Operation Manual
Please read this manual prior of using the air dryer. Keep the manual readily available for
reference.
Refrigerated Air Dryer
IDU22E-30
IDU37E-30
IDU55E-30
IDU75E-30
Initial issue August, 2006
rd
3
edition : Nobember,2010
Series
© 2010 SMC CORPORATION All Rights Reserved.
IDX-OM-K012-C
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for SMC Networks IDU22E-30
Summary of Contents for SMC Networks IDU22E-30
- Page 1 IDX-OM-K012-C Initial issue August, 2006 edition : Nobember,2010 Operation Manual Refrigerated Air Dryer Series IDU22E-30 IDU37E-30 IDU55E-30 IDU75E-30 Please read this manual prior of using the air dryer. Keep the manual readily available for reference. © 2010 SMC CORPORATION All Rights Reserved.
- Page 2 To Customers Thanks for purchasing SMC Refrigerated Air Dryer. This opertion manual must be read and understood throughoutly before handling. It provides all essential information for maximizing product operating efficiency, as well as, for safe and longer life span operation. For safety operation of SMC Refrigerated Air Dryer, read thoroughly and follow stated safety instructions, as well as regulation stated within ISO 4414 &...
-
Page 3: Table Of Contents
Air Dryer Table of Contents Table of Contents To Customers Chapter i Safety Instructions Warning: Before Using Air Dryer ................i - 1 i - 1 - 1 Meanings of signs: Caution, Warning, Danger ............i - 1 Danger Classifications / Position of Danger warning label ...... -
Page 4: Chapter I Safety Instructions
Air Dryer i Safety Instructions Safety Instructions Before use, read and comprehend important cautionary notification well on this operattion manual. i – 1 Warning: Before Useing Air Dryer In this chapter, the stated contents are especially about safety way to use the product. for customer. An Air Dryer is installed on the downstream of the air compressor to remove moisture. - Page 5 Air Dryer i Safety Instructions Warning Statements with the “Danger” sign explain about possibilities that can result in serious injury or loss of life if someone handle wrongly during operation or maintenance and did not follow the procedure to avoid danger. Caution Statements with the “Danger”...
-
Page 6: I - 2 Danger Classifications / Position Of Danger Warning Label
Air Dryer i Safety Instructions i – 2 Danger Classifications / Position of Danger Warning Label To protect operator’s sefety, we group danger into some types uniquely and attached labels indicating those types. Comfirm the contents of the danger types and positions of the labels before operation. Warning No one but professionals should operate an air dryer. -
Page 7: I - 2 - 2 Danger Of Electricity
Air Dryer i Safety Instructions i – 2 – 2 Danger of Electricity Inside of this product, there is power-supplying section with high voltage separated by the cover panel. Do not operate the product without the cover panel. No one but trained qualified person should operate or inspect in the power transmission sections. -
Page 8: I - 2 - 6 Positions Of Danger Warning Label
Air Dryer i Safety Instructions i – 2 – 6 Positions of Danger Warning Label Warning Read with caution and pay attention to the notations of danger warning labels. Do not remove or rub danger warning labels. Confirm the positions of danger warning labels. WARNING 警告... -
Page 9: I - 2 - 7 Danger Of Refrigerant
Air Dryer i Safety Instructions i – 2 – 7 Danger of Refrigerant Caution This product uses Fluorocarbon (HFC) as a refrigerant. This product is specified by “Class 1 Fluorocarbon Collection and Destruction Law in Japan.” It is strictly forbitten to emit Fluorocarbon to the atmosphere. Before you repair this product, you should collect the refrigerant with “Refrigerant collector.”... -
Page 10: Cautions About Usage
Air Dryer i Safety Instructions i – 2 – 8 Cautions about Usage Warning Read with caution and pay attention to the notations on danger warning labels. Do not remove or rub danger warning labels. Cimfirm the positions of danger warning labels. CAUTION 注... -
Page 11: I - 3 Disposal
Air Dryer i Safety Instructions i – 3 Disposal refrigerat oil enclosed in the When you dispose of the product, you shoud collect the refrigerant and the refrigerant circuit. Caurion A sort of Fluorocarbon (HFC) is used for this product as refrigerant. This product is specified by “Class1 Fluorocarbon Collection Destruction Law in Japan.”... -
Page 12: I - 4 Limited Warranty And Disclaimer / Compliance Requirements
Air Dryer i Safety Instructions i – 4 Limited warranty and Disclaimer / Compliance Requirements The product used subject to the following “Limited warranty and Disclaimer“ and “Compliance Requirements. Read and accept them before using the product. Limited warranty and Disclaimer The warranty period of the product is 1 year in service or 1.5 years after the product is delivered. -
Page 13: Chapter 1 Parts Name And Functions
Air Dryer 1 Name and Functions Parts Parts Name and Functions 1 - 1 Parts Name and Functions IDU22E,37E Compressed Air (OUT) Switch with Lamp Compressed Air (IN) (ON/OFF Switch) The lamp is continuously ON Right Side Ventilation Grille during normal operation. Use it (Outlet) for ON/OFF operations. - Page 14 Air Dryer 1 Name and Functions Parts Front Fixing Screw for Front Panel Another one is on the right side. Rubber Grommet Power cord outlet Left Side Ventilation Grille (Inlet) Breathe in cooling air from this grill. Do not bung up with wall and so on. 1 - 2...
- Page 15 Air Dryer 1 Name and Functions Parts IDU55E,75E Compressed Air (OUT) Switch with Lamp Compressed Air (IN) (ON/OFF Switch) The lamp is continuously ON Right Side Ventilation Grille during normal operation. Use it (Outlet) for ON/OFF operations. Waste heat will be exhausted as hot air by the fan motor.
- Page 16 Air Dryer 1 Name and Functions Parts Front Fixing Screw for Front Panel Another one is on the right side. Left Side Ventilation Grille (Inlet) Rubber Grommet Breathe in cooling air from this grill. Power cord outlet Do not bung up with wall and so on. 1 - 4...
-
Page 17: Chapter 2 Transportation / Installation
Air Dryer 2 Transportation / Installation Transportation / Installation Warning Use the product in the right way. During Installation, operation, maintenance, and check, you should be careful in keeping the safety of human body. Caution Transportation, installation, and maintenance including dangerous work must be done by a personnel who has enough knowledge and experience about the product and the sysytem. -
Page 18: Installation
Air Dryer 2 Transportation / Installation 2 - 2 Installation 2 - 2 - 1 Location The product should not be used or stored in the circumstances as follows. Those circumstances will cause not only malfunction but also failures. • •... -
Page 19: Drain Tube
Air Dryer 2 Transportation / Installation • Be careful not to let the vibration of the air compressor transmit. • If the temperature of compressed air on the inlet side is higher than 80 C, place an aftercooler after the air compressor. -
Page 20: Cautions About Reinstallation
Air Dryer 2 Transportation / Installation Specification of power cable Prepare following power cable. Power cable: 1.25mm (16AWG), External diameter: about 8 ~ 12mm IDU22E 75E-30 (3 phase power supply) …4 cores (including grounding) Additional length of about 0.2m is needed to wire inside of the product. Length of the power cable The length of the power cable should extend less than 30m from the product. -
Page 21: Chapter 3 Operation / Shutdown
Air Dryer 3 Operation / Shutdown Operation / Shutdown Caution No one but someone who has enough knowledge and experience about the product and incidental devices should operate or shut down the product. 3 - 1 Check points before operation Before a trial running, check following points. -
Page 22: Shutdown
Air Dryer 3 Operation / Shutdown Caution Avoid frequent ON / OFF operation, which can cause troubles. The auto drain used for the product has a structre that closes the valve with air pressure higher than 0.15MPa. Therefore, until the pressure increase, air will be emitted form the drain outlet at the begining of opening the IN side valve. -
Page 23: Chapter 4 Maintenance
Air Dryer 4 Maintenance Maintenance 4 - 1 Daily Inspection Check following points during usual operations. If you find some problems, immediately stop the operation and refer to “Chapter 5 Troubleshooting” as soon as possible. • There is no air leakage •... - Page 24 Air Dryer 4 Maintenance Warning Maintenance of the air dryer should only be carried out by someone with sufficient knowledge and experience of air dryers and related equipment. Before carrying out maintenance, the important warnings in this manual must be thoroughly read and understood.
- Page 25 Air Dryer 4 Maintenance Ball valve Ball valve Bleed valve Bleed valve Auto drain strainer Lock button Drain tube Turn to 45° release bush right or left) Drrain tube Float assembly ・ Close the ball valve. ・ Open the bleed valve by turning it anticlockwise to release air left in the product.
-
Page 26: Chapter 5 Troubleshooting
Air Dryer 5 Troubleshooting Troubleshooting 5 - 1 Cause and countermeasure of errors Should any problem occur, inspect the following table, and if the problem cannot be solved, shut off the power supply and then contact one of our sales offices for further instructions. Problem Probable Causes Remedy... - Page 27 Air Dryer 5 Troubleshooting Installation place is poorly Improve the ventilation system to lower the ambient Evaporation ventilated. Ambient temperature temperature. thermometer points the is too high. value exceeding a green range under the The ventilation grilles are Install the air dryer more than 40cm away from the condition where no hot obstructed by wall or clogged wall.
-
Page 28: How To Reset The Thermal Relay And High Pressure Switch
Air Dryer 5 Troubleshooting 5 - 2 How to reset the thermal relay and high pressure switch If light goes off during operation and refrigerating compressor stops, the thermal relay or high pressure switch (for only the IDU55E and IDU75E) to protect the refrigerating compressor starts operating and needs to be reset manually. -
Page 29: Specifications
Air Dryer 6 References References 6 - 1 Specifications Model IDU22E-30 IDU37E-30 IDU55E-30 IDU75E-30 Specification 50Hz Air Flow Rate /min (ANR)(Note 1) 60Hz 12.5 Operating Pressure Inlet Air Temperature Ambient Temperature Pressurized Dew Point Compressed Air Working Fluid 5 80 Inlet Air Temperature 0.15 1.0... - Page 30 Air Dryer 6 References 6 - 2 External Dimentions IDU22E 75E AIR OUTLET AIR INLET PORT SIZE PORT SIZE SWITCH EVAPORATION WITH LAMP THERMOMETER VENTILATION VENTILATION DRAFT AIR OUTLET BALL VALVE AUTO DRAIN DRAIN TUBE TERMINAL (O.D.10, BLOCK LENGTH:1m) L±2 N±1 POWER SUPPLY ENTRY φ...
-
Page 31: Electrical Circuit
Air Dryer 6 References 6 - 3 Electrical Circuit IDU22E, 37E-30 (3 phase AC200V) IDU55E-30 (3 phase AC200V) PRS2 THP1 THP2 θ θ θ θ θ PSR1 IDU75E-30 (3 phase AC200V) PRS2 SYMBOL DESCRIPTION Compressor Motor FM1,FM2 Fan Motor For Condensor THP2 THP1 MC1,MC2... -
Page 32: Compressed Air And Refrigerant Circuit / Operation Principles
Air Dryer 6 References 6 - 4 Compressed Air and Refrigerant Circuit / Operation Principles Compressed Air Circuit Hot and humid air which has come in an air dryer firstly enters air-cooled aftercooler part, and is cooled. Then, it enters reheating part and exchanges its heat with dehumidified cold air and becomes cooler.
