Summary of Contents for AUDAC CELO2D
- Page 1 CELO2 User & Installation Manual...
- Page 3 Introduction 2” High-end slim ceiling speaker The CELO2 is the 2” version of AUDAC’s CELO High-end slim ceiling speaker series with an RMS power of 10 Watt and Maximum power of 20 Watt, consisting of a 2” full range aluminum cone driver.
- Page 4 Precautions READ FOLLOWING INSTRUCTIONS FOR YOUR OWN SAFETY • ALWAYS KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE. NEVER THROW THEM AWAY • ALWAYS HANDLE THIS UNIT WITH CARE • CLEAN ONLY WITH DRY CLOTH • HEED ALL WARNINGS AND FOLLOW ALL INSTRUCTIONS •...
- Page 5 CAUTION • USE CABLES OF THE RIGHT GAUGE TO CONNECT THE LOUDSPEAKER • USE CABLES WITH CLEAR COLOUR CODING INDICATING THE POLARITY AND MAINTAIN THE SAME POLARITY THROUGHOUT THE WHOLE SYSTEM. • ONLY USE THE CORRECT AMPLIFIER OUTPUT VOLTAGE AND IMPEDANCE. EXCEEDING THESE LIMITS COULD CAUSE FIRE OR OTHER FAILURES.
- Page 6 Installing the CELO Introduction The CELO speakers feature a quick-fixing mechanism, which allows quick and easy installation of the loudspeakers in only a few minutes. The installation of the CELO speakers requires a minimum amount of installation skills. Before the loudspeaker is installed, the location whereto it will be mounted should be carefully checked to make sure the surface can support the weight of the speaker and no lines for water, gas, electricity or other supplies are crossing this point.
- Page 7 4) Connect the loudspeaker connection cable to the gold plated spring clamp connectors. Press the button of the corresponding terminal down and insert the connection cable. After releasing the button, the cable is connected to the loudspeaker. The Red terminal indicates positive (+) pole and the Black terminal indicates the negative (-) pole.
- Page 8 Additional Information Technical specifications RMS Power 10 Watt Max. Power 20 Watt Nominal impedance 8 Ohm Sensitivity (1W / 1m) 83 dB Sound pressure (Max W / 1m) 93 dB Frequency response (±3 dB) 120 Hz - 20 kHz Drivers 2”...
