRODUCT NAME
MODEL / Series
IDFB22E-11
IDFB22E-23
IDFB37E-23
IDFB55E-46
IDFB75E-46
© 2017 SMC CORPORATION All Rights Reserved.
IDX-OM-K021
Initial issue October, 2006
Rev.F:Feb,2017
- A,K,R,S,T,V
- A,K,R,T,V
- A,K,R,T,V
- A,L,R,T,V
- A,L,R,T,V
