Assembly.
1. Turn the radiator upside-down and install wheel support into the first
and the last element of the radiator sections' battery .
2. Fix wheel supports by means of supplied U-shaped clamps and thumb
nuts. To do so, you need to pass U-shaped clamp under the section-to-
section connecting element of the battery, then you must connect the
clamp with the wheel support and tighten the thumb nut as far as it will
go.
Turn the unit into the right, vertical position. Make sure that the unit
stands evenly on the surface and doesn't wobble; the wheels are fixed
evenly.
CAUTION!
1. The unit must be located away from flammable and/or easily
deformed objects (for example: curtains, plastic partitions and
structures, etc).
2. Prevent damage of the radiator's surface by sharp objects since
scratches on a painted coating can result in rusting.
3. Try to handle the operating unit carefully and do not touch anything
but unit's knobs and its switches. Unit's sections can heat up to a high
temperature!
4. Do not dry either wet clothes on the unit's surface or any other things
since it can result in malfunction of the thermostat and failure of the
unit.
It is forbidden to cover the unit during the operation! It can result in an
accident.
Technical data.
Rated
Model Power (W)
current, A
TOR 21.1206 BTX I 1200 5,45
TOR 21.1507 BTX I 1500 6,8
TOR 21.2009 BTX I 2000 9,1
TOR 21.2512 BTX I 2500 11,4
TOR 21.1206 HBX I 1200 5,45
TOR 21.1507 HBX I 1500 6,8
TOR 21.2009 HBX I 2000 9,1
TOR 21.2512 HBX I 2500 11,4
TOR 31.1706 RRX 1700 7,7
TOR 31.2007 RRX 2000 9,1
TOR 31.2509 RRX 2500 11,4
TOR 31.3012 RRX 3000 13,6
TOR 31.1706 EHX I 1700 7,7
TOR 31.2007 EHX I 2000 9,1
TOR 31.2509 EHX I 2500 11,4
TOR 31.3012 EHX I 3000 13,6
TOR 21.1006 SLX I 1000 4,55
TOR 21.1507 SLX I 1500 6,8
TOR 21.1809 SLX I 1800 8,2
TOR 21.2212 SLX I 2200 10,0
Noise level, dB (for models TOR 31... RRX, TOR 31... EHX I): 58
Rated current, V/Hz: 220/50
The manufacturer reserves the right to change the set-list of the device (including
liquid and powder components) for different supplies without prior notice. The
changes either in no way influence the basic technical parameters of the device or
may improve them, and also not violate the legislation or quality standards of the
countries of manufacture, transit and selling.
The changes in the set-list may result in changing of the weight and dimensions of the
device, but not more than by +\- 5-20% (depending on the product category)
ENGLISH
~Net weight (kg)*
Fins Dimensions (mm)
315x280x625 6,5
6
353x275x625 7,2
7
429x275x625 8,7
9
543x275x625 11,1
12
315x280x625 6,5
6
353x275x625 7,2
7
429x275x625 8,7
9
543x275x625 11,1
12
311x280x625 7,3
6
349x275x625 8,1
7
425x275x625 10,2
9
539x275x625 12,4
12
323x280x625 7,7
6
361x275x625 8,4
7
437x275x625 10,2
9
551x275x625 11,8
12
277x280x625 5,7
6
315x275x625 6,4
7
391x275x625 7,8
9
505x275x625 10,1
12
