Operation Manual
IDFB22E-11
IDFB22E-23
IDFB37E-23
IDFB55E-46
IDFB75E-46
Please read this manual prior of using the air dryer. Keep the manual readily available for
reference.
PRODUCT NAME
Refrigerated Air Dryer
MODEL / Series
IDFB22E-11 - K,R,T,V
IDFB22E-23 - K,R,T,V
IDFB37E-23 - K,R,T,V
IDFB55E-46 - L,R,T,V
IDFB75E-46 - L,R,T,V
Initial issue October, 2006
nd
2
edition January, 2011
© 2011 SMC CORPORATION All Rights Reserved.
IDX-OM-K021-B
