Your set-up checklist
To make sure you don't get lost along the way, here's
a checklist of the 3 main connections you'll need to
make while setting up:
Step 1
Connecting to the internet
There are 3 different ways you can connect your
Yes TV box to the internet – that's via Ethernet Cable
direct to your modem, using a pair of Power Line
Adaptors or WiFi. The best option for you depends
on the location of your broadband modem or router
in your home.
Option 1
USING ETHERNET CABLE
Recommended if your modem's within 3 metres
of your TV.
1 Grab the Ethernet Cable (B) and plug one end
into the port labelled 'INTERNET' on the back
of your Yes TV box (A).
ANTENNA OPTICAL HDMI USB
2
IMM01887 1418547 Optus TV Fetch Gen 3 Quick Start Guide 220x220mm v6.indd 2-3
1 Connect to your broadband modem
(via Ethernet cable or WiFi)
2 Connect to your TV antenna
3 Connect to your TV
Top Tip: Using an Ethernet Cable or a pair
of Power Line Adaptors will help you get the
most out of your connection.
2 Plug the other end into a spare port on the
back of your broadband modem or router (J).
(J)
12V DC
INTERNET POWER
(A)
(B)
Option 2
POWERLINE ADAPTORS (PLAs)
If your modem's in a different room or more than
3 metres away from your TV.
What are Powerline Adaptors? They're a pair of
devices that transmit high-speed data between two
power points in different parts of your home using
existing electrical wiring - super handy hey!
1 If you already have a pair of PLAs continue onto
Step 2 (below). If you need a pair of PLAs just give
us a call on 1300 760 013 and we can arrange to
send a pair out to you for a small cost.
2 Grab one of the PLAs (C) and plug it into the
power point nearest to your modem.
THE ROOM WITH YOUR MODEM
(B) (C)
(J)
INTERNET DELIVERED
THROUGH YOUR POWER LINES
Option 3
WIFI
If you modem's more than 3 metres away from your
TV and you have strong WiFi available.
3 Using the Ethernet Cable (B), plug one end into the
port on that PLA and the other end into a free port
on the back of your broadband modem or router (J).
4 Grab the other PLA (C) and plug it into the power
point nearest to your TV (K) and Yes TV box (A).
5 Finally, plug one end of the second Ethernet
Cable (B) into the PLA and the other end into
the port labelled 'INTERNET' on the back of your
Yes TV box (A).
Still need a hand? No problem.
Visit optus.com.au/yestv/plcinstall to download
our full PLA Setup Guide.
THE ROOM WITH YOUR YES TV BOX AND TV
(C) (B)
(A)
12V DC
ANTENNA OPTICAL HDMI USB INTERNET POWER
If you're going to connect using WiFi check out Step 6
of this guide after you've completed Steps 2, 3, 4 and
5. For now, continue onto Step 2.
