- Page 1 Installation manual CELOxI audac.eu...
-
Page 2: Table Of Contents
This manual is put together with much care, and is as complete as could be on the publication date. However, updates on the specifications, functionality or software may have occurred since publication. To obtain the latest version of both manual and software, please visit the Audac website @ audac.eu. REV-1.0... -
Page 3: Introduction
Introduction High-end slim ceiling speaker Due to CELO High-end slim ceiling speaker series’ slim grill design with a very thin border of only 1 mm and a limited grill depth which extrudes from the ceiling surface by only 3.2 mm, these speakers will become nearly invisible when mounted. -
Page 4: Precautions
Precautions READ FOLLOWING INSTRUCTIONS FOR YOUR OWN SAFETY ALWAYS KEEP THESE INSTRUCTIONS. NEVER THROW THEM AWAY ALWAYS HANDLE THIS UNIT WITH CARE HEED ALL WARNINGS FOLLOW ALL INSTRUCTIONS NEVER EXPOSE THIS EQUIPMENT TO RAIN, MOISTURE, ANY DRIPPING OR SPLASHING LIQUID. AND NEVER PLACE AN OBJECT FILLED WITH LIQUID ON TOP OF THIS DEVICE NO NAKED FLAME SOURCES, SUCH AS LIGHTED CANDLES, SHOULD BE PLACED ON THE APPARATUS DO NOT PLACE THIS UNIT IN AN ENCLOSED ENVIRONMENT SUCH AS A BOOKSHELF OR CLOSET. - Page 5 CAUTION USE CABLES OF THE RIGHT GAUGE TO CONNECT THE LOUDSPEAKER USE CABLES WITH CLEAR COLOUR CODING INDICATING THE POLARITY AND MAINTAIN THE SAME POLARITY THROUGHOUT THE WHOLE SYSTEM. ONLY USE THE CORRECT AMPLIFIER OUTPUT VOLTAGE AND IMPEDANCE. EXCEEDING THESE LIMITS COULD CAUSE FIRE OR OTHER FAILURES.
-
Page 6: Installing The Celoxi
Chapter 1 Installing the CELOxI Introduction The CELO speakers feature a quick-fixing mechanism, which allows quick and easy installation of the loudspeakers in only a few minutes. The installation of the CELO speakers requires a minimum amount of installation skills. Before the loudspeaker is installed, the location whereto it will be mounted should be carefully checked to make sure the surface can support the weight of the speaker and no lines for water, gas, electricity or other supplies are crossing this point. - Page 7 4) Connect the loudspeaker connection cable to the gold plated spring clamp connectors. Press the button of the corresponding terminal down and insert the connection cable. After releasing the button, the cable is connected to the loudspeaker. The Red terminal indicates positive (+) pole and the Black terminal indicates the negative (-) pole.
-
Page 8: Technical Specifications
Technical specifications CELO2I CELO5I Peak Power handling 200W Program Power handling 100W RMS/AES power handling 8 Ω (CELO2I) Nominal impedance 8 Ω 16 Ω (CELO2DI) Sensitivity 1W/1m 83 dB 85 dB Sound pressure Max W/1m 93 dB 102 dB Frequency response - 3dB 120 Hz - 20kHz 70 Hz - 20kHz Speaker type... - Page 9 Technical specifications CELO6I CELO8I Peak Power handling 240W 320W Program Power handling 120W 160W RMS/AES power handling Nominal impedance 8 Ω 8 Ω Sensitivity 1W/1m 88 dB 89 dB Sound pressure Max W/1m 106 dB 108 dB Frequency response - 3dB 55 Hz - 20kHz 46 Hz - 20kHz Speaker type...
- Page 10 CELOxI - Installation manual...
- Page 11 CELOxI - Installation manual...
- Page 12 Discover more on audac.eu...
