Introduction This user guide will walk you through how to use and operate the Desktop Viewer Software for your UCIT 2 Camera System. Note: This is a Windows Application. Table of Contents A. Downloading the Desktop Software…………………………………1 B. Removing and Inserting the Micro SD Card into Camera System…..1-2 C.
2. Hover over the support tab at the top and select Camera Installation and User Manuals. 3. One of the first items listed is the UCIT 2 Channel System. You will see Desktop SD Card Player. Click this link and you will start to download the zip file for the software.
Insertion: To replace the micro SD Card, push the SD Card into the slot until you hear a “click”. Let go as you will hear a second “click” telling you that card is in position. Install the tamper proof locking bracket included with your camera. C.
D. Launching the Viewer Software Viewer Layout: After Clicking the software Icon you will see the screen above. 1- Close Application 11- Vehicle Speed 2- Minimize Application 12- Volume Control 3- Playback 13- Playback Control 4- Calendar 14- Rear View Camera 5- Backup 15- Forward View Camera 6- Snapshot...
E. Playback Play back is of course used to playback the video recorded on to the SD Card. Once you select Playback, Icon number 3 in section D, you will enter the playback window. Step 1: Select “Removable Storage” and choose the proper drive your SD Card is in.
Page 7
Depending on the configuration of your SD Card. You may see up to 3 different types of events. Two of them will not be overwritten (Push Button and G-Sensor). 1. Record Start - This is general continuous recorded video. This is captured when the Camera System receives power.
F. Backup Here you can save recorded files to your PC. This is done by clicking on Backup, number 5 in section D. The Backup window will appear like the one below. Step 1: Assuming you want to backup a video(s) from your Micro SD Card to your PC, you will just need to select the drive your Micro SD is in under “Removable Storage”.
NOTE: If you backup by original format of Micro SD Card (*sd), the file recorded with location of GPS, speed and G-Sensor. (Carbox Player is used to playback these type of backups.) If backup by the format of (*.avi), the file recorded date, video and audio. Step 4: Backup Path: Select your backup destination (e.g.: C:\blackbox) Step 5: Select “Backup”...
Page 10
1- Video Quality: Adjust the video quality to High, Normal or Low. High is of course recommended for the best video quality. You can adjust to Normal or Low to have more space on your Micro SD Card. The Higher the quality of video the more storage space it uses.
Very Low, Low, Normal, High, Very High. Set the settings according to the night conditions. Example: Set to Very High if you want the IR’s to provide light to the lens at the slightest sign of darkness. 11- Audio Recording: Choose On or Off to enable or disable audio recording. 12- Daylight Savings Time: Choose On or Off to enable or disable Daylight Savings Time.
/Snapshot folder. File type: BMP If there are any questions about this user guide please contact your sales rep or our support team. Thank you very much. Safety Track - 249 Main St. Belleville MI 48198 - 734-699-7633...
