- Page 1 72-4139-250 8/03 Lionel Duck Shooting Gallery Owner’s Manual...
-
Page 2: Table Of Contents
Powering the accessory Controlling the accessory Controlling the accessory in the Command Control environment Limited Warranty/Lionel Service The following Lionel marks may be used throughout this instruction manual and are protected under law. All rights reserved. Lionel ® , TrainMaster ®... -
Page 3: Powering The Accessory
15 volts, you may find that the sound is distorted. You may choose to power the accessory with a separate accessory power supply or through a Lionel Lockon (available separately, 6-62900) or a FasTrack Accessory Power Wire (available separately, 6-12053). To make the proper connections, the wires should be stripped back 1/8”... -
Page 4: Controlling The Accessory
Controlling the accessory lide the switch to the ON position to activate the animation. Use the rotary switch to turn on the sounds and adjust the volume. To turn off the sounds, turn the rotary switch until it clicks in the OFF position. Back of accessory Figure 2. -
Page 5: Controlling The Accessory In The Command Control Environment
Controlling the accessory in the Command Control environment or operation in the TrainMaster Command Control environment, you may choose to wire this accessory with an SC-2 Switch and Accessory Controller (available separately, 6-22980) or the Accessory Switch Controller (available separately, 6-14182). Refer to these manuals for additional information. - Page 6 Controlling the accessory in the Command Control environment (continued) SC-2 wiring and operation hree wires are needed to connect the accessory to the SC-2 Switch and Accessory Controller and a separate accessory transformer. Refer to Figure 3. 1. Attach one wire to the transformer Common/Ground/U terminal and connect it to the accessory COMM (common) position on the SC-2.
- Page 7 Controlling the accessory in the Command Control environment (continued) Accessory Switch Controller wiring and operation hree wires are needed to connect the accessory to the Accessory Switch Controller (ASC) and a separate accessory transformer. Refer to Figure 4. 1. Attach one wire to the transformer Power/A terminal and connect it to the COMM terminal on the ASC.
-
Page 8: Limited Warranty/Lionel Service
Lionel L.L.C. or an authorized Lionel L.L.C. Service Center, together with proof of original purchase will, at the option of Lionel L.L.C., be repaired or replaced, without charge for parts or labor. In the event the defective product cannot be repaired, and a replacement is not available, a refund of the original purchase price will be granted.
