- Page 1 72-4131-250 8/03 Dumbo Pylon Owner’s Manual © Disney...
- Page 2 Congratulations ongratulations on your purchase of the Lionel Dumbo Pylon! Watch as Dumbo circles the tower. Mrs. Jumbo and Timothy Q. Mouse peer out of the illuminated windows at the base of the pylon. Dumbo Pylon Inventory • Pylon • Dumbo figure •...
- Page 3 Wiring your Dumbo Pylon with a conventional power supply iring your accessory is the first step in preparing for flight. The Dumbo Pylon will operate best at 12-18 volts (AC), and it can be powered through track power with a Lionel Lockon (available separately, 6-62900), or a FasTrack Accessory Power Wire (available separately, 6-12053), OR through an accessory power supply.
-
Page 4: Power Supply
Wiring your Dumbo Pylon with a conventional power supply (continued) Mounting holes Mounting holes Figure 1. Wiring for conventional operation POWER SUPPLY FasTrack Accessory Power Wire... - Page 5 Installing your Dumbo Pylon hoose a flat, level area on your layout for the accessory. Secure this accessory to your layout with four screws (not included) using the holes near the corners of the base. Be sure to wire your accessory before you secure it to your layout—the wire terminals are on the underside of the base.
- Page 6 Attaching the figure to your Dumbo Pylon omplete the assembly of your Dumbo Pylon by attaching the Dumbo figure and support rods to the structure. Figure 2 illustrates the following procedure. 1. Note that the supporting rod has different shaped ends. Insert the flattened end of the support rods into the tube protruding from the top of the pylon.
- Page 7 Operating your Dumbo Pylon with TrainMaster Command Control ou may choose to wire your accessory with an SC-2 Switch and Accessory Controller (available separately, 6-22980) or the Accessory Switch Controller (available separately, 6-14182). Refer to these manuals for additional information. SC-2 wiring and operation Three wires (not included) are needed to connect your Pylon to the SC-2 and a separate accessory transformer.
- Page 8 Operating your Dumbo Pylon with TrainMaster Command Control (continued) Accessory Switch Controller wiring and operation Three wires (not included) are needed to connect your Pylon to the Accessory Switch Controller (ASC) and a separate accessory transformer. Refer to Figure 4. 1.
- Page 9 Replacing the lamp in your Dumbo Pylon our Pylon is illuminated by one 18-volt lamp. During the course of normal operations, this lamp may require replacement. Follow these steps to replace the lamp with Lionel part no. 612-3011-311. 1. Lift the support arm out of the tubes at the top of the pylon. Also, remove any screws securing the base to your layout.
- Page 10 Replacing the lamp on your Dumbo Pylon (continued) Mounting holes Base screws (recessed) Mounting holes Figure 5. Screw locations Base of the Pylon Roof screws (recessed)
- Page 11 Replacing the lamp on your Dumbo Pylon (continued) Interior of the building with the roof removed Figure 6. Lamp location...
-
Page 12: Warranty Information
Limited Warranty/Lionel Service his Lionel product, including all mechanical and electrical components, moving parts, motors and structural components, except for light bulbs, is warranted to the original consumer-purchaser, for one year against original defects in materials or workmanship when purchased through an authorized Lionel merchant.
