73-0005-250
6/05
Ready-to-Run Set
Owner's Manual
CAUTI O N—ELECTRI C TOY
NOT RECOMMENDED FOR CHILDREN UNDER EIGHT YEARS OF AGE. AS WITH
ALL ELECTRIC PRODUCTS, PRECAUTIONS SHOULD BE OBSERVED DURING
HANDLI N G AND USE TO REDUCE THE RI S K OF ELECTRI C SHOCK.
TRANSFORMER RATINGS—I N PUT:120 VAC; 60 HZ ONLY.
AC OUTPUT:20 V; 54 VA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Disney Train Set and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Lionel Disney Train Set

Summary of Contents for Lionel Disney Train Set

  • Page 1 73-0005-250 6/05 Ready-to-Run Set Owner’s Manual CAUTI O N—ELECTRI C TOY NOT RECOMMENDED FOR CHILDREN UNDER EIGHT YEARS OF AGE. AS WITH ALL ELECTRIC PRODUCTS, PRECAUTIONS SHOULD BE OBSERVED DURING HANDLI N G AND USE TO REDUCE THE RI S K OF ELECTRI C SHOCK. TRANSFORMER RATINGS—I N PUT:120 VAC;...
  • Page 2 In the event that such conditions exist, the transformer should not be used until properly repaired. The following Lionel marks may be used throughout this instruction manual and are protected under law. All rights reserved. Lionel ®...

  • Page 3: Table Of Contents

    Replacing the lamp in your passenger cars Advanced connections: powering two isolated blocks with two transformers Troubleshooting Notes Limited Warranty/Lionel Service Disney Train Set Inventory • 4-4-2 steam locomotive and tender • Two coach cars • Observation car • 40-Watt Transformer •...

  • Page 4: Creating Your Layout Operating Your Transformer Safely

    • Parents should periodically inspect this product for potential hazards and, if necessary, have them repaired by an authorized Lionel Service Center. In the event that such a condi- tion exists, the transformer should not be used until it has been properly repaired.

  • Page 5: Building Your Lionel Layout

    Creating your layout Building your Lionel layout our set comes with eight curved, three straight, and one terminal section of track. Figure 1 provides some examples of layouts that you can build with these track sections. By adding more FasTrack track sections, you can create an endless number of exciting track arrangements for more fun, action, and variety.

  • Page 6: Wiring Your Transformer

    Creating your layout Wiring your Transformer hen connecting your transformer, make sure that all power connections are secure. Loose connections can produce extremely high temperatures. For this reason, do not touch the terminals or track connections during use. Also, do not locate scenery materials such as lichen or ground foam near the terminals.

  • Page 7: Running Your Train Set

    Power up your locomotive with your transformer. Your locomotive is designed to operate on 7-15 volts alternating cur- rent. Virtually all Lionel and Lionel-compatible alternating-current transformers are suitable. Note! Do not power your locomotive with direct-current (DC) transformers.

  • Page 8: Adding Smoke Fluid To Your Locomotive's Smoke Generator

    12 for the location of the switch. The smoke generator requires the periodic addition of Lionel smoke fluid in order to function. A small bottle of smoke fluid is included with this set. Press down and unscrew the cap. Pierce the end of the nozzle with a pin, then add about four drops of fluid directly into the locomotive’s...

  • Page 9: Coupling

    Running your train Coupling hen coupling your cars, at least one of the mating couplers must be open as shown at the left in Figure 5. Press down on the lock release to open the coupler, then push the cars toward each other until they lock together.

  • Page 10: Transformer Functions

    Running your train Transformer functions s you turn the throttle control knob to the right, power to the track is increased. Figure 6 illustrates the throttle control knob settings. When the indicator reaches the green band, there should be sufficient power to operate the locomotive. The further into the green area the knob is turned, the faster your train will go.

  • Page 11: Whistle Operation

    Dirt and grease may accumulate on the track, wheels, and rollers. The whistle may sound intermittently as a result of this build-up. Cleaning the wheels and track should eliminate this problem. We suggest using the Lionel Lubrication and Maintenance Kit (6-62927), available at your authorized Lionel Dealer.

  • Page 12: Reverse Unit Procedure

    Running your train Reverse unit procedure he electronic reverse unit inside your Lionel locomotive acts like the transmission in a car. When you apply power to the track, the locomotive moves in the direction specified by the reverse unit—or it sits in neutral, awaiting another power interruption. Power interruptions are the signal that tells the reverse unit to sequence to the next operational state.

  • Page 13: Maintaining And Servicing Your Set Lubricating Your Locomotive

    We recommend that you purchase a Lionel Lubrication and Maintenance Kit (6-62927), available from your Lionel dealer. Two basic rules to keep in mind: never over-lubricate (a small amount will do) and avoid getting grease or oil on the locomotive’s wheels, contact rollers, or your track.

  • Page 14: Replacing Your Locomotive's Traction Tire

    Refer to Figure 9. Remove the old traction tire from under the drive rod and slip on the replacement, Lionel part no. 600-0242-206. Replace the spacer, retighten the drive rod nut, and you’re ready to pull that long freight back to the yard.

  • Page 15: Replacing Your Locomotive's Headlamp

    2. Lift the smoke unit out far enough from the cab to allow lamp extraction. 3. Pull the lamp straight out and replace it with Lionel part no. 600-0161-300, available from your nearest authorized Lionel Service Center or from Lionel Service. Be careful not to twist the lamp, or it may break.

  • Page 16: Replacing The Lamp In Your Passenger Cars

    See Figure 11. Once these screws are removed, you can lift off the roof, remove the expired lamp, and then install the replacement. Replace the roof and the two screws on the underside of the frame. Lionel part no. 600-8352-310 Figure 11. Lamp replacement...

  • Page 17: Advanced Connections: Powering Two Isolated Blocks With Two Transformers

    Maintaining and servicing your set Advanced connections: powering two isolated blocks with two transformers s you expand your layout, you may decide to create two isolated blocks of track. Trains in each block are controlled by separate transformers. Before you operate your trains on this type of layout, be sure that your transformers are in phase.

  • Page 18: Troubleshooting

    Maintaining and servicing your set Troubleshooting No lights or operation Be sure that the Transformer is plugged in and the wires are connected. No change when DIRECTION button is pressed Be sure that your locomotive’s reverse unit switch is ON. Locomotive runs slowly or lights dim at the far end of the track On larger layouts, additional track resistance may cause reduced track voltage as the trains move away from the power terminal section.

  • Page 19: Notes

    Maintaining and servicing your set Notes...

  • Page 20: Limited Warranty/Lionel Service

    Lionel L.L.C. or an authorized Lionel L.L.C. Service Center, together with proof of original purchase will, at the option of Lionel L.L.C., be repaired or replaced, without charge for parts or labor. In the event the defective product cannot be repaired, and a replacement is not available, a refund of the original purchase price will be granted.
