Table of Contents A. Features………………………………………………………………. 1 B. Specifications………………………………………………………….2-3 C. Notices……………………………………………….…………………4 D. What’s in the Box/Tools Required……………………………………5 D. Structure of Product…………………………………………………..6-7 E. Dimensions …………………………………………………..………. 8 F. Installation Guide ………………………………………………..….. 9-11 ...
A. Features 1. Suitable for all personal vehicles i.e taxi, bus, trucks etc. 2. Small size, easy installation and dismount, it does not affect the driver's line of sight. 3. Insert the SD card and power on to start recording without additional operating.
Page 5
Recording Format Specific format for software player. Microphone Built-in high sensitivity single microphone for automatic voice adjustment. Time Setup Auto-calibrated by GPS signals. If GPS is not available, the built-in clock will be used. G-Sensor Internal 3D G-Sensor. Out Device (a) TV-Out (1 Vp-p composite video output, 75 ohms), Video Output format: NTSC / PAL alternative.
C. Notices (a) The GPS positioning speed will be influenced by solar film of the front windshield, weather or other environment factors. (b) Starting and closing time of infrared will be subject to light intensity, the installation location, front windshield and other factors. (c) Day and night mode has a delay for about 30 seconds.
D. What’s in the Box Standard: Camera System Hardwire Kit (Battery Backup/Charge Guard) SD card locking bracket (with screws and tool) Cigarette lighter adapter (If requested) Suction cup bracket with cups, Bracket holder and Adhesive mount option Optional: (a) Micro SD card (16GB/32GB/64GB/128GB) E.
F. Structure of Product 1. Force Recording Button Recording Indicator 2. Recording Indicator 3. GPS Indicator 4. IVR LEDS 5. Light Sensor 6. Backward Facing Lens Structure of Product (Continued on next page)
Page 9
1. Forward Facing Lens 4. DC5V(1) Power cable Port (Cable Locked into place) 2. Video Out 5. Micro SD Slot 3. N/A Unused *Please do not plug the power in both micro-USB terminals. The system can be damaged! ...
H. Installation Guide *NOTE: If you have any issues or questions in regards to installation don’t hesitate to contact Support at support@safetytrack.net or Call us at: 888-286-9829 and press 6 for Support 1. Make the bracket face upward. 2. Assemble the suction cups. 3.
Page 12
7. Wire Schematic: White: Power Black: Ground Step 1: Hardwire to vehicle according to schematic above. Attach power to either Switch (ignition) or Constant. Depending on how you want the camera to operate. Step 2: Use electrical tape to conceal exposed wires once connected.
Page 13
8. When the power is successfully connected, the IVR LED will be lit for 10 seconds. 9. Force Record Button light is also on when power is successfully connected. 10. Green light is GPS. This light will flash when GPS is positioning, Light will be on and solid when GPS is ready.
