installation guide
isodrive 1600
Revision V1
HOME APPLIANCES
www.schweigen.com.au

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Isodrive 1600 and is the answer not in the manual?

Questions and answers

Summary of Contents for Schweigen Isodrive 1600

  • Page 1 1600 Revision V1 HOME APPLIANCES www.schweigen.com.au...
  • Page 2: Table Of Contents

    Wall installation _____________________________________________________________________________________________ 10 Flat Roof installation ________________________________________________________________________________________ 12 through Wall installation for isodrive 1600 ___________________________________________________ 13 Fan unit shutter assembly for isodrive 1600 _________________________________________________ 14 twin Motor installation ____________________________________________________________________ 15 twin Motor installation example ____________________________________________________________ 16 twin 200mm outlet installation example ____________________________________________________ 17 5.
  • Page 3: Welcome

    We trust that you will enjoy your new schweigen isodrive system. Please always retain your proof of purchase to aid in any warranty queries.
  • Page 4: Your Safety

    Children should be supervised to ensure that they do not play with the appliance, it is not a toy. do not install isodrive motor to a non-schweigen and/or non-silent rangehood. if you fail to do so, your warranty will be voided.
  • Page 5: Motor Features

    Fan module and dual foil flexi-duct are acoustically matched. Use of semi-rigid or rigid ducting will result in increased noise and may void warranty. See installation instruction notes ‘Why flexi-duct’. recommended Installation Distance isodrive 1600 motor, recommended 5 to 6 metres of flexi ducting. Page 5...
  • Page 6: Minimum Mounting Height

    Any installation problem must be reported to schweigen. Call outs relating to incorrect installation will result in a service fee direct to the customer. schweigen takes no responsibility for problems caused by faulty installation, this may void warranty.
  • Page 7: Description

    3. description Isodrive Motor Included in the box: 1. isodrive 1600 motor (405W x 220H mm approx.) approx. 3 metre, 10amp cable and standard male plug 2. Fire resistant 150mm (160mm od ) PVC riser pipe note: Cable cut-out at the bottom end only 3.
  • Page 8: Installation

    4. installation 1600 motor Weather shield attachment (only for 1600 motor) 50mm Pipe protrusion above dektite Power Cord 150mm PVC Pipe (locking holes fan end) dektite Fix fan module using side locking screw Fit side supports to locate pipe strap to supports Bell-mouth adaptor Connect to noTE: Prevent any cord bunching...
  • Page 9: Roof Installation

    Please be aware that the 1600 motor is capable of expelling air at 1600m /hr. For more information on environmental noise limit and conditions please contact your local Council. We have a list of recommended installers available on the schweigen website. Page 9...
  • Page 10: Wall Installation

    *Optional wall mounting flange (P40113MF) is available tightened engaging in holes from Schweigen, please contact 1300 829 066. Figure 2 Wall Installation IMPoranT For more flexible ducting instructions, refer page 22. Shutter assembly for 1600 motor is not shown in the diagram.
  • Page 11 4. installation IMPorTanT: When mounting pipe fan locking holes to be in outside end of pipe (fan end) Min 150mm long 150mm PVC pipe Weather shield locking holes at 10 upper most and 4 o’clock Bell-mouth adaptor locking screw Flexible 200mm ducting Min 50mm 1600 motor...
  • Page 12: Flat Roof Installation

    *Optional wall mounting flange (P40113MF) is available from Schweigen, please contact 1300 829 066. Figure 4 IMPoranT For more flexible ducting instructions, refer page 22. Shutter assembly for 1600 motor is not shown in the diagram.
  • Page 13: Through Wall Installation For Isodrive 1600

    4. installation Installation Through Wall for Isodrive 1600 due to the weight and to create stability for the isodrive 1600 motor, it is require to use a hanging bracket. Warranty will be void if a hanging bracket is not used.
  • Page 14: Fan Unit Shutter Assembly For Isodrive 1600

    4. installation Fan Unit Shutter assembly for Isodrive 1600 1. Assemble by fitting shutter assembly into fan inlet shroud moulding, ensuring that attaching screws align with holes. Alignment can be checked visually by folding in shutter flaps. 2. Fully tighten both screws and re-check fitment into holes.
  • Page 15: Twin Motor Installation

    4. installation Twin Motor Installation (suitable for the Cl Range) Where two motors are to be used, follow the method below. Each motor should have a separate flue pipe. Refer figure 9. The two motors can be wired by an electrician. 1600 motor Z: Minimum distance between the two fans is 600mm.
  • Page 16: Twin Motor Installation Example

    4. installation Twin Motor Installation Example Where two motors are to be used and there is only one 200mm outlet, follow the below methods for each motor then join into the “Y” piece prior to joining ducting to the canopy / rangehood. Refer figure 10.
  • Page 17: Twin 200Mm Outlet Installation Example

    4. installation Twin 200mm outlet Installation Example This is for use where one motor is to be used and there are two 200mm outlets, refer figure 11. 1600 motor Ensure flexible ducting is fully extended and as short as possible. use smooth flowing curves for maximum air flow.
  • Page 18: Measurements

    5. Measurements Measurements for Isodrive 1600 (not to scale) 405mm 148mm 220mm 190mm 90mm 35mm 225mm 440mm dektite 160mm shutter assembly is not shown in the diagram. Page 18...
  • Page 19: Flexible Duct

    Call outs relating to incorrect installation will result in a service fee directed to the customer. schweigen will take no responsibility for problems caused by faulty installation. a list of preferred Schweigen installers can be obtained from the Schweigen website www.schweigen.com.au.
  • Page 20: Shallow Roof Space

    1. 6. Flexible duct Shallow roof Space In shallow roof spaces, do not crush or kink flexible ducting, as it will reduce air flow severely. 90 degree curve made of PVC or galvanise can be used as a substitute for the bend, refer to figure 12. 90 degree curve PVC or galvanise curve Figure 12...
  • Page 21: Securing Flexible Duct

    6. Flexible duct Securing Flexible Duct Flexible duct must be installed with supports at maximum intervals of 1.5 metres. Flexible ductwork can be supported by using gaffer or electrical tape. Provided that it does not restrict the internal diameter of the ducting. ducting installed looped over hanging beams should be installed in such a manner as to ensure the changes of direction are gradual.
  • Page 22: Parts List

    7. Parts list Parts List for Isodrive 1600 Page 22...
  • Page 23 7. Parts list Parts List for Isodrive 1600 number Part number Description Quantity P1120 M4X160mm Pan Head screw P1120n M4 KEPS Nut (not shown in figure) P1114 Capacitor 3.5μF P1100 Fan Motor Mounting Bracket P1102 Fan Base spinning P1113 Heyco snap Bushing...
  • Page 24: Maintenance

    1. 8. Maintenance roof restoration or Cleaning Before doing your roof restoration or cleaning, please completely cover the outside motor system and avoid all chemical contact. IMPoranT any damages caused by the use of chemical products are not covered by warranty. Figure 15 Avoid chemical contact to motor system IMPoranT it is a requirement to use the hanging bracket for all wall mount...
  • Page 25: Warranty/Disclaimer

    Home appliances will not be liable for any loss, liability or damage of whatever kind arising as a result of any reliance upon such information.
  • Page 26 1. notes Page 26...
  • Page 27 notes Page 27...
  • Page 28 HOME APPLIANCES 8/3-4 anzed Court, distributed by: Mulgrave 3170 Victoria. 1300 881 693 (EST) www.schweigen.com.au 20.07.16...
