Table of Contents A. Features..................1 B. Specifications ................2 C. Structure of Product..............5 D. Dimensions ................. 5 E. Installation Guide ..............6 F. Functions of Remote Controller ..........7 G. Start / Stop Recording.............10 H.
A. Features 1. Suitable for all personal vehicles i.e taxi, bus, trucks etc. 2. Small size, easy installation and dismount, it does not affect the driver's line of sight. 3. Insert the SD card and power on to start recording without additional operating.
Page 5
Specific format for software player. Microphone Build-in high sensitivity of single microphone for automatic voice adjustment. Time Setup Auto-calibrating by GPS signals. If GPS is not available, the built-in clock will be used. G-Sensor Internal 3D G-Sensor. Out Device (a) TV-Out (1 Vp-p composite video output, 75 ohms), Video Output format: NTSC / PAL alternative.
Page 6
(c) Day and night mode has a delay for about 30 seconds. Night mode will be priority when powered on. (d) Memory card formatted by using the playback software. This may be done for you already. Important Notice (a) The current consumption of the system over standard USB hole (output 500mA).
Page 7
Accessories Standard: Camera System Hardwire Kit (Battery Backup/Charge Guard) Suction cup bracket with cups, Bracket holder and Adhesive mount option Optional: (a) Micro SD card (16GB/32GB/64GB/128GB) Add On: 3G/4G Dongle for Live Streaming...
Structure of Product 1. Force Recording Button Recording Indicator 2. Recording Indicator 3. GPS Indicator 4. IVR LEDS 5. Light Sensor 6. Backward Facing Lens Structure of Product (Continued on next page)
Page 9
1. Forward Facing Lens 4. DC5V(1) Power cable Port 2. Video Out 5. Micro SD 3. DC5V(2) 3G/4G Dongle Port ※ Please do not plug the power in both micro-USB terminals. The system can be damaged!
E. Installation Guide Make the bracket face upward. Assemble the suction cups. Set up the device in the proper position. Adjust the viewing angle. Installation Guide continued on next page…...
Page 12
Plug 3G/4G Dongle into DC5V (1) Socket. Plug the Power Cable into DC5V (2) Socket. Wire Schematic: Yellow: Power Blue: Ignition Signal Black: Ground Step 1: Hardwire to vehicle according to schematic above. (extend wire if needed) Step 2: Use electrical tape to conceal exposed wires once connected.
Page 13
Force Record Button light is also on when power is successfully connected. Green light is GPS. This light will flash when GPS is positioning, Light will be on and solid when GPS is ready. Red light is recording. Flashing signifies recording, fast flashing occurs in emergency mode or force record.
