Other Modes - Endress+Hauser FMX 570 Operating Instructions Manual

Silometer FMX 570
5.3

Other modes

This mode (default) is selected when the Silometer FMX 570 transmitter is to revert to
measurement of level after being used for volume measurement.
• If the volume is proportional to level, e.g. standing cylinder, a volume
measurement is obtained by entering the »empty« and »full« volumes at
V0H1 and V0H2 respectively, see Section 4.3.
Step Matrix Entry
1 V2H0 0
2 - »E«
Use this option if you wish to enter an entirely new manual characteristic without a
transmitter reset. All values in the linearization table are cancelled and can be entered
anew. The function does not affect the horizontal cylinder characteristic or any factory
characteristic stored in the transmitter.
Step Matrix Entry
1 V2H0 4
2 - »E«
Significance
Select linear characteristic
Press »E« to activate linearization
Significance
Cancel all previous entries in the manual linearization table
Press E to register
Chapter 5: Linearization
Linear
V2H0 = 0
Cancel current setting
V2H0 = 4
29
