Page 1 For Windows 7 & 8 V14.1.00...
Page 3 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent vendor. They assume no responsibility or liability for any errors or inaccuracies that may appear in this publication nor are they in anyway responsible for any loss or damage resulting from the use (or misuse) of this publication.
Page 4 Preface R&TTE Directive This device is in compliance with the essential requirements and other relevant provisions of the R&TTE Direc- tive 1999/5/EC. This device will be sold in the following EEA countries: Austria, Italy, Belgium, Liechtenstein, Denmark, Lux- embourg, Finland, Netherlands, France, Norway, Germany, Portugal, Greece, Spain, Iceland, Sweden, Ireland, United Kingdom, Cyprus, Czech Republic, Estonia, Hungary, Latvia, Lithuania, Malta, Slovakia, Poland, Slov- enia.
Page 5: Fcc Statement
Preface FCC Statement (Federal Communications Commission) You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
Page 6: Fcc Rf Radiation Exposure Statement
Preface FCC RF Radiation Exposure Statement: This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body.
Page 7: Important Safety Instructions
Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock, and injury to persons when using any electrical equipment: Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.
Page 8: Instructions For Care And Operation
Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...
Page 9 Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong magnetic fields. These can hinder proper performance and damage your data. Follow the proper working procedures for the computer. Shut the computer down properly and don’t forget to save your work.
Page 10: Power Safety
Preface Power Safety The computer has specific power requirements:  • Only use a power adapter approved for use with this computer. • Your AC/DC adapter may be designed for international travel but it still requires a steady, Power Safety uninterrupted power supply.
Page 11: Polymer Battery Precautions
Preface Polymer Battery Precautions Note the following information which is specific to polymer batteries only, and where applicable, this overrides the general battery precaution information overleaf. • Polymer batteries may experience a slight expansion or swelling, however this is part of the battery’s safety mecha- nism and is not a cause for concern.
Page 12: Battery Precautions
Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not remove any batteries from the computer while it is powered on. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.
Page 13: Cleaning
Preface Cleaning Do not apply cleaner directly to the computer; use a soft clean cloth. Do not use volatile (petroleum distillates) or abrasive cleaners on any part of the computer. Servicing Do not attempt to service the computer yourself. Doing so may violate your warranty and expose you and the computer to electric shock.
Page 14: Travel Considerations
Preface Travel Considerations Packing As you get ready for your trip, run through this list to make sure the system is ready to go: Check that the battery pack and any spares are fully charged. Power off the computer and peripherals. Close the display panel and make sure it’s latched.
Page 15 Preface On the Road In addition to the general safety and maintenance suggestions in this preface, and Chapter 8: Troubleshooting, keep these points in mind: Hand-carry the notebook - For security, don’t let it out of your sight. In some areas, computer theft is very common.
Page 16 Preface Developing Good Work Habits Developing good work habits is important if you need to work in front of the computer for long periods of time. Improper work habits can result in discomfort or serious injury from repetitive strain to your hands, wrists or other joints.
Page 17: Lcd Screen Care
Preface Lighting Proper lighting and a comfortable viewing angle can reduce eye strain and shoulder and neck muscle fatigue. • Position the display to avoid glare or reflections from overhead lighting or outside sources of light. • Keep the display screen clean and set the brightness and contrast to levels that allow you to see the screen clearly. •...
Page 18 Preface...
Page 19: Table Of Contents
Preface Contents Notice ................................I FCC Statement ............................III FCC RF Radiation Exposure Statement: ....................IV ErP Off Mode Power Consumption Statement: ..................IV Instructions for Care and Operation ......................VI Power Safety ............................VIII Polymer Battery Precautions ........................IX Battery Precautions ............................X Cleaning ..............................XI Servicing ..............................XI Travel Considerations ..........................
Page 20 Preface System Startup ............................1-5 System Map: LCD Panel Open & Top View ....................1-6 LED Indicators ............................1-8 Touch Sensor Instant Keys ........................1-9 Keyboard ..............................1-10 Keyboard LED ............................1-11 Effects Buttons & Help ..........................1-13 Function Keys & Visual Indicators ......................1-14 Control Center ............................1-15 System Map: Front &...
Page 21 Preface Hard Disk Drive ............................2-2 Optical Device ............................2-3 Loading Discs ............................2-3 Handling CDs or DVDs ..........................2-4 DVD Regional Codes ..........................2-5 Multi-In-1 Card Reader ..........................2-6 ExpressCard Slot ............................2-7 Inserting and Removing ExpressCards ......................2-7 Audio Features ............................2-8 Setup for 5.1 or 7.1 Surround Sound ......................2-9 Setup for Audio Recording ........................2-11 Audio Notes for Fn + 5 ..........................2-12 TouchPad and Buttons/Mouse .........................2-13...
Page 22 Preface Power-Saving States ..........................3-6 Sleep ................................3-6 Hibernate ..............................3-7 Shut down ..............................3-7 Configuring the Power Buttons .........................3-8 Resuming Operation ..........................3-9 Power Conservation Modes ........................3-10 Battery Information ..........................3-11 Conserving Battery Power ........................3-12 Battery Life ..............................3-13 New Battery .............................3-13 Recharging the Battery with the AC/DC Adapter ...................3-13 Proper handling of the Battery Pack ......................3-14 Battery FAQ .............................3-15 Multi GPU Configuration &...
Page 23 Preface User Account Control ..........................4-5 Windows Security Message ........................4-5 New Hardware Found ..........................4-5 Driver Installation Procedure ........................4-6 Chipset ...............................4-6 USB 3.0 (Win 7 Only) ..........................4-6 NVIDIA Video (VGA) ..........................4-7 AMD Video (VGA) ...........................4-7 LAN ................................4-7 Card Reader ...............................4-8 TouchPad ..............................4-8 Hot Key ..............................4-8 MEI Driver ..............................4-8 Audio .................................4-8...
Page 24 Preface The Setup Utility ............................5-4 Entering Setup ............................5-4 Setup Screens .............................5-5 Main Menu ..............................5-6 System Time & Date (Main Menu) ......................5-6 SATA Port # (Main Menu) ........................5-7 System/Extended Memory (Main Menu) ....................5-7 BIOS Revision/ KBC/EC firmware Revision / VGA Card etc. (Main Menu) ..........5-7 Advanced Menu ............................5-8 Advanced Chipset Control (Advanced Menu) ..................5-8 Bluetooth Power Setting (Advanced Menu >...
Page 25 Preface TPM State (Security Menu > TPM Support Enabled) ................5-14 Pending TPM operation (Security Menu > TPM Support & TPM State Enabled) .........5-15 Boot Menu ...............................5-16 Boot Option Priorities (Boot Menu) ......................5-17 OS Select (Boot Menu) ..........................5-17 UEFI Boot (Boot Menu > OS Select) ......................5-17 Save &...
Page 26 Preface SATA RAID Setup Procedure (BIOS) ......................7-5 RAID Setup (Intel Matrix) .........................7-6 Intel Rapid Storage Technology ......................7-11 IRST Driver Installation ..........................7-11 Intel® Rapid Storage Technology for RAID Systems ................7-12 RAID Volume Data Verification and Repair ..................7-14 PC Camera Module ..........................7-17 PC Camera Driver Installation .........................7-18 PC Camera Audio Setup ..........................7-19 Wireless LAN Module ..........................7-25...
Page 27 Preface BioExcess Application ..........................7-56 Bluetooth Module ............................7-67 3rd Party Bluetooth (V4.0) Combo Driver Installation ................7-69 Intel Bluetooth Combo Driver Installation ....................7-70 Standard Bluetooth Configuration in Windows 7 ...................7-71 Trusted Platform Module .........................7-75 Enabling & Activating TPM ........................7-76 Trusted Platform Module (TPM) Driver Installation ................7-78 Initializing TPM ............................7-79 Infineon Security Platform Settings Tool ....................7-81 Sound Blaster Audio ..........................7-89...
Page 28 Preface Intel® My WiFi Configuration ........................8-23 Interface (Ports & Jacks) Overview ..............................A-1 Ports and Jacks ............................A-2 Card Reader ..............................A-2 DC-In Jack ..............................A-2 DisplayPort ...............................A-2 DVI-Out Port ............................A-2 e-SATA/Powered USB 3.0 Port .......................A-3 HDMI-Out Port ............................A-3 Headphone-Out Jack ..........................A-3 Line-In Jack ..............................A-4 Microphone-In Jack ..........................A-4 Mini-IEEE 1394 Port ..........................A-4 RJ-45 LAN Jack ............................A-4...
Page 29 Preface NVIDIA Video Driver Controls NVIDIA Video Driver Installation ......................C-1 NVIDIA Control Panel ..........................C-2 Display Devices ............................C-5 Configuring an External Display (NVIDIA) ....................C-6 Extending the Display ..........................C-7 Multiple Display Connection to HDMI-Out Port & DisplayPort ............C-10 Attaching Other Displays (Win 7) ......................C-11 Configuring an External Display in Windows 7 ..................C-11 Using the Windows Logo Key + P/Fn + F7 Key Combination to Switch Displays ......C-13 NVIDIA®...
Page 30 Preface Set Up Stereoscopic 3D ..........................C-26 AMD Video Driver Controls Video Driver Installation ..........................D-1 Video (VGA) ............................D-1 Catalyst™ Control Center ........................D-2 Display Devices & Options ........................D-7 Configuring an External Display In the CCC....................D-8 Configuring an External Display In Windows 7 ..................D-12 AMD CrossFireX™...
Page 31 Preface Card Reader .............................. E-4 Slots ................................E-4 Interface ..............................E-4 Communication ............................E-4 Indicators ..............................E-5 Security ..............................E-5 Operating System ............................E-5 Design Feature ............................E-5 Power Management ..........................E-5 Power ................................ E-5 Environmental Spec ..........................E-5 Physical Dimensions & Weight ........................ E-5 Windows 8 Overview ..............................
Page 32 Preface Windows 8 Taskbar ..........................F-11 LED Indicators ............................F-12 Keyboard - Windows 8 ........................... F-13 Keyboard Shortcuts ..........................F-14 Function/Hot Key Indicators & Control Center ..................F-15 Video Features ............................F-16 To Configure Displays from Devices (Charms Bar): ................F-16 Power Options ............................
Page 33 Preface Desktop Mode ............................F-34 Control Panel ............................F-35 Fingerprint Reader Module (Windows 8) ....................F-37 Protector Suite Fingerprint Reader Driver Installation (Windows 8) ............. F-38 BioExcess Fingerprint Reader Driver Installation (Windows 8) ............F-38 Protector Suite Application (Windows 8) ....................F-39 Enabling the .NET Framework 3.5 in the Windows Control Panel ............
Page 34 Preface XXXII...
Page 35: Quick Start Guide Overview
Quick Start Guide Chapter 1: Quick Start Guide Overview This Quick Start Guide is a brief introduction to the basic features of your computer, to navigating around the computer and to getting your system started. The remainder of the manual covers the following: •...
Page 36: Advanced Users
Quick Start Guide Advanced Users If you are an advanced user you may skip over most of this Quick Start Guide. However you may find it useful to refer to “Drivers & Utilities” on page 4 - “BIOS Utilities” on page 5 - 1 “Upgrading The Computer”...
Page 37: Model Differences
Quick Start Guide Model Differences This notebook series includes two different model types (only Model B computers support 3D). Note that your model may appear slightly different from those pictured in this manual. Not Included Operating Systems (e.g. Windows 7) and applications (e.g. word processing, spreadsheet and database pro- grams) have their own manuals, so please consult the appropriate manuals.
Page 38: System Software
Quick Start Guide System Software Your computer may already come with system software pre-installed. Where this is not the case, or where you are re-configuring your computer for a different system, you will find the Windows 7 (with Service Pack 1 in- stalled) and Windows 8 (64 bit) operating systems are supported.
Page 39: System Startup
Quick Start Guide System Startup 1. Remove all packing materials, and place the computer on a stable surface. 2. Securely attach any peripherals you want to use with the notebook (e.g. keyboard and mouse) to their ports. 3. Attach the AC/DC adapter to the DC-In jack at the rear of the computer, then plug the AC power cord into an outlet, and connect the AC power cord to the AC/DC adapter.
Page 40: System Map: Lcd Panel Open & Top View
Quick Start Guide System Map: LCD Panel Open & Top View Figure 1 - 2 LCD Panel Open  & Top View 1. Built-In PC Camera Wireless Device 2. Built-In Microphone Operation Aboard 3. PC Camera LED Aircraft 4. LCD The use of any portable elec- 5.
Page 41 Quick Start Guide Speaker Note Note that the speaker area is covered by a protective mylar film on shipping. In order to prevent any impair- ment to audio quality, this film should be removed when the system is ready for use. Figure 1 - 3 - Speaker Area System Map: LCD Panel Open &...
Page 42: Led Indicators
Quick Start Guide LED Indicators The two sets of LED indicators (LED Status Indicators and LED Power Indicators) display helpful informa- tion about the current status of the computer. Icon Color Description Icon Color Description Blinking HDD/ODD Activity Orange DC Power is Plugged In Blue Number Lock is Activated Green...
Page 43: Touch Sensor Instant Keys
Quick Start Guide Touch Sensor Instant Keys Press the Touch Sensor Instant Keys on the computer to toggle the appropriate function on/off. When a module is powered on the appropriate icon will be highlighted blue. Icon Description Mute Toggle Bluetooth Module (optional) Power Toggle Win 8 - Indicates the (optional) Bluetooth Module is Installed (this is not a power on/off indicator in Windows 8) Wireless LAN Module (optional) Power Toggle...
Page 44: Keyboard
Quick Start Guide Keyboard  The keyboard has an embedded numerical keypad for easy numeric data input, and Other Keyboards features function keys to allow you to change operational features instantly. See Table 1 - 5, on page 1 - 14 for full function key combination details.
Page 45: Keyboard Led
Quick Start Guide Keyboard LED Press Fn plus the key to toggle the keyboard LED on/off. The keyboard LED may be configured using the Fn + key combination outlined in the table below. In addition press Fn plus the key to launch the keyboard backlight application to configure the settings (see overleaf).
Page 46 Quick Start Guide Keyboard Backlight Application The keyboard Backlight application can be accessed by pressing the Fn plus key. Click the Help button in the application to display the configuration keys. • Click the Custom button to display the three sections of the keyboard which may be configured. •...
Page 47: Effects Buttons & Help
Quick Start Guide Effects Buttons & Help LED Effects Buttons Random Color Up/Down Wave Dancing Effect Breathing (All Colors) Tempo Beat Cycle (Colors as Selected in RGB) Custom Mode - Display & Configure Flashing Keyboard Sections & Colors  Illumination Keys Note that the keyboard illumi- nation (increase/decrease) keys may be used to config-...
Page 48: Function Keys & Visual Indicators
Quick Start Guide Function Keys & Visual Indicators The function keys (F1 - F12 etc.) will act as hot keys when pressed while the Fn key is held down. Visual in- dicators (see the table below) are available when the Hot Key driver is installed (see “Hot Key”...
Page 49: Control Center
Quick Start Guide Control Center Press the Fn + Esc key combination, or double-click the icon in the notification area of the taskbar to toggle the Control Center on/off. The Control Center gives quick access to frequently used controls and en- ables you to quickly turn modules on/off.
Page 50: System Map: Front & Rear Views
Quick Start Guide System Map: Front & Rear Views Figure 1 - 6 Front & Rear Views 1. LED Power Indica- tors 2. Express Card Slot 3. Multi-In-1 Card Reader 4. DC-In Jack Appendix A for a more detailed description of the ports &...
Page 51: System Map: Right View
Quick Start Guide System Map: Right View Figure 1 - 7 Right View 1. Line-In Jack 2. S/PDIF-Out Jack 3. Microphone-In Jack 4. Headphone-Out Jack 5. 2 * USB 2.0 Ports 6. Sub Woofer  7. Security Lock Slot USB Ports Appendix A for a more Note that the connections to the USB ports only fit one way, do not force them.
Page 52: System Map: Left View
Quick Start Guide System Map: Left View Figure 1 - 8 Left View 1. DVI-Out Port 2. RJ-45 LAN Jack 3. HDMI-Out Port 4. Display Port 5. 2 * USB 3.0 Ports 6. Combined eSATA/ Powered USB 3.0  Port HDMI Port 7.
Page 53 Quick Start Guide   Changing DVD Regional Codes Disk Eject Warning Go to the Control Panel and double-click Device Don’t try to eject a CD/DVD while the system is ac- Manager (Hardware and Sound), then click the + cessing it. This may cause the system to “crash”. Stop next to DVD/CD-ROM drives.
Page 54: System Map: Bottom View
Quick Start Guide System Map: Bottom View Figure 1 - 9 Bottom View 1. Fan Outlet/Intake 2. Component Bay Cover 3. Battery (HDD Bay located under the battery) 4. HDD Bay  Overheating  To prevent your comput- Battery Information er from overheating make sure nothing blocks the Always completely discharge, then fully charge, a new battery before using it.
Page 55: Windows 7 Start Menu & Control Panel
Quick Start Guide Windows 7 Start Menu & Control Panel Most of the control panels, utilities and programs within Windows 7 are accessed from the Start menu (see pendix F for information on the Windows 8 OS). When you install programs and utilities they will be installed on your hard disk drive, and a shortcut will usually be placed in the Start menu and/or the desktop.
Page 56: Video Features
Quick Start Guide Video Features This computer features two different (either AMD or NVIDIA) video options. You can switch display devices, and configure display options, from the Display control panel (in Appearances and Personalization) in Win- dows 7 (see “Video Features” on page F - 16 for information on the Windows 8 OS).
Page 57 Quick Start Guide Screen Resolution  Video Options Note that card types, specifi- cations and drivers are sub- ject to continual updates and changes. Check with your service center for the latest details on video cards sup- ported. Figure 1 - 11 - Screen Resolution Video Features 1 - 23...
Page 58: Nvidia Control Panel
Quick Start Guide NVIDIA Control Panel You can access the NVIDIA Control Panel as follows: Click Start, and click Control Panel. Click NVIDIA Control Panel (Figure 1 - 12) - In the Appearances and Personalization category. “NVIDIA Video Driver Controls” on page B - 1 for full details on control panels etc.
Page 59: Catalyst Control Center
Quick Start Guide Catalyst Control Center You can access the Catalyst Control Center as follows: Right-click the desktop and select Catalyst Control Center (Figure 1 - 13). Double-click (or right-click the icon and select Catalyst Control Center) the icon (Figure 1 - 13) in the Windows system tray notification area (make sure “Enable System Tray Menu”...
Page 60: Power Options
Quick Start Guide Power Options The Power Options (Hardware and Sound menu) control panel icon in Windows (see page 1 - 21 or page or see Appendix F for information on the Windows 8 OS) allows you to configure power management fea- tures for your computer.
Page 61: Storage Devices, Mouse & Audio Overview
Storage Devices, Mouse & Audio Chapter 2: Storage Devices, Mouse & Audio Overview Read this chapter to learn more about the following main features and components of the computer: • Hard Disk Drive • Optical Device • Multi-In-1 Card Reader •...
Page 62: Hard Disk Drive
Storage Devices, Mouse & Audio Hard Disk Drive  The hard disk drive(s) is(are) used to store your data in the computer. The hard Power Safety disk(s) can be taken out to accommodate other 2.5" serial (SATA) hard disk drives with a height of 9.5 mm.
Page 63: Optical Device
Storage Devices, Mouse & Audio Optical Device  There is a bay for a 5.25" optical (CD/DVD) device (12.7mm height). The actual de- Sound Volume vice will depend on the model you purchased (see “Storage” on page E - 3). The Adjustment optical device is usually labeled “Drive D:”...
Page 64: Handling Cds Or Dvds
Storage Devices, Mouse & Audio Handling CDs or DVDs  Proper handling of your CDs/DVDs will prevent them from being damaged. Please follow the advice below to make sure that the data stored on your CDs/DVDs can be CD Emergency Eject accessed.
Page 65: Dvd Regional Codes
Storage Devices, Mouse & Audio DVD Regional Codes To change the DVD regional codes see “Changing DVD Regional Codes” on page 1 - DVD Regional Coding Table 2 - 1 Region Geographical Location DVD Regional Coding USA, Canada Western Europe, Japan, South Africa, Middle East &...
Page 66: Multi-In-1 Card Reader
Storage Devices, Mouse & Audio Multi-In-1 Card Reader  The card reader allows you to use some of the latest digital storage cards. Push the Card Reader Cover card into the slot and it will appear as a removable device, and can be accessed in the same way as your hard disk (s).
Page 67: Expresscard Slot
Storage Devices, Mouse & Audio ExpressCard Slot  The computer is equipped with an ExpressCard/34/54 slot that reads Express Card/ ExpressCard 34 and ExpressCard/54 formats. ExpressCards are the successors to PCMCIA (PC Slot Cover Cards). Make sure you keep the ExpressCard/54 is used for applications which require a larger interface slot, e.g.
Page 68: Audio Features
Storage Devices, Mouse & Audio Audio Features  You can configure the audio options on your computer from the Sound control Volume Adjustment panel in Windows, or from the Realtek HD Audio Manager icon in the notifi- The sound volume level cation area/control panel (right-click the taskbar notification area icon to bring up is set using the volume...
Page 69: Setup For 5.1 Or 7.1 Surround Sound
Storage Devices, Mouse & Audio Setup for 5.1 or 7.1 Surround Sound  To setup your system for 5.1 or 7.1 surround sound you will need to connect the au- dio cables to the Headphone-Out, Line-In, Microphone-In jack and S/PDIF-Out Sound Blaster Audio &...
Page 70 Storage Devices, Mouse & Audio Plug the front speaker cables into the Headphone-Out Jack. Plug in the other cables (you may require an adapter to connect each cable to the appropriate jack e.g a stereo mini to dual RCA adapter) from your speakers as follows: •...
Page 71: Setup For Audio Recording
Storage Devices, Mouse & Audio Setup for Audio Recording To record audio sources on your computer at optimum quality follow the instruc- tions below: Click Start, and click Control Panel (or point to Settings and click Control Panel) and make sure you are in Classic View. Click Realtek HD Audio Manager (or right-click the taskbar icon and select Sound Manager).
Page 72: Audio Notes For Fn + 5
Storage Devices, Mouse & Audio Audio Notes for Fn + 5 This computer features an Fn +5 key combination to toggle between standard audio and enhanced audio. Note the following which applies to software mode audio con- figuration through the computer’s internal speakers only (this does not apply to surround sound when configured through external Quadraphonic, 5.1 or 7.1 speaker systems): •...
Page 73: Touchpad And Buttons/Mouse
Storage Devices, Mouse & Audio TouchPad and Buttons/Mouse  The TouchPad is an alternative to the mouse; however, you can also add a mouse to TouchPad Scrolling your computer through one of the USB ports. The TouchPad buttons function in much the same way as a two-button mouse.
Page 74: Gestures And Device Settings
Storage Devices, Mouse & Audio Gestures and Device Settings  The Synaptics Gestures Suite application allows you to use a specific gesture (ac- Show Video tion) on the surface of the Touchpad to perform specific actions to manipulate doc- uments, objects and applications. You can get a clearer view of the gestures in- You can configure the settings from the Device Settings tab in Mouse Properties:...
Page 75 Storage Devices, Mouse & Audio Smart Sense The Smart Sense feature helps prevent operating the Touchpad by accident, by rec- ognizing when your palm is resting on it or brushing its surface while you are typing. You can adjust the sensitivity of Smart Sense by moving the slider towards Max (to help remove undesired pointer movement or clicks) or Off (if it misses intended mo- tions or taps).
Page 76 Storage Devices, Mouse & Audio Scrolling The Two-Finger scrolling feature works in most scrollable windows and allows you to scroll horizontally and vertically. Place two fingers, slightly separated, on the TouchPad surface and slide both fingers in the direction required (in a straight con- Figure 2 - 12 tinuous motion).
Page 77 Storage Devices, Mouse & Audio Rotating Use the Pivot Rotate gesture to rotate objects (e.g. photos) in 90 degree increments. Place a finger down on the left “target” zone and keep it stationary. Place another finger near the middle of the TouchPad and slide it in a circular motion around the stationary finger (clockwise or counterclockwise) to rotate the object.
Page 78 Storage Devices, Mouse & Audio 2 - 18...
Page 79: Power Management Overview
Power Management Chapter 3: Power Management  Overview OS Note Power management To conserve power, especially when using the battery, your computer power man- functions will vary slight- agement conserves power by controlling individual components of the computer ly depending on your (the LCD and hard disk drive) or the whole system.
Page 80: The Power Sources
Power Management The Power Sources The computer can be powered by either an AC/DC adapter or a battery pack. AC/DC Adapter Use only the AC/DC adapter that comes with your computer. The wrong type of AC/ DC adapter will damage the computer and its components (see page Attach the AC/DC adapter to the DC-In jack at the rear of the computer.
Page 81: Turning On The Computer
Power Management Turning On the Computer  Now you are ready to begin using your computer. To turn it on simply press the pow- Forced Off er button on the front panel. If the system “hangs”, When the computer is on, you can use the power button as a Stand by/Hibernate/ and the Ctrl + Alt + Del Shutdown hot-key button when it is pressed for less than 4 seconds (pressing and key combination doesn’t...
Page 82: Power Plans
Power Management Power Plans  The computer can be configured to conserve power by means of power plans. You Resuming can use (or modify) an existing power plan, or create a new one. Operation The settings may be adjusted to set the display to turn off after a specified time, and Table 3 - 1, on to send the computer into Sleep after a period of inactivity.
Page 83 Power Management Each Windows power plan will also adjust the processor performance of your ma- chine in order to save power. This is worth bearing in mind if you are experiencing any reduced performance (especially under DC/battery power). Choose High performance (you may need to click Show additional plans to view the High performance plan) for maximum performance when the computer is pow- ered from an AC power source.
Page 84: Power-Saving States
Power Management Power-Saving States You can use power-saving states to stop the computer’s operation and restart where you left off. Win 7 uses the Sleep, Hibernate and Shut Down power-saving states. Sleep In Sleep all of your work, settings and preferences are saved to memory before the system sleeps.
Page 85: Hibernate
Power Management Hibernate  Hibernate uses the least amount of power of all the power-saving states and saves all of your information on a part of the hard disk before it turns the system off. If a Silent Mode power failure occurs the system can restore your work from the hard disk; if a power You can use Silent failure occurs when work is saved only to memory, then the work will be lost.
Page 86: Configuring The Power Buttons
Power Management Configuring the Power Buttons  The power/sleep button (Fn + F4 key combo) and closed lid may be set to send the Password computer in to a power-saving state. Click Choose what the power buttons do on Protection the left menu in Power Options to bring up the menu.
Page 87: Resuming Operation
Power Management Resuming Operation  You can resume operation from power-saving states by pressing the power button, or in some cases pressing the sleep button (Fn + F4 key combo). Closing the Lid If you have chosen to send the computer to Power Status Icon Color...
Page 88: Power Conservation Modes
Power Management Power Conservation Modes  This system supports Energy Star power management features that place comput- ers (CPU, hard drive, etc.) into a low-power sleep modes after a designated period Power Conservation of inactivity. Adjust Power Conservation Modes from the Control Center: Modes The Energy Star setting Press the Fn + Esc key combination to toggle the Control Center on/off.
Page 89: Battery Information
Power Management Battery Information  Follow these simple guidelines to get the best use out of your battery. Low Battery Battery Power Warning Your computer’s battery power is dependent upon many factors, including the pro- When the battery is criti- grams you are running, and peripheral devices attached.
Page 90: Conserving Battery Power
Power Management Conserving Battery Power  • Use a power plan that conserves power (e.g Power saver), however note that this may have an affect on computer performance. Windows Mobility Center • Lower the brightness level of the LCD display. The system will decrease LCD brightness slightly to save power when it is not powered by the AC/DC adapter.
Page 91: Battery Life
Power Management Battery Life Battery life may be shortened through improper maintenance. To optimize the life and improve its performance, fully discharge and recharge the battery at least once every 30 days. We recommend that you do not remove the battery yourself. If you do need to re- move the battery for any reason (e.g.
Page 92: Proper Handling Of The Battery Pack
Power Management Proper handling of the Battery Pack  • DO NOT disassemble the battery pack under any circumstances. • DO NOT expose the battery to fire or high temperatures, it may explode. Caution • DO NOT connect the metal terminals (+, -) to each other. Danger of explosion if battery is incorrectly re- ...
Page 93: Battery Faq
Power Management Battery FAQ How do I completely discharge the battery? Use the computer with battery power until it shuts down due to a low battery. Don’t turn off the computer even if a message indicates the battery is critically low, just let the computer use up all of the battery power and shut down on its own.
Page 94 Power Management Click Change plan settings (after creating it) and click Change plan settings > Change advanced power settings. Figure 3 - 9 Change Plan Settings / Change Advanced Power Settings 3 - 16 Battery Information...
Page 95 Power Management Scroll down to Battery and click + to expand the battery options. Choose the options below (click Yes if a warning appears): Figure 3 - 10 Power Options Advanced Settings - Battery • Low battery levels = 0% •...
Page 96 Power Management How do I fully charge the battery? When charging the battery, don’t stop until the LED charging indicator light changes from orange to green. How do I maintain the battery? Completely discharge and charge the battery at least once every 30 days or after about 20 partial discharges.
Page 97: Multi Gpu Configuration & Power
Power Management Multi GPU Configuration & Power  Note that due to the high power and system demands created when two video Multi GPU adapters are installed in a multi GPU (NVIDA® SLI or AMD CrossFireX™) Configuration & configuration, you should not power the system using the battery only and you Multiple Displays will require identical (300W) dual power adapters, connected to a power con- verter box, to power the system.
Page 98 Power Management 3 - 20...
Page 99: Drivers & Utilities
Drivers & Utilities Chapter 4: Drivers & Utilities  This chapter deals with installing the drivers and utilities essential to the operation or Driver Installation & improvement of some of the computer’s subsystems. The system takes advantage of Power some newer hardware components for which the latest versions of most available op- When installing driv- erating systems haven’t built in drivers and utilities.
Page 100: Driver Installation
Drivers & Utilities Driver Installation Check the driver installation order from Table 4 - 1, on page 4 - 3 (the drivers must be installed in Insert the Device Drivers & Utilities + User’s Manual this order) which is the same as that listed in the disc and click Install Drivers (button), or Option Driv- Drivers Installer menu below.
Page 101 Drivers & Utilities Win 7 SP1/Win 8 Driver Intel Rapid Storage Technology Chipset Page 4 - 6 Page 7 - 11 (for RAID & AHCI mode Hard Disk Drives) USB 3.0 (Win 7 Only) Page 4 - 6 PC Camera Module Page 7 - 17 NVIDIA Video (VGA) Page 4 - 7...
Page 102: Manual Driver Installation
Drivers & Utilities Manual Driver Installation Updating/Reinstalling Individual Drivers Click the Browse CD/DVD button in the Drivers In- If you wish to update/reinstall individual drivers it staller application and browse to the executable file in may be necessary to uninstall the original driver.To do the appropriate driver folder.
Page 103: User Account Control
Drivers & Utilities User Account Control New Hardware Found If a User Account Control prompt appears as part of If you see the message “New Hardware Found” dur- the driver installation procedure, click Continue/Al- ing the installation procedure (other than when out- low, and follow the installation procedure as directed.
Page 104: Driver Installation Procedure
Drivers & Utilities Driver Installation Procedure RAID Note: Setting up a RAID, or AHCI mode, needs to be done prior to installing the Windows OS, Insert the Device Drivers & Utilities + User’s Manual and therefore before installing the other drivers listed disc and click Install Drivers (button), or Option Driv- here.
Page 105: Nvidia Video (Vga)
Drivers & Utilities NVIDIA Video (VGA) Note that when attempting to access the AMD Cata- lyst™ Control Center in Windows 7, you may be 1. Click 3./2.Install VGA Driver > Yes. prompted to install Microsoft.net Framework 2. Click AGREE AND CONTINUE (button) to VX.X.
Page 106: Card Reader
Drivers & Utilities Card Reader Audio 1. Click 5./4.Install Cardreader Driver > Yes. 1. Click 9. /8.Install Audio Driver > Yes. 2. Click Finish to complete the installation. 2. Click Next. 3. Click Finish to restart the computer. TouchPad After installing the audio driver the system will not re- 1.
Page 107: Optional Drivers
Drivers & Utilities Optional Drivers  See the pages indicated for the driver installation pro- cedures for any modules included in your purchase op- Windows Update tion. After installing all the drivers make sure you enable Win- dows Update in order to get all the latest security up- dates etc.
Page 108 Drivers & Utilities 4 - 10...
Page 109: Bios Utilities Overview
BIOS Utilities Chapter 5: BIOS Utilities  Overview BIOS Screens Note that BIOS This chapter gives a brief introduction to the computer’s built-in software: screens pictured these pages are intend- Diagnostics: The POST (Power-On Self Test) ed for guidance in set- ting up your system’s BIOS.
Page 110: The Power-On Self Test (Post)
BIOS Utilities The Power-On Self Test (POST) If you enable the Boot-time Diagnostic Screen in the Setup Utility, each time you turn on the computer the system takes a few seconds to conduct a POST, including a quick test of the on-board RAM (memory). As the POST proceeds, the computer will tell you if there is anything wrong.
Page 111: Failing The Post
BIOS Utilities Failing the POST Errors can be detected during the POST. There are two categories, “fatal” and “non- fatal”. Fatal Errors These stop the boot process and usually indicate there is something seriously wrong with your system. Take the computer to your service representative or authorized service center as soon as possible.
Page 112: The Setup Utility
BIOS Utilities The Setup Utility  The Aptio Setup Utility tells the system how to configure itself and manage basic BIOS Settings features and subsystems (e.g. port configuration). Warning Entering Setup Incorrect settings can cause your system to To enter Setup, turn on the computer and press F2 during the POST. The prompt malfunction.
Page 113: Setup Screens
BIOS Utilities Setup Screens  The following pages contain additional advice on portions of the Setup. Along the top of the screen is a menu bar with menu headings. When you select a heading, a Setup Menus new screen appears. Scroll through the features listed on each screen to make chang- Setup menus es to Setup.
Page 114: Main Menu
BIOS Utilities Main Menu Figure 5 - 2 Main Menu System Time & Date (Main Menu) The hour setting uses the 24-hour system (i.e., ØØ = midnight; 13 = 1 pm). If you can change the date and time settings in your operating system, you will also change these settings.
Page 115: Sata Port # (Main Menu)
BIOS Utilities SATA Port # (Main Menu) Pressing Enter opens the sub-menu to show the configuration of a optical Device/ HDD on the computer’s SATA ports. System/Extended Memory (Main Menu) This item contains information on the system memory, and is not user configurable. The system will auto detect the amount of memory installed.
Page 116: Advanced Menu
BIOS Utilities Advanced Menu Figure 5 - 3 Advanced Menu Advanced Chipset Control (Advanced Menu) The sub-menu here allows you to adjust the Bluetooth Power Setting. 5 - 8 Advanced Menu...
Page 117: Bluetooth Power Setting (Advanced Menu > Advanced Chipset Control)
BIOS Utilities Bluetooth Power Setting (Advanced Menu > Advanced Chipset Control)  You can adjust the Bluetooth module power setting to your preference. The default setting (Disabled) will see the Bluetooth module powered off when the system is SATA Mode started up or restarted.
Page 118: Boot Logo (Advanced Menu)
BIOS Utilities Boot Logo (Advanced Menu) Use this menu item to enable/disable the Boot Logo screen at system startup. Power On Boot Beep (Advanced Menu) Use this menu item to enable/disable the beep as the computer starts up. Battery Low Alarm Beep (Advanced Menu) Use this menu item to enable/disable the battery low alarm beep.
Page 119: Security Menu
BIOS Utilities Security Menu  Security Menu The changes you make here affect the access to the Setup utility itself, and also access to your machine as it boots up after you turn it on. These settings do not affect your machine or network passwords which will be set in your...
Page 120: Set User Password (Security Menu)
BIOS Utilities Set User Password (Security Menu)  You can set a password for user mode access to the Aptio Setup Utility. This will not affect access to the computer OS, (only the Setup utility) unless you choose to Password Warning set a Password on Boot (see below).
Page 121: Trusted Computing (Security Menu)
BIOS Utilities Trusted Computing (Security Menu) This sub-menu will allow you to enable/disable Trusted Platform Module (TPM) support, and to configure the TPM State. Select Trusted Computing and press En- ter to access the sub-menu. Press Enter to access the TPM Support menu and select Enable to display the full TPM configuration menu (see “Trusted Platform Mod- ule”...
Page 122: Tpm State (Security Menu > Tpm Support Enabled)
BIOS Utilities TPM State (Security Menu > TPM Support Enabled) Select TPM State, press Enter and select Enable to change the TPM state to en- abled. You will then need to press F4 to save the changes and restart the computer. Figure 5 - 6 TPM State (Enabled) As the computer restarts press F2 to enter the BIOS again and go to the TPM Con-...
Page 123: Pending Tpm Operation (Security Menu > Tpm Support & Tpm State Enabled)
BIOS Utilities Pending TPM operation (Security Menu > TPM Support & TPM State Enabled) Select Pending TPM operation, press Enter and select the option you require (if you are initializing TPM you should select Enable Take Ownership). You will then need to press F4 to save the changes and restart the computer.
Page 124: Boot Menu
BIOS Utilities Boot Menu Figure 5 - 8 Boot Menu  BIOS Screens Note that BIOS screens pictured these pages are intend- ed for guidance in set- ting up your system’s BIOS. BIOS versions are sub- ject to constant change and revision, therefore your computer’s actual When you turn the computer on it will look for an operating system (e.g.
Page 125: Boot Option Priorities (Boot Menu)
BIOS Utilities Boot Option Priorities (Boot Menu) Press Enter to select the Boot Option # and use the keys to move any de- vice’s boot priority up and down the list (the selected device will be highlighted in white). OS Select (Boot Menu) This item tells allows you to set the operating system you intend to use.
Page 126: Save & Exit Menu
BIOS Utilities Save & Exit Menu Figure 5 - 9 Save & Exit Menu Select Save Changes and Reset to save any changes made to the BIOS. Choosing to Discard Changes, or Exit Discarding Changes, will wipe out any changes you have made to the Setup.
Page 127: Upgrading The Computer Overview
Upgrading The Computer Chapter 6: Upgrading The Computer Overview  This chapter contains information on upgrading the computer. Follow the steps out- Warranty Warning lined to make the desired upgrades. If you have any trouble or problems you can con- tact your service representative for further help.
Page 128: When Not To Upgrade
Upgrading The Computer When Not to Upgrade  These procedures involve opening the system’s case, adding and sometimes replac- ing parts.You should not perform any of these upgrades if: Power Safety Warning Before you undertake • Your system is still under warranty or a service contract upgrade proce- •...
Page 129 Upgrading The Computer Upgrading the Processor If you want to upgrade your computer by replacing the existing processor with a fast- er/new one you will need to contact your customer service representative. We rec- ommend that you do not do this yourself, since if it is done incorrectly you may damage the processor or mainboard.
Page 130: Removing The Battery
Upgrading The Computer Removing the Battery  If you are confident in undertaking upgrade procedures yourself, for safety reasons Warranty Warning it is best to remove the battery. Before removing the battery disconnect the AC/ DC adapter from the computer first. Please check with your service representative...
Page 131: Upgrading The Optical (Cd/Dvd) Device
Upgrading The Computer Upgrading the Optical (CD/DVD) Device Locate the hard disk bay cover and remove screws & Remove the hard disk bay cover Remove the screw at point , and use a screwdriver to carefully push out the optical device at point Reverse the process to install any new optical device.
Page 132: Upgrading The Hard Disk Drive(S)
Upgrading The Computer Upgrading the Hard Disk Drive(s)  The hard disk drive(s) can be taken out to accommodate other 2.5" serial (SATA) HDD System Warning hard disk drives with a height of 9.5mm (h) (see “Storage” on page E - 3).
Page 133 Upgrading The Computer Removing the Hard Disk(s) from the Primary HDD Bay  Turn the computer off, remove the AC/DC adapter, turn it over and remove the bat- tery. RAID Hard Disks Locate the hard disk bay cover and remove screws &...
Page 134 Upgrading The Computer Remove screws from the hard disk assembly. Carefully pull up the tab to disconnect the hard disk cable Carefully (the HDD case edges may be sharp) apply pressure using two fingers at & points Lift the assembly out of the bay and separate the hard disk board from the case by pulling on the tab Figure 6 - 4...
Page 135 Upgrading The Computer Remove screws (depending on how many hard disks you have installed in the assembly). Separate the hard disk(s) & from the case and mylar insulation cover 10. Reverse the process to install any new disk(s) and do not forget to install the insulation plate (onto the upper hard disk), screws, cables and covers (pay careful attention to the orientation of the hard disks in the case).
Page 136 Upgrading The Computer Removing the Hard Disk from the Secondary HDD Bay Remove the battery (the Secondary hard disk bay is located under the battery). Remove screws from the hard disk assembly. Grip the tab and slide the hard disk assembly in the direction of the arrow Lift the hard disk assembly out of the compartment.
Page 137 Upgrading The Computer Remove the screws to release the hard disk from the case Reverse the process to install any new hard disk(s). Figure 6 - 7 Secondary HDD Case Removal Upgrading the Hard Disk Drive(s) 6 - 11...
Page 138: Upgrading The System Memory (Ram)
Upgrading The Computer Upgrading the System Memory (RAM) The computer has four memory sockets for 204 pin Small Outline Dual In-line (SO- DIMM) DDR III (DDR3) type memory modules (see “Memory” on page E - The total memory size is automatically detected by the POST routine once you turn on your computer.
Page 139 Upgrading The Computer Turn the computer over, open the Lid/LCD, and carefully (a cable is connected to the underside of the LED cover module) unsnap up the LED cover module from point on the right. Figure 6 - 9 LED Cover Module Removal Lift up the LED cover module and disconnect cable...
Page 140 Upgrading The Computer Remove screws from the keyboard. Figure 6 - 11 Keyboard Screw Removal Carefully lift the keyboard up, being careful not to bend the keyboard ribbon cable or keyboard LED cable. Disconnect the keyboard ribbon cable from the locking collar socket, and the keyboard LED cable from its locking collar socket.
Page 141 Upgrading The Computer Remove the keyboard Figure 6 - 13 Keyboard Removal Remove screws from the keyboard shielding plate. Figure 6 - 14 Keyboard Shielding Plate Screws Upgrading the System Memory (RAM) 6 - 15...
Page 142 Upgrading The Computer 10. Remove the keyboard shielding plate Figure 6 - 15 Keyboard Shielding Plate Removal  Contact Warning Be careful not to touch 11. Gently pull the two release latches ( & on the sides of the memory socket in the metal pins on the the direction indicated below.
Page 143 Upgrading The Computer 12. The RAM module will pop-up, and you can remove it.  Contact Warning Be careful not to touch the metal pins on the module’s connecting edge. Even the cleanest hands have oils which can attract particles, and degrade the module’s performance.
Page 144 Upgrading The Computer 16. Replace the screws and shielding plate Figure 6 - 18 Keyboard Shielding Plate Insertion 17. Replace the keyboard and make sure you reconnect the keyboard cable. 18. Reconnect the keyboard ribbon cable to the locking collar socket, and the keyboard LED cable to its locking collar socket.
Page 145 Upgrading The Computer 19. Reconnect the LED Module cable (see Figure 6 - 10). 20. Snap the LED cover module down at the top of the module at points & 21. Push the LED cover module down on the left side at point , and then slide the module to the right (as illustrated) and snap down to secure it in place.
Page 146 Upgrading The Computer Removing the Secondary System Memory (1 memory socket) Turn off the computer, and turn it over and remove the battery. Remove screws and component bay cover Figure 6 - 21 Component Bay Cover Removal Carefully disconnect CPU fan cables &...
Page 147 Upgrading The Computer Carefully (they may be hot) pull the plastic tabs to lift up the heatsink off the computer. Figure 6 - 23 CPU Heatsink Removal Remove screws from the fan unit, disconnect the fan cable , and lift the fan unit off the computer.
Page 148 Upgrading The Computer Gently pull the two release latches ( & on the sides of the memory socket in  the direction indicated below. The RAM module will pop-up, and you can remove it. Contact Warning Be careful not to touch the metal pins on the module’s connecting...
Page 149 Upgrading The Computer 11. Replace the fan unit above the RAM module slot and replace screws , then reconnect the cable Figure 6 - 26 Fan Unit Screws & Cable 12. Carefully Insert the heatsink Figure 6 - 27 Heatsink Insertion Upgrading the System Memory (RAM) 6 - 23...
Page 150 Upgrading The Computer 13. Tighten the CPU heat sink screws , and replace screws & in the order indicated on the label (i.e. tighten screw first, and lastly replace screw 14. Replace the component bay cover and screws. Figure 6 - 28 Heatsink Screws &...
Page 151: Upgrading The Video Card
Upgrading The Computer Upgrading the Video Card  If you intend to upgrade or add another video card follow the procedures outlined Warranty Warning here. However please check with your service representative first to make sure your computer can support more than one video card, and that you are not going to void Please check with your service representative...
Page 152 Upgrading The Computer The video card(s) will be visible at point on the mainboard (one video card is  pictured). Carefully disconnect the video card fan cable(s) , and remove screws Caution Remove the fan unit The heat sink, and video card area in general, contains parts which are subject to high tempera-...
Page 153 Upgrading The Computer Remove screws from the heat sink in the order indicated on the heat  sink unit label (and heat sink itself). Heat Sink Screws Make sure you remove the heat sink screws in the order (screw first to screw last).
Page 154 Upgrading The Computer Carefully pull the tab and lift with the other tab to disconnect the heat sink  from the VGA assembly. Remove the heat sink unit(s) (one heat sink unit is pictured here). Caution The heat sink, and video card area in general, contains parts which are subject to high tempera-...
Page 155 Upgrading The Computer 10. Only use a flat-headed screwdriver (do not try to use any other screwdriver type  here) to remove screws & 11. Carefully remove the video card Caution The heat sink, and video card area in general, contains parts which are subject to high tempera- tures.
Page 156 Upgrading The Computer Dual Video Cards  If your system includes two video cards you will need to disconnect the cable tween the master and slave cards (do not forget to reconnect the cable if you are re- Dual Video Card Connection placing two cards).
Page 157 Upgrading The Computer Installing a New Video Card  Do not forget to replace the master and slave cable if you are replacing two video cards (see Figure 6 - 34 on page 6 - 30). Contact Warning Prepare to fit the video card into the slot by holding it at about a 30° angle. Be careful not to touch the metal pins on the VGA card’s connecting...
Page 158 Upgrading The Computer Fit the connectors firmly into the socket, straight and evenly. DO NOT attempt to push one end of the card in ahead of the other. Figure 6 - 36 Video Card Insertion Procedure The card’s pin alignment will allow it to only fit one way. Make sure the module is seated as far into the socket as it will go (none of the gold colored contact should be showing).
Page 159 Upgrading The Computer Secure the card with screws & Figure 6 - 37 Video Card Screws Upgrading the Video Card 6 - 33...
Page 160 Upgrading The Computer Hold the heatsink by the tab & and insert it back on the card as pictured.  Secure the screws in the order indicated on the heat sink unit label (and heat sink itself). Heat Sink Screws Make sure you remove the heat sink screws in the order...
Page 161 Upgrading The Computer 10. Reinsert the fan(s) and secure with screws and fan cable 11. Replace the component bay cover and screws Figure 6 - 39 Fan Unit Screws & Component Bay Cover Screws Upgrading the Video Card 6 - 35...
Page 162 Upgrading The Computer  NVIDIA® SLI or AMD CrossFireX™ Multi GPU Configuration & Power This computer features an NVIDIA® Scalable Link Interface (SLI) or AMD CrossFireX™ technology configuration that improves graphic quality and performance by combining dual GPUs (two video cards are required) in a single system. Note that due to the high power and system demands created by enabling a multi GPU configuration, you should not power the system using the battery only and you will require identical dual power adapters, connected to a power converter box to power the system (see...
Page 163: Modules Overview
Modules Chapter 7: Modules Overview This chapter contains information on the various modules (some of which are op- tional) which may come with your computer, depending on the configuration pur- chased. If you are unsure please contact your service representative. The chapter includes information on the following: •...
Page 164: Setting Up Sata Raid Or Ahci Mode
Modules Setting Up SATA RAID or AHCI Mode  AHCI Mode RAID Hard Disks Advanced Host Controller Interface (AHCI) is an interface specification that allows All hard disks in a RAID the storage driver to enable advanced serial ATA features such as Native Command should be identical (the Queuing (for maximum hard disk efficiency and performance).
Page 165 Modules RAID Level Description Two Identical drives reading and writing data in parallel to increase performance. RAID 0 RAID 0 implements a striped disk array and the data is broken into blocks and each block is written to a separate disk drive. Two Identical drives in a mirrored configuration used to protect data.
Page 166 Modules Prepare the following before setting up your serial ATA hard disks in RAID mode (to con- figure AHCI mode you do not need to prepare any extra hard disks but will need to install the Intel® Rapid Storage Technology application): The Microsoft Windows 7 OS DVD.
Page 167: Sata Raid Setup Procedure (Bios)
Modules SATA RAID Setup Procedure (BIOS) Start-up your notebook computer and press <F2> to enter the BIOS. Go to the Advanced menu, select "SATA Mode" and press Enter (see page • Select “RAID Mode”. Go to the Boot menu. Set the DVD-ROM Drive (make sure the Microsoft Windows 7 OS DVD is inserted) as the first device in the boot order from the Boot menu (see “Boot Menu”...
Page 168: Raid Setup (Intel Matrix)
Modules RAID Setup (Intel Matrix) As the computer starts up press Ctrl + i to enter RAID configuration menu. Figure 7 - 1 Intel(R) Rapid Storage Technology enterprise - SATA Option ROM - 3.0.0.1184 Intel(R) Rapid Copyright (C) 2003-11 Intel Corporation. All Rights Reserved. [ MAIN MENU Storage Technology Create RAID Volume...
Page 169 Modules Press Enter and the system will select the physical disks to use (see sidebar for  Recovery Level). Press Enter and select (if applicable) the Strip Size (best set to default). Recovery Level Press Enter and select the Capacity size (best set to default). Press Enter to select Create Volume.
Page 170 Modules 12. Make sure the Windows 7 OS DVD is in the DVD drive, and as the computer starts up it will automatically boot from the Windows 7 OS DVD (you will be prompted to press a key to boot from the DVD). 13.
Page 171 Modules Press a key at system startup to begin installing Windows from your Microsoft Windows 7 disc (make sure the DVD device is set at the top of the Boot Sequence in the BIOS - see “Boot Option Priorities (Boot Menu)” on page 5 - 17).
Page 172 Modules 12. Follow the on-screen instructions to install the Windows 7 operating system. 13. Install the Windows drivers from the Device Drivers & Utilities + User’s Manual disc as per Table 4 - 1, on page 4 - 3 (make sure you install the Intel Rapid Storage Technology driver - see “IRST Driver Installation”...
Page 173: Intel Rapid Storage Technology
Modules Intel Rapid Storage Technology  The Intel Rapid Storage Technology application provides high-performance SATA and SATA RAID capabilities. Install the Intel Rapid Storage Technology Intel® Control Center application to support your RAID system or SATA drive if set up in AHCI mode in the BIOS (see “SATA Mode (Advanced Menu)”...
Page 174: Intel® Rapid Storage Technology For Raid Systems
Modules Intel® Rapid Storage Technology for RAID Systems Intel® Rapid Storage Technology application displays status information on your RAID configuration. Run the Intel® Rapid Storage Technology enterprise appli- cation from the Intel item in the All Programs menu. When the Intel® Rapid Storage Technology enterprise application is launched the system will open the Status window.
Page 175 Modules Intel® Rapid Storage Technology Help  If a hard drive member of a RAID volume is reported as “Degraded” or “Failed” it may be possible to recover the volume. If the volume cannot be restored then you Help will need to recreate the RAID volume and restore the data from a back up. Click the Click the Help (or Help menu (or press F1) for instructions on how to recover or recreate RAID Vol-...
Page 176: Raid Volume Data Verification And Repair
Modules RAID Volume Data Verification and Repair The RAID volume data verification process identifies any inconsistencies or bad data on a RAID 0, RAID 1 or RAID 5 volume. The table outlines what occurs for each RAID level: RAID Verify Verify &...
Page 177 Modules Verifying and Repairing RAID Volume Data Initializing, Before verifying the volume data you will need to initialize the volume. Run the Intel® Rapid Storage Technology enterprise application from the Intel item in the All Programs menu. Click the volume icon and click Initialize in Volume Properties. Click Yes (button) to begin the process.
Page 178 Modules After the initialization process you will need to verify the volume. Click the volume icon and click Verify, in Volume Properties. Click Verify (button) to begin the process. The completion percentage will be listed under Information. Verify Figure 7 - 6 ®...
Page 179: Pc Camera Module
Modules PC Camera Module  Before installing the driver, make sure the PC Camera is on. Use the Fn + F10 key Latest PC Camera combination or Touch Sensor Instant Key to toggle power to the PC Cam- Driver Information era module.
Page 180: Pc Camera Driver Installation
Modules PC Camera Driver Installation 1. Insert the Device Drivers & Utilities + User’s Manual disc into the CD/ DVD drive. 2. Click Option Drivers (button). 3. Click 1.Install Webcam Driver > Yes. 4. Click Finish to restart the computer. Click Next >...
Page 181: Pc Camera Audio Setup
Modules PC Camera Audio Setup If you wish to capture video & audio with your camera, it is necessary to setup the audio recording options in Windows. Click Start, and click Control Panel (or point to Settings and click Control Panel). Click Sound (Hardware and Sound).
Page 182 Modules Figure 7 - 7 Audio Setup for PC Camera Right-click 7 - 20 PC Camera Module...
Page 183 Modules Camera Application The camera application is a video viewer for general purpose video viewing and test- ing, and for capturing video files to .avi format. Run the camera application from the desktop shortcut (it is recommended that you set the capture file before the capture process - see below). Go to the Capture menu heading (if you wish to capture audio check “PC Camera Audio Setup”...
Page 184 Modules Reducing Video File Size Note that capturing high resolution video files requires a substantial amount of disk space for each file. After recording video, check the video file size (right-click the file and select Properties) and the remaining free space on your hard disk (go to My Computer, right-click the hard disk, and select Properties).
Page 185 Modules Eliminating Screen Flicker  If you find that the video screen in the camera program is flickering, you can try to adjust the setting in the Video Capture Filter options. Latest PC Camera Driver Information Run the camera application from the desktop shortcut. Go to Options and scroll down to select Video Capture Filter..
Page 186 Modules Taking Still Pictures  The camera application allows you to take still pictures. Snapshot Folder Run the camera application from the desktop shortcut. Go to Options and select Take Picture. The Snapshot folder’s The picture (in JPEG format) will be placed in the Snapshot folder on the default location is on the desktop.
Page 187: Wireless Lan Module
Modules Wireless LAN Module  If you have included an Intel®, 3rd Party 802.11b/g/n or Qualcomm Atheros Wireless Device WLAN (Combo) module in your purchase option, make sure that the Wireless LAN Operation Aboard module is on before installing the driver. See “Wireless LAN Settings (Windows 8)”...
Page 188: 3Rd Party 802.11B/G/N Wlan Combo Driver Installation
Modules 3rd Party 802.11b/g/n WLAN Combo Driver Installation 1. If you see the message “Found New Hardware” click Cancel to close the window. 2. Make sure the module is powered on, and then insert the Device Drivers & Utilities + User’s Manual disc into the CD/DVD drive. 3.
Page 189: Intel® Wlan Driver Installation
Modules Intel® WLAN Driver Installation For a standard Intel® WLAN driver installation and configuration choose the Typ- ical Installation below and use the Windows OS for Wireless LAN control (see overleaf). If you want to use Intel® PROSet/Wireless WiFi Connection Utility as your WLAN interface see overleaf.
Page 190 Modules Custom Installation (for Intel® PROSet/Wireless WiFi Connection Utility):  1. If you see the message “Found New Hardware” click Cancel to close the window. Intel® My WiFi 2. Make sure the module is powered on, and then insert the Device Drivers If you want to install In- &...
Page 191 Modules Figure 7 - 9 Install Intel® PROSet/Wireless WiFi Software Wireless LAN Module 7 - 29...
Page 192: Qualcomm Atheros Wlan Combo Driver Installation
Modules Qualcomm Atheros WLAN Combo Driver Installation 1. If you see the message “Found New Hardware” click Cancel to close the window. 2. Make sure the module is powered on, and then insert the Device Drivers & Utilities + User’s Manual disc into the CD/DVD drive. 3.
Page 193 Modules Qualcomm Atheros Killer Network Manager  You can use the Qualcomm Atheros Killer Network Manager to monitor your network connection (use the method outlined on page 7 - 37 to connect to a WLAN Killer Network access point). Manager Go to the Qualcomm Atheros Killer Network Manager by double-clicking the The Killer Network Man- ager allows you to:...
Page 194 Modules PC Monitor The PC Monitor logs performance information on the computer. Use the drop- down menu to select Processor, Memory, FPS (frames per second), Wireless Signal Strength and Internet Bandwidth. You can click on the graph to display to display the time and measurement at that point.
Page 195 Modules Applications  The Applications window allows you to view network applications and prioritize how each one uses any available bandwidth. The numbers to the left indicate the cur- Changing rent priority level for the application, from 1 - highest to 4 - lowest. Click in an ap- Application plication to expand the item, and click the number to change the priority level, or Bandwidth...
Page 196 Modules Network Configure the network connection settings and internet provider bandwidth speed from the Network window. Click Test to run a test of your bandwidth, and when complete use the results to configure the optimal upload and download bandwidth for the Killer Network Manager (these are the maximum values displayed in Appli- cations).
Page 197 Modules Advanced  Customize Killer Network Manager features from the Advanced window. Here you can change items displayed in Overview, configure default settings for Applications Help and features such as updates, closing dialog, bandwidth units displayed and perfor- access Help mance statistics.
Page 198 Modules Quitting Killer Network Manager Clicking the close icon simply minimizes the application to the system tray, and it will continue to run in the background. To quit the application right-click the icon in the system tray and select Quit from the menu. Figure 7 - 15 Killer Network Manager - Quit...
Page 199: Connecting To A Wireless Network In Windows 7
Modules Connecting to a Wireless Network in Windows 7  Make sure the Wireless LAN module is turned on. Click the taskbar wireless icon , and then double-click an access point to con- Network and nect to or click to Open Network and Sharing Center if you do not see a network Sharing Center you want to connect to in the taskbar menu (a list of options will appear allowing You can also use the Net-...
Page 200 Modules You may need to enter a security key for any access point to which you are trying to connect. Click to select a network location (e.g. Home, Work or Public). Click “View or change settings in Network and Sharing Center” to access further options for the connection.
Page 201 Modules Click the taskbar icon to see any currently connected networks.  To disconnect from the wireless network you can click the taskbar wireless icon , click the active connection and then click Disconnect (button). Security Enabled Networks You should try to make sure that any network you are connecting to is a se- cure network.
Page 202: Connecting To A Wireless Network Using Intel® Proset Wireless
Modules Intel Connecting to a Wireless Network Using ® PROSet Wireless (For Intel® WLAN Modules Only) Make sure the Wireless LAN module is on. Access the Intel® WiFi Connection Utility from the Start menu (Start > All Programs > Intel PROSet Wireless > WiFi Connection Utility). Click to select a network from the found list WiFi network access points, or click Refresh to update the list.
Page 203 Modules Click Connect to connect to the select WiFi network access point. If the access point is encrypted then you will need to enter the password and click Figure 7 - 20 Intel® PROSet/ Wireless WiFi Connection Utility (Connecting & Connected) You can turn WiFi On/WiFi Off from the button at the bottom of the Utility.
Page 204: Windows Mobility Center
Modules Windows Mobility Center The Windows Mobility Center control panel provides an easy point of access for information on battery status, power plans used and wireless device status etc. To access the Windows Mobility Center: Click Start, and click Control Panel (or point to Settings and click Control Panel).
Page 205: Security Modules (Fingerprint & Tpm)
Modules Security Modules (Fingerprint & TPM)  The encrypted channel between the Trusted Platform Module security chip (see Password Warning “Trusted Platform Module” on page 7 - 75) and the fingerprint reader with appli- cation software (see “Fingerprint Reader Module” on page 7 - 44) provides a high If you set passwords for level of security for your computer.
Page 206: Fingerprint Reader Module
Modules Fingerprint Reader Module The fingerprint reader module provides a high level of security for your computer. Make sure you have administrator’s rights to your computer, and have a Windows password enabled for full security protection. There are three fingerprint applications supplied with this model. Install the driver from the Device Drivers &...
Page 207: Authentec Truesuite Fingerprint Reader Driver Installation
Modules AuthenTec TrueSuite Fingerprint Reader Driver Installation 1. Insert the Device Drivers & Utilities + User’s Manual disc into the CD/ DVD drive. 2. Click Option Drivers. 3. Click 3.Install Fingerprint Driver > Yes. 4. Click Next. 5. Click the button to accept the license and click Next. 6.
Page 208: Authentec Truesuite Application
Modules AuthenTec TrueSuite Application  The AuthenTec TrueSuite application is used in conjunction with your fingerprint reader to enroll fingerprints and manage settings etc. Fingerprint Enrollment User Enrollment Note that it is strongly rec- Click Start > All Programs > AuthenTec TrueSuite. ommended that you enroll Click Yes when you have identified your fingerprint sensor ( Fingerprint...
Page 209 Modules You will be prompted to select another finger for enrollment (it is recommended  that you enroll a number of fingers - see sidebar). Click the button to continue once you have enrolled a number of fingerprints. Help Enter the required information and click the button to register your software, or click to register later.
Page 210 Modules Settings Click the Settings button on the menu bar to access the personalization settings for AuthenTec TrueSuite. Here you can choose to enable/disable Website Log On, QuickLaunch, Fast User Switching and the desktop icon. You can also select the Theme and export/import identities.
Page 211 Modules Windows Log On Windows log on allows you to gain access to your computer by swiping your finger across the fingerprint reader sensor. Use the Biometric Devices control panel (in the Hardware & Sound category) in Windows to turn Biometrics on/off when re- quired.
Page 212 Modules Website Log On Use a fingerprint swipe to log on to websites to help you avoid having to remember user names and passwords across multiple websites (browsers supported are Internet Explorer, Firefox and Chrome). Registering a Website Use your web browser to navigate to the website required. Enter your user name and password and sign in to the website.
Page 213 Modules QuickLaunch QuickLaunch allows you to drag and drop icons (which represent websites, folders, applications and/or computer actions) to any enrolled finger and then swipe your fin- ger to launch the icons assigned to that finger. Click Start > All Programs > AuthenTec TrueSuite. Click Select Category (button) to group icons if required.
Page 214 Modules Adding a Website to QuickLaunch Click Start > All Programs > AuthenTec TrueSuite. Click the Add Website button on the menu bar and the dialog box will be displayed. Enter the website URL, name, icon and category as required. Click Save and an icon will be associated with the selected website.
Page 215 Modules Dock View Dock View displays the website icons across the bottom of the screen. Each icon wiLl have an associated web card which displays the website information, user name and password etc. This information may be edited or deleted as required. Figure 7 - 30 Dock View Editing a Web Card...
Page 216 Modules Exporting and Importing Your Identity You can export your identity to backup your information, or to move it to another computer. Exporting Your Identity Click Start > All Programs > AuthenTec TrueSuite. Click the Settings button on the menu bar. Click Export My Identity.
Page 217 Modules AuthenTec KeepSafe The KeepSafe folder is an encrypted area assigned on your hard drive that allows you to store files and folders to be protected by fingerprint protection. The folder will appear on your desktop (if selected in the Personalization Settings) and in My Computer, but will not be visible to other users of your computer.
Page 218: Bioexcess Application
Modules BioExcess Application The BioExcess application is used in conjunction with your fingerprint reader to en- roll fingerprints and manage settings etc. User Enrollment Click Start > All Programs EgisTec > BioExcess. Identify your fingerprint sensor ( Fingerprint Reader Module in Figure 1 - 2 on page 1 - Click Next when the Initial Wizard appears.
Page 219 Modules Enter your Windows log on password, and then click Next.  Click on the fingerprint diagram to select any finger to enroll. Swipe the finger until the finger is enrolled and then repeat for other fingers. Fingerprint Click Next to continue once you have enrolled a number of fingerprints. Enrollment Note that it is strongly recommended that you...
Page 220 Modules BioExcess Control Center Click Start > All Programs EgisTec > BioExcess and swipe a registered finger to run the Control Center (or swipe a finger across the fingerprint sensor and select Control Center from the BioExcess Menu). Figure 7 - 34 BioExcess Menu &...
Page 221 Modules Use the Control Center to adjust all the BioExcess application settings. Click on  any of the menu headings to access the sub-menu to adjust functions or settings in- cluding Fingerprint Management, Data Protection, Online Accounts Manage- Help ment, General settings and Information. Click the Help icon and select a help topic...
Page 222 Modules Fingerprint Management Fingerprint Enrollment: You can add or delete enrolled fingers by clicking in the box above any of the fingers. Application Launcher: Use any of your fingers to launch any chosen application, website, online account or use Launch Express to launch functions such as Shut Down, Windows Lock etc.
Page 223 Modules • Simply drag and drop an executable file onto any enrolled fingers to launch an application, or click and select Launch Application and then browse to the exe- cutable file. • Select Launch Web Site and then input the URL to use a finger to go to any website.
Page 224 Modules Data Protection File Encryption/Decryption: Click Add or drag and drop any file for encryption/ decryption. Click Encrypt and you will be asked for a backup pass ow rd for the file. You can right-click any file and select Decrypt/Encrypt File from the BioExcess item in the menu.
Page 225 Modules Online Accounts Management You can store user IDs and passwords for websites and/or applications and the soft- ware will then automatically fill in your log on and password information for you when you swipe your finger. When you visit a registered website or program you will see a BioExcess icon in the top left of the screen prompting you to swipe a finger to log on.
Page 226 Modules General Settings User Settings: Fast User Switch enables multiple users to switch to their own Win- dows environment with the swipe of a finger. Use Pre-Boot Authentication to pre- vent the Windows OS from loading until the password has been confirmed. Password Settings: You can change your backup password and Windows password settings from this menu.
Page 227 Modules Data Backup Settings: Use this menu to set the location of the back up data (click Browse and set location), manage the backup password and to select which items are backed up (enrolled fingerprints and online accounts data). Figure 7 - 41 Control Center Data Backup Settings...
Page 228 Modules Information These menu items provide online information on your software version, support and any new features. You can also access the animated Tutorial on Online Accounts, Swipe One and Secure Drive. Figure 7 - 42 Control Center Information 7 - 66 BioExcess Application...
Page 229: Bluetooth Module
Modules Bluetooth Module  If your purchase option includes the Combination Wireless LAN Bluetooth mod- Wireless Device ule (either Intel® or 3rd Party) then install the driver as instructed (note that the Operation Aboard Qualcomm Atheros WLAN (Combo) module only requires the WLAN driver in- Aircraft stallation).
Page 230 Modules Use the Fn + F12 key combination or Touch Sensor Instant Key to toggle  power to the Bluetooth module. When the Bluetooth module is powered on the LED will be highlighted and the indicator will briefly be displayed. Bluetooth Headset Stereo Setup •...
Page 231: 3Rd Party Bluetooth (V4.0) Combo Driver Installation
Modules 3rd Party Bluetooth (V4.0) Combo Driver Installation 1. Before installing the driver make sure the Bluetooth module is powered on (use Fn + F12 key combination), then insert the Device Drivers & Utili- ties + User’s Manual disc into the CD/DVD drive. If a Found New Hard- ware window appears, click Cancel in all windows that appear, and then proceed to install the driver as below.
Page 232: Intel Bluetooth Combo Driver Installation
Modules Intel Bluetooth Combo Driver Installation  1. Before installing the driver make sure the Bluetooth module is powered on (use Fn + F12 key combination), then insert the Device Drivers & Utili- High Speed Bluetooth Data Transfer ties + User’s Manual disc into the CD/DVD drive. If a Found New Hard- ware window appears, click Cancel in all windows that appear, and then The Combination Wire- less...
Page 233: Standard Bluetooth Configuration In Windows 7
Modules Standard Bluetooth Configuration in Windows 7  Setup your Bluetooth Device so the Computer Can Find it Turn your Bluetooth device (e.g. PDA, mobile phone etc.) on. Add a Device Make the device discoverable (to do this check your device documentation). Click Start, and click Con- trol Panel and then click To Turn the Bluetooth Module On...
Page 234 Modules To Add a Bluetooth Device  Access the Bluetooth Devices control panel and click Add a device. Double-click the device you want to pair with the computer. Pairing Options If a device has been pre- viously connected then the pairing option menu will appear when you at- tempt subsequent con- nections.
Page 235 Modules Enter the code into your Bluetooth enabled device and follow any on-screen instructions to complete the pairing.  Figure 7 - 45 Pairing Codes Pairing Code Example The example outlined here shows a connection to a mobile device. Other devices e.g. computers, may have a slightly different connection proce- dure, and may require you to confirm a pairing code is correct on both devices.
Page 236 Modules To Change Settings for the Bluetooth Device  Click the notification area icon and select Show Bluetooth Devices. Right-click on the device you want to change and click Properties to: Bluetooth Help • Change the name of the device (click Bluetooth, type a new name and click OK). •...
Page 237: Trusted Platform Module
Modules Trusted Platform Module The TPM security chip allows you to create and manage digital certificates for user and platform authentication. This type of security is usually administered within large enterprises and organizations, and therefore requires implementation by a sys- tem administrator before users can access security features.
Page 238: Enabling & Activating Tpm
Modules Enabling & Activating TPM Restart the computer. Enter the Aptio Setup Utility pressing F2 during the POST/startup. Use the arrow keys to select the Security menu. Select Trusted Computing and press Enter to access the sub-menu. Press Enter to access the TPM Support menu and select Enable to display the full TPM configuration menu.
Page 239 Modules Select Pending TPM operation, press Enter and select the option you require (if you are initializing TPM you should select Enable Take Ownership). You will then need to press F4 to save the changes and restart the computer. Figure 7 - 49 Pending TPM operation (Enable Take...
Page 240: Trusted Platform Module (Tpm) Driver Installation
Modules Trusted Platform Module (TPM) Driver Installation 1. Make sure you have enabled and activated the TPM in the BIOS before installing the driver (if you do not do see the note below). 2. Insert the Device Drivers & Utilities + User’s Manual disc into the CD/ DVD drive.
Page 241: Initializing Tpm
Modules Initializing TPM Run the application from the Infineon Security Platform Solution > Manage Security Platform item in the Start > Programs menu. Click User Settings (tab) and click Yes, or right-click the icon in the notification area of the taskbar, and select Security Platform Initialization (or click the Security Platform State taskbar bubble).
Page 242 Modules Choose the Security Platform Features you want to use by clicking the  appropriate tickbox. Enter a Basic User Password (and re-type to confirm it) and click Next. Help Right-click the icon the notification area of the taskbar to bring up the menu to select Help or How to use the Security Platform Fea- tures.
Page 243: Infineon Security Platform Settings Tool
Modules Infineon Security Platform Settings Tool  The Infineon Security Platform Settings Tool allows you to manage and check the TPM state, manage your password information, and to backup and restore the TPM Menus data. As TPM is usually administered within large enterprises and organizations, Note that not all the your system administrator will need to assist you in managing the information here.
Page 244 Modules User Settings This page allows the settings to be configured for the currently logged in Infineon Security Platform user including the ability to change the password, configure se- cure e-mail, file and folder encryption and Enhanced Authentication. You can also import or delete certificates protected by the security platform.
Page 245 Modules Backup Here you can configure backup and restore operations. Backup files contain the computer identification and user identification information which is used to match the machine name and user name with the current machine and user during restora- tion. Figure 7 - 54 Infineon Security Platform Settings...
Page 246 Modules Migration The Migration tab is used to help securely transfer keys and certificates from one platform to another. Figure 7 - 55 Infineon Security Platform Settings Tool (Migration) 7 - 84 Trusted Platform Module...
Page 247 Modules Password Reset Use Password Reset to reset basic user passwords when required. Figure 7 - 56 Infineon Security Platform Settings Tool (Password Reset) Trusted Platform Module 7 - 85...
Page 248 Modules BitLocker BitLocker Drive Encryption can be used in conjunction with the TPM to encrypt data on the disk and is done via the Microsoft BitLocker Control Panel Applet. Click Configure and select a drive to be encrypted and then follow the Wizard to begin the encryption process.
Page 249 Modules Access the Microsoft BitLocker Drive Encryption control panel applet from the Windows control panel (System and Security). Figure 7 - 58 BitLocker Drive Encryption Trusted Platform Module 7 - 87...
Page 250 Modules Advanced Configure all the Security Platform owner and policy settings from the Advanced tab. The settings that can be changed are for the local computer only. Figure 7 - 59 Infineon Security Platform Settings Tool (Advanced) 7 - 88 Trusted Platform Module...
Page 251: Sound Blaster Audio
Modules Sound Blaster Audio Install the Sound Blaster AP to allow you to configure the audio settings to your requirements for the best performance in games, music and movies. Sound Blaster X-Fi MB-3 Audio AP Installation 1. Insert the Device Drivers & Utilities + User’s Manual disc into the DVD drive.
Page 252: Sound Blaster X-Fi Mb-3 Audio Ap Installation
Modules Volume Controls You can click on the volume dials to adjust the level for either the microphone or master volume. You can choose to save the settings for Music, Movie or Game, and these settings can be exported or imported as required. Figure 7 - 61 Sound Blaster X-Fi 3 Volume Controls...
Page 253 Modules SBX Pro Studio  Click the tickbox to enable/disable the control, and use the slider to adjust the levels. Press the play button to test settings. Smart Volume Setting The default setting for Smart Volume in SBX Pro Studio is set to Normal.
Page 254 Modules Scout Mode Click in the box to enable Scout Mode to enhance your ability to hear enemies in games from a further distance away than would normally be possible. Figure 7 - 63 Sound Blaster X-Fi 3 Scout Mode 7 - 92 Sound Blaster Audio...
Page 255 Modules Voice FX Click in the box to enable Voice FX and click on the sliders to adjust the settings. Select the mode required from the dropbox, and click on Test to hear the playback of the effect. Figure 7 - 64 Sound Blaster X-Fi 3 Voice FX Sound Blaster Audio 7 - 93...
Page 256 Modules EAX Effects & EQ Click to select either/or EAX Effects or EQ, select the mode required from the drop- box and click on the sliders to adjust the settings. Click on Save to save any custom changes to the set levels and effects. Figure 7 - 65 Sound Blaster X-Fi 3 EAX Effects &...
Page 257 Modules Advanced Settings Select the speaker/headphone configuration from the dropbox, and click on Test to hear the effect. You can also adjust the Bass Management by clicking the Bass Re- direction and Subwoofer Gain, and click on the slider to adjust the Crossover Fre- quency.
Page 258 Modules Hot Key Configuration Click Configure Hot Keys in Scout Mode or Advanced Settings menus to access the Hot Key Configuration menu. Click Enable All Hot Keys, and then click on the task and press the key sequence required. Any hotkeys chosen will be locked by the application, and therefore will not be able to be used in other applications.
Page 259 Modules Creative ALchemy The Creative ALchemy application can be run from the shortcut in the Start menu. Use the left menu to select any installed games and click the button to move them to the right column to enable ALchemy support for the game. Creative ALchemy re- stores hardware accelerated audio to enable EAX effects and 3D Audio when play- ing Direct Sound3D games.
Page 260: Irst Driver
Modules IRST Driver Install the Intel Rapid Storage Technology to support your SATA drive if set up in AHCI mode in the BIOS (see “SATA Mode (Advanced Menu)” on page 5 - 9) or if you have set up your hard disks in a RAID configuration (“Setting Up SATA RAID or AHCI Mode”...
Page 261: Troubleshooting
Troubleshooting Chapter 8: Troubleshooting Overview Should you have any problems with your computer, before consulting your service representative, you may want to try to solve the problem yourself. This chapter lists some common problems and their possible solutions. This can’t anticipate every problem, but you should check here before you panic. If you don’t find the answer in these pages, make sure you have followed the instructions carefully and observed the safety precautions in the preface.
Page 262: Basic Hints And Tips
Troubleshooting Basic Hints and Tips Many of the following may seem obvious but they are often the solution to a problem when your computer ap- pears not to be working. • Power - Is the computer actually plugged into a working electrical outlet? If plugged into a power strip, make sure it is actually working.
Page 263: Backup And General Maintenance
Troubleshooting Backup and General Maintenance • Always backup your important data, and keep copies of your OS and programs safe, but close to hand. Don’t forget to note the serial numbers if you are storing them out of their original cases, e.g. in a CD wal- let.
Page 264: Viruses
Troubleshooting Viruses • Install an Anti-Virus program and keep the definitions file (the file which tells your program which viruses to look for) up to date. New computer viruses are discovered daily, and some of them may seriously harm your computer and cause you to lose data. Anti-Virus programs are commercially available and the defini- tions file updates are usually downloadable directly from the internet.
Page 265: Upgrading And Adding New Hardware/Software
Troubleshooting Upgrading and Adding New Hardware/Software • Do not be tempted to make changes to your Windows Registry unless you are very sure of what you are doing, otherwise you will risk severely damaging your system. • Don’t open your computer or undertake any repair or upgrade work if you are not comfortable with what you are doing.
Page 266 Troubleshooting • Don’t over complicate things. The less you have to deal with then the easier the source of the problem may be found; Example - if your computer has many devices plugged into its ports, and a number of programs running, then it will be difficult to determine the cause of a problem.
Page 267: Problems & Possible Solutions
Troubleshooting Problems & Possible Solutions Problem Possible Cause - Solution You turned the power on Battery missing / incorrectly installed. Check the battery bay, make sure the battery is present and but it doesn’t work. seated properly (the design of the battery only allows it to go in one way). Make sure there’s nothing interfering with the battery contacts.
Page 268 Troubleshooting Problem Possible Cause - Solution The computer feels too Make sure the computer is properly ventilated and the vents/fan intakes are not blocked. If this hot. doesn’t cool it down, put the system into Hibernate mode or turn it off for an hour. Make sure the computer isn’t sitting on a thermal surface (see “Overheating”...
Page 269 Troubleshooting Problem Possible Cause - Solution forget boot If you forget the password, you may have to discharge the battery of the CMOS. Contact your password. service representative for help.  Password Warning If you choose to set a boot password, NEVER forget your password. The consequences of this could be serious. If you cannot remember your boot password you must contact your vendor and you may lose all of the information on your hard disk.
Page 270 Troubleshooting Problem Possible Cause - Solution I am sliding my finger up There are different TouchPad versions available on this computer, and this version requires and down on the right tapping/holding to scroll. Either tap repeatedly, or hold the finger down, at the top or bottom right side of the TouchPad to of the touchpad (depending on the scrolling direction required) to scroll the window.
Page 271 Troubleshooting Problem Possible Cause - Solution When a DVD is played in This is an issue with Windows Media Player/Media Center and audio output through the S/PDIF- Windows Media Player/ Out Jack. We recommend that you use the Power DVD application to play DVDs. Media Center, the audio track in other languages (commentaries etc.) is...
Page 272 Troubleshooting Problem Possible Cause - Solution have installed The audio driver is not installed. Install all the drivers as instructed in Chapter 4 "Drivers & Windows OS but cannot Utilities" and make sure you install the audio driver (see “Audio” on page 4 - hear any sound.
Page 273 Troubleshooting Problem Possible Cause - Solution The computer is off (or in The port is not powered on. Toggle power to the port using the Fn + power button combination. Sleep Mode) powered by the AC/DC This function may not work with certain external USB compliant devices (check your device’s doc- adapter plugged in to a umentation).
Page 274 Troubleshooting Problem Possible Cause - Solution When the battery is being This can occur as the battery cell performs poorly in a low temperature environment, especially used to power the system with a discharge rate of over 2C. Systems powered by the battery will perform normally at °...
Page 275 Troubleshooting Problem Possible Cause - Solution The Bluetooth module There is a conflict between an existing Bluetooth module and a Bluetooth & WLAN combination experiencing module. You should have only one Bluetooth module installed in order to prevent any problems/ 2 Bluetooth conflicts (this includes the Bluetooth element of any combination WLAN &...
Page 276 Troubleshooting Problem Possible Cause - Solution Note that after installing By default, Intel® Rapid Storage Technology is set to Automatic (Delayed Start). If you want IRST driver to change the setting then follow these steps to change the Startup type: Windows system Go to Intel®...
Page 277 Troubleshooting Problem Possible Cause - Solution have connected This is an issue with this mouse model and the Intel Wireless 7260 WLAN and Bluetooth combo Bluetooth Mouse but it module series. To resolve this issue do the following: loses Bluetooth Go to the Device Manager control panel in Windows.
Page 278 Troubleshooting Problem Possible Cause - Solution When using a Bluetooth This is a common issue with Bluetooth headsets. To resolve this issue do the following (you will headset audio need to repeat this procedure after every boot up, restart, or when the system resumes from appears to be mono hibernation): and not stereo.
Page 279: Bluetooth Connection Problems
Troubleshooting Bluetooth Connection Problems If you are experiencing problems connecting to some Bluetooth devices (in particular certain mobile phones and headsets) it maybe necessary to download and install the Windows Mobile Device Center software (for Win- dows Vista and Windows 7). Go to the Microsoft website and search for the Microsoft Windows Device Center Driver for Windows Vista (64-bit or 32-bit) and Windows 7 (64-bit or 32-bit), and then download the driver.
Page 280 Troubleshooting Right-click Bluetooth Peripheral Device and click on Update Driver Software. Click Browse my computer for driver software. Click Let Me pick from a list of device drivers on my computer. Figure 8 - 3 - Browse my computer.../Let me pick from... Select Bluetooth Radios from the list.
Page 281 Troubleshooting 10. A list of drivers will appear with Manufacturer on one side and Model in the other. 11. Choose Microsoft Corporation (make sure you choose the full name Microsoft Corporation and do not choose Microsoft - Note that you must have installed the Microsoft Windows Device Center Driver for Microsoft Corporation to appear in the list).
Page 282 Troubleshooting 15. The Device Manager should now display the Windows Mobile-based device support under Bluetooth Radios. 16. You will need to repeat the process for any other Bluetooth Peripheral Devices listed under Other Devices. Figure 8 - 6 - Device Manager - Bluetooth Radio 8 - 22 Bluetooth Connection Problems...
Page 283: Intel My Wifi Configuration
Troubleshooting Intel My WiFi Configuration ®  (For Intel® WLAN Modules Only) Intel® My WiFi Technology (Intel® MWT) uses your WLAN to transform your sys- Intel® My WiFi Help tem into a Wi-Fi Personal Area Network, and enables you wirelessly share your vid- To get help on Intel®...
Page 284: Intel® My Wifi Configuration
Troubleshooting Installing Intel® MyWiFi Technology (for Intel® WLAN Modules Only) If you want to install Intel® MyWifi Technology (Personal Area Network) then follow the procedure outlined here. Note that if you wish to install Intel® MyWiFi you will need to install Microsoft.net Framework 4.0 (or later version) before installing the driver as per the procedure below.
Page 285 Troubleshooting Intel® My WiFi Configuration You can configure the My WiFi settings as follows. Make sure the Wireless LAN module is on. Access the Intel® WiFi Connection Utility from the Start menu (Start > All Programs > Intel PROSet Wireless > Intel(R) My WiFi Dashboard), or click the icon in the notification area of the taskbar (or right-click and select Open Dashboard).
Page 286 Troubleshooting Intel® My WiFi Interface Help Wireless ON/OFF Configuration Options & Preferences Figure 8 - 8 Intel® My WiFi Utility - Interface Your Computer 8 - 26 Intel® My WiFi Configuration...
Page 287 Troubleshooting Intel® My WiFi Help Click the Help icon in the dashboard to bring up the Help menu and select and item from the Contents menu to obtain the help information. Help Figure 8 - 9 Intel® My WiFi Utility - Help Your Intel®...
Page 288 Troubleshooting Preferences Click the Options icon and select Preferences to configure the options. Help Figure 8 - 10 Intel® My WiFi Utility - Preferences Your Computer 8 - 28 Intel® My WiFi Configuration...
Page 289 Troubleshooting Hotspot You can turn the computer into a hotspot to allow other devices to connect to it (and any locally connected devices), and also (if available) the internet. Click the Hotspot icon to turn the Hotspot on. The Hotspot settings tab shows the SSID and password (you will need to enter this information when accessing the Hotspot from the client computer/device).
Page 290 Troubleshooting Finding Devices You can find any Nearby Devices by clicking the Refresh button in the main window. Click again at any time to update the list. If a lot of devices are found they will be listed on multiple pages and you can use the left or right buttons to turn the pages.
Page 291 Troubleshooting Favorite Devices The Favorite Devices tab is where you keep devices to which you connect most of- ten, and this is particularly useful in environments where many devices are listed nearby. A favorite device will display the icon To make any device a favorite just click to select it and select Add Favorite. Figure 8 - 12 Intel®...
Page 292 Troubleshooting Connect to a Device Click the device you want to connect to, and click the connect icon An invitation will be sent to the target device. The user must then accept the invitation. After the invitation is accepted the connection will be made. Use the Windows Network and Sharing Center to set permissions for viewing and sharing the resources on your computer with another connected computer.
Page 293: Interface (Ports & Jacks) Overview
Interface (Ports & Jacks) Appendix A: Interface (Ports & Jacks) Overview The following chapter will give a quick description of the ports & jacks which allow your computer to commu- nicate with external devices, connect to the internet etc. Interface (Ports & Jacks) A - 1...
Page 294: Ports And Jacks
Interface (Ports & Jacks) Ports and Jacks Item Description Card Reader The card reader allows you to use the following digital storage cards: MMC (MultiMedia Card) / RSMMC SD (Secure Digital) / Mini SD / SDHC / SDXC MS (Memory Stick) / MS Pro / MS Duo Push the card into the slot and it will appear as a removable device.
Page 295: Hdmi-Out Port
Interface (Ports & Jacks) Item Description e-SATA/Powered USB This is a combined e-SATA (external Serial Advanced Technology Attachment)/ USB 3.0 3.0 Port compatible port. Plug external Serial ATA hard drives into this e-SATA (external Serial Advanced Technology At- tachment) port. *See “USB 2.0/1.1 Ports*”...
Page 296: Line-In Jack
Interface (Ports & Jacks) Item Description Line-In Jack The Line-In jack allows you to play audio sources through the computer’s speakers. Note that audio input through Line-in will default to the mute setting. To set up your audio sources to play through the Line-in jack go to the Sound control panel and make sure the Mute box is not ticked.
Page 297: Security Lock Slot
Interface (Ports & Jacks) Item Description Security Lock Slot To prevent possible theft, a Kensington-type lock can be attached to this slot. Locks can be purchased at any computer store. USB 2.0/1.1 Ports* These USB (Universal Serial Bus) 2.0 compatible ports (USB 2.0 is fully USB 1.1 compliant) are for low-speed peripherals such as keyboards, mice or scanners, and for high-speed peripherals such as external HDDs, digital video cameras or high-speed scanners etc.
Page 298 Interface (Ports & Jacks) A - 6...
Page 299: Control Center
Control Center Appendix B: Control Center Overview The following chapter will give a quick description of the functions of the Control Center. The Control Center gives quick access to frequently used controls, power management features and enables you to quickly turn mod- ules on/off.
Page 300 Control Center Power Modes You can set a Power Mode by clicking the appropriate icon at the top of the Control Center. Each power mode will affect the power status of modules (e.g. WLAN, Bluetooth, 3G or Camera), screen brightness, TouchPad power and Silent Mode.
Page 301 Control Center User Modes Power Saving Flight Entertainment Quiet Performance Defined Icon Power Plan Power Saver Balanced Power Saving Power Saving High Performance Power Conservation Mode Energy Star BIOS Default Energy Star Energy Star Performance Brightness WLAN Bluetooth BIOS Defined PC Camera TouchPad Table B - 1- Power Modes...
Page 302 Control Center Power Status The Power Status icon will show whether you are currently powered by the battery, or by the AC/DC adapter plugged in to a working power outlet. The power status bar will show the current battery charge state. Brightness The Brightness icon will show the current screen brightness level.
Page 303 Control Center Sleep Click the Sleep button to bring up the Hibernate or Sleep buttons, and click either button to have the computer enter the appropriate power-saving mode (see “Power-Saving States” on page 3 - Display Switch Click the Display Switch button to access the menu (or use the + P key combination) and select the appro- priate attached display mode (see page 13).
Page 304 Control Center B - 6...
Page 305: Nvidia Video Driver Controls
NVIDIA Video Driver Controls Appendix C: NVIDIA Video Driver Controls The basic settings for configuring the LCD are outlined in “Video Features” on  page 1 - 22. For information on the Windows 8 operating system see Appendix Video Card Options NVIDIA Video Driver Installation Note that card types, Make sure you install the drivers in the order indicated in...
Page 306: Nvidia Control Panel
NVIDIA Video Driver Controls NVIDIA Control Panel  More advanced video configuration options are provided in the NVIDIA Control NVIDIA Control Panel tab. Panel Click Start, and click Control Panel (or point to Settings and click Control Panel). To access the Ge- Double-click NVIDIA Control Panel (click "Classic View"...
Page 307 NVIDIA Video Driver Controls The NVIDIA Control Panel provides additional video configuration controls and  tools which allow quick access to features such as display configuration, 3D Settings and Help menus etc. Navigating the Control Panel Navigate through the control panels in much the same way as you would a web page.
Page 308 NVIDIA Video Driver Controls The Help menus provide index and search features, and direct links to the NVIDIA website etc. Figure C - 3 Help Menu C - 4 NVIDIA Control Panel...
Page 309: Display Devices
NVIDIA Video Driver Controls Display Devices  Note that you can use a DVI cable connected to the DVI-Out port, an HDMI (High- Sound Blaster Definition Multimedia Interface) cable connected to the HDMI-Out port (if you are Audio & HDMI using an older type of monitor you can use a converter to convert the signal from Connection DVI to VGA) or DisplayPort cable connected to the DisplayPort, to connect an ex-...
Page 310: Configuring An External Display (Nvidia
NVIDIA Video Driver Controls Configuring an External Display (NVIDIA)  Clone the Displays Display Not Shown Attach your external display to the appropriate port, and turn it on. Go to NVIDIA Control Panel (see page If the attached display Double-click Display (if the sub-menus are not visible), and then click Set up does not appear in the multiple displays.
Page 311: Extending The Display
NVIDIA Video Driver Controls Extending the Display  Attach your external display to the appropriate port, and turn it on. Go to NVIDIA Control Panel (see page Changing the Double-click Display (if the sub-menus are not visible), and then click Set up Primary Display on multiple displays.
Page 312 NVIDIA Video Driver Controls The Primary display (the main window display) will be denoted by an asterix * in the top right corner of the icon. To change the Primary display right-click the icon and select Make primary. Click Apply > Yes to save any changes. Figure C - 6 Switch Primary Display...
Page 313 NVIDIA Video Driver Controls You can drag the icons to match the desktop layout you want to use (e.g. you may want to extend the display to the right or left of the primary display). 10. Click Apply > Yes to save any further changes. Figure C - 7 Drag Display Icons...
Page 314: Multiple Display Connection To Hdmi-Out Port & Displayport
NVIDIA Video Driver Controls Multiple Display Connection to HDMI-Out Port & DisplayPort Note that the NVIDIA video cards can support up to two external displays (one attached to the HDMI-Out port and another attached top the DisplayPort), in addi- tion to the built-in LCD. Therefore it is possible to set up 3 simultaneous displays (including the built-in LCD), and these may be configured in Clone mode or Extend mode as required.
Page 315: Attaching Other Displays (Win 7
NVIDIA Video Driver Controls Attaching Other Displays (Win 7)  Configuring an External Display in Windows 7 Function Key Attach your external display to the appropriate port, and turn it on. Combination Go to the Screen resolution control panel. You can use the Fn + F7 Click the Detect button.
Page 316 NVIDIA Video Driver Controls You can configure the displays from the Multiple Displays menu. Figure C - 10 Screen Resolution Multiple Display Options (Win 7) • Duplicate these displays - Shows an exact copy of the main display desktop on the other display(s) •...
Page 317 NVIDIA Video Driver Controls Using the Windows Logo Key + P/Fn + F7 Key Combination to Switch Displays You can also use the + P/Fn +F7 key combination to quickly change display con- figuration and modes in Windows 7. Attach your external display to the appropriate port, and turn it on. + P/Fn + F7 Press the key combination.
Page 318: Nvidia® Sli Multi Gpu Configuration
NVIDIA Video Driver Controls NVIDIA SLI Multi GPU Configuration ®  This computer features an NVIDIA Scalable Link Interface (SLI) that improves Video Card graphic quality and performance by combining dual NVIDIA GPUs (two video Options cards are required) in a single system. To enable/disable SLI Configuration: Note that card types, Go to NVIDIA Control Panel (see page specifications and driv-...
Page 319: Nvidia® Sli Multi Gpu Configuration & Power
NVIDIA Video Driver Controls ® NVIDIA SLI Multi GPU Configuration & Power  Note that due to the high power and system demands created when two video adapters are installed in an SLI configuration, you should not power the system SLI Configuration &...
Page 320: Manage 3D Settings
NVIDIA Video Driver Controls Manage 3D Settings You can configure the 3D global settings (to be applied to all application programs) or make specific adjustments for installed program settings. Go to NVIDIA Control Panel (see page Click Manage 3D Settings and select either Global Settings or Program Settings. Click the Setting menu items to select any global options required, or select a program to customize from the drop-down menu (click Add to add any program that does not appear in the menu).
Page 321: Adjust Video Settings
NVIDIA Video Driver Controls Adjust Video Settings You can adjust video color and image settings from the Video sub-menus. Go to NVIDIA Control Panel (see page Click “+” next to Video if its sub-items are not shown and then click either Adjust video color settings or Adjust video image settings.
Page 322: Hdmi Audio Configuration
NVIDIA Video Driver Controls HDMI Audio Configuration As HDMI (High-Definition Multimedia Interface) carries both audio and video sig- nals you can configure the audio output from the NVIDIA control panel and Sound control panel. The settings will depend upon the external HDMI display you have connected to.
Page 323: Audio Setup For Hdmi
NVIDIA Video Driver Controls Audio Setup for HDMI In some cases it will be necessary to go to the Sound control panel and manually con- figure the HDMI audio output. Click Start, and click Control Panel (or point to Settings and click Control Panel). Click Sound (Hardware and Sound).
Page 324 NVIDIA Video Driver Controls Adjust the HDMI settings from the control panel tabs. Click OK to close the Sound control panel. Figure C - 18 HDMI Device Properties C - 20 HDMI Audio Configuration...
Page 325: Hdmi Notes
NVIDIA Video Driver Controls HDMI Notes  • Connect a device with HDMI support to the HDMI-Out port BEFORE attempt- ing to play audio/video sources through the device. Other Applications • Under certain conditions, if the HDMI cable is disconnected, the default audio If you are using a third playback device will not revert to speakers until the computer is restarted (if you party application to play...
Page 326: Hdcp Status
NVIDIA Video Driver Controls HDCP Status If your external display is HDCP (High Bandwith Digital Content protection) com- patible then the NVIDIA control panel will display the HDCP system status. Figure C - 19 HDCP Status C - 22 HDMI Audio Configuration...
Page 327: Nvidia 3D Shutter Glasses Kit
NVIDIA Video Driver Controls NVIDIA 3D Shutter Glasses Kit  The NVIDIA 3DVISION™ 2 shutter glasses kit is supported only by Model B NVIDIA Driver computers which include the built-in 3D emitter and shutter glasses kit. Install the video driver as indicated in “NVIDIA Video (VGA)”...
Page 328: Stereoscopic 3D Hardware Setup
NVIDIA Video Driver Controls Stereoscopic 3D Hardware Setup If your computer model features a built-in 3D IR emitter the loa ct ion is illustrat- ed below. The effective viewing angles of the emitter are illustrated overleaf. Make sure that you are viewing the notebook screen within the area highlighted overleaf in order to get the proper stereoscopic 3D effect.
Page 329: Viewing Angles
NVIDIA Video Driver Controls Viewing Angles The emitter’s horizontal viewing angle is 100 degrees. The emitter’s vertical viewing angle is 75 degrees. Figure C - 21 Emitter - Viewing Angles 75° NVIDIA 3D Shutter Glasses Kit C - 25...
Page 330: Set Up Stereoscopic 3D
NVIDIA Video Driver Controls Set Up Stereoscopic 3D  Click Start, and click Control Panel (or point to Settings and click Control Panel). Double-click NVIDIA Control Panel (click "Classic View" from the left of the Enable 3D Vision menu if you are in Control Panel Home). You can enable 3D Vi- Double-click Stereoscopic 3D (if the sub-menus are not visible), and then click sion if the NVIDIA con-...
Page 331 NVIDIA Video Driver Controls Select the drop-down menu at the bottom of the screen to Test stereoscopic 3D. Select Run Setup Wizard from the drop-down menu (you can also select Run Medical Image Test from this menu). Follow the on-screen instructions to set up 3D Vision and click “Next” to progress through the steps (this notebook has a built-in emitter).
Page 332 NVIDIA Video Driver Controls 11. The stereoscopic depth may be adjusted by using the control panel slider. 12. Click View Compatibility With Games to check 3D support for any games. Figure C - 24 Compatibility With Games C - 28 NVIDIA 3D Shutter Glasses Kit...
Page 333: Amd Video Driver Controls
AMD Video Driver Controls Appendix D: AMD Video Driver Controls The basic settings for configuring the LCD are outlined in “Video Features” on page 1 -  Video Driver Installation Video Card Options Make sure you install the drivers in the order indicated in Table 4 - 1, on page 4 - Note that card types, Video (VGA)
Page 334: Catalyst™ Control Center
AMD Video Driver Controls Catalyst Control Center ™  Adjust the video settings from the Catalyst™ Control Center. Taskbar Icon Right-click the desktop and select Catalyst Control Center. The Catalyst Control Center can also be ac- Click Advanced settings in the Screen Resolution control panel (see “Video cessed by double-clicking Features”...
Page 335 AMD Video Driver Controls Catalyst™ Control Center Preferences  The Preferences button in the Catalyst Control Center menu allows you to con- ™ figure the control panel settings. You can view the control panel in either Standard Preferences & View or Advanced View. To display Standard View or Advanced View: Views Open the Catalyst ™...
Page 336 AMD Video Driver Controls Standard View The Standard View menus feature a series of menu headings with clickable sub- menus which allow you to adjust Desktops and Displays, Power, Video, Gaming and Information. Click the Start button to access the top level menu from any sub- menu heading.
Page 337 AMD Video Driver Controls Advanced View  The Advanced View menus display all the menu headings as a series of buttons on the left. Click the arrows in any button to display the sub-menus (note all the figures Sub-Menus in the remainder of this chapter are in Advanced View). Click a menu button to expand any sub-menus, and then click the appro-...
Page 338 AMD Video Driver Controls The Catalyst Control Center provides additional video configuration controls ™  and tools which allow quick access to features such as display options, 3D Settings, color, power and Information menus etc. Adjust settings from the options in the sub- Help Menus menus.
Page 339: Display Devices & Options
AMD Video Driver Controls Display Devices & Options  Note that you can use a DVI cable connected to the DVI-Out port, an HDMI (High- Sound Blaster Definition Multimedia Interface) cable connected to the HDMI-Out port (if you are Audio & HDMI using an older type of monitor you can use a converter to convert the signal from Connection DVI to VGA) or DisplayPort cable connected to the DisplayPort, to connect an ex-...
Page 340: Configuring An External Display In The Ccc
AMD Video Driver Controls Configuring an External Display In the CCC  You can use the Catalyst Control Center to configure any attached displays. ™ Detect Displays Attach your external display to the appropriate port, and turn it on. Open the Catalyst ™ Control Center. Click Detect Displays (button) to automati- Select Desktop Management from the menu on the left (click the arrow to expand...
Page 341 AMD Video Driver Controls Click the triangle icon (or right-click the display icon) on the attached display  icon at the bottom to bring up the options (e.g Duplicate or Extend). Select an option from the menu (click Continue if required), and click Yes to Disable Displays accept the settings.
Page 342 AMD Video Driver Controls My Digital Flat-Panels An additional menu button entitled My Digital Flat-Panels will appear when an ex- ternal digital display is attached. This menu allows you to configure the properties of the external display. After making any adjustments you may need to click the Ap- ply button to confirm the changes.
Page 343 AMD Video Driver Controls HDTV Support If your flat panel supports HDTV functions then this can be configured from My Digital Flat-Panels > HDTV Support (Digital Flat-Panel). Figure D - 9 My Digital Flat- Panels (HDTV Support) Display Devices & Options D - 11...
Page 344: Configuring An External Display In Windows 7
AMD Video Driver Controls Configuring an External Display In Windows 7 Attach your external display to the appropriate port, and turn it on. Go to the Screen resolution control panel (see “Video Features” on page 1 - 23). Click the Detect button. The computer will then detect any attached displays.
Page 345 AMD Video Driver Controls You can configure the displays from the Multiple Displays menu. Figure D - 11 Screen Resolution Multiple Display Options (Win 7) • Duplicate these displays - Shows an exact copy of the main display desktop on the other display(s) •...
Page 346 AMD Video Driver Controls Using the Windows Logo Key + P/Fn + F7 Key Combination to Switch Displays You can also use the + P/Fn +F7 key combination to quickly change display con- figuration and modes in Windows 7. Attach your external display to the appropriate port, and turn it on. + P/Fn + F7 Press the key combination.
Page 347 AMD Video Driver Controls PowerPlay™ When enabled, PowerPlay can be used to automatically set to adjust the graphics ™ processor settings for higher performance or longer battery life when the system is either Plugged In or on Battery. Figure D - 13 PowerPlay ™...
Page 348: Amd Crossfirex™ Multi Gpu Configuration
AMD Video Driver Controls AMD CrossFireX ™ Multi GPU Configuration The Gaming menu includes configuration options for AMD CrossFireX ™. CrossFireX combines the processing power of multiple GPUs to s single display, ™ and this may be enabled/disabled from the AMD CrossFireX Configuration ™...
Page 349: Amd Crossfirex™ Multi Gpu Configuration & Power
AMD Video Driver Controls ™ AMD CrossFireX Multi GPU Configuration & Power  Note that due to the high power and system demands created when two video adapters are installed in a CrossFire configuration, you should not power the sys- CrossFire tem using the battery only and you will require identical (300W) dual power Configuration &...
Page 350: Hdmi Audio Configuration
AMD Video Driver Controls HDMI Audio Configuration HDMI (High-Definition Multimedia Interface) carries both audio and video signals. Configure the audio output as per the instructions below. Connect a device with HDMI support to the HDMI-Out port. Click Start, and click Control Panel (or point to Settings and click Control Panel). Click Sound (Hardware and Sound), and click Playback (tab).
Page 351 AMD Video Driver Controls Double-click the connected HDMI device (or right-click and select Properties) to adjust the HDMI settings from the control panel tabs. Click OK to close the control panel (see notes overleaf). Figure D - 17 HDMI Device Properties HDMI Audio Configuration D - 19...
Page 352 AMD Video Driver Controls HDMI Notes  • Connect a device with HDMI support to the HDMI-Out port BEFORE attempt- ing to play audio/video sources through the device. Other Applications • To play audio sources through your external display’s (TV or LCD) speakers If you are using a third you will need to go to the audio configuration control panel on the display and party...
Page 353 AMD Video Driver Controls Audio You can use Audio menu in the Catalyst Control Center to configure any at- ™ tached audio device. Figure D - 18 Audio HDMI Audio Configuration D - 21...
Page 354 AMD Video Driver Controls D - 22...
Page 355: Specifications
Specifications Appendix E: Specifications  Latest Specification Information The specifications listed in this Appendix are correct at the time of going to press. Certain items (particularly processor types/ speeds and CD/DVD device types) may be changed, updated or delayed due to the manufacturer's release schedule. Check with your service center for details.
Page 356: Processor
Specifications Processor Memory For All Models: NVIDIA® GeForce GTX 780M PCIe * 16 Intel® Core i7-3960X (3.30GHz) Four Channel DDRIII (DDR3) Video Card 15MB L3 Cache, 32nm (32 Nanometer), 4GB GDDR5 Video RAM Four 204 Pin SO-DIMM Sockets DDR3-1600MHz, TDP 130W Supporting DDRIII (DDR3) 1333/1600 Supports Microsoft DirectX®...
Page 357: Bios
Specifications For Model A Only: For Model A Only:  NVIDIA® Quadro K5100M PCIe * 16 AMD Radeon™ R9 M290X PCIe * 16 Video Card Video Card NVIDIA® SLI or AMD™ CrossfireX 8GB GDDR5 Video RAM 4GB GDDR5 Video RAM Multi GPU Configuration &...
Page 358: Audio
Specifications Audio Card Reader One DVI-I Out Port (Single Link) One HDMI™ (High-Definition Multimedia High Definition Audio Embedded Multi-In-1 Push-Push Card Interface) Out Port (with HDCP) Reader S/PDIF Digital Output One Headphone/Speaker-Out Jack - MMC / RSMMC Built-In Microphone One Microphone-In Jack - SD / Mini SD / SDHC / SDXC 5 Built-In Speakers One S/PDIF Out Jack...
Page 359: Indicators
Specifications Intel® Wireless-N 7260 (2*2 802.11 b/g/n) Indicators Power Half Mini-Card PCIe WLAN Bluetooth LED Indicators (Power/Suspend, Battery, Full Range AC/DC Adapter – AC in 100 - Combo Module (Factory Option) HDD/ODD, WLAN, Bluetooth, Num Lock, 240V, 50 - 60Hz DC Output 19.5V, Combo WLAN (802.11b/g/n) and Caps Lock, Scroll Lock, *Camera) 16.92A (330 Watts) OR 20V, 15A (300...
Page 360 Specifications E - 6...
Page 361: Windows 8
Windows 8 Appendix F: Windows 8 Overview This Appendix contains information (including control panel information, driver installation etc.) for users of the Windows 8 OS. You can refer to the main manual for details of drivers required, audio & video information, BIOS, modules etc. However any information specific to Windows 8 will be included in this Appendix, as well as details on how to navigate the Windows 8 Metro User Interface to access the applications, control panels, taskbar etc.
Page 362: Windows 8 Start Screen & Desktop
Windows 8 Windows 8 Start Screen & Desktop The apps, control panels, utilities and programs within Windows 8 are accessed from the Metro user interface’s Start screen and/or Windows Desktop. The Desktop (which runs as an app within the Start screen) can be ac- cessed from the Desktop item in the Start screen (or by using the Windows Logo Key + D key combination).
Page 363: Apps & Tiles
Windows 8 Apps & Tiles The Windows 8 Start screen will contain a number of apps, and many more will be installed as you add more applications etc. Not all of these apps can fit on one screen so you will often need use the slider at the bottom of the screen in order to view all the necessary apps.
Page 364: Desktop Application
Windows 8 Desktop Application When the Desktop app is running (click the app in the Start screen or use the Windows Logo Key + D key combination) you can use lower left hot corner to switch between the Start screen and the Windows Desktop. To do so move your mouse to hover over the bottom left corner of the screen and click the pop-up.
Page 365 Windows 8 When the Desktop app is running you can right-click the lower left hot corner (or use the Windows Logo Key + X key combination) to bring up an advanced context  menu of useful features such as Control Panel, Programs and Features, Power Op- Display Most tions, Task Manager, Search, Windows Explorer, Command Prompt, Device Man- Recently Used...
Page 366: Windows 8 Charms Bar
Windows 8 Windows 8 Charms Bar The right side of the screen displays the Windows 8 Charms Bar. The Charms Bar contains the Search, Share, Start, Devices and Settings menus. To access up the Charms Bar move the cursor to the upper or lower right corners of the screen, and then hover over one of the items in the Charms Bar to activate it (the bar will be black when it is active), or use the Windows Logo Key + C key combination.
Page 367: Charms Bar Items
Windows 8 Charms Bar Items • Search : You can search for any file, application, apps and control panel settings with instantaneous results. • Share : This button is used to share information with people via mail or social networks. •...
Page 368: Windows 8 Control Panel
Windows 8 Windows 8 Control Panel In many instances throughout this manual you will see an instruction to open the Control Panel. The Control Panel is much the same as that in Windows 7, however it can be accessed in a number of ways in Windows 8. •...
Page 369 Windows 8 • When in the Desktop app (this does not apply to the Start screen) click on Settings in the Windows Charms Bar and select Control Panel from the menu. Figure F - 9 - Settings Charms Bar (Desktop App Only) •...
Page 370 Windows 8 • Right-click the lower left hot corner to bring up the menu and select Control Panel (see Figure F - 4 on page F -  Keyboard Shortcut to Control Panel You can also use keyboard shortcuts to access the Control Panel. Press the Windows logo key and X to bring up the context menu, and then press P to bring up the Control Panel.
Page 371: Windows 8 Taskbar
Windows 8 Windows 8 Taskbar In many instances throughout this manual you will see an instruction to access the notification area of the task- bar. In Windows 8 the taskbar is accessed from the Desktop application. If you are in the Start screen you will need to click the Desktop app to switch to the Desktop.
Page 372: Led Indicators
Windows 8 LED Indicators The two sets of LED indicators (LED Status Indicators and LED Power Indicators) display helpful informa- tion about the current status of the computer. Icon Color Description Icon Color Description Blinking Hard Disk Activity Orange DC Power is Plugged In Blue Number Lock is Activated Green...
Page 373: Keyboard - Windows 8
Windows 8 Keyboard - Windows 8  The main difference between the Windows 7 & Windows 8 keyboards is in the func- Windows Logo tion of the Windows Logo Key (in the Start screen), otherwise the keyboard func- Keyboard Shortcut tions are identical (see “Keyboard”...
Page 374: Keyboard Shortcuts
Windows 8 Keyboard Shortcuts The following Windows Logo Key (Winkey) keyboard shortcuts are useful for navigation/operation in Windows 8. Description Windows Logo Key + Tap Winkey Toggle between the Start screen and the foremost running app or the Windows Desktop Display Charms menu Switch to the Windows Desktop and toggle show Desktop Switch to the Windows desktop and launch Windows Explorer with Computer displayed...
Page 375: Function/Hot Key Indicators & Control Center
Windows 8 Function/Hot Key Indicators & Control Center The function/hot key indicators and Control Center function in the same manner as outlined for Windows 7 (ex- cept for the Mute, Volume and Brightness indicators which use the standard Windows 8 indicators) in “Func- tion Keys &...
Page 376: Video Features
Windows 8 Video Features You can switch display devices, and configure display options, from the Display control panel (in Appearances and Personalization) in Windows 8 in the same manner as Windows 7 running the Desktop app (see “Desktop Application” on page F - 4 Appendix C).
Page 377: Power Options
Windows 8 Power Options Power Options can be accessed from the Control Panel in the same manner as Windows 7 from the Desktop app. The Power item in Settings in the Charms Bar in Windows 8 may be used to Shut down, Restart or send the computer to Sleep.
Page 378: Ctrl + Alt + Delete Key Combination
Windows 8 Ctrl + Alt + Delete Key Combination You can use the CTRL + ALT + DEL key combination from almost any of the Windows 8 interfaces/apps to bring up a full-screen displaying Lock, Switch User, Log off, Change a password and Task Manager options. If you click the Power icon in the lower right corner of the screen a power management option menu appears to display Sleep, Shut down, and Restart.
Page 379: Wake On Lan Settings
Windows 8 Wake On LAN Settings  If you require your computer to wake up from network activity in Windows 8 then make sure that the computer is either in Sleep or Hibernate. The power/sleep button Wake On LAN (Fn + F4 key combo) and closed lid may be set to send the computer in to a power- Support saving state.
Page 380: Running Metro Ui Apps
Windows 8 Running Metro UI Apps  To run apps in the Metro UI in Windows 8 you will need to check that the Screen Screen Resolution Resolution and User Account Control Settings are compatible with the system re- for Metro Style Apps quirements: (Windows 8) Screen Resolution Settings...
Page 381: User Account Control Settings
Windows 8 User Account Control Settings If your computer meets the minimum screen resolution requirements, and still you can't run Metro apps, then that you have to check the status of User Account Control (UAC). Metro apps may fail to open when the UAC is turned off.
Page 382: F - 22 Drivers & Utilities
Windows 8 Drivers & Utilities Make sure you install all the drivers and uti lites for your system. Follow the instructions in Chapter 4 “Drivers & Utilities” on page 4 - “Modules” on page 7 - 1 for installing all the basic system drivers and module drivers for Windows 7 &...
Page 383: Driver Installation (Windows 8
Windows 8 Driver Installation (Windows 8) Insert the Device Drivers & Utilities + User’s Manual disc into the computer’s DVD drive. Click the message “Tap to choose what happens with this disc.” Click Run autorun.exe.  Driver Installation If you miss the message above you can eject the De- vice Drivers &...
Page 384 Windows 8 Win 7 SP1/Win 8 Driver Intel Rapid Storage Technology (for RAID & AHCI mode Hard Disk Drives) Chipset Page 4 - 6 “RAID Setup (Windows 8)” on page F - 53 if you want to config- ure a RAID in Windows 8. The USB 3.0 driver is not required for Windows 8 The PC Camera driver is not required for Windows 8 (see page NVIDIA Video (VGA)
Page 385: Pc Camera (Windows 8
Windows 8 PC Camera (Windows 8) Use the Fn + F10 key combination (see “Function Keys & Visual Indicators” on page 1 - 14) or Control Cen- ter button to toggle power to the PC Camera module. When the PC Camera is in use the LED indicator to the left of the camera will be illuminated in (see Figure 1 - 2 on page 1 - Note that you need to use the Camera app in Windows 8 to take pictures and capture video (the camera appli-...
Page 386: Metro Ui Camera App
Windows 8 Metro UI Camera App Make sure the PC Camera is turned on by using the Fn + F10 key combination (or Control Center button). Run the Camera app from the Metro UI by clicking on the Camera app icon The camera interface is a translucent app bar with three buttons.
Page 387 Windows 8 • You can also click on More to adjust Brightness, Contrast and Flicker (if you find that the video screen in the camera program is flickering, you can try to adjust the setting here), Figure F - 23 -More Camera Options •...
Page 388: Taking Pictures/Capturing Video
Windows 8 Taking Pictures/Capturing Video Make sure the PC Camera is turned on by using the Fn + F10 key combination (or Control Center button). Run the Camera app from the Metro UI by clicking on the Camera app icon Click to select the timer if you require a countdown before capture.
Page 389 Windows 8 A scroll arrow will appear on the left side of the screen after any pictures/videos have been captured. Click the arrows (on either side of the screen) to browse through the captured photos/video, and back to the Camera app. 10.
Page 390: Wireless Lan Settings (Windows 8
Windows 8 Wireless LAN Settings (Windows 8) If you have included an Intel®, 3rd Party 802.11b/g/n or Qualcomm Atheros WLAN (Combo) module in your purchase option, make sure that the WLAN module is on before installing the driver. Use the Fn + F11 key combination (see “Function Keys &...
Page 391: Wlan Configuration In Windows 8
Windows 8 WLAN Configuration in Windows 8 You can configure a wireless connection using one of the following options, however make sure the Wireless LAN module is turned on (and not in Airplane Mode) before configuration begins. Charms Bar Go to the Charms Bar. Select Settings and then click the WiFi icon (it should read Available under the icon and Airplane mode should be Off).
Page 392 Windows 8 Double-click an access point to connect to it (or click it and click Connect). Enter a network security key (password) if required, and click Next. You can choose to share or connect to devices or not. When you are connected to the network access point it will display the Connected icon Select any connected network and click Disconnect to disconnect from a connected access point.
Page 393 Windows 8 11. You need to either use Airplane Mode, or to turn the WLAN module off aboard aircraft.  Wireless Device Operation Aboard Aircraft The use of any portable electronic transmission devices aboard aircraft is usually prohibited. Make sure the module is either OFF or in Air- plane Mode (for Win- dows 8 only) if you are...
Page 394: Desktop Mode
Windows 8 Desktop Mode Switch to the Windows Desktop (click the app or use the Windows logo key + D key combination). Click the wireless icon in the notification area of the taskbar. A list of available access points will appear. Double-click an access point to connect to it (or click it and click Connect).
Page 395: Control Panel
Windows 8 Control Panel If you are in Category View do the following (see over for Icon View): Open the Control Panel (see “Windows 8 Control Panel” on page F - Click the Network and Internet control panel. Click Connect to a network. Figure F - 31 - Network and Internet Control Panel A list of available access points will appear.
Page 396 Windows 8 If you are in Icon View do the following: Open the Control Panel (see “Windows 8 Control Panel” on page F - Click Network and Sharing Center. Click Change Adapter Settings. Double-click Wi-Fi. Figure F - 32 - Network and Sharing Center Control Panel A list of available access points will appear.
Page 397: Fingerprint Reader Module (Windows 8
Windows 8 Fingerprint Reader Module (Windows 8)  The fingerprint reader module provides a high level of security for your computer. Password Warning Make sure you have administrator’s rights to your computer, and have a Windows password enabled for full security protection. If you set passwords for any of the security mod- ules, NEVER forget your...
Page 398: Protector Suite Fingerprint Reader Driver Installation (Windows 8
Windows 8 Protector Suite Fingerprint Reader Driver Installation (Windows 8) 1. Insert the Device Drivers & Utilities + User’s Manual disc into the CD/DVD drive. 2. Click Option Drivers. 3. Click 2.Install FingerPrint Driver > Yes. 4. Click Next > Next > Next. 5.
Page 399: Protector Suite Application (Windows 8
Windows 8 Protector Suite Application (Windows 8) Enabling the .NET Framework 3.5 in the Windows Control Panel Make sure you have a working internet connection. Go to the Control Panel. Click to select Programs and Features (Programs). Click Turn Windows features on or off (in the menu on the left). Click to select the .NET Framework 3.5 (includes .NET 2.0 and 3.0) check box (the sub menu items are not required).
Page 400 Windows 8 Click OK to install the features required. Windows will search for (as long as you have a working internet connection) and install the features. Click Restart now to complete the installation. Figure F - 34 - Windows Features (Restart now) F - 40 Protector Suite Application (Windows 8)
Page 401: User Enrollment
Windows 8 User Enrollment Run the Control Center from the Start screen, or double click the notification area icon (click Initialize). On the first run of the program you will be asked to click the Accept button to accept the license. If you have not set a Windows password you will be prompted to do so (note: If you have not set a password Protector Suite cannot secure access to your computer).
Page 402 Windows 8 Put the finger flat in the center of the reader until prompted to lift the finger off the reader. For Intel PRO Wireless 2200BG Figure F - 36 - Fingerprint Enrollment Tutorial F - 42 Protector Suite Application (Windows 8)
Page 403 Windows 8 Keep placing the finger flat on the reader, and lifting it off the reader as instructed, until the progress bar reaches 100% to enroll that finger. Tutorial Figure F - 37 - Fingerprint Enrollment Process Repeat the process for all the fingers you wish to enroll (see sidebar). 10.
Page 404 Windows 8 11. It is recommended you set a strong backup password. 12. Click Set backup password and then enter a password of your choice and click Apply. Figure F - 38 - Set Backup Password F - 44 Protector Suite Application (Windows 8)
Page 405 Windows 8 13. Right-click the taskbar icon and select Start Control Center (and place a finger on the reader) to allow you to Edit Fingerprints, register Applications, edit Settings and access the Help menu etc. You can also run the Control Center from the Start screen.
Page 406 Windows 8 17. If you place a finger on the reader at any time you can access the Biomenu to lock the computer, register websites, access the Personal Safe or E-Wallet, open the Control Center and access the Help menu etc. Figure F - 40 - Biomenu F - 46 Protector Suite Application (Windows 8)
Page 407: Fingerprint Control Center Features
Windows 8 Fingerprint Control Center Features  Application Launcher Help The Application Launcher allows you to register applications to be launched when assigned to a particular finger. Simply copy the application icon on to one of the reg- For more information on istered fingers and then click OK to close the application window.
Page 408: Bluetooth Settings (Windows 8
Windows 8 Bluetooth Settings (Windows 8) If your purchase option includes the Combination Wireless LAN & Bluetooth module (either Intel® or 3rd Party) then install the driver as instructed in Chapter 7 (see links below). Note that the Qualcomm Atheros WLAN (Combo) module only requires the WLAN driver installation.
Page 409: Bluetooth Configuration In Windows 8
Windows 8 Bluetooth Configuration in Windows 8 You can configure a Bluetooth connection as below, however make sure the Bluetooth module is turned on (and not in Airplane Mode) before configuration begins. Desktop Mode Switch to the Windows Desktop (click the app or use the Windows logo key + D key combination).
Page 410 Windows 8 Click Add a Device. Double-click the device you want to pair with the computer. Figure F - 42 - PC Settings (Devices) - Add A Device On first connection the computer will provide you with a pairing code to be entered onto the device. Figure F - 43 - Enter the Passcode Enter the code into your Bluetooth enabled device and click Yes on the computer to complete the pairing.
Page 411 Windows 8 You need to either use Airplane Mode, or to turn the Bluetooth module off aboard aircraft.  Wireless Device Operation Aboard Aircraft The use of any portable electronic transmission devices aboard aircraft is usually prohibited. Make sure the module is either OFF or in Air- plane Mode (for Win- dows 8 only) if you are...
Page 412: To Make Your Computer Discoverable To Bluetooth Devices
Windows 8 To Make your Computer Discoverable to Bluetooth Devices Switch to the Windows Desktop (click the app or use the Windows logo key + D key combination). Click the notification area of the taskbar, click the Bluetooth icon and click Open Settings. Click Options, and make sure that Allow Bluetooth devices to find this computer check box (Discovery) has a tick inside it.
Page 413: Raid Setup (Windows 8
Windows 8 RAID Setup (Windows 8)  To configure your RAID (Redundant Array of Independent Disks) system in Striping SATA Mode Selec- (RAID 0), Mirroring (RAID 1) or Recovery modes you will require at least two tion identical (see sidebar below) hard disks; to configure your system in Parity Across The SATA mode selec- Disks (RAID 5) mode you will require three hard disks installed.
Page 414 Windows 8 RAID Level Description Two Identical drives reading and writing data in parallel to increase performance. RAID 0 implements a striped disk RAID 0 array and the data is broken into blocks and each block is written to a separate disk drive. Two Identical drives in a mirrored configuration used to protect data.
Page 415: Sata Raid Setup Procedure (Windows 8
Windows 8 SATA RAID Setup Procedure (Windows 8) Before setting up the system you will need to copy a driver folder to a USB flash drive or external USB hard disk. This driver folder is included on the Device Drivers & Utilities + User’s Manual disc but you will need to go to an operable computer and copy the folder to a USB Flash drive or external USB hard disk.
Page 416 Windows 8 13. You can now setup your RAID volume using any two installed disks. 14. Go to Name: and press <Enter>. 15. Type a name of your choice for your RAID volume and press <Enter>. Figure F - 47 - Name the RAID Volume (Advanced > Intel(R) Rapid Storage Technology) F - 56 RAID Setup (Windows 8)
Page 417 Windows 8 16. Go to RAID Level: and press <Enter>. 17. Choose the RAID Level required (see Table F - 4, on page F - 54 for details) and press <Enter>. • RAID0 (Stripe) • RAID1 (Mirror) • RAID5 (Parity) •...
Page 418 Windows 8 20. You should select two identical disks to form your RAID volume. 21. If you have selected RAID0 (Stripe) then you can adjust the “Strip Size” to your requirements. 22. If you have selected Recovery then you can adjust the Synchronization to “On Request” or “Continuous”. 23.
Page 419 Windows 8 25. Press <Esc> to exit the menu. 26. Press <F4> and <Yes> to “Save Changes and Reset”, however ensure that the two conditions in the bulleted points below are met before doing so. • Make sure the Windows 8 OS DVD is in the DVD drive. and as the computer starts up it will automatically boot from the Windows 8 OS DVD (you will be prompted to press a key to boot from the DVD).
Page 420: Irst Driver Installation
Windows 8 IRST Driver Installation 1. Insert the Device Drivers & Utilities + User’s Manual disc into the CD/DVD drive. 2. Click Option Drivers (button). 3. Click 6.Install IRST Driver > Yes. 4. Click Next > Next > Yes > Next > Next. 5.
Page 421: Deleting A Raid (Windows 8
Windows 8 Deleting a RAID (Windows 8) If you wish to delete an existing RAID then follow the procedure below to do so. However backup up any neces- sary files and data before deleting a RAID, as doing so will result in the loss of all data on the RAID volumes. Start-up your notebook computer and press <F2>...
Page 422 Windows 8 F- 62...

Clevo P570WM User Manual

Quick Start Guide Overview

Storage Devices, Mouse & Audio Overview

Power Management Overview

Drivers & Utilities

BIOS Utilities Overview

Upgrading the Computer Overview

Modules Overview

Troubleshooting

Interface (Ports & Jacks) Overview

Control Center

NVIDIA Video Driver Controls

AMD Video Driver Controls

Specifications

Windows 8

Quick Links

Related Manuals for Clevo P570WM

Summary of Contents for Clevo P570WM
