GRUNDFOS INSTRUCTIONS
Grundfos CIU 300
BACnet MS/TP for Grundfos Hydro MPC, Control MPC and Multi-E
Functional profile and user manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CIU 300 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Grundfos CIU 300

Summary of Contents for Grundfos CIU 300

  • Page 1 GRUNDFOS INSTRUCTIONS Grundfos CIU 300 BACnet MS/TP for Grundfos Hydro MPC, Control MPC and Multi-E Functional profile and user manual...

  • Page 3: Table Of Contents

    2. Introduction About this functional profile Assumptions 2.1 About this functional profile Definitions and abbreviations System diagram This functional profile describes the CIU 300 (BACnet Specifications Communication Interface Unit 300) for the following Grundfos booster systems: BACnet interface BACnet bus topology •...

  • Page 4: System Diagram

    CIM/CIU 300 to the Grundfos booster system that is to be connected to a BACnet MS/TP network. The CIU 300 solution is a box with a power supply module and a CIM 300 BACnet module. It can either be mounted on a DIN rail or on a wall.

  • Page 5: Specifications

    BACnet segmentation support Base definition for the widely used character code Character set support ANSI X3.4 known as ASCII. BACnet device profile B-ASC BACnet Application-Specific Controller. BACnet MS/TP master The CIM/CIU 300 is a BACnet MS/TP master device. Manual slave address binding...

  • Page 6: Bacnet Interface

    3. BACnet interface 3.1 BACnet bus topology The Grundfos CIM/CIU 300 is connected as a BACnet MS/TP master directly to the BACnet MS/TP network. Slave Master Master Slave Slave Master Slave LT = Line Termination BR = Bias Resistors Fig. 2...

  • Page 7: Cim 300 Bacnet Module

    The Device Object Identifier value consists of two components: LED2 communication between the • a 10-bit Object Type (bits 22 to 31) CIM 300 and the Grundfos booster • a 22-bit Instance Number (bits 0 to 21). Hexadecimal rotary switch for setting the BACnet MAC address...

  • Page 8: Default Instance Number

    The property Device_Name is a character string that must be unique inter-network-wide. By default, the name will be constructed as "Grundfos - XXXXXX" where XXXXXX is the current Device Object Instance Number as described in section 3.5 Selecting the Device Object Instance Number...

  • Page 9: Leds

    The CIM 300 BACnet module has two LEDs. • Red/green status LED (LED1) for BACnet MS/TP communication • Red/green status LED (LED2) for internal communication between the CIM 300 and the Grundfos booster. 4.1 LED1, BACnet MS/TP communication Status Description No communication.

  • Page 10: Supported Services

    "B" device. Both devices are nodes on a BACnet inter-network. In most cases, the "A" device will act as the user of data (client), and the "B" device will be the provider of this data (server). The CIM/CIU 300 is a BACnet Application-Specific Controller (B-ASC) with a few additional services. 5.1 Data sharing services...

  • Page 11: Object Overview

    System_Status BACnetDeviceStatus OPERATIONAL. Vendor_Name CharacterString Grundfos. Vendor_Identifier Unsigned16 227. Will show the Grundfos booster model to which the Model_Name CharacterString CIM/CIU 300 is connected. Firmware_Revision CharacterString Revision of the firmware in the CIM/CIU 300. Application_Software_Version CharacterString Software build date, DD-MM-YYYY.

  • Page 12: Binary Inputs

    6.2 Binary inputs Binary objects that provide information from the Grundfos booster. Object Name Notes Multi-E Status of the actual control source. BI, 0 Control source status 0 = Local control 1 = Bus control. Rotation status. BI, 2 Rotation status 0 = No rotation 1 = Rotation (one or more pumps running).

  • Page 13: Binary Outputs

    6.3 Binary outputs Binary objects for control of the Grundfos booster. Object Name Notes Multi-E Sets the control source. Set to 1 to enable control via BACnet. BO, 0 Set control source 0 = Local control (default) 1 = Bus control.

  • Page 14: Multistate Outputs

    6.5 Multistate outputs Objects that set an enumeration value in the booster. Object Name Notes Multi-E Sets the control mode if bus control is enabled. 1 = Constant speed 2 = Constant pressure 3 = Proportional pressure 4 = RESERVED 5 = Constant flow MO, 0 Set control mode...

  • Page 15: Analog Inputs

    Object Name Notes Unit Multi-E Grundfos fault code. AI, 0 Fault code See section 11. Grundfos alarm and warning codes Grundfos warning code. AI, 1 Warning code See section 11. Grundfos alarm and warning codes AI, 3 Capacity Actual capacity value (process feedback).

  • Page 16: Analog Outputs

    Set setpoint A value of 0 does not imply a stop. See section 7.2 Setpoint 6.8 Analog values Objects for configuration of the CIM/CIU 300 and/or the booster. Object Name Notes Multi-E Value for Custom Device Object Instance Number. Used in conjunction with DIP switch SW3.

  • Page 17: Detailed Descriptions

    7. Detailed descriptions 7.1 Control modes Control modes Description Illustration Open loop The setpoint of the booster system will be interpreted as setpoint for the system performance. Constant speed The setpoint value is a percentage of the maximum performance of the subpumps. No sensor is required.

  • Page 18: Setpoint

    A BACnet communication watchdog is implemented in the This is illustrated in fig. 9. CIM/CIU 300. If no BACnet communication is detected for the time period defined by the BACnet watchdog object (AV, 1), and the The setpoint is a percentage of the maximum setpoint...

  • Page 19: Control Via Bacnet

    Product profile simulation (booster simulation) can be useful for testing and pre-commissioning purposes. It is possible to simulate a booster profile when using a CIU 300 that is not connected to any product. The CIU 300 will behave as if a booster was connected on the GENIbus, even if that is not the case.

  • Page 20: Commissioning

    Connect the GENIbus cable from the CIU 300 to the booster. 3.3 Connecting to the BACnet network Connect the necessary cables from the CIU 300 to the BACnet network. See section Connect the power supply cable to the CIU 300, and switch it on.

  • Page 21: Fault Finding

    9. Fault finding 9.1 LED status Faults in a CIM/CIU 300 can be detected by observing the status of the two communication LEDs. See the table below. Fault (LED status) Possible cause Remedy 1. Both LEDs (LED1 and LED2) remain a) The CIM 300 is defective.

  • Page 22: Bacnet Telegrams

    10. BACnet telegrams 10.1 BACnet MS/TP telegram overview All BACnet MS/TP telegrams have the following format: Preamble Telegram type Destination Source Length Header CRC Data Data CRC (Pad) Variable, At most 2 bytes: 2 bytes, 2 bytes, 1 byte 1 byte 1 byte 1 byte [0-501]...

  • Page 23: Grundfos Alarm And Warning Codes

    11. Grundfos alarm and warning codes This is a general Grundfos alarm and warning code list. Code Description Code Description Code Description Gas in pump head, deaerating Leakage current Internal communication fault problem Communication fault, twin-head Missing phase Discharge valve leakage...
  • Page 24 Code Description Code Description Code Description Start capacitor, low Signal fault, extra temperature Pilot pump alarm (single-phase motors) sensor Run capacitor, low Signal fault, general-purpose sensor Alarm, general-purpose sensor high (single phase motors) Motor temperature 3 Unknown sensor type Alarm, general-purpose sensor low (Pt100, t_mo3) Bearing temperature high (Pt100), Signal fault, power meter sensor...

  • Page 25: Bacnet Mac Address

    12. BACnet MAC address BACnet BACnet BACnet address address address If the MAC address switches are set to an invalid MAC address value, a MAC address of 0 will be used. Subject to alterations.
  • Page 27 Germany Switzerland Belgium México GRUNDFOS GMBH GRUNDFOS Pumpen AG N.V. GRUNDFOS Bellux S.A. Schlüterstr. 33 Bombas GRUNDFOS de México S.A. de Bruggacherstrasse 10 Boomsesteenweg 81-83 40699 Erkrath C.V. CH-8117 Fällanden/ZH B-2630 Aartselaar Tel.: +49-(0) 211 929 69-0 Boulevard TLC No. 15 Tel.: +41-1-806 8111...
  • Page 28 Being responsible is our foundation Thinking ahead makes it possible Innovation is the essence 97572671 1209 The name Grundfos, the Grundfos logo, and the payoff Be–Think–Innovate are registrated trademarks owned by Grundfos Management A/S or Grundfos A/S, Denmark. All rights reserved worldwide. www.grundfos.com...
