Clevo P150e User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

V12.3.00

Advertisement

Table of Contents
loading

Related Manuals for Clevo P150e

Summary of Contents for Clevo P150e

  • Page 1 V12.3.00...
  • Page 3 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent vendor. They assume no responsibility or liability for any errors or inaccuracies that may appear in this publication nor are they in anyway responsible for any loss or damage resulting from the use (or misuse) of this publication.

  • Page 4: Eup-Standby And Off Mode Power Consumption Statement

    Preface R&TTE Directive This device is in compliance with the essential requirements and other relevant provisions of the R&TTE Direc- tive 1999/5/EC. This device will be sold in the following EEA countries: Austria, Italy, Belgium, Liechtenstein, Denmark, Lux- embourg, Finland, Netherlands, France, Norway, Germany, Portugal, Greece, Spain, Iceland, Sweden, Ireland, United Kingdom, Cyprus, Czech Republic, Estonia, Hungary, Latvia, Lithuania, Malta, Slovakia, Poland, Slov- enia.
  • Page 5 Preface CE Marking This device has been tested to and conforms to the regulatory requirements of the European Union and has at- tained CE Marking. The CE Mark is a conformity marking consisting of the letters “CE”. The CE Mark applies to products regulated by certain European health, safety and environmental protection legislation.

  • Page 6: Fcc Statement

    Preface FCC Statement (Federal Communications Commission) You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.

  • Page 7: Fcc Rf Radiation Exposure Statement

    Preface FCC RF Radiation Exposure Statement: This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body.

  • Page 8: Important Safety Instructions

    Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock, and injury to persons when using any electrical equipment: Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.

  • Page 9: Instructions For Care And Operation

    Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...
  • Page 10 Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong magnetic fields. These can hinder proper performance and damage your data. Follow the proper working procedures for the computer. Shut the computer down properly and don’t forget to save your work.

  • Page 11: Power Safety

    Preface Power Safety The computer has specific power requirements:  • Only use a power adapter approved for use with this computer. • Your AC/DC adapter may be designed for international travel but it still requires a Power Safety steady, uninterrupted power supply. If you are unsure of your local power specifications, Warning consult your service representative or local power company.

  • Page 12: Polymer Battery Precautions

    Preface Polymer Battery Precautions Note the following information which is specific to polymer batteries only, and where applicable, this overrides the general battery precaution information overleaf. • Polymer batteries may experience a slight expansion or swelling, however this is part of the battery’s safety mecha- nism and is not a cause for concern.

  • Page 13: General Battery Precautions

    Preface General Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not remove any batteries from the computer while it is powered on. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.

  • Page 14: Cleaning

    Preface Cleaning Do not apply cleaner directly to the computer; use a soft clean cloth. Do not use volatile (petroleum distillates) or abrasive cleaners on any part of the computer. Servicing Do not attempt to service the computer yourself. Doing so may violate your warranty and expose you and the computer to electric shock.

  • Page 15: Travel Considerations

    Preface Travel Considerations Packing As you get ready for your trip, run through this list to make sure the system is ready to go: Check that the battery pack and any spares are fully charged. Power off the computer and peripherals. Close the display panel and make sure it’s latched.
  • Page 16 Preface On the Road In addition to the general safety and maintenance suggestions in this preface, and Chapter 8: Troubleshooting, keep these points in mind: Hand-carry the notebook - For security, don’t let it out of your sight. In some areas, computer theft is very common.
  • Page 17 Preface Developing Good Work Habits Developing good work habits is important if you need to work in front of the computer for long periods of time. Improper work habits can result in discomfort or serious injury from repetitive strain to your hands, wrists or other joints.

  • Page 18: Lcd Screen Care

    Preface Lighting Proper lighting and a comfortable viewing angle can reduce eye strain and shoulder and neck muscle fatigue. • Position the display to avoid glare or reflections from overhead lighting or outside sources of light. • Keep the display screen clean and set the brightness and contrast to levels that allow you to see the screen clearly. •...

  • Page 19: Table Of Contents

    Preface Contents Notice ................................I EuP-Standby and Off Mode Power Consumption Statement: ..............II FCC Statement ............................IV FCC RF Radiation Exposure Statement: ..................... V Instructions for Care and Operation ......................VII Power Safety ...............................IX Polymer Battery Precautions ........................X General Battery Precautions ........................XI Cleaning ..............................
  • Page 20 Preface System Map: LCD Panel Open - Models A & B ..................1-7 System Map: LCD Panel Open - Model C ....................1-8 LED Indicators ............................1-9 Keyboard - Models A & C ........................1-10 Keyboard LED - Models A & C ......................1-11 Effects Buttons & Help (Models A & C) ....................1-13 Keyboard - Model B ..........................1-14 Function Keys &...
  • Page 21 Preface Optical Device ............................2-3 Loading Discs ............................2-3 Handling CDs or DVDs ..........................2-4 DVD Regional Codes ..........................2-5 Multi-in-1 Card Reader ..........................2-6 Audio Features ............................2-7 Setup for Audio Recording ........................2-8 Setup for 5.1 or 7.1 Surround Sound ......................2-9 TouchPad and Buttons/Mouse .........................2-11 Gestures and Device Settings ........................2-13 Power Management Overview ..............................3-1...
  • Page 22 Preface Configuring the Power Buttons .........................3-8 Resuming Operation ..........................3-9 Power Conservation Modes ........................3-10 Battery Information ..........................3-11 Conserving Battery Power ........................3-12 Battery Life ..............................3-13 New Battery .............................3-13 Recharging the Battery with the AC/DC Adapter ...................3-13 Proper handling of the Battery Pack ......................3-14 Battery FAQ .............................3-15 Drivers &...
  • Page 23 Preface Video (VGA) .............................4-6 NVIDIA Video (VGA) ..........................4-6 LAN ................................4-6 Card Reader ...............................4-7 TouchPad ..............................4-7 Hot Key ..............................4-7 USB 3.0 ..............................4-7 MEI Driver ..............................4-7 Audio .................................4-7 Windows Experience Index ........................4-8 Optional Drivers ............................4-9 BIOS Utilities Overview ..............................5-1 The Power-On Self Test (POST) .......................5-2 Failing the POST ............................5-3 Fatal Errors ..............................5-3 Non-Fatal Errors ............................5-3...
  • Page 24 Preface System Time & Date (Main Menu) ......................5-6 SATA Port # (Main Menu) ........................5-7 System/Extended Memory (Main Menu) ....................5-7 MB Series / BIOS Revision / KBC/EC firmware Revision / VGA Card (Main Menu) ......5-7 Advanced Menu ............................5-8 Advanced Chipset Control (Advanced Menu) ..................5-8 Bluetooth Power Setting (Advanced Menu >...
  • Page 25 Preface When Not to Upgrade ..........................6-2 Removing the Battery ..........................6-3 Upgrading the Optical Device (Model A/B) .....................6-4 Upgrading the Optical Device (Model C) ....................6-5 Upgrading the Hard Disk Drive(s) ......................6-6 Upgrading the System Memory (RAM) ....................6-16 Replacing the Primary System Memory Modules ...................6-17 Modules Overview ..............................7-1 Setting Up SATA RAID or AHCI Mode ....................7-2...
  • Page 26 Preface PC Camera Audio Setup ..........................7-17 Wireless LAN Module ..........................7-23 3rd Party 802.11b/g/n Driver Installation ....................7-24 Intel® WLAN Driver Installation ......................7-25 Connecting to a Wireless Network in Windows 7 ...................7-28 Connecting to a Wireless Network Using Intel® PROSet Wireless ............7-31 Intel®...
  • Page 27 Preface Standard Bluetooth Configuration in Windows 7 ...................7-71 THX TruStudio Pro Audio ........................7-75 THX TruStudio AP Installation .......................7-75 THX TruStudio Pro Activation .......................7-76 THX TruStudio Pro Application ......................7-76 Intel® Rapid Storage Technology Driver ....................7-80 Intel® Smart Response Technology ......................7-81 Enabling Intel Smart Response Technology ....................7-82 Intel®...
  • Page 28 Preface Interface (Ports & Jacks) Overview ..............................A-1 Ports and Jacks ............................A-2 Card Reader ..............................A-2 DC-In Jack ..............................A-2 DisplayPort ...............................A-2 DVI-Out Port ............................A-2 e-SATA / USB 3.0 Combo Port .......................A-2 HDMI-Out Port ............................A-3 Headphone-Out Jack ..........................A-3 Line-In Jack ..............................A-3 Microphone-In Jack ..........................A-3 Mini-IEEE 1394a Port ..........................A-4 RJ-45 LAN Jack ............................A-4 S/PDIF-Out Jack ............................A-4...
  • Page 29 Preface Video Driver Controls Video Driver Installation ..........................C-1 Video (VGA) ............................C-1 NVIDIA Video (VGA) ..........................C-1 NVIDIA® Optimus™ Technology ......................C-2 Intel® Graphics & Media Control Panel ....................C-4 Display Devices & Options ........................C-6 Attaching Other Displays .........................C-7 Configuring an External Display in Windows 7 ..................C-10 NVIDIA Control Panel ...........................C-13 Optimus™...
  • Page 30 Preface Video Adapter Options ..........................D-3 Storage ..............................D-4 BIOS .................................D-4 Audio ................................D-4 Keyboard & Pointing Device ........................D-4 Interface ..............................D-4 Slots ................................D-4 Card Reader ..............................D-5 Communication ............................D-5 Communication ............................D-5 Security ..............................D-5 Features ..............................D-5 Power Management ..........................D-5 Power ................................D-5 Environmental Spec ..........................D-5 Physical Dimensions & Weight ........................D-6 XXVIII...

  • Page 31: Quick Start Guide Overview

    Quick Start Guide Chapter 1: Quick Start Guide Overview This Quick Start Guide is a brief introduction to the basic features of your computer, to navigating around the computer and to getting your system started. The remainder of the manual covers the following: •...

  • Page 32: Advanced Users

    Quick Start Guide Advanced Users If you are an advanced user you may skip over most of this Quick Start Guide. However you may find it useful to refer to “Drivers & Utilities” on page 4 - “BIOS Utilities” on page 5 - 1 “Upgrading The Computer”...

  • Page 33: Not Included

    Quick Start Guide Not Included Operating Systems (e.g. Windows 7) and applications (e.g. word processing, spreadsheet and database programs) have their own manuals, so please consult the appropriate manuals.  Drivers If you are installing new system software, or are re-configuring your computer for a different system, you will need to install the appropriate drivers.

  • Page 34: System Software

    Quick Start Guide System Software Your computer may already come with system software pre-installed. Where this is not the case, or where you are re-configuring your computer for a different system, you will find the Windows 7 operating system is sup- ported.

  • Page 35: Model Differences

    Quick Start Guide Model Differences This notebook series includes three different model types that mainly differ as indicated in the table below. Note that your model may appear slightly different from those pictured in this manual. Feature Model A Model B Model C CPU Type “Specifications”...

  • Page 36: System Startup

    Quick Start Guide System Startup 1. Remove all packing materials, and place the computer on a stable surface. 2. Securely attach any peripherals you want to use with the notebook (e.g. keyboard and mouse) to their ports. 3. Attach the AC/DC adapter to the DC-In jack at the rear of the computer, then plug the AC power cord into an outlet, and connect the AC power cord to the AC/DC adapter.

  • Page 37: System Map: Lcd Panel Open - Models A & B

    Quick Start Guide System Map: LCD Panel Open - Models A & B Figure 1 - 2 LCD Panel Open  1. Built-In PC Camera 2. LCD Wireless Device 3. LED Lock Indicators Operation Aboard 4. Power Button Aircraft 5. Speakers The use of any portable 6.

  • Page 38: System Map: Lcd Panel Open - Model C

    Quick Start Guide System Map: LCD Panel Open - Model C Figure 1 - 3 LCD Panel Open  1. Built-In PC Camera 2. LCD Wireless Device 3. Speakers Operation Aboard 4. LED Indicators Aircraft 5. Power Button 6. Keyboard The use of any portable electronic transmission de- 7.

  • Page 39: Led Indicators

    Quick Start Guide LED Indicators The LED indicators display helpful information about the current status of the computer. Icon Color Models A&B or C Description Icon Color Description Number Lock is Activated Blue / White Orange The Battery is Charging Caps Lock is Activated The Battery has Reached Critically Blue / White...

  • Page 40: Keyboard - Models A & C

    Quick Start Guide Keyboard - Models A & C  The keyboard has an embedded numerical keypad for easy numeric data input, and Other Keyboards features function keys to allow you to change operational features instantly. See Table 1 - 5, on page 1 - 15 for full function key combination details.

  • Page 41: Keyboard Led - Models A & C

    Quick Start Guide Keyboard LED - Models A & C Press Fn plus the key to toggle the keyboard LED on/off. The keyboard LED may be configured using the Fn + key combination outlined in the table below. In addition press Fn plus the key to launch the keyboard backlight application to configure the settings (see overleaf).
  • Page 42 Quick Start Guide Keyboard Backlight Application (Models A & C) The keyboard Backlight application can be accessed by pressing the Fn plus key. Click the Help button in the application to display the configuration keys. • Click the Custom button to display the three sections of the keyboard which may be configured.

  • Page 43: Effects Buttons & Help (Models A & C)

    Quick Start Guide Effects Buttons & Help (Models A & C) LED Effects Buttons Random Color Up/Down Wave Dancing Effect Breathing (All Colors) Tempo Beat Cycle (Colors as Selected in RGB) Custom Mode - Display & Configure Flashing Keyboard Sections & Colors ...

  • Page 44: Keyboard - Model B

    Quick Start Guide Keyboard - Model B  The keyboard has an embedded numerical keypad for easy numeric data input, and Other Keyboards features function keys to allow you to change operational features instantly. See Table 1 - 5, on page 1 - 15 for full function key combination details.

  • Page 45: Function Keys & Visual Indicators

    Quick Start Guide Function Keys & Visual Indicators The function keys (F1 - F12 etc.) will act as hot keys when pressed while the Fn key is held down. Visual in- dicators (see the table below) are available when the Hot Key driver is installed. Keys Function/Visual Indicators Keys...

  • Page 46: Control Center

    Quick Start Guide Control Center Press the Fn + Esc key combination, or double-click the icon in the notification area of the taskbar to toggle the Control Center on/off. The Control Center gives quick access to frequently used controls and en- ables you to quickly turn modules on/off.

  • Page 47: System Map: Front & Rear Views

    Quick Start Guide System Map: Front & Rear Views Figure 1 - 7 Front View Models A & B 1. LED Power Indica- tors 2. Vent/Fan Intake Models A & B 3. Display Port 4. HDMI-Out Port 5. DVI-Out Port 6.

  • Page 48: System Map: Right View

    Quick Start Guide System Map: Right View Figure 1 - 8 Right View 1. Optical Device Models A & B Drive Bay 2. Headphone Jack 3. Microphone Jack 4. S/PDIF-Out Jack 5. Line-In Jack Model C 6. 1 * USB 2.0 Port 7.

  • Page 49: System Map: Left View

    Quick Start Guide System Map: Left View Figure 1 - 9 Left View Models A & B 1. Mini-IEEE 1394a Port 2. RJ-45 LAN Jack 3. 1 * Powered USB 3.0 Port Model C 4. 1 * USB 3.0 Port 5.

  • Page 50: System Map: Bottom View - Models A & B

    Quick Start Guide System Map: Bottom View - Models A & B Figure 1 - 10 Bottom View 1. Sub Woofer 2. Fan Outlet/Intake 3. Component Bay Cover 4. HDD Bay 5. Battery  Overheating  To prevent your comput- Battery Information er from overheating make sure nothing blocks the...

  • Page 51: System Map: Bottom View - Model C

    Quick Start Guide System Map: Bottom View - Model C Figure 1 - 11 Bottom View 1. Sub Woofer 2. Fan Outlet/Intake 3. Component Bay Cover 4. Primary HDD Bay 5. Secondary HDD 6. Battery  Overheating  To prevent your comput- er from overheating make Battery Information sure nothing blocks the...

  • Page 52: Windows 7 Start Menu & Control Panel

    Quick Start Guide Windows 7 Start Menu & Control Panel Most of the control panels, utilities and programs within Windows 7 are accessed from the Start menu. When you install programs and utilities they will be installed on your hard disk drive, and a shortcut will usually be placed in the Start menu and/or the desktop.

  • Page 53: Video Features

    Quick Start Guide Video Features ® NVIDIA Optimus Technology ™ NVIDIA Optimus technology is a seamless technology designed to get best performance from the graphics ® ™ system while allowing longer battery life, without having to manually change settings. The computer will auto- matically switch between the integrated UMA (Unified Memory Architecture) GPU (iGPU) and the discrete GPU (dGPU) when required by the applications in use.
  • Page 54 Quick Start Guide To access Display (Control Panel) and Screen Resolution in Windows: Click Start and click Control Panel. Click Display (icon) - In the Appearances and Personalization category. Click Adjust Screen Resolution/Adjust resolution. Alternatively you can right-click the desktop and select Screen resolution. Use the dropbox to select the screen Resolution (Figure 1 - 13).
  • Page 55 Quick Start Guide To access the Intel(R) Graphics and Media Control Panel: Click Advanced settings (Figure 1 - 13 on page 1 - 24) in the Display Settings control panel in Windows. Click Graphics Properties (button) (Figure 1 - 14) in the Intel Graphics & Media Control Panel tab. Right-click the desktop and select Graphics Properties from the menu.
  • Page 56 Quick Start Guide To access the NVIDIA Control Panel: Right-click the desktop and select NVIDIA Control Panel (Figure 1 - 15). Double-click the icon (Figure 1 - 15) in the Windows control panel. Figure 1 - 15 - NVIDIA Control Panel 1 - 26 Video Features...

  • Page 57: Power Options

    Quick Start Guide Power Options The Power Options (Hardware and Sound menu) control panel icon in Windows (see page 21) allows you to configure power management features for your computer. You can conserve power by means of power plans and configure the options for the power button, sleep button, computer lid (when closed), display and sleep mode from the left menu.
  • Page 58 Quick Start Guide 1 - 28...

  • Page 59: Storage Devices, Mouse, & Audio Overview

    Storage Devices, Mouse, & Audio Chapter 2: Storage Devices, Mouse, & Audio Overview Read this chapter to learn more about the following main features and components of the computer: • Hard Disk Drive • Optical Device • Multi-in-1 Card Reader •...

  • Page 60: Hard Disk Drive

    Storage Devices, Mouse, & Audio Hard Disk Drive  The hard disk drive(s) is used to store your data in the computer. The hard disks) can Power Safety be taken out to accommodate other 2.5" serial (SATA) hard disk drives with a height of 9.5 mm.

  • Page 61: Optical Device

    Storage Devices, Mouse, & Audio Optical Device  There is a bay for a 5.25" optical (CD/DVD) device (12.7mm height). The actual de- Sound Volume vice will depend on the model you purchased (see “Storage” on page D - 4). The Adjustment optical device is usually labeled “Drive D:”...

  • Page 62: Handling Cds Or Dvds

    Storage Devices, Mouse, & Audio Handling CDs or DVDs  Proper handling of your CDs/DVDs will prevent them from being damaged. Please follow the advice below to make sure that the data stored on your CDs/DVDs can be CD Emergency Eject accessed.

  • Page 63: Dvd Regional Codes

    Storage Devices, Mouse, & Audio DVD Regional Codes  To change the DVD regional codes: DVD Region Note Go to the Control Panel Double-click Device Manager (Hardware and Sound), then click the + next to DVD region detection is DVD/CD-ROM drives. device dependent, not Double-click on the DVD-ROM device to bring up the Properties dialog box, and OS-dependent.

  • Page 64: Multi-In-1 Card Reader

    Storage Devices, Mouse, & Audio Multi-in-1 Card Reader  The card reader allows you to use some of the latest digital storage cards. Push the Card Reader Cover card into the slot and it will appear as a removable device, and can be accessed in the same way as your hard disk (s).

  • Page 65: Audio Features

    Storage Devices, Mouse, & Audio Audio Features  You can configure the audio options on your computer from the Sound control Volume Adjustment panel in Windows, or from the Realtek HD Audio Manager icon in the notifi- The sound volume level is cation area/control panel (right-click the notification area icon to bring up an au- set using the volume con-...

  • Page 66: Setup For Audio Recording

    Storage Devices, Mouse, & Audio Setup for Audio Recording To record audio sources on your computer at optimum quality follow the instruc- tions below: Click Start, and click Control Panel (or point to Settings and click Control Panel) and make sure you are in Classic View. Click Realtek HD Audio Manager (or right-click the notification area icon select Sound Manager).

  • Page 67: Setup For 5.1 Or 7.1 Surround Sound

    Storage Devices, Mouse, & Audio Setup for 5.1 or 7.1 Surround Sound  To setup your system for 5.1 or 7.1 surround sound you will need to connect the au- dio cables to the Headphone-Out, Line-In, Microphone-In jack and S/PDIF-Out THX Audio &...
  • Page 68 Storage Devices, Mouse, & Audio Plug the front speaker cables into the Headphone-Out Jack. Plug in the other cables (you may require an adapter to connect each cable to the appropriate jack e.g a stereo mini to dual RCA adapter) from your speakers as follows: •...

  • Page 69: Touchpad And Buttons/Mouse

    Storage Devices, Mouse, & Audio TouchPad and Buttons/Mouse  The TouchPad is an alternative to the mouse; however, you can also add a mouse to Mouse Driver your computer through one of the USB ports. The TouchPad buttons function in much the same way as a two-button mouse.
  • Page 70 Storage Devices, Mouse, & Audio Once you have installed the TouchPad driver (see “TouchPad” on page 4 - 7) you  can configure the functions from the Mouse control panel in Windows, or by double- clicking the TouchPad driver icon in the notification area.

  • Page 71: Gestures And Device Settings

    Storage Devices, Mouse, & Audio Gestures and Device Settings  The Synaptics Gestures Suite application allows you to use a specific gesture (ac- tion) on the surface of the TouchPad to perform specific actions to manipulate doc- Show Video uments, objects and applications. You can get a clearer view of the gestures in- volved by clicking the...
  • Page 72 Storage Devices, Mouse, & Audio Scrolling The Two-Finger scrolling feature works in most scrollable windows and allows you to scroll horizontally and vertically. Place two fingers, slightly separated, on the TouchPad surface and slide both fingers in the direction required (in a straight con- tinuous motion).
  • Page 73 Storage Devices, Mouse, & Audio Rotating Use the Pivot Rotate gesture to rotate objects (e.g. photos) in 90 degree increments. Place a finger down on the left “target” zone and keep it stationary. Place another finger near the middle of the TouchPad and slide it in a circular motion around the stationary finger (clockwise or counterclockwise) to rotate the object.
  • Page 74 Storage Devices, Mouse, & Audio 2 - 16...

  • Page 75: Power Management Overview

    Power Management Chapter 3: Power Management  Overview OS Note Power management To conserve power, especially when using the battery, your computer power man- functions will vary slight- agement conserves power by controlling individual components of the computer ly depending on your (the monitor and hard disk drive) or the whole system.

  • Page 76: The Power Sources

    Power Management The Power Sources The computer can be powered by either an AC/DC adapter or a battery pack. AC/DC Adapter Use only the AC/DC adapter that comes with your computer. The wrong type of AC/ DC adapter will damage the computer and its components. Attach the AC/DC adapter to the DC-In jack at the rear of the computer.

  • Page 77: Turning On The Computer

    Power Management Turning On the Computer  Now you are ready to begin using your computer. To turn it on simply press the pow- Forced Off er button on the front panel. If the system “hangs”, When the computer is on, you can use the power button as a Stand by/Hibernate/ and the Ctrl + Alt + Del Shutdown hot-key button when it is pressed for less than 4 seconds (pressing and key combination doesn’t...

  • Page 78: Power Plans

    Power Management Power Plans  The computer can be configured to conserve power by means of power plans. You Resuming can use (or modify) an existing power plan, or create a new one. Operation The settings may be adjusted to set the display to turn off after a specified time, and Table 3 - 1, on to send the computer into Sleep after a period of inactivity.
  • Page 79 Power Management Each Windows power plan will also adjust the processor performance of your ma- chine in order to save power. This is worth bearing in mind if you are experiencing any reduced performance (especially under DC/battery power). Choose High performance (you may need to click Show additional plans to view the High performance plan) for maximum performance when the computer is pow- ered from an AC power source.

  • Page 80: Power-Saving States

    Power Management Power-Saving States You can use power-saving states to stop the computer’s operation and restart where you left off. Win 7 uses the Sleep, Hibernate and Shut Down power-saving states. Sleep In Sleep all of your work, settings and preferences are saved to memory before the system sleeps.

  • Page 81: Hibernate

    Power Management Hibernate Hibernate uses the least amount of power of all the power-saving states and saves all of your information on a part of the hard disk before it turns the system off. If a power failure occurs the system can restore your work from the hard disk; if a power failure occurs when work is saved only to memory, then the work will be lost.

  • Page 82: Configuring The Power Buttons

    Power Management Configuring the Power Buttons  The power/sleep button (Fn + F4 key combo) and closed lid may be set to send the Password computer in to a power-saving state. Click Choose what the power buttons do on Protection the left menu in Power Options to bring up the menu.

  • Page 83: Resuming Operation

    Power Management Resuming Operation  You can resume operation from power-saving states by pressing the power button, or in some cases pressing the sleep button (Fn + F4 key combo). Closing the Lid If you have chosen to Power Status Icon Color To Resume...

  • Page 84: Power Conservation Modes

    Power Management Power Conservation Modes  This system supports Energy Star power management features that place comput- ers (CPU, hard drive, etc.) into a low-power sleep modes after a designated period Power Conservation of inactivity. Adjust Power Conservation Modes from the Control Center: Modes The Energy Star setting Press the Fn + Esc key combination to toggle the Control Center on/off.

  • Page 85: Battery Information

    Power Management Battery Information  Follow these simple guidelines to get the best use out of your battery. Low Battery Battery Power Warning Your computer’s battery power is dependent upon many factors, including the pro- When the battery is criti- grams you are running, and peripheral devices attached.

  • Page 86: Conserving Battery Power

    Power Management Conserving Battery Power  • Use a power plan that conserves power (e.g Power saver), however note that this may have an affect on computer performance. Windows Mobility Center • Lower the brightness level of the LCD display. The system will decrease LCD The Windows Mobility brightness slightly to save power when it is not powered by the AC/DC adapter.

  • Page 87: Battery Life

    Power Management Battery Life Battery life may be shortened through improper maintenance. To optimize the life and improve its performance, fully discharge and recharge the battery at least once every 30 days. We recommend that you do not remove the battery yourself. If you do need to re- move the battery for any reason (e.g.

  • Page 88: Proper Handling Of The Battery Pack

    Power Management Proper handling of the Battery Pack  • DO NOT disassemble the battery pack under any circumstances. • DO NOT expose the battery to fire or high temperatures, it may explode. Caution • DO NOT connect the metal terminals (+, -) to each other. Danger of explosion if battery is incorrectly re- ...

  • Page 89: Battery Faq

    Power Management Battery FAQ How do I completely discharge the battery? Use the computer with battery power until it shuts down due to a low battery. Don’t turn off the computer even if a message indicates the battery is critically low, just let the computer use up all of the battery power and shut down on its own.
  • Page 90 Power Management Click Change plan settings (after creating it) and click Change plan settings > Change advanced power settings. Figure 3 - 9 Change Plan Settings / Change Advanced Power Settings 3 - 16 Battery Information...
  • Page 91 Power Management Scroll down to Battery and click + to expand the battery options. Choose the options below (click Yes if a warning appears): Figure 3 - 10 Power Options Advanced Settings - Battery • Low battery levels = 0% •...
  • Page 92 Power Management How do I fully charge the battery? When charging the battery, don’t stop until the LED charging indicator light changes from orange to green. How do I maintain the battery? Completely discharge and charge the battery at least once every 30 days or after about 20 partial discharges.

  • Page 93: Drivers & Utilities

    Drivers & Utilities Chapter 4: Drivers & Utilities  Driver Installation & This chapter deals with installing the drivers and utilities essential to the operation or Power improvement of some of the computer’s subsystems. The system takes advantage of some newer hardware components for which the latest versions of most available op- When installing driv- erating systems haven’t built in drivers and utilities.

  • Page 94: Driver Installation

    Drivers & Utilities Driver Installation Check the driver installation order from Table 4 - 1, on page 4 - 3 (the drivers must be installed in Insert the Device Drivers & Utilities + User’s Manual this order) which is the same as that listed in the disc and click Install Drivers (button), or Option Driv- Drivers Installer menu below.
  • Page 95 Drivers & Utilities Windows 7 SP1 Driver Page Windows 7 SP1 Driver Page Chipset Page 4 - 6 PC Camera Module Page 7 - 15 Video (VGA) Page 4 - 6 Wireless LAN Module Page 7 - 23 NVIDIA Video (VGA) Page 4 - 6 Intel®...

  • Page 96: Manual Driver Installation

    Drivers & Utilities Manual Driver Installation Updating/Reinstalling Individual Drivers Click the Browse CD/DVD button in the Drivers In- If you wish to update/reinstall individual drivers it staller application and browse to the executable file in may be necessary to uninstall the original driver.To do the appropriate driver folder.

  • Page 97: User Account Control

    Drivers & Utilities User Account Control New Hardware Found If a User Account Control prompt appears as part of If you see the message “New Hardware Found” dur- the driver installation procedure, click Continue/Al- ing the installation procedure (other than when out- low, and follow the installation procedure as directed.

  • Page 98: Driver Installation Procedure

    Drivers & Utilities Driver Installation Procedure Video (VGA) Insert the Device Drivers & Utilities + User’s Manual 1. Click 2.Install VGA Driver > Yes. disc and click Install Drivers (button), or Option Driv- 2. Click Next > Yes > Next > Next. ers (button) to access the Optional driver menu.

  • Page 99: Card Reader

    Drivers & Utilities Card Reader USB 3.0 1. Click 5.Install Cardreader Driver > Yes. 1. Click 8.Install USB 3.0 Driver > Yes. 2. Click Finish. 2. Click Next > Yes > Next > Next. 3. Click Finish to restart the computer. TouchPad MEI Driver 1.

  • Page 100: Windows Experience Index

    Drivers & Utilities Windows Experience Index It is recommended that you install the THX Tru Stu- dio Pro Audio application (see “THX TruStudio AP After Video (VGA) driver has been installed, and the Installation” on page 7 - 75) and Intel Rapid Storage system restarted, the OS will automatically run the Technology driver (see “IRST Driver Installation”...

  • Page 101: Optional Drivers

    Drivers & Utilities Optional Drivers See the pages indicated in Table 4 - 1, on page 4 - 3 for the driver installation procedures for any modules in- cluded in your purchase option. Models A & B Figure 4 - 3 - Optional Drivers Installer Screen Note that for Intel and some 3rd party WLAN &...
  • Page 102 Drivers & Utilities 4 - 10...

  • Page 103: Bios Utilities Overview

    BIOS Utilities Chapter 5: BIOS Utilities  BIOS Screens Overview Note that BIOS This chapter gives a brief introduction to the computer’s built-in software: screens pictured these pages are intend- Diagnostics: The POST (Power-On Self Test) ed for guidance in set- ting up your system’s BIOS.

  • Page 104: The Power-On Self Test (Post)

    BIOS Utilities The Power-On Self Test (POST) If you enable the Boot-time Diagnostic Screen in the Setup Utility, each time you turn on the computer the system takes a few seconds to conduct a POST, including a quick test of the on-board RAM (memory). As the POST proceeds, the computer will tell you if there is anything wrong.

  • Page 105: Failing The Post

    BIOS Utilities Failing the POST Errors can be detected during the POST. There are two categories, “fatal” and “non- fatal”. Fatal Errors These stop the boot process and usually indicate there is something seriously wrong with your system. Take the computer to your service representative or authorized service center as soon as possible.

  • Page 106: The Setup Utility

    BIOS Utilities The Setup Utility  The Aptio Setup Utility tells the system how to configure itself and manage basic BIOS Settings features and subsystems (e.g. port configuration). Warning Entering Setup Incorrect settings can cause your system to To enter Setup, turn on the computer and press F2 (give the system a few seconds malfunction.

  • Page 107: Setup Screens

    BIOS Utilities Setup Screens  The following pages contain additional advice on portions of the Setup. Along the top of the screen is a menu bar with menu headings. When you select a heading, a Setup Menus new screen appears. Scroll through the features listed on each screen to make chang- Setup menus es to Setup.

  • Page 108: Main Menu

    BIOS Utilities Main Menu Figure 5 - 2 Main Menu System Time & Date (Main Menu) The hour setting uses the 24-hour system (i.e., ØØ = midnight; 13 = 1 pm). If you can change the date and time settings in your operating system, you will also change these settings.

  • Page 109: Sata Port # (Main Menu)

    BIOS Utilities SATA Port # (Main Menu) Pressing Enter opens the sub-menu to show the configuration of a optical Device/ HDD on the computer’s SATA Ports. System/Extended Memory (Main Menu) This item contains information on the system memory, and is not user configurable. The system will auto detect the amount of memory installed.

  • Page 110: Advanced Menu

    BIOS Utilities Advanced Menu Figure 5 - 3 Advanced Menu Advanced Chipset Control (Advanced Menu) The sub-menu here allows you to adjust the Bluetooth Power Setting and enable/ disable Intel(R) Rapid Start Technology. 5 - 8 Advanced Menu...

  • Page 111: Bluetooth Power Setting (Advanced Menu > Advanced Chipset Control)

    BIOS Utilities Bluetooth Power Setting (Advanced Menu > Advanced Chipset Control)  You can adjust the Bluetooth module power setting to your preference. The default setting (Disabled) will see the Bluetooth module powered off when the system is SATA Mode started up or restarted.

  • Page 112: Legacy Usb Support (Advanced Menu)

    BIOS Utilities Legacy USB Support (Advanced Menu) Choose “Enabled” if you intend to use USB devices in systems which do not nor- mally support USB functionality (e.g. DOS). The default setting is “Enabled” and does not need to be changed if you intend to use your USB devices in Windows. Boot Logo (Advanced Menu) Use this menu item to enable/disable the Boot Logo screen at system startup.

  • Page 113: Security Menu

    BIOS Utilities Security Menu  Security Menu The changes you make here affect the access to the Setup utility itself, and also access to your machine as it boots up after you turn it on. These settings do not affect your machine or network passwords which will be set in your...

  • Page 114: Password On Boot: (Security Menu)

    BIOS Utilities Note: To clear existing passwords press Enter and type the existing password, then  press Enter for the new password (without typing any password entry) and Enter again to confirm the password clearance. Password Warning Note: You can only set the user password after you have set the supervisor pass- If you set a boot pass- word.

  • Page 115: Boot Menu

    BIOS Utilities Boot Menu Figure 5 - 5 Boot Menu  BIOS Screens Note that BIOS screens pictured these pages are intend- ed for guidance in set- ting up your system’s BIOS. BIOS versions are sub- ject to constant change and revision, therefore your computer’s actual When you turn the computer on it will look for an operating system (e.g.

  • Page 116: Boot Option Priorities (Boot Menu)

    BIOS Utilities Boot Option Priorities (Boot Menu) Use the arrow keys to move up and down the menu and use the F5 and F6 keys to move the device’s boot priority up and down the list (the selected device will be highlighted in white).

  • Page 117: Exit Menu

    BIOS Utilities Exit Menu Figure 5 - 6 Exit Menu Click Save Changes and Reset to save all changes made. Choosing to Discard Changes, or Exit Discarding Changes, will wipe out any changes you have made to the Setup. You can also choose to restore the original Setup defaults that will re- turn the Setup to its original state, and erase any previous changes you have made in a previous session.
  • Page 118 BIOS Utilities 5 - 16...

  • Page 119: Upgrading The Computer Overview

    Upgrading The Computer Chapter 6: Upgrading The Computer Overview  This chapter contains information on upgrading the computer. Follow the steps out- Warranty Warning lined to make the desired upgrades. If you have any trouble or problems you can con- tact your service representative for further help.

  • Page 120: When Not To Upgrade

    Upgrading The Computer When Not to Upgrade  These procedures involve opening the system’s case, adding and sometimes replac- ing parts.You should not perform any of these upgrades if: Power Safety Warning Before you undertake • Your system is still under warranty or a service contract upgrade proce- •...

  • Page 121: Removing The Battery

    Upgrading The Computer Removing the Battery  If you are confident in undertaking upgrade procedures yourself, for safety reasons Warranty Warning it is best to remove the battery. Before removing the battery disconnect the AC/ DC adapter from the computer first. Note that only Model A/B is pictured, how- Please check with your ever the procedure for removing the battery from Model C is the same.

  • Page 122: Upgrading The Optical Device (Model A/B)

    Upgrading The Computer Upgrading the Optical Device (Model A/B)  Locate the hard disk bay cover and remove screws & Secondary Hard Disk Remove the hard disk bay cover Module (Models A/B) Remove the screw at point , and use a screwdriver to carefully push out the optical device at point Model A and B comput- Reverse the process to install any new optical (CD/DVD) device.

  • Page 123: Upgrading The Optical Device (Model C)

    Upgrading The Computer Upgrading the Optical Device (Model C) Locate the secondary hard disk bay cover and remove screws & Remove the hard disk bay cover. Remove the screw at point , and use a screwdriver to carefully push out the optical device out of the bay.

  • Page 124: Upgrading The Hard Disk Drive(S)

    Upgrading The Computer Upgrading the Hard Disk Drive(s)  The hard disk Drive(s) can be taken out to accommodate other 2.5" serial (SATA) HDD System Warning hard disk drives with a height of 9.5mm (h) (see “Storage” on page D - 4).
  • Page 125 Upgrading The Computer Removing the Hard Disk from the Primary HDD Bay  Note that only Model A/B is pictured, however the procedure for removing the pri- mary hard disk from Model C is the same (note the screw location differences). RAID Hard Disks Turn the computer off, remove the AC/DC adapter, turn it over and remove the bat- All hard disks in a RAID...
  • Page 126 Upgrading The Computer Slide the HDD assembly in the direction of arrow Remove the hard disk assembly Figure 6 - 5 Hard Disk Assembly Removal 6 - 8 Upgrading the Hard Disk Drive(s)
  • Page 127 Upgrading The Computer Remove screws & and the insulation plate Reverse the process to install a new disk and do not forget to install the insulation plate. Figure 6 - 6 Hard Disk Insulation Plate Removal Upgrading the Hard Disk Drive(s) 6 - 9...
  • Page 128 Upgrading The Computer Inserting the Hard Disk Into the Primary HDD Bay Make sure the HDD assembly is aligned with the black taped area When aligned, carefully insert the HDD assembly into the case so that the connectors line up. Replace the hard disk bay covers and screws.
  • Page 129 Upgrading The Computer Removing the Hard Disk from the Secondary HDD Bay (Model C)  Note that the secondary hard disk (Model C if installed) is located under the optical device bay (CD/DVD). RAID Hard Disks Turn the computer off, remove the AC/DC adapter, turn it over and remove the bat- All hard disks in a RAID tery.
  • Page 130 Upgrading The Computer Slide the secondary HDD assembly in the direction of the arrow (it will not move fully out of the bay), Lift the secondary HDD assembly up out of the bay (in the reverse direction to arrow Figure 6 - 9 Secondary HDD Assembly Removal (Model C)
  • Page 131 Upgrading The Computer Remove screws and the insulation plate Figure 6 - 10 Secondary Hard Disk Insulation Plate Removal (Model C) Reverse the process to install a new disk (make sure you install the insulation plate). Slide the HDD assembly into the bay at an angle as illustrated. 10.
  • Page 132 Upgrading The Computer Removing the Hard Disk from the Secondary HDD Bay (Model A/B) Note that the secondary hard disk module is used to replace the optical device mod- ule (CD/DVD) in Model A & B computers. Turn the computer off, remove the AC/DC adapter, turn it over and remove the bat- tery.
  • Page 133 Upgrading The Computer When the module is removed turn it over to access the rear. Remove screws from the secondary HDD module assembly. Remove the hard disk from the module caddy Reverse the process to install a new hard disk. Figure 6 - 13 Removing the Secondary HDD...

  • Page 134: Upgrading The System Memory (Ram)

    Upgrading The Computer Upgrading the System Memory (RAM) The computer has four memory sockets for 204 pin Small Outline Dual In-line (SO- DIMM) DDR III (DDR3) type memory modules (see “Memory” on page D - The total memory size is automatically detected by the POST routine once you turn on your computer.

  • Page 135: Replacing The Primary System Memory Modules

    Upgrading The Computer Replacing the Primary System Memory Modules Turn off the computer, and turn it over and remove the battery. Remove screws from the bottom of the computer Figure 6 - 14 Bottom Cover Screws Models A & B Model C Slide the bottom cover until the cover and case indicators are aligned.
  • Page 136 Upgrading The Computer Lift the bottom cover off the computer case. Figure 6 - 16 Bottom Cover Removal  Contact Warning Be careful not to touch the metal pins on the module’s connecting Gently pull the two release latches ( &...
  • Page 137 Upgrading The Computer Pull the latches to release the second module if necessary. Insert a new module holding it at about a 30° angle and fit the connectors firmly into the memory socket. The module’s pin alignment will allow it to only fit one way. Make sure the module is seated as far into the socket as it will go.
  • Page 138 Upgrading The Computer 6 - 20...

  • Page 139: Modules Overview

    Modules Chapter 7: Modules Overview This chapter contains the information on the various modules (some of which are optional) which may come with your computer, depending on the configuration purchased. If you are unsure please contact your service representative. The chapter includes information on the following: •...

  • Page 140: Setting Up Sata Raid Or Ahci Mode

    Modules Setting Up SATA RAID or AHCI Mode  AHCI Mode RAID Hard Disks Advanced Host Controller Interface (AHCI) is an interface specification that allows All hard disks in a RAID the storage driver to enable advanced serial ATA features such as Native Command should be identical (the same size and brand) in Queuing (for maximum hard disk efficiency and performance).
  • Page 141 Modules RAID Level Description Table 7 - 1 RAID Levels Identical drives reading and writing data in parallel to increase performance. RAID 0 RAID 0 implements a striped disk array and the data is broken into blocks and each block is written to a separate disk drive.
  • Page 142 Modules Prepare the following before setting up your serial ATA hard disks in RAID mode: The Microsoft Windows 7 OS DVD. A hard disk installed in the Primary HDD bay. A second (identical) hard disk installed in the Secondary HDD bay. The Device Drivers &...

  • Page 143: Sata Raid Setup Procedure (Bios)

    Modules SATA RAID Setup Procedure (BIOS) Start-up your notebook computer and press <F2> to enter the BIOS. Go to the Advanced menu, select "SATA Mode" and press Enter (see page • Select “RAID Mode”. Press Esc and go to the Boot menu. Set the DVD-ROM Drive (make sure the Microsoft Windows 7 OS DVD is inserted) as the first device in the boot order from the Boot menu (see “Boot...

  • Page 144: Raid Setup (Intel Matrix)

    Modules RAID Setup (Intel Matrix) As the computer starts up press Ctrl + i to enter RAID configuration menu. Figure 7 - 1 Intel(R) Rapid Storage Technology Option ROM  Recovery Level When selecting disks for the Recovery RAID level you will need to use the Tab key to select a Mas- ter disk, and the Space...
  • Page 145 Modules Press Enter and the system will select the physical disks to use (see sidebar for  Recovery Level). Press Enter and select (if applicable) the Strip Size (best set to default). Recovery Level Press Enter and select the Capacity size (best set to default). Press Enter to select Create Volume.
  • Page 146 Modules 12. Make sure the Windows 7 OS DVD is in the DVD drive. and as the computer  starts up it will automatically boot from the Windows 7 OS DVD (you will be prompted to press a key to boot from the DVD). Win7 (pre SP1) &...

  • Page 147: Intel Rapid Storage Technology

    Modules Intel Rapid Storage Technology The Intel Rapid Storage Technology application provides high-performance SATA and SATA RAID capabilities. Install the Intel Rapid Storage Technology application (after installing all necessary drivers in the correct order) to support your RAID system or SATA drive if set up in AHCI mode in the BIOS (see “SATA Mode (Advanced Menu)”...
  • Page 148 Modules Intel® Rapid Storage Technology for RAID Systems Intel® Rapid Storage Technology application displays status information on your RAID configuration. Run the Intel® Rapid Storage Technology application from the Intel item in the All Programs menu. When the Intel® Rapid Storage Technology application is launched the system will open the Status window.
  • Page 149 Modules Intel® Rapid Storage Technology Help  If a hard drive member of a RAID volume is reported as “Degraded” or “Failed” it may be possible to recover the volume. If the volume cannot be restored then you Help will need to recreate the RAID volume and restore the data from a back up. Click the Help menu (or press F1) for instructions on how to recover or recreate RAID Vol- Click the Help (or press F1) menu button at the...

  • Page 150: Raid Volume Data Verification And Repair

    Modules RAID Volume Data Verification and Repair The RAID volume data verification process identifies any inconsistencies or bad data on a RAID 0 or RAID 1 volume. The table outlines what occurs for each RAID level: RAID Verify Verify & Repair Level Table 7 - 2 RAID 0...
  • Page 151 Modules Verifying and Repairing RAID Volume Data Before verifying the volume data you will need to initialize the volume. Run the Intel® Rapid Storage Technology application from the Intel item in the Programs/All Programs menu. Click Manage and click Advanced. Click Initialize and click Yes (button) to begin the process.
  • Page 152 Modules Click Advanced and click Verify, then click Verify (button) to begin the process. The completion percentage will be listed under Status (verifying and repairing). Figure 7 - 6 ® Intel Rapid Storage Technology Verify 7 - 14 Intel Rapid Storage Technology...

  • Page 153: Pc Camera Module

    Modules PC Camera Module  Before installing the driver, make sure the PC Camera is on. Use the Fn + F10 key Latest PC Camera combination, or Control Center button, to toggle power to the to the PC Camera mod- Driver Information ule.

  • Page 154: Pc Camera Driver Installation

    Modules PC Camera Driver Installation 1. Insert the Device Drivers & Utilities + User’s Manual disc into the CD/ DVD drive. 2. Click Option Drivers (button). 3. Click 1.Install Webcam Driver > Yes. 4. Click Finish to restart the computer. Click Next >...

  • Page 155: Pc Camera Audio Setup

    Modules PC Camera Audio Setup If you wish to capture video & audio with your camera, it is necessary to setup the audio recording options in Windows. Click Start, and click Control Panel (or point to Settings and click Control Panel). Click Sound (Hardware and Sound).
  • Page 156 Modules Figure 7 - 7 Audio Setup for PC Camera Right-click 7 - 18 PC Camera Module...
  • Page 157 Modules Camera Application The camera application is a video viewer for general purpose video viewing and test- ing, and for capturing video files to .avi format. Run the camera application from the desktop shortcut (it is recommended that you set the capture file before the capture process - see below). Go to the Capture menu heading (if you wish to capture audio check “PC Camera Audio Setup”...
  • Page 158 Modules Reducing Video File Size Note that capturing high resolution video files requires a substantial amount of disk space for each file. After recording video, check the video file size (right-click the file and select Properties) and the remaining free space on your hard disk (go to My Computer, right-click the hard disk, and select Properties).
  • Page 159 Modules Eliminating Screen Flicker  If you find that the video screen in the camera program is flickering, you can try to adjust the setting in the Video Capture Filter options. Latest PC Camera Driver Information Run the camera application from the desktop shortcut. Go to Options and scroll down to select Video Capture Filter..
  • Page 160 Modules Taking Still Pictures  The camera application allows you to take still pictures. Snapshot Folder Run the camera application from the desktop shortcut. Go to Options and select Take Picture. The Snapshot folder’s The picture (in JPEG format) will be placed in the Snapshot folder on the default location is on the desktop.

  • Page 161: Wireless Lan Module

    Modules Wireless LAN Module  If you have included an Intel® WLAN or 3rd party module in your purchase op- Wireless Device tion, make sure that the Wireless LAN module is on before installing the driver. Operation Aboard Aircraft Use the Fn + F11 key combination, or Control Center button, to toggle power to the The use of any portable Wireless LAN module.

  • Page 162: 3Rd Party 802.11B/G/N Driver Installation

    Modules There are two different drivers provided for 3rd party WLAN & Bluetooth combo  modules (one for the V3.0 Bluetooth combo module and one for the V4.0 Bluetooth combo module). The appropriate driver for your system will be installed from the WLAN &...

  • Page 163: Intel® Wlan Driver Installation

    Modules Intel® WLAN Driver Installation For a standard Intel® WLAN driver installation and configuration choose the Typ- ical Installation below and use the Windows OS for Wireless LAN control (see overleaf). If you want to use Intel® PROSet/Wireless WiFi Connection Utility as your WLAN interface, and/or add Intel®...
  • Page 164 Modules Custom Installation (for Intel® ProSet and/or Intel® MyWiFi Technology): Note that if you wish to install Intel® MyWiFi you will need to install Micro- soft.net Framework 4.0 (or later version) before installing the driver as per the procedure below. To get the Microsoft.net Framework file go to the Microsoft website, search for the file, Download it and then install it.
  • Page 165 Modules Figure 7 - 9 Install Intel® MyWiFi Technology & Intel® PROSet/Wireless WiFi Connection Utility Wireless LAN Module 7 - 27...

  • Page 166: Connecting To A Wireless Network In Windows 7

    Modules Connecting to a Wireless Network in Windows 7  Make sure the Wireless LAN module is turned on. Network and Click the notification area wireless icon , and then double-click an access point Sharing Center to connect to or click to Open Network and Sharing Center if you do not see a network you want to connect to in the notification area menu (a list of options will You can also use the Net- appear allowing setting changes, and creating a new network).
  • Page 167 Modules You may need to enter a security key for any access point to which you are trying to connect. Click to select a network location (e.g. Home, Work or Public). Click “View or change settings in Network and Sharing Center” to access further options for the connection.
  • Page 168 Modules Click the notification area icon to see any currently connected networks.  To disconnect from the wireless network you can click the notification area wireless icon , click the active connection and then click Disconnect (button). Security Enabled Networks You should try to make sure that any network you are connecting to is a se-...

  • Page 169: Connecting To A Wireless Network Using Intel® Proset Wireless

    Modules Intel Connecting to a Wireless Network Using ® PROSet Wireless (For Intel® WLAN Modules Only) Make sure the Wireless LAN module is on. Access the Intel® WiFi Connection Utility from the Start menu (Start > All Programs > Intel PROSet Wireless > WiFi Connection Utility). Click to select a network from the found list WiFi network access points, or click Refresh to update the list.
  • Page 170 Modules Click Connect to connect to the select WiFi network access point. If the access point is encrypted then you will need to enter the password and click Figure 7 - 14 Intel® PROSet/ Wireless WiFi Connection Utility (Connecting & Connected) You can turn WiFi On/WiFi Off from the button at the bottom of the Utility.

  • Page 171: Intel My Wifi Configuration

    Modules Intel My WiFi Configuration ®  (For Intel® WLAN Modules Only) Intel® My WiFi Technology (Intel® MWT) uses your WLAN to transform your Intel® My WiFi Help system into a Wi-Fi Personal Area Network, and enables you wirelessly share your To get help on Intel®...
  • Page 172 Modules Intel® My WiFi Configuration You can configure the My WiFi settings as follows. Make sure the Wireless LAN module is on. Access the Intel® WiFi Connection Utility from the Start menu (Start > All Programs > Intel PROSet Wireless > Intel(R) My WiFi Dashboard), or click the icon in the notification area of the taskbar (or right-click and select Open Dashboard).
  • Page 173 Modules Intel® My WiFi Interface Help Wireless ON/OFF Configuration Options & Preferences Figure 7 - 16 Intel® My WiFi Utility - Interface Your Computer Wireless LAN Module 7 - 35...
  • Page 174 Modules Intel® My WiFi Help Click the Help icon in the dashboard to bring up the Help menu and select and item from the Contents menu to obtain the help information. Help Figure 7 - 17 Intel® My WiFi Utility - Help Your 7 - 36 Wireless LAN Module...
  • Page 175 Modules Preferences Click the Options icon and select Preferences to configure the options. Help Figure 7 - 18 Intel® My WiFi Utility - Preferences Your Computer Wireless LAN Module 7 - 37...
  • Page 176 Modules Hotspot You can turn the computer into a hotspot to allow other devices to connect to it (and any locally connected devices), and also (if available) the internet. Click the Hotspot icon to turn the Hotspot on. The Hotspot settings tab shows the SSID and password (you will need to enter this information when accessing the hotspot from the client computer/device).
  • Page 177 Modules Finding Devices You can find any Nearby Devices by clicking the Refresh button in the main window. Click again at any time to update the list. If a lot of devices are found they will be listed on multiple pages and you can use the left or right buttons to turn the pages.
  • Page 178 Modules Favorite Devices The Favorite Devices tab is where you keep devices to which you connect most of- ten, and this is particularly useful in environments where many devices are listed nearby. A favorite device will display the icon To make any device a favorite just click to select it and select Add Favorite. Figure 7 - 20 Intel®...
  • Page 179 Modules Connect to a Device Click the device you want to connect to, and click the connect icon An invitation will be sent to the target device. The user must then accept the invitation. After the invitation is accepted the connection will be made. Use the Windows Network and Sharing Center to set permissions for viewing and sharing the resources on your computer with another connected computer.

  • Page 180: Windows Mobility Center

    Modules Windows Mobility Center The Windows Mobility Center control panel provides an easy point of access for information on battery status, power plans used and wireless device status etc. To access the Windows Mobility Center: Click Start, and click Control Panel (or point to Settings and click Control Panel).

  • Page 181: Intel® Wireless Display Application

    Modules Intel Wireless Display Application ®  The Intel ® Wireless Display Application (requires Intel® Centrino WLAN/ Compatible Combo module), in conjunction with a compatible video adapter (purchased sep- Adapters arately), allows you to display the contents of the notebook display on another dis- play (e.g.

  • Page 182: Intel® Widi Application Installation

    Modules Intel WiDi Application Installation ® 1. Insert the Device Drivers & Utilities + User’s Manual disc into the CD/ DVD drive. 2. Click Option Drivers (button). 3. Click 3.Install WiDi AP > Yes. 4. Click Next. 5. Click the button to accept the license and click Next. 6.

  • Page 183: Intel® Widi Application Configuration

    Modules Intel WiDi Application Configuration ® Click Start > All Programs > Intel Corporation > Intel(R) Wireless Display > Intel(R) Wireless Display, or double click the icon on the desktop. Click I agree to the terms of this license (button). The application will scan for any connected compatible adapters (or you can click the Scan for available adapters button to enable Intel My WiFi Technology).
  • Page 184 Modules Click to select any detected adapters, and click Connect. The system will then prompt you to enter the 4-digit security code which will be displayed on the external TV Screen (or press the connect button on the wireless speaker adapter). Enter the code for the video adapter and click Continue.
  • Page 185 Modules You will then be prompted to enter a name for the video adapter and click  Continue. Click Finished to complete the setup. Test Audio Adapter To verify a successful audio connection (for In- tel® Wireless Music), select the “Test your audio connection”...

  • Page 186: Fingerprint Reader Module

    Modules Fingerprint Reader Module  The fingerprint reader Protector Suite Software provides a high level of security Password Warning for your computer. Make sure you have administrator’s rights to your computer, and have a Windows password enabled for full security protection. A further level of se- If you set passwords for curity and control is provided in the BIOS (see “Security Menu”...

  • Page 187: Fingerprint Reader Driver Installation

    Modules Fingerprint Reader Driver Installation 1. Insert the Device Drivers & Utilities + User’s Manual disc into the CD/ DVD drive. 2. Click Option Drivers. 3. Click 4.Install Fingerprint Driver > Yes. 4. Click Next. 5. Click the button to accept the license and click Next. 6.

  • Page 188: Authentec Truesuite Application

    Modules AuthenTec TrueSuite Application  The AuthenTec TrueSuite application is used in conjunction with your fingerprint reader to enroll fingerprints and manage settings etc. Fingerprint Enrollment User Enrollment Note that it is strongly rec- Click Start > All Programs > AuthenTec TrueSuite. ommended that you enroll Click Yes when you have identified your fingerprint sensor ( Fingerprint...
  • Page 189 Modules You will be prompted to select another finger for enrollment (it is recommended  that you enroll a number of fingers - see sidebar). Click the button to continue once you have enrolled a number of fingerprints. Help Enter the required information and click the button to register your software, or click to register later.
  • Page 190 Modules Settings Click the Settings button on the menu bar to access the personalization settings for AuthenTec TrueSuite. Here you can choose to enable/disable Website Log On, QuickLaunch, Fast User Switching and the desktop icon. You can also select the Theme and export/import identities.
  • Page 191 Modules Windows Log On Windows log on allows you to gain access to your computer by swiping your finger across the fingerprint reader sensor. Use the Biometric Devices control panel (in the Hardware & Sound category) in Windows to turn Biometrics on/off when re- quired.
  • Page 192 Modules Website Log On Use a fingerprint swipe to log on to websites to help you avoid having to remember user names and passwords across multiple websites (browsers supported are Internet Explorer, Firefox and Chrome). Registering a Website Use your web browser to navigate to the website required. Enter your user name and password and sign in to the website.
  • Page 193 Modules QuickLaunch QuickLaunch allows you to drag and drop icons (which represent websites, folders, applications and/or computer actions) to any enrolled finger and then swipe your fin- ger to launch the icons assigned to that finger. Click Start > All Programs > AuthenTec TrueSuite. Click Select Category (button) to group icons if required.
  • Page 194 Modules Adding a Website to QuickLaunch Click Start > All Programs > AuthenTec TrueSuite. Click the Add Website button on the menu bar and the dialog box will be displayed. Enter the website URL, name, icon and category as required. Click Save and an icon will be associated with the selected website.
  • Page 195 Modules Dock View Dock View displays the website icons across the bottom of the screen. Each icon wiLl have an associated web card which displays the website information, user name and password etc. This information may be edited or deleted as required. Figure 7 - 33 Dock View Editing a Web Card...
  • Page 196 Modules Exporting and Importing Your Identity You can export your identity to backup your information, or to move it to another computer. Exporting Your Identity Click Start > All Programs > AuthenTec TrueSuite. Click the Settings button on the menu bar. Click Export My Identity.
  • Page 197 Modules AuthenTec KeepSafe The KeepSafe folder is an encrypted area assigned on your hard drive that allows you to store files and folders to be protected by fingerprint protection. The folder will appear on your desktop (if selected in the Personalization Settings) and in My Computer, but will not be visible to other users of your computer.

  • Page 198: Bluetooth Module

    Modules Bluetooth Module  If your purchase option includes the Combination Wireless LAN & Bluetooth Wireless Device module (either Intel® or 3rd Party) then install the driver as instructed overleaf. Operation Aboard Follow the instructions on page 7 - 67 to configure the Bluetooth settings.

  • Page 199: 3Rd Party Bluetooth Combo Driver Installation Information

    Modules 3rd Party Bluetooth Combo Driver Installation Information  There are two different drivers provided for 3rd party WLAN & Bluetooth combo modules for this computer. Bluetooth In Device Manager (For Driver Version 2 • Driver Version 1 (for WLAN & Bluetooth Combo V3.0) requires the Blue- Bluetooth V4.0) tooth driver to be installed separately (see overleaf).

  • Page 200: 3Rd Party Bluetooth Combo Driver Version 1 Installation

    Modules 3rd Party Bluetooth Combo Driver Version 1 Installation  Note this driver is required for the 3rd Party combo Bluetooth and WLAN module version 1 (Bluetooth V3.0) only. High Speed Bluetooth Data Transfer 1. Before installing the driver make sure the Bluetooth module is powered The Combination Wire- on (use Fn + F12 key combination), then insert the Device Drivers &...

  • Page 201: 3Rd Party Bluetooth & Wlan Combo Settings

    Modules 3rd Party Bluetooth & WLAN Combo Settings  This information applies to the combo Bluetooth and WLAN module driver ver- sion 1 (Bluetooth V3.0) only. For driver version 2 (Bluetooth V4.0) see “Standard Bluetooth Module & Bluetooth Configuration in Windows 7” on page 7 - Resuming From Sleep Mode Make sure the Bluetooth module is powered on.
  • Page 202 Modules Click General Settings to change the computer name that other Bluetooth devices will see, and click the tickbox to Allow Bluetooth devices to find this computer Click OK to confirm the settings. Figure 7 - 36 General Settings 7 - 64 Bluetooth Module...
  • Page 203 Modules Click File Transfer Settings to Enable sharing of my files with other Bluetooth devices. Click OK to confirm the settings. Figure 7 - 37 File Transfer Settings Bluetooth Module 7 - 65...

  • Page 204: 3Rd Party Bluetooth Networking Setup

    Modules 3rd Party Bluetooth Networking Setup This information applies to the combo Bluetooth and WLAN module driver ver- sion 1 (Bluetooth V3.0) only. Make sure the Bluetooth module is powered on. Double-click the My Bluetooth application on the desktop (or access it from the Programs/All Programs menu).

  • Page 205: 3Rd Party Bluetooth & Wlan Combo Module Configuration

    Modules 3rd Party Bluetooth & WLAN Combo Module Configuration  Setup your Bluetooth Device so the Computer Can Find it Turn your Bluetooth device (e.g. PDA, mobile phone etc.) on. Bluetooth Module & Make the device discoverable (to do this check your device documentation). Resuming From Sleep Mode To Turn the Bluetooth Module On...
  • Page 206 Modules You will then be presented with a menu of options to select from. Figure 7 - 40 Bluetooth Device Options Click the appropriate button to connect to the device. 7 - 68 Bluetooth Module...
  • Page 207 Modules You may need to allow the connection from your device, and you will then need to provide a passcode from the device. You can then enter the passcode on the computer and click OK to establish the connection. Figure 7 - 41 Bluetooth Pairing Code &...

  • Page 208: Intel Bluetooth Combo Driver Installation

    Modules Intel Bluetooth Combo Driver Installation  Note this driver is required only for the Intel combo Bluetooth and WLAN module only. High Speed Bluetooth Data Transfer 1. Before installing the driver make sure the Bluetooth module is powered The Combination Wire- on (use Fn + F12 key combination), then insert the Device Drivers &...

  • Page 209: Standard Bluetooth Configuration In Windows 7

    Modules Standard Bluetooth Configuration in Windows 7  For Intel and 3rd Party Driver Version 2 (Bluetooth V4.0) modules only. Setup your Bluetooth Device so the Computer Can Find it Add a Device Turn your Bluetooth device (e.g. PDA, mobile phone etc.) on. Click Start, and click Con- Make the device discoverable (to do this check your device documentation).
  • Page 210 Modules To Add a Bluetooth Device  Access the Bluetooth Devices control panel and click Add a device. Double-click the device you want to pair with the computer. Pairing Options If a device has been pre- viously connected then the pairing option menu will appear when you at- tempt subsequent con- nections.
  • Page 211 Modules Enter the code into your Bluetooth enabled device and follow any on-screen instructions to complete the pairing.  Figure 7 - 44 Pairing Codes Pairing Code Example The example outlined here shows a connection to a mobile device. Other devices e.g. computers, may have a slightly different connection proce- dure, and may require you to confirm a pairing code is correct on both devices.
  • Page 212 Modules To Change Settings for the Bluetooth Device  Click the notification area icon and select Show Bluetooth Devices. Right-click on the device you want to change and click Properties to: Bluetooth Help • Change the name of the device (click Bluetooth, type a new name and click OK). •...

  • Page 213: Thx Trustudio Pro Audio

    Modules THX TruStudio Pro Audio  Install the THX TruStudio AP to allow you to configure the audio settings to your THX TruStudio & requirements for the best performance in games, music and movies. Speaker Configuration THX TruStudio AP Installation Note that THX TruStu- 1.

  • Page 214: Thx Trustudio Pro Activation

    Modules THX TruStudio Pro Activation  On the first run of THX TruStudio Pro you will need to activate the application. THX Audio & HDMI To activate the application you will need to be connected to the internet. Double-click the THX Activate icon on the desktop and click the Activate Note that the THX audio effects do not apply to...
  • Page 215 Modules THX Control Panel Each control has an On/Off button to allow you to enable/disable the control, and most controls feature a slider to adjust the levels (the subwoofer may be turned on/ off). Figure 7 - 48 Menu THX TruStudio Pro Controls •...
  • Page 216 Modules THX TruStudio Pro Headphone Settings THX TruStudio selects the built-in speakers by default and this setting may cause some sound quality issues when using headphones. To adjust the settings for head- phones do the following: Run the THX TruStudio Pro application. Select Settings from the menu.
  • Page 217 Modules THX TruStudio Pro & HDMI When you connect an HDMI display to the HDMI-Out port, the THX Tru Studio Pro controls will be disabled. A warning box will pop-up and will prompt “Do you want to select another audio device now?”.

  • Page 218: Intel® Rapid Storage Technology Driver

    Modules Intel Rapid Storage Technology Driver ® Install the Intel® Rapid Storage Technology to support your SATA drive if set up in AHCI mode in the BIOS (see “SATA Mode (Advanced Menu)” on page 5 - or if you have set up your hard disks in a RAID configuration (see“Setting Up SATA RAID or AHCI Mode”...

  • Page 219: Intel® Smart Response Technology

    Modules Intel® Smart Response Technology Intel® Smart Response Technology is an Intel® Rapid Storage Technology (RST) caching feature that accelerates computer system performance by using the SSD as cache memory between the hard disk drive and system memory. System Requirements to support Intel® Smart Response Technology: •...

  • Page 220: Enabling Intel Smart Response Technology

    Modules Enabling Intel Smart Response Technology Run the Intel® Rapid Storage Technology application from the All Programs menu. Click Enable acceleration either under Status or Accelerate. Figure 7 - 52 Enable Acceleration Select the SSD to be used as a cache device. Select the size from the SSD to be allocated for the cache memory (any remaining space on the SSD can be used for data storage using the simple data single-disk RAID 0 volume that is automatically created).
  • Page 221 Modules Select the HDD (or RAID volume) to be accelerated (it is highly recommended that you accelerate the system volume or system disk for maximum performance). Select the acceleration mode, and then click OK (Enhanced mode is selected by default). Note: Enhanced mode (default): Acceleration optimized for data protection.
  • Page 222 Modules The page will refresh and report the new configuration in Acceleration. Figure 7 - 54 Intel® Rapid Storage Technology Accelerate 7 - 84 Intel® Rapid Storage Technology Driver...

  • Page 223: Intel® Rapid Start Technology Driver

    Modules Intel Rapid Start Technology Driver ® Intel(R) Rapid Start Technology can resume power from Hibernation within 5 to 6 seconds and can remember your computer's previous state with zero power. System Requirements to support Intel® Rapid Start Technology: • Rapid Start Technology should be enabled in the BIOS (see ““Intel(R) Rapid Start Technology (Advanced Menu)”...

  • Page 224: Intel® Rapid Start Technology Configuration

    Modules Intel® Rapid Start Technology Configuration Enable/disable Intel(R) Rapid Start Technology from the BIOS (see “Intel(R) Rapid Start Technology (Advanced Menu)” on page 5 - Go the Windows control panel and double-click Administrative Tools (System and Security)> Computer Management > Storage > Disk Management Right-click the SSD and select Shrink Volume from the menu.
  • Page 225 Modules Enter the figure, which should be equal to amount of system memory (RAM) in your computer, in “Enter the amount of space to shrink in MB”. Figure 7 - 56 Shrink Volume Size Click Shrink (any unallocated file space may be formatted for storage use). ...
  • Page 226 Modules Click the Start menu and type “CMD” in the search box. Click CMD from the found list. Figure 7 - 57 Search for CMD Prompt Type “DISKPART”. At the DISKPART command type “list disk”. Figure 7 - 58 Diskpart - List Disk 7 - 88 Intel®...
  • Page 227 Modules 10. Type “select disk #” (# is disk number where you want to create the store partition, so refer to the results obtained from "list disk" for exact disk number). 11. The message “Disk # is now the selected disk.” will appear. Figure 7 - 59 Diskpart - Select Disk #...
  • Page 228 Modules 14. Type “detail disk”. Figure 7 - 61 Diskpart - Detail Disk 15. Type “select Volume #” (# is volume of your storage partition so refer to results obtained from "detail disk" for the exact volume number). 16. The message “Volume # is now the selected volume.” will appear. Figure 7 - 62 Diskpart - Select Volume #...
  • Page 229 Modules 17. Type “set id=84 override” (the id must be set to 84). Figure 7 - 63 Diskpart - Set id=84 Override 18. The message “DiskPart successfully set the partition ID.” will appear. 19. Close the CMD window. 20. Go the Windows control panel and double-click Administrative Tools (System and Security)>...

  • Page 230: Intel® Rapid Start Technology Driver Installation

    Modules Intel® Rapid Start Technology Driver Installation 1. Insert the Device Drivers & Utilities + User’s Manual disc into the CD/ DVD drive. 2. Click Option Drivers (button). 3. Click 8.Install Rapid Start Driver > Yes. 4. Click Next > Next > Yes > Next > Next. 5.

  • Page 231: Troubleshooting Overview

    Troubleshooting Chapter 8: Troubleshooting Overview Should you have any problems with your computer, before consulting your service representative, you may want to try to solve the problem yourself. This chapter lists some common problems and their possible solutions. This can’t anticipate every problem, but you should check here before you panic. If you don’t find the answer in these pages, make sure you have followed the instructions carefully and observed the safety precautions in the preface.

  • Page 232: Basic Hints And Tips

    Troubleshooting Basic Hints and Tips Many of the following may seem obvious but they are often the solution to a problem when your computer ap- pears not to be working. • Power - Is the computer actually plugged into a working electrical outlet? If plugged into a power strip, make sure it is actually working.

  • Page 233: Backup And General Maintenance

    Troubleshooting Backup and General Maintenance • Always backup your important data, and keep copies of your OS and programs safe, but close to hand. Don’t forget to note the serial numbers if you are storing them out of their original cases, e.g. in a CD wal- let.

  • Page 234: Viruses

    Troubleshooting Viruses • Install an Anti-Virus program and keep the definitions file (the file which tells your program which viruses to look for) up to date. New computer viruses are discovered daily, and some of them may seriously harm your computer and cause you to lose data. Anti-Virus programs are commercially available and the defini- tions file updates are usually downloadable directly from the internet.

  • Page 235: Upgrading And Adding New Hardware/Software

    Troubleshooting Upgrading and Adding New Hardware/Software • Do not be tempted to make changes to your Windows Registry unless you are very sure of what you are doing, otherwise you will risk severely damaging your system. • Don’t open your computer or undertake any repair or upgrade work if you are not comfortable with what you are doing.
  • Page 236 Troubleshooting • Don’t over complicate things. The less you have to deal with then the easier the source of the problem may be found; Example - if your computer has many devices plugged into its ports, and a number of programs running, then it will be difficult to determine the cause of a problem.

  • Page 237: Problems & Possible Solutions

    Troubleshooting Problems & Possible Solutions Problem Possible Cause - Solution You turned the power on Battery missing / incorrectly installed. Check the battery bay, make sure the battery is present and but it doesn’t work. seated properly (the design of the battery only allows it to go in one way). Make sure there’s nothing interfering with the battery contacts.
  • Page 238 Troubleshooting Problem Possible Cause - Solution The computer feels too Make sure the computer is properly ventilated and the vents/fan intakes are not blocked. If this hot. doesn’t cool it down, put the system into Hibernate mode or turn it off for an hour. Make sure the computer isn’t sitting on a thermal surface (see “Overheating”...
  • Page 239 Troubleshooting Problem Possible Cause - Solution forget boot If you forget the password, you may have to discharge the battery of the CMOS. Contact your password. service representative for help.  Password Warning If you choose to set a boot password, NEVER forget your password. The consequences of this could be serious. If you cannot remember your boot password you must contact your vendor and you may lose all of the information on your hard disk.
  • Page 240 Troubleshooting Problem Possible Cause - Solution The TouchPad doesn’t The Touchpad has been disabled. Press the Touchpad toggle (Fn + F1) key combination (make work. sure you have installed the Touchpad driver. I am sliding my finger up There are different TouchPad versions available on this computer, and this version requires and down on the right tapping/holding to scroll.
  • Page 241 Troubleshooting Problem Possible Cause - Solution When a DVD is played in This is an issue with Windows Media Player/Media Center and audio output through the S/PDIF- Windows Media Player/ Out Jack. We recommend that you use the Power DVD application to play DVDs. Media Center, the audio track in other languages (commentaries etc.) is...
  • Page 242 Troubleshooting Problem Possible Cause - Solution No sound can be heard You have not configured the HDMI audio output. See “HDMI Audio Configuration” on page C - through HDMI connected display. Audio Volume is too You have set the Speaker Configuration to 5.1 or 7.1 Speaker. It is recommended that you set the when listening Speaker Configuration to Stereo (not to 5.1 or 7.1 Speaker) when listening through...
  • Page 243 Troubleshooting Problem Possible Cause - Solution The computer is off (or in The port is not powered on. Toggle power to the port using the Fn + power button combination. Sleep Mode) powered by the AC/DC This function may not work with certain external USB compliant devices (check your device’s doc- adapter plugged in to a umentation).
  • Page 244 Troubleshooting Problem Possible Cause - Solution The Bluetooth module experiencing problems/ 2 Bluetooth adapters appear in the Device Manager under Bluetooth Radios. There is a conflict between an existing Bluetooth module and a Bluetooth & WLAN combination module. You should have only one Bluetooth module installed in order to prevent any conflicts (this includes the Bluetooth element of any combination WLAN &...
  • Page 245 Troubleshooting Problem Possible Cause - Solution cannot obtain high To obtain high speed Bluetooth data transfer take into account the following: speed Bluetooth data transfer. • Only the combination Wireless LAN & Bluetooth module supports high speed (data transfer. • To achieve high speed transfer speeds, both devices must support high speed data transfer (i.e both the computer and the Bluetooth compatible device you are connecting to).

  • Page 246: Bluetooth Connection Problems

    Troubleshooting Bluetooth Connection Problems If you are experiencing problems connecting to some Bluetooth devices (in particular certain mobile phones and headsets) it maybe necessary to download and install the Windows Mobile Device Center software (for Win- dows Vista and Windows 7). Go to the Microsoft website and search for the Microsoft Windows Device Center Driver for Windows Vista (64-bit or 32-bit) and Windows 7 (64-bit or 32-bit), and then download the driver.
  • Page 247 Troubleshooting Right-click Bluetooth Peripheral Device and click on Update Driver Software. Click Browse my computer for driver software. Click Let Me pick from a list of device drivers on my computer. Figure 8 - 2 - Browse my computer.../Let me pick from... Select Bluetooth Radios from the list.
  • Page 248 Troubleshooting 10. A list of drivers will appear with Manufacturer on one side and Model in the other. 11. Choose Microsoft Corporation (make sure you choose the full name Microsoft Corporation and do not choose Microsoft - Note that you must have installed the Microsoft Windows Device Center Driver for Microsoft Corporation to appear in the list).
  • Page 249 Troubleshooting 15. The Device Manager should now display the Windows Mobile-based device support under Bluetooth Radios. 16. You will need to repeat the process for any other Bluetooth Peripheral Devices listed under Other Devices. Figure 8 - 5 - Device Manager - Bluetooth Radio Bluetooth Connection Problems 8 - 19...

  • Page 250: Intel® Wlan & Bluetooth V3.0+Hs Combo Modules

    Troubleshooting Intel® WLAN & Bluetooth V3.0+HS Combo Modules Note that, at the time of going to press, Intel® Centrino® Wireless-N 2230 and Intel® Centrino Advanced 6235 WLAN & Bluetooth combo modules use the standard Bluetooth configuration in Windows 7 (see “Intel Bluetooth Combo Driver Installation”...

  • Page 251: Installing Windows 7 (Pre Service Pack 1) For Raid Systems With Advanced Format Disks

    Troubleshooting Installing Windows 7 (pre Service Pack 1) for RAID Systems with Advanced Format Disks The following information is only applicable under the following conditions: • You are configuring your SATA hard disks in a RAID. • You are using Advanced Format hard disks that have a 4KB physical sector size. •...
  • Page 252 Troubleshooting Press a key at system startup to begin installing Windows from your Microsoft Windows 7 disc (make sure the DVD device is set at the top of the Boot Sequence in the BIOS - see “Boot Option Priorities (Boot Menu)”...

  • Page 253: Interface (Ports & Jacks) Overview

    Interface (Ports & Jacks) Appendix A: Interface (Ports & Jacks) Overview The following chapter will give a quick description of the ports & jacks which allow your computer to commu- nicate with external devices, connect to the internet etc. Interface (Ports & Jacks) A - 1...

  • Page 254: Ports And Jacks

    Interface (Ports & Jacks) Ports and Jacks Item Description Card Reader The card reader allows you to use the following digital storage cards: MMC (MultiMedia Card) / RSMMC SD (Secure Digital) / Mini SD / SDHC / SDXC MS (Memory Stick) / MS Pro / MS Duo Push the card into the slot and it will appear as a removable device.

  • Page 255: Hdmi-Out Port

    Interface (Ports & Jacks) Item Description HDMI-Out Port The HDMI-Out (High-Definition Multimedia Interface) port is an audio/video connector interface for transmitting uncompressed digital streams. This allows you to connect an external HDMI monitor, TV or Flat Panel Display etc. as a display device (see “Attaching Other Displays”...

  • Page 256: Mini-Ieee 1394A Port

    Interface (Ports & Jacks) Item Description Mini-IEEE 1394a Port This allows high-speed connection to various peripheral devices, e.g. external disk drives and digital cameras (see note below).  IEEE 1394a The Mini-IEEE 1394 ports only support SELF POWERED IEEE 1394 devices. RJ-45 LAN Jack This port supports LAN (Network) functions.

  • Page 257: Usb 2.0/1.1 Ports

    Interface (Ports & Jacks) Item Description USB 2.0/1.1 Ports These USB (Universal Serial Bus) 2.0 compatible ports (USB 2.0 is fully USB 1.1 compliant) are for low-speed peripherals such as keyboards, mice or scanners, and for high-speed peripherals such as external HDDs, digital video cameras or high-speed scanners etc. Devices can be USB 3.0 Port plugged into the computer, and unplugged from the computer, without the need to turn the system off (if the power rating of your USB device is 500mA or above, make sure you use the power...
  • Page 258 Interface (Ports & Jacks) A - 6...

  • Page 259: Control Center Overview

    Control Center Appendix B: Control Center Overview The following chapter will give a quick description of the functions of the Control Center. The Control Center gives quick access to frequently used controls, power management features and enables you to quickly turn mod- ules on/off.
  • Page 260 Control Center Power Modes You can set a Power Mode by clicking the appropriate icon at the top of the Control Center. Each power mode will affect the power status of modules (e.g. WLAN, Bluetooth, 3G or Camera), screen brightness, TouchPad power and Silent Mode.
  • Page 261 Control Center User Modes Power Saving Flight Entertainment Quiet Performance Defined Icon Power Plan Power Saver Balanced Power Saving Power Saving High Performance Power Conservation Mode Energy Star BIOS Default Energy Star Energy Star Performance Brightness WLAN Bluetooth PC Camera TouchPad Table B - 1- Power Modes Control Center B - 3...
  • Page 262 Control Center Power Status The Power Status icon will show whether you are currently powered by the battery, or by the AC/DC adapter plugged in to a working power outlet. The power status bar will show the current battery charge state. Brightness The Brightness icon will show the current screen brightness level.
  • Page 263 Control Center Sleep Click the Sleep button to bring up the Hibernate or Sleep buttons, and click either button to have the computer enter the appropriate power-saving mode (see “Power-Saving States” on page 3 - 6). Click in a blank area of the icon or press a key on the keyboard to exit Power Conservation Mode without making any changes Display Switch Click the Display Switch button to access the menu (or use the...
  • Page 264 Control Center Caps Lock/Scroll Lock/ Number Lock Click the button to toggle the appropriate lock mode. B - 6 Control Center...

  • Page 265: Video Driver Controls

    Video Driver Controls Appendix C: Video Driver Controls The basic settings for configuring the LCD are outlined in “Video Features” on  page 1 - Video Driver Installation Video Card Options Note that card types, Make sure you install the drivers in the order indicated in Table 4 - 1, on page 4 - specifications and driv- Insert the Device Drivers &...

  • Page 266: Nvidia Optimus ™ Technology

    Video Driver Controls NVIDIA Optimus Technology ® ™  Most notebook computers come with either a discrete or integrated graphics solu- iGPU or dGPU tion. Note the NVIDIA control Discrete graphics solutions feature a dedicated Graphics Processing Unit (GPU) panel refers to High- performance NVIDIA which are capable of playing games, watching HD video or running GPU-based ap-...
  • Page 267 Video Driver Controls How Optimus Technology works When the system is powered up and is displaying just the desktop, the dGPU will be powered off. In this case the system is running in the same way as a system without a discrete graphics solution.

  • Page 268: Intel® Graphics & Media Control Panel

    Video Driver Controls Intel Graphics & Media Control Panel ®  Advanced video configuration options are provided by the Intel Graphics and ® Application Mode Media Control Panel. To access the control panel: Note that all figures pic- Click Advanced settings in the Screen Resolution control panel in Windows. tured, and instructions Click the Intel(R)...
  • Page 269 Video Driver Controls You may make changes to any of the graphics properties by clicking the appropriate  menu tab on the left of the menu and adjusting the settings on the right. Options & Support Click Options & Sup- port and select an item from the sub-menu to bring up the help and...

  • Page 270: Display Devices & Options

    Video Driver Controls Display Devices & Options  Note that you can use an external display connected to the DVI-Out port (if you are using an older type of monitor you can use a converter to convert the signal from Function Key Combination DVI to VGA), HDMI-Out port or DisplayPort.

  • Page 271: Attaching Other Displays

    Video Driver Controls Attaching Other Displays  If you prefer to use a monitor or flat panel display, connect it to the external monitor Multiple Display port or HDMI-Out port on the left of the computer. At least one other dis- To Clone Displays: play must be attached in Attach your external display to the DVI-Out Port, HDMI-Out port or DisplayPort,...
  • Page 272 Video Driver Controls To Enable Extended Desktop:  Attach your external display to the DVI-Out Port, HDMI-Out port or DisplayPort, and turn it on. Display Settings Go to the Intel(R) G&M control panel and click Display > Multiple Displays. Extended Desktop Click Operating Mode and select Extended Desktop from the menu.
  • Page 273 Video Driver Controls Display Profiles You can save display settings to be loaded at any time. Go to the Intel(R) G&M control panel and click Display. Configure the General Settings, Multiple Displays, Color Enhancement, Custom Resolution & Monitor/TV Settings to your preferences. Click Apply, and OK to confirm the settings change.

  • Page 274: Configuring An External Display In Windows 7

    Video Driver Controls Configuring an External Display in Windows 7  You can also use the Screen Resolution control panel in Windows 7 to configure an Function Key external display. Combination Attach your external display to the DVI-Out Port, HDMI-Out port or DisplayPort, You can use the Fn + and turn it on.
  • Page 275 Video Driver Controls You can configure the displays from the Multiple Displays menu. Figure C - 7 Screen Resolution Multiple Display Options (Win 7) • Duplicate these displays - Shows an exact copy of the main display desktop on the other display(s) •...
  • Page 276 Video Driver Controls Using the Windows Logo Key + P Key Combination to Switch Displays You can also use the + P key combination to quickly change display configura- tion and modes (this is particularly useful when attaching a projector) in Windows 7. Attach your external display to the DVI-Out Port, HDMI-Out port or DisplayPort, and turn it on.

  • Page 277: Nvidia Control Panel

    Video Driver Controls NVIDIA Control Panel  More advanced video configuration options are provided in the NVIDIA Control NVIDIA Control Panel tab. Panel Click Start, and click Control Panel (or point to Settings and click Control Panel). To access the Ge- Double-click NVIDIA Control Panel (click "Classic View"...
  • Page 278 Video Driver Controls The NVIDIA Control Panel provides additional video configuration controls and  tools which allow quick access to features such as image settings, 3D Settings and video configuration. Navigating the Control Panel Navigate through the control panels in much the same way as you would a web page.

  • Page 279: Optimus™ Customization Options

    Video Driver Controls Optimus Customization Options ™  One of the most important aspects of Nvidia Optimus technology is that it will ® ™ Display GPU switch between the integrated GPU and discrete GPU seamlessly and automatically, Activity Icon and does not require any input from the user. However customization options are of- fered for users who prefer to set their own parameters for GPU usage.
  • Page 280 Video Driver Controls Close the NVIDIA Control Panel.  Find the executable file icon of the application you want to run. Right-click the icon and select Run with graphics processor from the context iGPU or dGPU menu. Select either High-performance NVIDIA processor (dGPU) or Integrated Note the NVIDIA con- graphics (iGPU) to run the program with the selected GPU.
  • Page 281 Video Driver Controls Global Settings Global settings allows you to set the preferred graphics processor for overall use. Ideally this would be the iGPU for battery life, but this can be set to the dGPU if pre- ferred. Run the NVIDIA Control Panel (see page 13).
  • Page 282 Video Driver Controls Program Settings Program settings allows you to make specific adjustments for installed applications. Run the NVIDIA Control Panel (see page 13). Click Manage 3D Settings (3D Settings) and select Program Settings (tab). Select a program to customize from the drop-down menu, or click Add to add any program that does not appear in the menu.

  • Page 283: Set Physx Configuration

    Video Driver Controls Set PhysX Configuration ® NVIDIA PhysX is a physics engine that can use the GPU to accelerate game and ® ® 3D application performance. You can select the GeForce video card or CPU as a PhysX processor, or configure the computer to auto-select a PhysX processor ®...

  • Page 284: Video Settings

    Video Driver Controls Video Settings Click the sub-menus under Video to adjust the video color or image settings. Figure C - 16 Video Settings C - 20 Video Settings...

  • Page 285: Hdmi Audio Configuration

    Video Driver Controls HDMI Audio Configuration  HDMI (High-Definition Multimedia Interface) carries both audio and video signals. Volume Indicator In some cases it will be necessary to go to the Sound control panel and manually configure the HDMI audio output as per the instructions below. Click the taskbar volume indicator when an...
  • Page 286 Video Driver Controls Double-click the connected HDMI device (or right-click and select Properties) to adjust the HDMI settings from the control panel tabs. Click OK to close the control panel (see notes overleaf). Figure C - 18 HDMI Device Properties C - 22 HDMI Audio Configuration...
  • Page 287 Video Driver Controls HDMI Notes  • Connect a device with HDMI support to the HDMI-Out port BEFORE attempt- ing to play audio/video sources through the device. Other Applications • To play audio sources through your external display’s (TV or LCD) speakers If you are using a third you will need to go to the audio configuration control panel on the display and party...
  • Page 288 Video Driver Controls C - 24...

  • Page 289: Specifications

    Specifications Appendix D:Specifications  Latest Specification Information The specifications listed in this Appendix are correct at the time of going to press. Certain items (particularly processor types/ speeds and CD/DVD device types) may be changed, updated or delayed due to the manufacturer's release schedule. Check with your service center for details.

  • Page 290: Processor

    Specifications Processor Processor Processor For Models A & B Only: Intel® Core i7-3520M (2.9GHz) Intel® Core i7-2670QM (2.2GHz) Intel® Core i7-3920XM (2.9GHz) Mobile Processor Quad-Core Mobile Processor Exterme Edition Processor 4M L3 Cache, 22nm (22 Nanometer), 6M L3 Cache, 32nm (32 Nanometer), DDR3-1600MHz, TDP 35W DDR3-1333MHz, TDP 45W 8M L3 Cache, 22nm (22 Nanometer),...

  • Page 291: Processor

    Specifications Core Logic Video Adapter Options Models A, B & C: nVIDIA® GeForce GTX 670M PCIe * 16 Mobile Intel® HM77 Express Chipset Intel® Integrated GPU and NVIDIA® Video Card GeForce Video: 1.5GB GDDR5 Video RAM On Board Memory ® Supports NVIDIA®...

  • Page 292: Storage

    Specifications Storage Audio Interface One 12.7 mm Super Multi/Blu-Ray High Definition Audio One USB 2.0 Port Combo/Blu-Ray Writer SATA Optical S/PDIF Digital Output Three USB 3.0 Ports (Note: One Device Drive (Factory Option) powered USB3.0 port (AC/DC) Built-In Microphone One eSATA Port (SATA/Powered USB 2 Built-In Speakers One Changeable 2.5"...

  • Page 293: Card Reader

    Specifications Card Reader Communication Power Embedded Multi-In-1 Push-Push Card (802.11b/g/n) Half Mini-Card PCIe WLAN Removable 8 Cell Smart Lithium Ion Battery Reader + Bluetooth V3.0+HS Combo Module Pack 76.96WH (Factory Option) - MMC / RSMMC Model A: - SD / Mini SD / SDHC / SDXC Full Range AC/DC Adapter –...

  • Page 294: Physical Dimensions & Weight

    Specifications Physical Dimensions & Weight Models A & B: 376mm (w) * 256mm (d) * 35 - 43mm (h) 3.1kg with ODD and Battery Model C: 412mm (w) * 276mm (d) * 41.8 - 45.4mm 3.9kg with ODD and Battery D - 6 Specifications...
