- Page 1 Ceiling speaker + Signal LED CSE55 AUDAC PROFESSIONAL AUDIO EQUIPMENT Ceiling Speaker + Signal LED CSE55 User Manual & Installation Guide...
- Page 2 A U D A C P R O F E S S I O N A L A U D I O E Q U I P M E N T User Manual & Installation Guide AUDAC http://www.audac.eu info@audac.eu...
- Page 3 Introduction The CSE55 is a single cone loudspeaker with an integrated red signal light with 6 integrated high intensity LEDS (24 V), which emit a visual evacuation signal. The ceiling speaker is specially designed to deliver high- quality speech reproduction, but can also be used for background music. It is standard fitted with a 100 Volt line transformer with connections for different powers.
- Page 4 Installation Make a hole with a diameter of 165mm. This is very easy when you use the carton that is inside of the box. Take the grille from the speaker and put the speaker in the hole. Tighten the screws of the speaker so that the speaker will be clasped on the ceiling or wall.
-
Page 5: Technical Specifications
Technical specifications Speaker Nominal Speaker Power: 15 W Sound pressure: 1W / 1m 90 dB Maximum SPL: 100.8 dB Impedance Loudspeaker: 8 Ohm Impedance line transformer: 1.600 Ohm/ 6 W 3.300 Ohm/ 3 W 6.600 Ohm/1.5 W Frequency range: 70 - 14.000 Hz Outside diameter: 200 mm Installation depth: 70 mm Cut-out measurement: 165 mm...
