K40 RL100 Owner's Manual

Hide thumbs Also See for RL100:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Owner's Manual
RL100 OWNERS MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RL100 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for K40 RL100

Summary of Contents for K40 RL100

  • Page 1 RL100 OWNERS MANUAL...
  • Page 2 If you get a speeding ticket within one year of purchase, we’ll reimburse you for the full cost of the ticket.* Guaranteed performance If your K40 radar detection system does not outperform any other radar detector you’ve owned, return it within 30 days for a full product credit.

  • Page 3: Mounting And Powering The Rl100

    Do not mount the unit behind wipers or any metal obstructions. 3. Slide the RL100 unit itself on to the bracket to complete the mounting. 4. Level the radar detector, if necessary, by carefully bending the Windshield Mounting Bracket.

  • Page 4: Quick Start

    Quick Start (using factory default settings) Once your K40 RL100 has been mounted and had the power connected, you may begin using immediately by following these steps: 1. Switch on the RL100 – Turn the Power On/Volume Control Wheel on the side of the unit.

  • Page 5: Receiving Alerts

    The K40 RL100 provides a combination of audio and visual alerts to warn you when radar and laser signals are detected. Radar Alert Sequence The RL100 detects X, K and KA-Band radar signals. When a signal is identified: A voice alerts which band was detected. (This assumes the •...

  • Page 6: Laser Alert Sequence

    Audio Alert: Voice announces “Laser” followed by unique tone. Alerts from non-police signals Your RL100 is sensitive enough to detect signals generated by non-police equipment, such as bank security systems. To learn how to deal with these signals, please read about FILTER...

  • Page 7: Special Features/Functions

    Special Features/Functions Mute Sounds Using the MUTE button, the RL100 provides you two ways to mute audio alerts (both voice and tones) for either 15 seconds or 2 minutes: OPTION 1: Silence all audio after an alert has sounded. •...
  • Page 8 Alrt Loc Display shows and voice announces “Marked • to Alert” After marking the location, in the future the RL100 will • alert you: When you arrive… You will hear a… …within 1500 foot radius of ..."Bing Bong"...

  • Page 9: Reference Guide

    Power Input Jack – Insert small end of power cord here Power On/Volume Control Wheel – Turn on the RL100 unit and adjusts volume of voice/tones MENU/DIM Button – Press and release to change display brightness from bright (factory default) to dim or dark, or press...
  • Page 10 Speaker – Alerts delivered via voice and tones FILTER Button – Press and release to select level of alert sensitivity (page XX), or enter “Speed Monitor” func- tion by pressing and holding for 3 seconds (page XX) MARK Button – Choose two levels of alert at specific locations you identify and “mark”...

  • Page 11: Filter Operation

    Filter Operation (i.e. signal sensitivity) The Filter system on the RL100 offers you 3 levels of sensitivity settings to accommodate various driving situations. To change the level at any time, press and release FILTER button. Level / Mode Sensitivity Recommended Use 1.

  • Page 12: Speed Monitor

    The Speed Monitor can be set to any speed between 40-100 mph in 5 mph increments. When the preset speed is exceeded: The RL100 emits a “Slow Down” voice alert accompanied • SlowDown by the visual display The alerts will continue until the vehicle’s speed is reduced...

  • Page 13: Menu / Customizable Settings

    Menu / Customizable Settings The RL100 comes with factory default settings on certain features that we’ve learned are desirable for the majority of our customers. However, we provide you with the option of changing the settings based on your preferences.
  • Page 14 Enables the detection of KA-Band radar. Laser Enables the detection of laser. Factory Reset RESET! Returns the K40 to its original factory defaults for all settings. To save your settings and exit: Press and hold MENU button for 3 seconds. (or do •...

  • Page 15: Troubleshooting Guide

    800.323.6768 Warranty K40 Electronics offers a one-year “repair or replace” warranty if your RL100 fails to work properly. To ensure you are covered by our warranty please register your product online today by visiting K40.com/register...
  • Page 16 Product subject to one or more of the following patents: Learn more at k40.com ©K40 Electronics...
  • Page 17 (2) this device must accept any interference received, including interference that may cause undesired operation. In addition, any changes or modifications to this product, which are not expressly approved by K40 Electronics in wiring, could void the user’s authority to operate this product.
  • Page 19 Elgin, IL 60123 800.323.6768 Learn more at K40.com...
