    Home PBXware SERVERware TELCOware SIPmon SIPProt Desktop & Mobile UADs Appliances From Bicom Systems Wiki PLEASE NOTE! THIS CONFIGURATION MANUAL IS NOT READY, WORK IN PROGRESS. Contents 1 Introduction 2 Requirements 2.1 Identifying phone model 2.2 Phone firmware 2.3 DHCP server 2.4 PBXware version 3 Installation 3.1 Power adapter...

  • Page 2: Requirements

    This User Guide is written as a general guide on how to set up the Grandstream phone model GXP-2124 to work with PBXware 3.8.2. Requirements Identifying phone model To start and successfully complete registration of your phone you need to check the phone model.

  • Page 3: Pbxware Version

    PBXware version In order to find out the PBXware version, please login to PBXware and navigate to Settings: About. On the top of About page is a code similar to this one "PBXware Edition: Business, Release: 3.1 (041373f), Running: 1.4.24-gc-75ee203", where "Release" denotes the exact version of your PBXware.

  • Page 4: Registering Phone

    Go to Config and press the Select button. Go to Factory Resest and press the Select button. You'll be asked if you are sure you want to factory reset the phone, press the Ok button. You'll be prompted that you will lose all configuration settings and data , press the Ok button to factory resets your device.
  • Page 5 Make sure Grandstream UAD is enabled. To check the UAD status click on the edit icon corresponding to your Grandstream phone. Make sure Status is set to Active, Auto provisioning is set to No, and DHCP is set to Yes. Click on the Save button to save changes.
  • Page 6 Hostname or IP Address DNS SRV Registering your device A) Line configuration from devices web interface. To access the web interface of your Grandstream phone, first you must know it's IP address on your network. To find the IP address of your device please: Press the Menu button.
  • Page 7 Go to Line Configuration and press the Select button. Go to Line 1 and press the Select button. Go to Address and press the Edit button and enter PBXware extension number. Example: 1003 and press the Ok button. Go to Authentication and press the Select button. Go to User ID: and press the Edit button.

  • Page 8: Auto Provisioning

    or if you have access to the PBXware you can check this yourself. Open a new browser window and enter the IP address in order to access the PBXware web administration login screen. Example: http://192.168.1.10. Login to PBXware with your e-mail address and password. Navigate to Settings: Servers.
  • Page 9 The following topics are covered: UAD settings Creating extension Registering phone UAD Settings UAD settings Login to PBXware web administration interface Open a new browser window and enter the IP address in order to access the PBXware web administration login screen. Example: http://192.168.1.10. Login to PBXware with your e-mail address and password.
  • Page 10 Local is for all extensions registered on the LAN and Remote is for all extensions registered from remote networks, WAN, Internet etc. Click on the Next step button. Extension values Enter values into the required field text boxes. REQUIRED FIELDS: Name Enter a name for the extension being created.
  • Page 11 Registering phone This chapter describes how to register Grandstream phone using DHCP, TFTP, HTTP & HTTPS or DNS SRV. The following topics are covered: DHCP TFTP or HTTP & HTTPS DNS SRV DHCP Configure DHCP Make sure your DHCP router is configured to use option 66 to automatically instruct phones with the URL for auto provisioning.
  • Page 12 If the Server Type is HTTP or HTTPS enter http:// or https:// followed by Hostname or IP Address, followed then by /prov and press the Ok button. Example for Hostname using HTTP: http://abc.bicomsystems.com/prov Example for Hostname using HTTPS: https://abc.bicomsystems.com/prov Example for IP Address using HTTP: http://192.168.1.10/prov Example for IP Address USING HTTPS: https://192.168.1.10/prov If the Server Type is TFTP enter Hostname or IP Address and press the Ok button.
  • Page 13 Press the Select button to Save Config. Press the Back button again. Go to Reboot Phone and press the Select button. And press the Yes button to confirm your action. Auto provisioning process will start during phone reboot process, phone will pickup appropriate configuration file from PBXware.
