INSTALLER: Leave this manual with party responsible for use and operation.
OWNER: Retain this manual for future reference.
PELLET BURNING APPLIANCE
Model(s):
ECO-ADV-PS35
ECO-ADV-PS50
ECO-CAB50
CAUTION
Tested and approved for wood pellets, Burning of any
other type of fuel voids your warranty.
CAUTION
Check building codes prior to installation.
• Installation MUST comply with local, regional, state and na-
tional codes and regulations.
• Consult local building, fire officials or authorities having juris-
diction about restrictions, installation inspection, and permits.
Installation and service of this appliance should be performed by
qualified personnel. Hearth & Home Technologies recommends
HHT Factory Trained or NFI certified professionals.
1
Installation Manual
Installation & Appliance Set-Up
NOTICE: DO NOT DISCARD THIS MANUAL
If the information in these instruc-
tions is not followed exactly, a
fire could result causing property
damage, personal injury, or death.
• Do not store or use gasoline or other flam-
mable vapors and liquids in the vicinity of
this or any other appliance.
• Do not over fire - If appliance or chimney
connector glows, you are over firing. Over
firing will void your warranty.
• Comply with all minimum clearances to
combustibles as specified. Failure to
comply may cause house fire.
Hot glass will cause burns.
•
Do not touch glass until it is cooled
•
NEVER allow children to touch glass
•
Keep children away
•
CAREFULLY SUPERVISE children in same room as
fireplace.
•
Alert children and adults to hazards of high temperatures
•
High temperatures may ignite clothing or other
flammable materials.
•
Keep clothing, furniture, draperies and other flammable
materials away.
To obtain a French translation of this manual, please contact
your dealer or visit www.quadrafire.com
Pour obtenir une traduction française de ce manuel, s'il vous
plaît contacter votre revendeur ou visitez www.quadrafire.com
www.heatilatorecochoice.com or Consumer Care 1-800-926-4356:
Prior to calling, please have the model and serial number of the
appliance you are calling about. Information can be found at the rear
of the appliance.
7058-205F
WARNING
WARNING
HOT SURFACES!
Glass and other surfaces are hot
during operation AND cool down.
NOTE
02/28/2017
Advertisement
Table of Contents
Related Manuals for Hearth & Home ECO-ADV-PS35
Summary of Contents for Hearth & Home ECO-ADV-PS35
- Page 1 NOTICE: DO NOT DISCARD THIS MANUAL WARNING If the information in these instruc- tions is not followed exactly, a PELLET BURNING APPLIANCE fire could result causing property damage, personal injury, or death. Model(s): ECO-ADV-PS35 • Do not store or use gasoline or other flam- ECO-ADV-PS50 mable vapors and liquids in the vicinity of this or any other appliance. ECO-CAB50 • Do not over fire - If appliance or chimney connector glows, you are over firing. Over firing will void your warranty.
-
Page 2: Table Of Contents
HEATILATOR ECO-CHOICE Safety Alert Key: • DANGER! Indicates a hazardous situation which, if not avoided will result in death or serious injury. • WARNING! Indicates a hazardous situation which, if not avoided could result in death or serious injury. CAUTION! Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury. • NOTICE: Indicates practices which may cause damage to the appliance or to property. • TABLE OF CONTENTS Important Safety Information ....3 Venting Systems ......18 A. Appliance Certification ............3 A. Vertical - Interior - Typical Installation ........18 B. BTU & Efficiency Specifications........3 B. Through The Wall & Vertical - External ......18 C. Glass Specifications ............3 C. Vertical into Existing Class A Chimney ......18 D. Electrical Rating (on high) ..........3 D. Through The Wall ..............19 E. Mobile Home Approved ............ 3 E. Masonry ................20 F. Alternate Masonry .............20 Getting Started ........4 Appliance Set-Up ......21 A. Design, Installation & Location Considerations ......4 B. Thermostat Wall Control Location........5... -
Page 3: Important Safety Information
HEATILATOR ECO-CHOICE Important Safety Information A. Appliance Certification C. Glass Specifications Model ECO-ADV-PS35, ECO-ADV-PS50 This appliance is equipped with 5mm ceramic glass. and ECO-CAB50 Replace glass only with 5mm ceramic glass. Please con- tact your dealer for replacement glass. Laboratory Intertek Report No. 4001508 D. Electrical Rating (on high) Type Solid Fuel Room Appliance/Pellet Fuel Model PS35: BurningType 115 VAC, 60 Hz, Start 3.8 Amps, Run 1.3 Amps Model PS50: 115 VAC, 60 Hz, Start 5.1 Amps, Run 3.0 Amps Standard ASTM E1509-04 and ULC S627-00, ULC/ Model CAB50: 115 VAC, 60 Hz, Start 5.1 Amps, Run 3.0 Amps... -
Page 4: Getting Started
HEATILATOR ECO-CHOICE Install Guide Getting Started A. Design, Installation & Location Considerations Since pellet exhaust can contain ash, soot or sparks, you 1. Appliance Location must consider the location of: • Windows NOTICE: Check building codes prior to installation. • Air Intakes • Installation MUST comply with local, regional, state and • Air Conditioner national codes and regulations. -
Page 5: Thermostat Wall Control Location
HEATILATOR ECO-CHOICE B. Thermostat Wall Control Location WARNING The thermostat wall control’s location will have some affect on the appliance’s operation. Hearth & Home Technologies disclaims any responsibility for, and the warranty will be • Maximum wire length from appliance is 100 feet (30.48m) voided by, the following actions: continuous not spliced wire. Recommended 20 gauge • Installation and use of any damaged wire, solid copper . appliance. • When located close to the appliance, it may require a • Modification of the appliance. -
Page 6: Install Checklist
HEATILATOR ECO-CHOICE E. Install Checklist ATTENTION INSTALLER: Follow this Standard Work Checklist This standard work checklist is to be used by the installer in conjunction with, not instead of, the instructions contained in this installation manual. Customer: __________________________________________________________________________ Date Installed: __________________________________________________________________________ Lot/Address: __________________________________________________________________________ Location of Appliance: ______________________________________________________________... -
Page 7: Dimensions And Clearances
HEATILATOR ECO-CHOICE Dimensions and Clearances A. Appliance Dimensions MODEL: ECO-ADV-PS35 22-1/4 (565) 2-3/8 8-3/4 (60) (223) 31-3/4 (806) 22-15/16 (711) (583) 24-13/16 24-13/16 (630) (630) 20-1/4 (514) Figure 7.1 - Top View Figure 7.2- Front View 4-3/8 (111) 3-1/8 (79) - Page 8 HEATILATOR ECO-CHOICE MODEL: ECO-ADV-PS50 24-1/4 24-1/4 (616) (616) 9-3/4 2-3/8 (248) (60) 35-3/4 (908) 26-7/16 (672) (813) 28-5/16 (719) 20-1/4 (514) Figure 8.1 - Top View Figure 8.2- Front View 4-3/8 (111) 3-1/8 (79) 10-11/16 (272) 23-1/4 (591) Figure 8.4 - Side View with Top Vent Adapter Figure 8.3 -Side View 7058-205F 02/28/2017...
- Page 9 HEATILATOR ECO-CHOICE MODEL: ECO-CAB50 2-3/8 (60) 23-3/4 (603) 36-1/2 (927) 24-1/2 (622) Figure 9.1 - Top View Figure 9.2- Front View 25-7/8 (657) 4-3/8 (111) 3-1/8 (79) 30-1/8 (765) (711) (228) 26-3/4 (681) Figure 9.4 - Side View with Top Vent Adapter Figure 9.3 -Side View 02/28/2017 7058-205F...
-
Page 10: Clearances To Combustibles (Ul And Ulc)
HEATILATOR ECO-CHOICE C. Hearth Pad Requirements (UL and ULC) B. Clearances to Combustibles (UL and ULC) Use a Type I non-combustible floor protector, extending beneath appliance and to the front, sides and rear as indi- cated. Measure front distance “M” from the surface of the glass door. Straight Back Against Wall Inches Millimeters Back Wall to Appliance Side Wall to Appliance Corner Installation Inches Millimeters Walls to Appliance Hearth Pad Requirements Inches Millimeters... -
Page 11: Alcove
HEATILATOR ECO-CHOICE D. Alcove Installations Into Alcove All minimums listed are to a combustible surface. Minimum Maximum Model: PS35 Inches Millimeters Inches Millimeters Height 51-3/4 1314 Width 50-1/4 1276 Depth 1219 Side Wall Mantel Depth Minimum Maximum Model: PS50 Inches Millimeters Inches Millimeters Height 56-3/4 1441 Width 1346 Depth 1219 Side Wall Mantel... -
Page 12: Vent Information
HEATILATOR ECO-CHOICE Vent Information A. Venting Termination Minimum Requirements Electrical Service Inside Corner FIXED FIXED OPEN CLOSED CLOSED OPEN J or K Figure 12.1 Termination Cap Restricted Area Air Supply Inlet Gas Meter All minimum clearances are listed with an Outside Air Kit (OAK) installed, unless otherwise noted in table below. 12 in. -
Page 13: Avoiding Smoke And Odors
HEATILATOR ECO-CHOICE B. Avoiding Smoke and Odors Vent Configurations To reduce probability of reverse drafting during shut-down Negative Pressure, Shut-Down and Electrical Power conditions Hearth & Home Technologies strongly recom- Failure mends: To reduce the probability of back-drafting or burn-back in • I nstalling the pellet vent with a minimum vertical run of the pellet appliance during power failure or shut down con- 5 feet (1.52m). Preferably terminating above the roof... -
Page 14: Negative Pressure
HEATILATOR ECO-CHOICE C. Negative Pressure Minimum Vacuum Requirements per Appliance Negative pressure results from the imbalance of air avail- Minimum Vacuum MODEL able for the appliance to operate properly. It can be strongest Requirements in lower levels of the house. ECO-ADV-PS35 .065 inches W.C. Causes include: ECO-ADV-PS50 .075 inches W.C. • Exhaust fans (kitchen, bath, etc.) ECO-CAB50 .075 inches W.C. • Range hoods • Combustion air requirements for furnaces, water E. -
Page 15: Equivalent Feet Of Pipe
HEATILATOR ECO-CHOICE F. Equivalent Feet of Pipe WARNING The table below can help you calculate the equivalent feet Vent surfaces get HOT, can cause burns if of pipe which is a method used to determine pellet vent size. touched. Non-combustible shielding or guards Figure 15.1. may be required. Example of 3 Elbow-Rear Vent Termination Calculation Pellet Venting # of Feet of Multiplied Equivalent Components Component Elbows Pipe Feet Equivalent Feet 2 ft. Elbow or Tee Elbow Horizontal Pipe 3 ft. -
Page 16: Pellet Venting Charts
HEATILATOR ECO-CHOICE H. Pellet Venting Charts WARNING The maximum horizontal venting allowed with no vertical vent- ing attached is 48 inches (1219mm) including one 90° elbow Fire Risk. or two 45° elbows. This is our recommended horizontal vent- • Only LISTED venting components may be used. ing installation. Addition of any horizontal venting beyond 48 • NO OTHER vent components may be used. inches (1219mm) requires a minimum 60 inches (1524mm) of Substitute or damaged vent components may impair additional vertical vent. Horizontal sections of vent pipe should safe operation. -
Page 17: Venting Termination Requirements
HEATILATOR ECO-CHOICE I. Venting Termination Requirements CAUTION Do not terminate vent in any enclosed or semi-enclosed area such as a carport, garage, attic, crawl space, under a sun deck or porch, narrow walkway or closely fenced area, or any location that can build up a concentration of fumes such as a stairwell, covered breezeway, etc. . Termination must exhaust above air inlet elevation. It is strongly recommended that at least 60 inches (1.5m) of vertical pipe be installed when appliance is vented directly through a wall. This will create a natural draft, which will help prevent the possibility of smoke or odor venting into the home during a power outage. It will also keep exhaust from causing a nuisance or hazard by exposing people or shrubs to high temperatures. The... -
Page 18: Venting Systems
HEATILATOR ECO-CHOICE Venting Systems B. Through The Wall & Vertical - External A. Vertical - Interior - Typical Installation PREFERRED METHOD #2 PREFERRED METHOD #1 Rain Cap Rain Cap 12 in. 12 in. Flashing (305mm) Flashing (305mm) Minimum Minimum Firestop 2 in. -
Page 19: Through The Wall
HEATILATOR ECO-CHOICE D. Through The Wall Horizontal termination cap must be a minimum of 6 inches. In Canada, where passage through a wall or partition of (152mm) from the wall. Approved for mobile home instal- combustible construction is desired, the installation shall lations. Must use 3 or 4 inch (76-102mm) “L” or “PL” listed conform to CAN/CSA-B365 pellet venting or Listed double wall pipe and an authorized Outside Air Kit in mobile homes. CAUTION NOTICE: Please note that while the minimum clear- DO NOT DOWNWARD VENT. ance for the termination cap is 6 inches (152mm) there The following will occur: is the possibly of soot build-up around the termination • The appliance will not vent properly area. If this occurs we suggest to move the termi- • Smoke spillage in the house nation further away from the house to prevent it. The • Excessive sooting suggested minimum is 12 inches. 2 in. Straight Out (51mm) Minimum 6 in. (152mm) Minimum From Glass Horizontal Wall... -
Page 20: Masonry
HEATILATOR ECO-CHOICE WARNING Fire Risk Inspection of Chimney: • Masonry chimney must be in good condition. • Meets minimum standard of NFPA 211 • Factory-built chimney must be a minimum 6 inch (152mm) UL103 HT. E. Masonry Fireclay flue Concrete Cap Liner with Airspace Flashing 1 in. (25mm) Clearance with Firestop 1 in. (25mm) Clearance 3 in. (76mm) Minimum 6 in. (152mm) Minimum Sheathing Clean-Out cover... -
Page 21: Appliance Set-Up
HEATILATOR ECO-CHOICE Appliance Set-Up A. Outside Air Kit 1. Measure distance from floor to air vent opening in appli- There are two Outside Air Kits available for purchase with ance and mark location on wall. this appliance. Kit 811-0872 uses a 2 inch flex hose (which is included in the kit) and uses hose clamps to secure the Use saw to cut opening in wall. hose. The OAK-3 uses 3 inch flex hose (which is not includ- 2 inch kit: Cut a 2-1/2 to 3 inch opening on inside wall ed in the kit) and uses wire ties to secure the hose. and a 3 to 3-1/2 inch opening on outside of house. Parts Included in 2 inch Kit 811-0872: 1 piece of 2 inch x 3 3 inch kit: Cut a 3-1/2 to 4 inch opening on inside wall ft. flex hose, 2 hose clamps, 1 collar assembly, 1 termination and a 4 to 4-1/2 inch opening on outside of house. -
Page 22: Top Vent Adapter Installation
HEATILATOR ECO-CHOICE Top Vent Adapter Installation C. Rear Vent & Rear Vent to Top Vent Adapter Installation 3 to 3 inch Top Vent Adapter 3 to 6 inch Top Vent Offset Adapter 1. Put a layer of high temperature silicone on the 3 inch (76mm) exhaust outlet. Do not put silicone inside of pipe. -
Page 23: Thermostat Installation
HEATILATOR ECO-CHOICE D. Thermostat Installation A low voltage thermostat is required to operate this CAUTION pellet appliance. You may use the included wall mount Shock hazard thermostat (Figure 23.2) or purchase an optional pro- • Do NOT remove grounding prong from plug. grammable thermostat or remote control. It is equipped • Plug directly into properly grounded 3 prong recep- with an adjustable heat anticipator. The current rating is tacle. .05 amps. The anticipator needs to be adjusted to the • Route cord away from appliance. lowest setting available. • Do NOT route cord under or in front of appliance. 2. When mounting a thermostat on a wall, be sure to follow your thermostat installation instructions carefully. NOTE: Thermostat must be mounted level for accu- rate readings. -
Page 24: Mobile Home Installation
HEATILATOR ECO-CHOICE Mobile Home Installation You must use a Quadra-Fire Outside Air Kit CAUTION for installation in a mobile home. THE STRUCTURAL INTEGRITY OF THE MOBILE HOME An outside air inlet must be provided for the combustion air and FLOOR, WALL AND CEILING/ROOF MUST BE MAINTAINED must remain clear of leaves, debris, ice and/or snow. It must Do NOT cut through: be unrestricted while the appliance is in use to prevent room • Floor joist, wall, studs or ceiling trusses. air starvation which causes smoke spillage. Smoke spillage • Any supporting material that would affect the structural can also set off smoke alarms. integrity. The combustion air duct system must be made of metal. It must permit zero clearance to combustible construction and This appliance is to be connected to a factory-built chimney prevent material from dropping into the inlet or into the area conforming to CAN/ULC-S629, Standard for 650°C Facto- beneath the dwelling and contain a rodent screen. ry-Built Chimneys. The appliance must be secured to the mobile home structure For removal of the chimney for mobile home transportation, by bolting it to the floor (using lag bolts). Use the same holes... -
Page 25: Accessory List
HEATILATOR ECO-CHOICE Accessory List ECO-ADV-PS35 Service Parts Beginning Manufacturing Date: Apr 2010 Ending Manufacturing Date: Active IMPORTANT: THIS IS DATED INFORMATION. Parts must be ordered from a dealer or distributor. Hearth and Stocked Home Technologies does not sell directly to consumers. Provide model number and serial number when requesting service parts from your dealer or distributor. -
Page 26: Service Parts
HEATILATOR ECO-CHOICE ECO-ADV-PS50 Service Parts Beginning Manufacturing Date: Apr 2010 Ending Manufacturing Date: Active IMPORTANT: THIS IS DATED INFORMATION. Parts must be ordered from a dealer or distributor. Hearth and Stocked Home Technologies does not sell directly to consumers. Provide model number and serial number when requesting service parts from your dealer or distributor. - Page 27 HEATILATOR ECO-CHOICE ECO-CAB50 Service Parts Beginning Manufacturing Date: May 2011 Ending Manufacturing Date: Active IMPORTANT: THIS IS DATED INFORMATION. Parts must be ordered from a dealer or distributor. Hearth and Stocked Home Technologies does not sell directly to consumers. Provide model number and serial number when requesting service parts from your dealer or distributor.
-
Page 28: Contact Information
CONTACT INFORMATION Hearth & Home Technologies 1445 North Highway Colville, WA 99114 Division of HNI INDUSTRIES Please contact your Heatilator Eco-Choice dealer with any questions or concerns. For the number of your nearest Heatilator dealer log onto http://www.heatilatorecochoice.com/ CAUTION DO NOT DISCARD THIS MANUAL Read, understand and Leave this manual with •...
